evertz TSMIP-10GE User manual

TSMIP-10GE
IP Transport Stream Monitor
User Manual
© Copyright 2016
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone: [phone]
Sales: [e-mail] Fax: [phone]
Tech Support: [e-mail] Fax: [phone]
Web Page: http://www.evertz.com
Version 1.0, June 2016
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of
purchasers of the TSMIP series product. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation
of the TSMIP series product. Due to on going research and development, features and specifications in this manual are subject to change without
notice.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.

This page left intentionally blank

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
•Read these instructions
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than other. A grounding-type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC –
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT
WARNING
TO COMPLETELY DISCONNECT
THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

INFORMATION TO USERS IN EUROPE
NOTE
CISPR 22 CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to the European Union EMC directive. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables
with the shield connected to the chassis ground of the device must be used.
EN60065
Safety
EN504192 2005
Waste electrical products should not be
disposed of with household waste. Contact
your Local Authority for recycling advice
EN55103-1: 1996
Emission
EN55103-2: 1996
Immunity

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-i
TABLE OF CONTENTS
1. OVERVIEW ...................................................................................................................................1
2. SPECIFICATIONS.........................................................................................................................5
2.1. INPUTS AND OUTPUTS ......................................................................................................5
2.2. SFP SUPPORTED TYPES ...................................................................................................5
2.3. MPEG-2 TS MEASUREMENTS............................................................................................5
2.4. ELECTRICAL .......................................................................................................................5
3. INSTALLATION OF TSMIP-10GE.................................................................................................7
3.1. CONFIGURE IP INTERFACES TO THE TSMIP...................................................................7
3.2. SET UP INPUTS AND OUTPUTS.........................................................................................8
3.3. CONNECTING DEVICE TO COMPUTER.............................................................................9
4. VISTALINK®PRO CONFIGURATION.........................................................................................11
4.1. TSMIP FRAME ...................................................................................................................12
4.1.1. Status......................................................................................................................12
4.1.2. Ethernet Ports Control .............................................................................................13
4.1.3. Ethernet Ports Monitor.............................................................................................14
4.1.4. SNMP Configuration................................................................................................15
4.1.5. Fault Tab .................................................................................................................15
4.1.6. Timing Configuration................................................................................................16
4.1.7. Disk Info ..................................................................................................................16
4.1.8. DNS Server .............................................................................................................17
4.2. TSMIP GENERAL...............................................................................................................17
4.2.1. General....................................................................................................................17
4.2.2. System ....................................................................................................................19
4.2.3. Hard Disk Management...........................................................................................19
4.3. INPUT CONFIGURATION ..................................................................................................20
4.3.1. Input Configuration ..................................................................................................20
4.3.2. Input Monitor............................................................................................................22
4.3.3. Transport Stream.....................................................................................................24
4.3.4. DPI Monitor..............................................................................................................25
4.3.5. TS Syntax Errors- P1&P2........................................................................................26
4.3.6. TS Syntax Errors-P3................................................................................................28
4.3.7. Template Check.......................................................................................................31
4.3.8. Trigger Faults ..........................................................................................................33
4.4. VIEW FUNCTIONAL...........................................................................................................34
4.4.1. PID View..................................................................................................................34
4.4.2. PID Tree View .........................................................................................................35
4.4.3. Buffer Analysis View................................................................................................36

TSMIP-10GE Series
IP Transport Stream Monitor
Page-ii Revision 1.0
5. UPGRADE PROCEDURES.........................................................................................................37
5.1. UPDATE VLPRO SERVER JAR FILE................................................................................37
5.2. FIRMWARE UPGRADE USING VISTALINK®....................................................................38
6. ABBREVIATIONS .......................................................................................................................41
Figures
Figure 1-1 : TSMIP-10GE Front and Rear Panel.............................................................................................2
Figure 1-2 : TSMIP-10GE Block Diagram........................................................................................................3
Figure 3-1 : Configure IP Interfaces to the TSMIP...........................................................................................7
Figure 3-2 : TSMIP-10GE Rear Panel .............................................................................................................8
Figure 4-1 : Tree View....................................................................................................................................11
Figure 4-2 : VistaLINK®PRO Hardware Configuration-Status Tab ...............................................................12
Figure 4-3 : VistaLINK®PRO Hardware Configuration - Ethernet Ports Control Tab....................................13
Figure 4-4 : VistaLINK®PRO Hardware Configuration - Ethernet Ports Monitor Tab ...................................14
Figure 4-5 : VistaLINK®PRO Hardware Configuration – SNMP Configuration Tab......................................15
Figure 4-6 : VistaLINK®PRO Hardware Configuration – Fault Tab...............................................................15
Figure 4-7 : VistaLINK®PRO Hardware Configuration – Timing Configuration Tab .....................................16
Figure 4-8 : VistaLINK®PRO Hardware Configuration – Disk Info................................................................16
Figure 4-9 : VistaLINK®PRO Hardware Configuration – DNS Server...........................................................17
Figure 4-10 : VistaLINK®PRO General Configuration – General..................................................................18
Figure 4-11 : VistaLINK®PRO General Configuration – Sync Option...........................................................18
Figure 4-12 : VistaLINK®PRO General Configuration – System...................................................................19
Figure 4-13 : VistaLINK®PRO General Configuration – Hard Disk Management.........................................19
Figure 4-14 : VistaLINK®PRO Input Configuration Tab.................................................................................20
Figure 4-15 : VistaLINK®PRO Input Configuration- Input Monitor Tab.........................................................22
Figure 4-16 : VistaLINK®PRO Input Configuration - Transport Stream Tab.................................................24
Figure 4-17 : VistaLINK®PRO Input Configuration - DPI Monitor Tab..........................................................25
Figure 4-18 : VistaLINK®PRO Input Configuration- TS syntax Errors- P1&P2.............................................26
Figure 4-19 : VistaLINK®PRO Input Configuration -TS Syntax errors-P3.....................................................28
Figure 4-20 : VistaLINK®PRO Input Configuration -Template Check ...........................................................31
Figure 4-21 : VistaLINK®PRO Input Configuration -Trigger Faults ...............................................................33
Figure 4-22 : VistaLINK®PRO - View Functional Selection...........................................................................34
Figure 4-23 : VistaLINK®PRO - PID View Tab..............................................................................................35
Figure 4-24 : VistaLINK®PRO - PID Tree View Tab......................................................................................36
Figure 4-25 : VistaLINK®PRO Buffer Analysis View Tab..............................................................................36
Figure 5-1 : VistaLINK®PRO - Updating Jar file............................................................................................37
Figure 5-2 : VistaLINK®PRO - Selecting Hardware Version Information......................................................38
Figure 5-3 : VistaLINK®PRO - Version information window..........................................................................39
Figure 5-4 : VistaLINK®PRO - Check mark the hardware for update ...........................................................39
Figure 5-5 : VistaLINK®PRO - Browsing Firmware window..........................................................................40
Figure 5-6 : VistaLINK®PRO - Selecting Firmware File ................................................................................40
Tables
Table 2-1 : MPEG-2 TS Measurements...........................................................................................................5
Table 4-1 : VistaLINK®PRO Mapping to Rear to TSMIP-10GE ....................................................................13
Table 4-2 : TR 101 290 DVB Reference values.............................................................................................30

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-iii
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First Release Jun 2016
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance either express or implied. The only warranty offered by
Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

TSMIP-10GE Series
IP Transport Stream Monitor
Page-iv Revision 1.0
This page left intentionally blank

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-1
1. OVERVIEW
The TSM (Transport Stream Monitor) line of products is a complete software based solution for
compressed network monitoring. By monitoring the MPEG Transport Stream at strategic points within the
distribution network, in conjunction with the industry leading VistaLINK®PRO NMS (Network Management
System), the TSM-IP10GE offers service providers the tools to continuously and effectively have the
confidence that their IP signals within any IPTV, Satellite, terrestrial or cable network is being delivered
properly.
The TSM-IP 10GE can monitor up to 256 transport streams. It can monitor MPEG2 or H.264 content and
can in real time separate encoder errors from network delivery errors allowing the operator to act quickly
and avoid down time. The industry leading Evertz®VistaLINK®PRO NMS offers a new dimension to TS
monitoring by allowing a graphical customization of any measurement performed and a quick viewing of
the different points in the system. It makes the TSM probe system a valuable system in any operational
environment.
Features & Benefits
•10G inputs (Over 2 SFPs)
•IGMP v1, v2, v3 subscription and IP layer monitoring including MDI
•Real-time T-STD buffer analysis
•Transport Stream analysis:
oPresence, Bitrate analysis, table rate analysis
oTR101290 Level 1, level 2*, and partial level 3
•Complete TS and PID bitrate measurement from 100kb/s to 200Mb/s with settable limits
•Display of Transport Stream tree (PID Tree View)
•Program Properties (Name, Program ID, etc.)
•Video/Audio/Data Component Properties (PID, Type, Codec, Bitrate, Resolution, Sampling Rate,
etc.)
•Matching of PID assignment with pre-defined PID list and TSID verification
•Fully Integrated with the Industry leading Evertz®VistaLINK®PRO NMS
•Auto-Response Scripting Capability
•Comparing of same stream at different location in network
•SNMP-enabled (control and alarms for monitoring)
•Complete customization of status view and error report in VistaLINK®PRO
•Built-in frame controller for control
•Dense Multi Service Ingest, NFS Server & Client
*Only PCR accuracy and PCR repetition rate supported at this time. No jitter measurement.

TSMIP-10GE Series
IP Transport Stream Monitor
Page-2 Revision 1.0
Figure 1-1 : TSMIP-10GE Front and Rear Panel

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-3
Controller
TS
Monitoring
IP
Monitoring
and IGMP
Subscription
TS
Monitoring
IP
Monitoring
and IGMP
Subscription
TS
Monitoring
IP
Monitoring
and IGMP
Subscription
TS
Monitoring
IP
Monitoring
and IGMP
Subscription
RX RX
SFP
SFP
Card
Edge
DATA3 MPEG
over IP
DATA4 MPEG
over IP
RX RX
CONTROL
VistaLINK
Interface
DATA1 MPEG
over IP
DATA2 MPEG
over IP
10/100/
1000 RJ 45
10/100/
1000 RJ 45
10/100/
1000 RJ 45
1G/10G SFTP10G-TR85AV
10G SPF10G-TR13S
Figure 1-2 : TSMIP-10GE Block Diagram

Note: The 10GE ports currently support up to 5 Gb/s per port.

TSMIP-10GE Series
IP Transport Stream Monitor
Page-4 Revision 1.0
This page left intentionally blank

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-5
2. SPECIFICATIONS
2.1. INPUTS AND OUTPUTS
•2xRJ45 10/100/1000 Data Ports
•2x10GbE SFP Input
•2xRJ45 10/100/1000 control port
2.2. SFP SUPPORTED TYPES
•SFP1G-TR13 SFP Optical Transceiver, 1.25Gbs, 1310mm, SMF, 20km
•SFP1G-TR15S SFP Optical Transceiver, 1.25Gbs, 1550mm, SMF, 40km
•SFP1G-TR15H SFP+ Optical Transceiver, 1.25Gbs, 1550mm, SMF, 80km
•SFP10G-TR13-A SFP Optical Transceiver, 10Gbs, 1310nm, SMF, 10km
•SFP10G-TR15S SFP+ Optical Transceiver, 10Gbs, 1550nm, SMF, 40km
2.3. MPEG-2 TS MEASUREMENTS
TR101290 P1
TR101290 P2
TR101290 P3 (DVB)
TR101290 P4 (ATSC)
1.1 TS_sync_loss
2.1 Transport_error
3.1 NIT_repetition
3.1 MGT_repetition
1.2 Sync_byte_error
2.2 CRC_error
3.2 NIT_error
3.2 TVCT_repetition
1.3 Pat_error
2.3 PCR_error
3.3 Unreferrenced_PID
3.3 CVCT_repetition
1.4 Continuity_count_error
2.4 PCR_accuracy_error
3.4 SDT_repetition
3.4 EIT_repetition
1.5 PMT_error
2.5 PTS_error
3.5 SDT_error
3.5 RRT_repetition
2.6 CAT_error
3.6 EIT_repetition
3.6 STT_repetitiion
3.7 EIT_error
3.8 RST_repetition
3.9 RST_error
3.10 TDT_repetition
3.11 TDT_error
Table 2-1 : MPEG-2 TS Measurements
2.4. ELECTRICAL
Power: 920W

TSMIP-10GE Series
IP Transport Stream Monitor
Page-6 Revision 1.0
This page left intentionally blank

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-7
3. INSTALLATION OF TSMIP-10GE
Upon unpacking, the user should find:
1 x TSMIP-10GE
2 x Power cords contained in a plastic bag
2 x Mounting brackets contained in a plastic bag
Remove the power cords from their package and connect each one to one of the two black power cords
on the rear plate of the TSMIP. Then connect the other end of each power cord to a power source that
meets product requirements. Connecting to a power source should automatically power the device on.
If there was a problem, pressing the Power button manually should power on the unit.
3.1. CONFIGURE IP INTERFACES TO THE TSMIP
a. Connect RS 232 cable to the TSM and set 115200 bitrate. Login and password is “customer”.
Figure 3-1 : Configure IP Interfaces to the TSMIP
b. Type 1 to open Network Configuration menu.
c. Type 1 to open Control port menu.
d. Type 2 to set IP address.
e. Type 4 to set Gateway.
f. Type x to exit Control port menu.

TSMIP-10GE Series
IP Transport Stream Monitor
Page-8 Revision 1.0
g. Type x to exit Network Configuration menu.
h. Type x to exit and save configuration.
i. The same steps can be done for Data 1 (Data Main) and Data 2 (Data Redundant) interfaces
j. All other Data ports must be configured through VLPro
3.2. SET UP INPUTS AND OUTPUTS
1. Connect the Ethernet cable to the CONTROL Ethernet ports on the rear panel and the other end to
an Ethernet switch. See Figure 3-2.
2. Connect Ethernet cables to desired ports and the other end to the Ethernet switch. User can
connect to 10GE ports.
Figure 3-2 : TSMIP-10GE Rear Panel
Control 1&2: These connectors allow the TSMIP to be able to communicate with the computer,
allowing for the user to control the TSM through the interface of choice.
Note: Control 2 is not used.
Data1: Data Port 1
Data2: Data Port 2
Data3: Data Port 3
Data4: Data Port 4
10GE-1 and 10GE-2: To access the 10GE Data port, connect a full duplex fiber cable to the
10GE1 and 10GE2 SFP ports on the rear panel. See specifications on the
SFP modules that need to be inserted before fiber connections can be
made.
Control2
10GE-2
10GE-1
Data1
Data2
Data3
Data4
Control1

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-9
3.3. CONNECTING DEVICE TO COMPUTER
a. Plug in a standard Ethernet cable (Cat 5e) from computer’s Ethernet port to the Ethernet
switch where the TSMIP is connected.
b. Power On the device.
c. On the computer screen, select “Start” in the bottom left corner. Then select “Control
Panel”. Search for the “Network and Sharing Center” icon and double click it. Double click
on “Change adapter settings”. Select “Local Area Connection” and click the “properties”
button. Following that, select “Internet Protocol (TCP/IPv4)” and click the “properties” button
again. Select the button labelled “Use the following IP address” and click “ok”. Enter in an
IP address that is on the same subnet as the TSMIP with the same subnet mask and
gateway.
d. Now check communication with the device. Select “Start” in the bottom left corner of the
computer screen. Then select “Run...” and in the space provided enter “cmd” followed by
clicking the “ok” button. In the command prompt type “ipconfig” and push the Enter key, this
will confirm the IP address has been set on your computer. Type in “ping” followed by the IP
address of the TSMIP and press the Enter key again; if the IP address replies then you are
connected. If “Request timed out” appears then there is a network problem.

TSMIP-10GE Series
IP Transport Stream Monitor
Page-10 Revision 1.0
This page left intentionally blank

TSMIP-10GE Series
IP Transport Stream Monitor
Revision 1.0 Page-11
4. VISTALINK®PRO CONFIGURATION
This chapter assumes that the VLPro server and VLPro client are already configured for your network and
you have basic knowledge of the VLPro interface. It also assumes that the user or network administrator
has already added the TSMIP-10GE jar file to the server and both the client and server applications have
been restarted. If you are the network administrator refer to section 5.1 for information on updating the
VLPro Server Jar File.
Open VLPro and click on the refresh tree icon. Expand the hardware tree by clicking on the “+” symbol.
The TSMIP-10GE should appear as a newly listed device with the IP address used to configure the card. It
may take up to a minute to appear while the card and switch negotiate network settings (this can be
verified directly on the switch if necessary).

Note: If after a couple of minutes the card has still not appeared, select Add
Agent from the Tree> Add/Update Agent menu. Enter the IP address used in the
configuration stage earlier and select OK. The card should now be listed and
will remain grayed out for a moment while VLPro finds the card and confirms its
configuration.
Please consult the network administrator if the user continue to have problems connecting the card with
VLPro, alternatively contact Evertz Microsystems Ltd. or the authorized reseller for technical support.
Under device IP (3480FR) there are three different types of menus:
•TSMIP Frame: This section is used for general settings like: Status, Ethernet Ports, and SNMP
Configuration etc.
•TSM General: This section is used for general settings like Card Status and Card Controls.
•TSM Input: This section is used for Input Configuration
.
Figure 4-1 : Tree View

TSMIP-10GE Series
IP Transport Stream Monitor
Page-12 Revision 1.0
4.1. TSMIP FRAME
4.1.1. Status
Figure 4-2 : VistaLINK®PRO Hardware Configuration-Status Tab
The Status tab indicates the current status of the module including firmware installed on the box and CPU
and memory usage in percentage.
