evertz 1200T Series User manual

1200T Series
Analog Clock Displays
Instruction Manual
© Copyright 2012 - 2013
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive,
Burlington, Ontario, Canada,
L7L 5Z9
Phone: [phone]
Sales Fax: [phone]
Support Fax: [phone]
Internet: Sales: [e-mail]
Tech Support: [email protected]
Web Page: http://www.evertz.com
Version 2.0 March 2013
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of the 1200T Series Analog Clock Displays. Evertz Microsystems expressly
prohibits the use of this manual for any purpose other than the operation of the device.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz
Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz
Microsystems.

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within a
n equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
•Read these instructions
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than other. A grounding-type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles
and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC – SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT.
WARNING
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE.
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE.

INFORMATION TO USERS IN EUROPE
NOTE
This equipment with the CE marking complies with bother the EMC Directive (89/336/EEC) and the Low
Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European standards:
•EN60065 Product Safety
•EN55103-1 Electromagnetic Interference Class A (Emission)
•EN55103-2 Electromagnetic Susceptibility (Immunity)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to the European Union EMC directive. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables
with the shield connected to the chassis ground of the device must be used.

1200T Series Analog Clock Displays Manual
1200T Revision 1.2
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 Preliminary Release Aug 2012
1.1 Updated specifications Feb 2013
1.2 Updated as 1200T manual – NTP is now an option Mar 2013
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof
nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning
performance of Evertz products are for informational use only and are not warranties of future performance either express or implied. The
only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order
confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no
warranty is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or
order confirmation. Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If
you encounter an error, please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make
changes in equipment design or specifications.

1200T Series Analog Clock Displays Manual
1200T Revision 1.2
TABLE OF CONTENTS
1. OVERVIEW ........................................................................................................................... 1
2. INSTALLATION..................................................................................................................... 3
2.1. TIMECODE INPUTS AND OUTPUTS .......................................................................................4
2.2. ETHERNET CONNECTIONS....................................................................................................4
2.3. RS-232 COMMUNICATIONS PORT.........................................................................................5
2.4. POWER ....................................................................................................................................6
2.5. MOUNTING ..............................................................................................................................6
3. SPECIFICATIONS................................................................................................................. 8
3.1. LTC INPUT................................................................................................................................8
3.2. LTC OUTPUT............................................................................................................................8
3.3. TIME KEEPING.........................................................................................................................8
3.4. SERIAL PORT:.........................................................................................................................8
3.5. ETHERNET:..............................................................................................................................8
3.6. BACKUP BATTERY..................................................................................................................8
3.7. ELECTRICAL............................................................................................................................9
3.8. PHYSICAL................................................................................................................................9
4. STATUS LED ...................................................................................................................... 10
5. REAR PANEL CONTROLS................................................................................................. 10
5.1. SETTING THE TIME ZONE OFFSET......................................................................................10
5.2. SETTING TIME AND BRIGHTNESS MANUALLY...................................................................12
6. BATTERY REPLACEMENT................................................................................................ 12
6.1. SAFETY GUIDELINES AND PRECAUTIONS CONCERNING THE USE OF 3V LITHIUM
BATTERIES............................................................................................................................13
6.2. REMOVING THE BACK COVER: ...........................................................................................13

1200T Series Analog Clock Displays Manual
1200T Revision 1.2
6.3. CHANGING THE BATTERY: ..................................................................................................13
6.4. REPLACING THE BACK COVER:..........................................................................................14
7. SOFTWARE CONTROL ......................................................................................................14
7.1. CONNECTING THE CLOCK TO ACOMPUTER.....................................................................14
7.1.1. Requirements....................................................................................................................14
7.1.2. Connecting the COM Port .................................................................................................14
7.1.3. Terminal Program Setup ...................................................................................................14
7.2. COMMAND DESCRIPTIONS..................................................................................................15
7.2.1. Show Commands Available...............................................................................................15
7.2.2. Commands........................................................................................................................15
7.2.2.1. HELP ..................................................................................................................15
7.2.2.2. UPGRADE..........................................................................................................15
7.2.2.3. REFERENCE......................................................................................................15
7.2.2.4. IP........................................................................................................................16
7.2.2.5. NTP ....................................................................................................................16
7.2.2.6. LIGHT.................................................................................................................16
7.2.2.7. DST ....................................................................................................................16
7.2.2.8. STATUS..............................................................................................................17
7.2.2.9. CLOCK ...............................................................................................................17
7.2.2.10.ZONE..................................................................................................................18
7.3. UPGRADING THE FIRMWARE ..............................................................................................18
7.3.1. Overview and Setup..........................................................................................................18
7.3.2. Putting the 1200T into Upgrade Mode...............................................................................19
7.3.3. Uploading the Firmware ....................................................................................................19
8. VISTALINK® CONFIGURATION AND CONTROL...............................................................19
8.1.1. Connecting the 1200T Series Display to VistaLINK®.........................................................20
8.1.2. Installing VistaLINK®..........................................................................................................20
8.1.3. Using VistaLINK® to Configure the 1200T series clock ......................................................20
Figures
Figure 1-1: Clock Block Diagram...........................................................................................................................2
Figure 2-1: Rear Panel Overview ..........................................................................................................................3
Figure 2-2: Rear Panel Connections and Controls................................................................................................3
Figure 2-3. Standard RJ45 Wiring Colour Codes..................................................................................................4
Figure 2-4: Rear Panel Mounting Template...........................................................................................................7
Figure 8-1: VistaLINK®Configuration - General Settings ...................................................................................21
Figure 8-2: VistaLINK®Configuration - NTP and SNMP Trap IP Settings..........................................................21
Figure 8-3: VistaLINK®Configuration - Fault Traps Settings..............................................................................22
Tables
Table 2-1: COM Port Pinout ..................................................................................................................................5
Table 5-1: DIP Switch Functions Overview .........................................................................................................10
Table 5-2: Time Zone Offset Switch Settings......................................................................................................11

1200T Series Analog Clock Displays Manual
Revision 1.2 1200T - 1
1. OVERVIEW
The 1200T Series Analog Clock Displays take master and slave clock technology to new levels of
convenience and excellence. The clocks are microprocessor controlled and employ separate direct drive
motors for each hand. This means that, as well as being able to set the time almost instantaneously, the
new displays are also silent in operation. The hands of the clocks can be programmed to move in sweep
mode or in steps.
Each clock can be programmed for automatic Daylight Saving Time adjustment, as well as for any time
zone offset using a laptop computer. It is then only necessary to supply the clock system with Universal
Coordinated Time (UTC) from the master clock. Daylight Saving Time changes will be automatic, as will
adjustments for different time zones.
Each clock can be used as a master or slave clock. When used as a slave clock, it reads SMPTE linear
timecode (LTC) from a master clock. When used as a master, it generates LTC for distribution to other
slave clocks. In fact, any clock in the chain can generate timecode as soon as it loses timecode input from
the master. The system is therefore extremely robust and reliable.
When the +T option is added, the 1200T series clocks can lock to time disctributed as Network Time
Prototcol (NTP) over Ethernet.
The problems of power distribution have also been considerably simplified. With other clock products, it is
necessary to install power outlets wherever clocks are to be located. The 1200T system slave clocks may
be powered from the Ethernet cable that distributes both power and NTP time. The clocks may also be
powered locally using the AC to 12VDC adapter provided.
Internal crystal oscillators ensure that the clocks will continue to operate in the absence of input timecode.
Internal battery backup ensures that each clock will continue to keep time in the absence of timecode and
power. When power resumes, the hands will immediately reset to the correct time.
The 1200T series clock displays are offered in two sizes. Backlighting is available for all models.
Model
Description
1212T
12” diameter clock display
1212TL
12” diameter clock display with back lighting
1216T
16” diameter clock display
1216TL
16” diameter clock display with back lighting
Throughout this manual the model 1200T will be used to describe the clocks when describing common
features. When necessary, the specific model numbers will be used to distinguish features only available
on some models.
Features:
•Automatic detection of 30 Fps or 25 Fps SMPTE LTC timecode input
•May act as an NTP client when +T option is ordered.
•Three motors for quiet operation and rapid hand setting - sets to time in 10 seconds
•Automatic Daylight Saving Time adjustment
•Addressable slave clocks with programmable time offsets of 0 to 23.5 hours in 0.5 hour increments -
set via DIP switches, RS-232 control or VistaLINK®
•Accepts date information from LTC User Bits using SMPTE ST 309 or Leitch™ protocol

1200T Series Analog Clock Displays Manual
1200T - 2 Revision 1.2
•Master or Slave operation with battery backed up clock
•Single cable distribution for both power and NTP using IEEE 802.3at Power over Ethernet
•Optional back lighting of clock face
•Two sizes 12” or 16”
•Time may be set manually via pushbutton switches, or through the RS-232 serial port, or via Vista Link
•Completely self-setting with NTP (Optional), SMPTE timecode input or battery back-up
•Built-in quartz time base oscillator with battery back-up
•May be configured as a timecode generator to drive other clocks
•Lighting brightness is adjustable
•Powered by 12VDC (with 50/60 Hz, 100240 VAC adapter), or IEEE 802.3at Power over Ethernet
•10/100Mbit Ethernet port for NTP and SNMP control/monitoring with VistaLINK® Pro
Serial Control
RS 232
NTP Input/Ouptut
Power over
Ethernet
Central
Processing
Unit
1200T Block Diagram
LTC I/O
Power
1
2
5
4
3
6
7
8
9
10
11 12
Figure 1-1: Clock Block Diagram
1.1. Compatibility with Original 1200 Series Analog Clocks
This manual is applicable only to the 1200T Series hardware. This 1200T Series hardware can be
distinquished from the original 1200 Series hardware by inspecting the rear panel of the unit. 1200T
series units are fitted with an RJ45 connector which is used to provide Power over Ethernet, SNMP and
NTP. The original 1200 series units do not have this RJ45 connector. This is the easiest way to tell the
difference between the two types of hardware. Please contact the Evertz service department to get
manual for the 1200 Series clocks.
Although this cursory examination reveals some obvious differences in the units, there are other
differences, which may not be as obvious. Series 2 hardware supports most but not all of the features of
the Series 1 hardware.
Features supported in the 1200 series hardware, that are not supported in the
1200T Series hardware are highlighted in special notes such as this throughout
this manual.

1200T Series Analog Clock Displays Manual
Revision 1.2 1200T - 3
2. INSTALLATION
The 1200 series clocks have keyhole slots for mounting. They have a 4 pin connector for timecode input
and output. They have a power jack for 12 VDC input and there is a 12 VDC adapter supplied which is
installed in a slot in the rear panel. This allows the clock to run on 12 VDC, 100240 VAC or to receive
power from a Power over Ethernet power sourcing device. There is a DB-9 connector for RS-232
communications from a PC.
12VDC Input
Mounting
holes Toggle
Pushbutton
DIP switches
COM
Adapter
LTC I/O
Ethernet POE
Figure 2-1: Rear Panel Overview
POE ETHERNET
Figure 2-2: Rear Panel Connections and Controls
If you wish to control the 1200T series clock using the VistaLINK®software, it is
important to set up the IP address before the clock is installed. This is done
using the com port and a computer. See section 7.

1200T Series Analog Clock Displays Manual
1200T - 4 Revision 1.2
2.1. TIMECODE INPUTS AND OUTPUTS
There is a terminal block at the rear of the clock that can contain the time code inputs and outputs.
IN+, IN- These two input pins are for connecting SMPTE/EBU linear timecode (LTC) to the clock.
OUT+, OUT-These two output pins are for connecting LTC to other clocks.
The LTC output can be configured to operate as a loop through from the input LTC, for
connection to downstream clocks, or an output of the local clock time.
The 1200T Series clocks are not compatible with the power over LTC feature of
the 1200 Series analog clocks. As such they can not be powered from an
upstream 1200 Series clock, neither can they power downstream 1200 Series
clocks. The LTC inputs of the 1200T Series clocks will not be damaged if they are
connected to powered LTC outputs from a 1200 Series clock.
2.2. ETHERNET CONNECTIONS
The 1200T clocks are designed to be used with either 10Base-T (10 Mbps) or 100Base-TX (100 Mbps)
also known as Fast Ethernet, twisted pair Ethernet cabling systems. When connecting for 10Base-T
systems, category 3, 4, or 5 UTP cable as well as EIA/TIA – 568 100 
STP cab
connecting for 100Base-TX systems, category 5 UTP cable is required. The cable must be “straight
through” with a RJ-45 connector.
The straight-through RJ-45 cable can be purchased or can be constructed using the pinout information in
Figure 2-3. A colour code wiring table is provided in Figure 2-3 for the current RJ 45 standards (AT&T
258A or EIA/TIA 258B colour coding shown). Also refer to the notes following the table for additional
wiring guide information.
Pin
1
Pin #
Signal
EIA/TIA 568A
AT&T 258A or
EIA/TIA 568B
10BaseT
or 100BaseT
1
Transmit +
White/Green
White/Orange
X
2
Transmit –
Green/White or White
Orange/White or Orange
X
3
Receive +
White/Orange
White/Green
X
4
N/A
Blue/White or Blue
Blue/White or Blue
Not used (required)
5
N/A
White/Blue
White/Blue
Not used (required)
6
Receive –
Orange/White or Orange
Green/White or Green
X
7
N/A
White/Brown
White/Brown
Not used (required)
8
N/A
Brown/White or Brown
Brown/White or Brown
Not used (required)
Figure 2-3. Standard RJ45 Wiring Colour Codes
Note the following cabling information for this wiring guide:
•Only two pairs of wires are used in the 8-pin RJ 45 connector to carry Ethernet signals.
•Even though pins 4, 5, 7 and 8 are not used, it is mandatory that they be present in the cable.
•10BaseT and 100BaseT use the same pins, a crossover cable made for one will also work with the
other.
•Pairs may be solid colours and not have a stripe.
•Category 5 cable must use Category 5 rated connectors.

1200T Series Analog Clock Displays Manual
Revision 1.2 1200T - 5
The maximum cable run between the 1200 and the supporting hub is 300 ft (90 m). The maximum
combined cable run between any two end points (i.e. 1200 and PC/laptop via network hub) is 675 feet
(205 m).
Devices on the Ethernet network continually monitor the receive data path for activity as a means of
checking that the link is working correctly. When the network is idle, the devices also send a link test
signal to one another to verify link integrity. The 1200T rear panel is fitted with two LEDs to monitor the
Ethernet connection.
10/100 This Amber LED is ON when a 100Base-TX link is last detected. The LED is OFF when a
10Base-T link is last detected (the LINK LED is ON). Upon power-up the LED is OFF as
the last detected rate is not known and therefore defaults to the 10Base-T state until rate
detection is completed.
LN/ACT This dual purpose Green LED indicates that the 1200 has established a valid link to its hub,
and whether the 1200T is sending or receiving data. This LED will be ON when the 1200T
has established a good link to its supporting hub. This gives you a good indication that the
segment is wired correctly. The LED will BLINK when the 1200T is sending or receiving
data. The LED will be OFF if there is no valid connection.
2.3. RS-232 COMMUNICATIONS PORT
The COM connector is a female 9 pin D connector used for connecting a computer to control the 1200T
series clocks. This port is wired at the factory as an RS232 DCE port as shown in Table 2-1 and can be
connected directly to most PC COM ports using a ‘straight through’ cable. The RS-232 communication is
57600 baud, 8 bits, no parity, 2 stop bits, no flow control. See section 7 for information on controlling the
clock using the serial port.
Pin #
Name
Description
1
2
TxD
RS-232 Transmit Output
3
RxD
RS-232 Receive Input
4
5
Sig Gnd
RS-232 Signal Ground
6
7
8
9
Table 2-1: COM Port Pinout

1200T Series Analog Clock Displays Manual
1200T - 6 Revision 1.2
2.4. POWER
The 1200T series clocks come with an auto-ranging DC voltage adapter that automatically
senses the input voltage. This power adapter should be used when the clock is operating in
Master mode. Power should be applied by connecting a 3-wire grounding type power supply
cord to the power entry module on the DC voltage adapter. The power cord should be
minimum 18 AWG wire size; type SST marked VW-1, maximum 2.5 m in length. The DC
cable of the voltage adapter should be connected to the DC power jack on the rear panel.
Alternativly, they can be powered from the Ethernet port if the Ethernet supports “Power Over
Ethernet”, type 1. If it is powered from Ethernet, then no power needs to be applied to the
power adapter.
The 1200T Series clocks are not compatible with the power over LTC feature of
the 1200 Series analog clocks. As such they can not be powered from an
upstream 1200 Series clock, neither can they power downstream 1200 Series
clocks. The LTC inputs of the 1200T Series clocks will not be damaged if they are
connected to powered LTC outputs from a 1200 Series clock.
2.5. MOUNTING
The 1200T series clocks are designed to be surface mounted on a wall using two screws in the keyhole
slots provided. The rear panel drawing shown in Figure 2-4 shows the location of the keyhole slots for the
1212T and 1216T clocks.

1200T Series Analog Clock Displays Manual
Revision 1.2 1200T - 7
76 1/5 mm
85 5/7
mm
76 1/5 mm
1212 Clock Mounting Dimensions
1216 Clock Mounting Dimensions
127 mm
127 mm
1212 Clock Outline
1216 Clock Outline
136 1/2 mm
330 5/7 mm
330 5/7 mm
1 3/5 mm
432 1/9 mm
C/L
Figure 2-4: Rear Panel Mounting Template

1200T Series Analog Clock Displays Manual
1200T - 8 Revision 1.2
3. SPECIFICATIONS
3.1. LTC INPUT
Standard: SMPTE ST 12-1 linear time code - 25 or 29.97 drop-frame Fps nominal.
Connector: Phoenix 4 pin terminal connector.
Signal Level: 1 Vp-p nominal.
Input impedance: > 30K Ohm
3.2. LTC OUTPUT
Standard: SMPTE ST 12-1 linear time code - 25 or 29.97 drop-frame Fps nominal.
Connector: Phoenix 4 pin terminal connector.
Signal Level: 2 Vp-p nominal
Mode: configurable as loop thru from input or output of local clock time.
3.3. TIME KEEPING
Accuracy: < 2 seconds per day with power on, no timecode present.
< 10 seconds / day with power removed.
Time Zone Offset: 0 to 23½ hours in ½ hour increments
Set with DIP switches or serial port command or VistaLINK®.
Automatic daylight saving time can be enabled.
3.4. SERIAL PORT:
Connector: Female DB-9
Level: RS232
Baud Rate: 57.6 Kbaud
Format: 8 data bits, no parity, 2 stop bits
3.5. ETHERNET:
Network Type: Fast Ethernet 100 Base-TX IEEE 802.3u standard for 100 Mbps baseband
CSMA/CD local area network.
Ethernet 10 Base-T IEEE 802.3 standard for 10 Mbps baseband CSMA/CD
local area network.
Supports type 1 Power Over Ethernet.
Connector: RJ-45
NTP Standard: NTP v4 compliant, client mode support when +T option is installed
3.6. BACKUP BATTERY
Type: CR-2032 3 volt lithium cell.
Life expectancy: > 5 years

1200T Series Analog Clock Displays Manual
Revision 1.2 1200T - 9
3.7. ELECTRICAL
Voltage:
AC/DC 12 VDC nominal.
Auto ranging 100240 VAC 50/60 Hz to 12VDC adapter provided.
Power over Ethernet IEEE 802.3at Type 1
Power consumption:12 Watts
3.8. PHYSICAL
Outside Dimensions:
1212, 1212L: 13" W x 13" H x 2.5" D
(330 mm W x 330 mm H x 64 mm D)
1216, 1216L: 17" W x 17" H x 2.5" D
(432 mm W x 432 mm H x 64 mm D)
Clock Face:
1212, 1212L: 12” diameter
1216, 1216L: 16” diameter
Weight:
1212, 1212L: 6.5 lb (2.9 Kg)
1216, 1216L: 10.5 lb (4.75 Kg)

1200T Series Analog Clock Displays Manual
1200T - 10 Revision 1.2
4. STATUS LED
The 1200T series clocks are fitted with a red status LED located at the bottom of the front face of the
clock, just below the number “6”. The LED has three modes:
OFF: The clock is running normally and has input LTC.
ON: The clock is running normally but has no LTC input.
FLASHING: The clock is in manual time or brightness setting mode.
5. REAR PANEL CONTROLS
The 1200T series clocks are equipped with a three position, return to center toggle switch that is used in
conjunction with a momentary pushbutton to set the clock time (see section 5.2). An 8 position DIP switch
allows the user to select various functions. DIP switch 1 is located at the right of the DIP switch, and the
On position is Up. Table 5-1 gives an overview of the DIP switch functions. Section 5.1 describes the DIP
switch functions in more detail.
DIP Switch
Function
1
Sets Time zone Offset
2
3
4
5
6
7
Not used
8
When Down enables Time zone from DIP
switches. When up, Time zone set via
serial port or VistaLINK®
Table 5-1: DIP Switch Functions Overview
5.1. SETTING THE TIME ZONE OFFSET
When DIP switch 8 is in the down position, DIP switches 1 to 6 are used to set the time zone offset for the
clock. The Time zone offsets can be set from 0 to 23.5 hours in one half our intervals and will be added to
the LTC time being received. Table 5-2 shows the settings for the various time zones. When DIP switch 8
is in the up position, the time zone must be set by software control (see section 7.2.2.10 for more
information).

1200T Series Analog Clock Displays Manual
Revision 1.2 1200T - 11
6
5
4
3
2
1
Time Offset
Time Zone Code
(Hex)
Off
Off
Off
Off
Off
Off
+ 0 hours
0x00
Off
Off
Off
Off
Off
On
+ ½ hours
0x01
Off
Off
Off
Off
On
Off
+ 1 hours
0x02
Off
Off
Off
Off
On
On
+ 1½ hours
0x03
Off
Off
Off
On
Off
Off
+ 2 hours
0x04
Off
Off
Off
On
Off
On
+ 2½ hours
0x05
Off
Off
Off
On
On
Off
+ 3 hours
0x06
Off
Off
Off
On
On
On
+ 3½ hours
0x07
Off
Off
On
Off
Off
Off
+ 4 hours
0x08
Off
Off
On
Off
Off
On
+ 4½ hours
0x09
Off
Off
On
Off
On
Off
+ 5 hours
0x0A
Off
Off
On
Off
On
On
+ 5½ hours
0X0B
Off
Off
On
On
Off
Off
+ 6 hours
0X0C
Off
Off
On
On
Off
On
+ 6½ hours
0X0D
Off
Off
On
On
On
Off
+ 7 hours
0X0E
Off
Off
On
On
On
On
+ 7½ hours
0X0F
Off
On
Off
Off
Off
Off
+ 8 hours
0x10
Off
On
Off
Off
Off
On
+ 8½ hours
0x11
Off
On
Off
Off
On
Off
+ 9 hours
0x12
Off
On
Off
Off
On
On
+ 9½ hours
0x13
Off
On
Off
On
Off
Off
+ 10 hours
0x14
Off
On
Off
On
Off
On
+ 10½ hours
0x15
Off
On
Off
On
On
Off
+ 11 hours
0x16
Off
On
Off
On
On
On
+ 11½ hours
0x17
Off
On
On
Off
Off
Off
+ 12 hours
0x18
Off
On
On
Off
Off
On
+ 12½ hours
0x19
Off
On
On
Off
On
Off
+ 13 hours
0x1A
Off
On
On
Off
On
On
+ 13½ hours
0X1B
Off
On
On
On
Off
Off
+ 14 hours
0X1C
Off
On
On
On
Off
On
+ 14½ hours
0X1D
Off
On
On
On
On
Off
+ 15 hours
0X1E
Off
On
On
On
On
On
+ 15½ hours
0X1F
On
Off
Off
Off
Off
Off
+ 16 hours
0x20
On
Off
Off
Off
Off
On
+ 16½ hours
0x21
On
Off
Off
Off
On
Off
+ 17 hours
0x22
On
Off
Off
Off
On
On
+ 17½ hours
0x23
On
Off
Off
On
Off
Off
+ 18 hours
0x24
On
Off
Off
On
Off
On
+ 18½ hours
0x25
On
Off
Off
On
On
Off
+ 19 hours
0x26
On
Off
Off
On
On
On
+ 19½ hours
0x27
On
Off
On
Off
Off
Off
+ 20 hours
0x28
On
Off
On
Off
Off
On
+ 20½ hours
0x29
On
Off
On
Off
On
Off
+ 21 hours
0x2A
On
Off
On
Off
On
On
+ 21½ hours
0X2B
On
Off
On
On
Off
Off
+ 22 hours
0X2C
On
Off
On
On
Off
On
+ 22½ hours
0X2D
On
Off
On
On
On
Off
+ 23 hours
0X2E
On
Off
On
On
On
On
+ 23½ hours
0X2F
On
On
On
On
On
On
Software control
0X3F
Table 5-2: Time Zone Offset Switch Settings

1200T Series Analog Clock Displays Manual
1200T - 12 Revision 1.2
5.2. SETTING TIME AND BRIGHTNESS MANUALLY
The 1200T series clocks are equipped with a three position, return to center, toggle switch that is used in
conjunction with a momentary pushbutton to manually set the time.
If the lighting option is present, to set the lighting brightness, press the HMS pushbutton once. The
lighting will go off and on once. The LED on the front panel will flash.Press the toggle switch in the UP
or DN position to adjust the brightness. If you are finished setting brightness, do not perform any further
action. In 15 seconds, the clock will exit the brightness setting mode and the LED will stop flashing. If the
lightning option is not present, then the first button push will go to Hours setting mode below.
To set the time, press the HMS pushbutton again. The LED on the front panel will flash, and the hour
hand will wiggle once. Press the toggle switch in the UP or DN position to set the hour hand to the correct
time. If you are finished setting time, do not perform any further action. In 15 seconds, the clock will exit
the time setting mode and the LED will stop flashing.
To set the minutes press the HMS pushbutton again, and the minute hand will wiggle. Press the toggle
switch in the UP or DN position to set the minute hand to the correct time. If you are finished setting time,
do not perform any further action. In 15 seconds, the clock will exit the time setting mode and the LED
will stop flashing.
To set the seconds press the HMS pushbutton again, and the second hand will wiggle and stop. Press
the toggle switch in the UP or DN position to set the second hand to the correct time. Press the HMS
pushbutton again to restart the second hand. Note that you can set the second hand to a future time, and
wait for that time to occur. Pressing the HMS pushbutton will then restart the second hand at the correct
time.
6. BATTERY REPLACEMENT
The 1200T series clocks are fitted with a 3V Lithium battery type CR2032. This battery is used to power
non-volatile memory of some of the frame controller’s parameters while power is removed from the frame.
Before attempting to change the battery remove power from the clock. If you are using Power over
Ethernet, disconnect the Ethernet cable.
CAUTION
Danger of explosion if battery is incorrectly replaced
Replace only with the same or equivalent type
CAUTION
Danger of explosion if battery is exposed to excessive heat such as direct
sunlight, fire, etc.
