EverSewn Maker 200 User manual

I
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT
DANGER!
WARNING!
When using an electrical machine, basic safety precautions should always be followed,
including the following:
Please read the instruction manual carefully before using this machine.
Keep the instruction manual at a suitable place with the machine and hand it over if you give the
machine to a third party.
To reduce the risk of electric shock:
1. Never leave the machine unattended when it is plugged in.
2. Always unplug this machine from the electric outlet immediately after using and before
cleaning.
3. LED RADIATION: Do not view directly with optical instruments Class.
To reduce the risk of burns, fire, electric shock or injury to persons:
1. The machine mustn't be used by children under 8 or by people with reduced physical,
sensory or mental capabilities or if there is a lack of experience and knowledge how to
operate the machine. Unless they have been given instruction concerning the use of the
machine And the involved risks by a person who is responsible for their safety.
2. Do not use this machine as a toy. Close attention is necessary when this machine is used
by children, near children or people with reduced sensation.
When the machine is not in use or left unattended, always disconnect the machine from
the power supply system. Unplug it from the outlet.

II
3. Use this machine only for its intended use as described in this manual. Use only
accessories recommended by the manufacturer.
4. Children should be supervised to ensure that they do not play with the machine.
5. Never operate this machine if it has a damaged cord or plug, if it is not working properly, if it
has been dropped or damaged, or dropped into water. Return the machine to the nearest
authorized dealer or service centre for examination, repair, electrical or mechanical
adjustment.
6. Never operate the machine with any air openings blocked. Keep ventilation openings of the
machine and the foot control free from accumulation of lint, dust, and loose cloth.
7. Keep fingers away from all moving parts. Special care is required around the machine
needle.
8. Always use the proper stitch plate. The wrong plate can cause needle breakage.
9. Do not use bent needles.
10. Do not pull or push the fabric while sewing. This can result in needle breakage.
11. Switch the machine off ("O") when making any adjustments in the needle area, such as
threading or changing the needle, threading the bobbin, or changing the presser foot, and
the like.
12. Always unplug the machine when performing cleaning or maintenance work such as
replacing the sewing light or when making any other user maintenance adjustments
mentioned in the instruction manual (disconnect the power plug). Cleaning and
maintenance work must not be carried out by children without supervision.
13. Never drop or insert any object into any openings.
14. Use this machine only in dry and protected areas. Never operate the machine in a damp or
wet environment.
15. Do not operate the machine where aerosol spray products are being used or where oxygen
is being administered.

17. If the supply cord of the foot control is damaged, it must be replaced by the manufacturer or
an appropriate service agent or a similar qualified person in order to avoid endangerment.
18. Never place anything on the foot control.
19. When replacing the light bulb, always use the same type.
20. The machine may only be used in combination with a foot control of the type
21. The sound pressure level during normal operation is lower than 75dB(A).
22. This machine is provided with double insulation (except U.S.A/Canada). Use only identical
replacement parts. See instructions for Servicing of double-insulated products.
KD-1902, FC-
1902 (110-120V area) / KD-2902, FC-2902A, FC-2902C, FC-2902D (220-240V area) / 4C-
316B (110-125V area) / 4C-316C (127V area) / 4C-326C (220V area) / 4C-326G (230V
area) / 4C-336G (220-240V area).
SERVICING OF DOUBLEINSULATED PRODUCTS
In a double-insulated product, two systems of insulation are provided instead of grounding. No
grounding means is provided on a double-insulated product nor should a means for grounding
be added to the product. Servicing a doubleinsulated product requires extreme care and
knowledge of the system and should only be done by qualified service personnel. Replacement
parts for a double-insulated product must be identical to those parts in the product. A
double insulated product is marked with the words "DOUBLE INSULATION" or
"DOUBLE INSULATED".
The symbol may also be marked on the product.
III

SAVE THESE INSTRUCTIONS!
Attention!
Note:
- This machine is intended for household use only. If used intensively or commercially, regular cleaning and
especially attentive care is required.
- Signs of wear and tear owing to intensive or commercial use are not covered automatically, even if they occur
within the warranty period. The decision on how to deal with any such cases rests with the local authorised
servicing staff.
If the machine is stored in a cold room, it should be brought to a warm room about one hour before use.
All rights reserved
Environmental protection
For technical and product improvement reasons, the machine's features, parts and accessory are subject to
unannounced changes and alterations at any time. The accessory included can differ from country to country.
Ever Sewn is committed to the protection of the environment. We strive to minimize the environmental
impact of our products by continuously improving product Design and our technology of manufacturing.
Do not dispose of electrical machines as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available.
If electrical machines are disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-being.
When replacing old machines with new ones, the retailer is legally obligated to take back your old
machine for professional disposal free of charge.
IV

Congratulations:
As the owner of a new sewing machine, you will enjoy precision quality stitching
on all types of fabrics, from multiple layers of denim to delicate silks.
Your sewing machine offers the ultimate in simplicity and ease of operation. For
your safety and to fully enjoy the many advantages and ease of operation of your
sewing machine, we recommend that you read all the important safeguards and
use and care instructions in this instruction book.
ay we suggest that before you start to use your sewing machine, you discover
the many features and advantages by going through this instruction book, step by
step, while seated at your sewing machine.
V

List of contents
Details of the machine.............................................................2/3
Accessories ................................................................................4
Fitting the snap-in sewing table..................................................5
Connecting machine to power source ........................................6
Two-step presser foot lifter.........................................................7
Attaching the presser foot holder ...............................................8
Winding the bobbin.....................................................................9
Inserting the bobbin..................................................................10
Inserting the needle (System 130/705H)..................................11
Threading the upper thread......................................................12
Automatic needle threader .......................................................13
Thread tension .........................................................................14
Raising the bobbin thread ........................................................15
atching needle/ fabric/ thread ................................................16
How to choose your pattern .....................................................17
Stitch width dial & stitch length dial ........................................18
Sewing straight stitch ...............................................................19
Reverse sewing/ Removing the work/ Cutting the thread ........20
Blind hem/ lingerie stitch ..........................................................21
Overlock stitches ......................................................................22
Sewing on buttons....................................................................23
Sew 1-step buttonholes............................................................24
Zippers and piping....................................................................25
Sewing with the Hemmer foot ..................................................26
3-step zig-zag...........................................................................27
Stitch selection .........................................................................28
Smocking stitch .......................................................................29
Sewing with the cording foot ....................................................30
Darning.....................................................................................31
Practical stitches ......................................................................32
Quilting .....................................................................................33
Gathering..................................................................................34
Patch work................................................................................35
Applique ...................................................................................36
Twin needle .............................................................37
onogramming and embroidering with Embroidery hoop*....38/39
The walking foot accessory ......................................40
aintenance.............................................................................41
Trouble shooting guide.............................................................42
(optional)
(optional)
VI

2
1. Thread tension dial
2. Thread take-up lever
3. Thread cutter
4. Presser foot
5. Needle plate
6. Sewing table and accessory box
7. Reverse sewing lever
8. Bobbin winder stopper
9. Stitch width dial
10. Stitch length dial
11. Pattern selector dial
12. One step buttonhole lever
13. Automatic threader
Details of the machine
1
2
3
5
6
7
8
9
11
1
4
12
13

14. Horizontal spool pin
15. Bobbin winder spindle
16. Hole for second spool pin
17. Handwheel
18. Power switch
19. ain plug socket
20. Bobbin thread guide
21. Upper thread guide
22. Face plate
23. Handle
24. Presser foot lifter
25. Foot control
26. Power cord
3
Details of the machine
18
19
14
15
17
16
2
21
22
24
23
25
26

Accessories
Standard accessories (1)
Optional accessories (2)
a. All purpose foot
b. Zipper foot
c. Buttonhole foot
d. Button sewing foot
e. Seam ripper/ brush
f. Edge/ quilting guide
g. Pack of needles
h. Spool holder
i. Bobbin (3x)
j. L-screwdriver
k. Oil bottle
l. Darning plate
m. Second spool pin
n. Spool pin felt
(These 10 accessories are not supplied with this machine; they
are however available as special accessories from your local
dealer.)
o. Satin stitch foot
p. Overcasting foot
q. Hemmer foot
r. Cording foot
s. Blind hem foot
t. Darning/ embroidery foot
u. Gathering foot
v. Quilting foot
w. Walking foot
x. Twin needle
4
006016008
r
006812008
po
006804008 006803008 006800008
q
006810008
006917008
tu
006916008 006815008
v
s
w
Optional accessories
ij lk
abcd
006806008 006905008 006914008
006Q6A0150
h
g
ef
m n
Standard accessories
1
2
x

Keep the snap-in sewing table horizontal, and push it in the
direction of the arrow. (1)
The inside of the snap-in sewing table can be utilized as an
accessory box. (2)
Fitting the snap-in sewing table
5
2
1

Polarized attachment plug
Conductor ilntended
to be grounded
1
23
6
Connect the machine to a power source as illustrated. (1)
For appliance is equipped with a polarized plug which must be
used with the appropriate polarized outlet. (2)
Unplug power cord when machine is not in use.
Foot control regulates the sewing speed. (3)
Consult a qualified electrician if in doubt as to connect
machine to power source.
Unplug power cord when machine is not in use.
Press main switch (A) for power and light on. (" l ")
Attention:
Foot control
Attention:
Sewing light
IMPORTANT NOTICE
For appliance with a polarized plug (one blade is wider than
the other).
To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If it does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician to install the proper outlet. Do not modify
the plug in any way. (2)
Connecting machine to power source
A

7
When sewing several layers or thick fabrics, the presser foot
can be raised a second stage for easy positioning of the work.
(A)
Two-step presser foot lifter
A

b
a
e
g
Raise the presser clamp (a) with the presser foot lifter. Attach
the presser foot holder (b) as illustrated. (1)
Lower the presser foot holder (b) using the presser foot lifter,
until the cut-out (c) is directly above the pin (d). (2) The presser
foot (f) will engage automatically.
Raise the presser foot using the presser foot lifter. (3)
Raise the lever (e) and the foot disengages.
Attach the edge/ quilting guide (g) in the slot as illustrated.
Adjust as needed for hems, pleats, quilting, etc. (4)
Turn power switch to off ("O") when carrying out any of the
above operations!
Attaching the presser foot
Removing the presser foot
Attaching the edge/ quilting guide
Attention:
Attaching the presser foot holder
1
3
2
4
8
a
c
d
e
f
b

9
1
3
5
8
2
4
7
6
1
9
Winding the bobbin
- Place thread and corresponding spool holder onto spool pin.
(1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin winder spindle to right. (6)
- Hold thread end. (7)
- Step on foot control. (8)
- Cut thread. (9)
- Push bobbin winder spindle to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding" position,
the machine will not sew and the hand wheel will not turn. To
start sewing, push the bobbin winder spindle to the left (sewing
position).
Please Note:

5
4
3
Inserting the bobbin
When inserting or removing the bobbin, the needle must be
fully raised.
Attention:
- Remove the sewing table, then open the hinged cover. (1)
- Pull the bobbin case tab (a) and remove the bobbin case. (2)
- Hold the bobbin case with one hand. Insert the bobbin so that
the thread runs in a clockwise direction (arrow). (3)
- Pull the thread through the slit and under the finger. (4) Leave
a 6 inch tail of thread.
- Hold the bobbin case by the hinged latch. (5)
- Insert it into the shuttle. (6)
Turn power switch to off ("O") before inserting or removing
the bobbin.
1
6
2
1
a

11
AC B
A
B
C
D
Change the needle regularly, especially if it is showing signs of
wear and causing problems.
Insert the needle as illustrated as follows:
A. Loosen the needle clamp screw and tighten again after
inserting the new needle. (1)
B. The flat side of the shaft should be towards the back.
C/D.Insert the needle as far up as it will go.
Turn power switch to off ("O") before inserting or removing
the needle.
Needles must be in perfect condition. (2)
Problems can occur with:
A. Bent needles
B. Damaged points
C. Blunt needles
Attention:
Inserting the needle (System 13 /7 5H)
1
2

12
Threading the upper thread
This is a simple operation but it is important to carry out correctly
as by not doing so .
- Start by raising the needle to its highest point (1), and continue
turning the handwheel counterclockwise until the needle just
slightly begins to descend. Raise the presser foot to release
the tension discs.
For safety, it is strongly suggested you turn off the
power before threading.
- Lift up the spool pin. Place the spool of thread on the holder
with the thread coming off the spool as shown. For small
thread spools, place small side of spool holder next to spool. (2)
- Draw thread from spool through the upper thread guide (3)
and pulling thread through pre-tension spring as illustrated. (4)
- Thread tension module by leading thread down right channel
and up left channel. (5) During this process it is helpful to hold
the thread between the spool and thread guide.
- At the top of this movement pass thread from right to left
through the slotted eye of the take-up lever and then
downwards again. (6)
- Now pass thread behind the thin wire needle clamp guide (7)
and then down to the needle which should be threaded from
front to back.
- Pull about 6-8 inches of thread to the rear beyond the needle
eye. Trim thread to length with built in thread cutter. (8)
If your sewing machine is equipped with the factory installed
optional automatic needle threader, instructions for use can be
found on page 14.
several sewing problems could result
Note:
Note:
1234
567 8

13
Automatic needle threader
- Raise the needle to its highest position.
- Press lever (A) down as far as it will go.
- The threader automatically swings to the threading position (B).
- Pass thread around thread guide (C).
- Pass the thread in front of the needle around the hook (D)
from bottom to top.
- Release lever (A).
- Pull the thread through the needle eye.
Turn power switch to off ("O")!
Attention:
2
1
A
B
D
C
A
C
B
D
A
