EVGA 141-GT-E770-A1 User manual

User Guide
EVGA X58 Classified3
Motherboard

EVGA X58 CLASSIFIED3 Motherboard
3
Table of Contents
Before You Begin… ...............................................................................................8
Parts NOT in the Kit...........................................................................................8
Intentions of the Kit ..........................................................................................9
EVGA X58 CLASSIFIED3 Motherboard .................................................................11
Motherboard Specifications ..............................................................................11
Unpacking and Parts Descriptions ....................................................................... 13
Unpacking.......................................................................................................13
Equipment ...................................................................................................... 13
Intel X58 Express Chipset Motherboard ............................................................15
Hardware Installation ..........................................................................................18
Safety Instructions ..........................................................................................18
Preparing the Motherboard ..............................................................................19
Installing the CPU ........................................................................................19
Installing the CPU Fan..................................................................................20
Installing Memory DIMMs.............................................................................21
Installing the Motherboard............................................................................... 22
Installing the I/O Shield ...............................................................................22
Securing the Motherboard into the Chassis....................................................23
Connecting Cables and Setting Switches ...........................................................23
Power Connections ......................................................................................24
24-pin ATX Power (PW1) ..........................................................................24
8-pin ATX 12V Power (PW12-1, PW12-2)...................................................25

EVGA X58 CLASSIFIED3 Motherboard
4
Connecting IDE Hard Disk Drives ..................................................................26
Connecting SATA Cables ..............................................................................27
Connecting Internal Headers ........................................................................28
Front Panel Header ..................................................................................28
IEEE 1394a..............................................................................................29
USB Headers ...........................................................................................30
Audio ......................................................................................................31
Fan Connections ..........................................................................................32
Expansion Slots ...........................................................................................33
PCI Slot...................................................................................................34
PCI Express x1 Slot ..................................................................................34
PCI Express x16 Slots...............................................................................34
Onboard Buttons .............................................................................................35
Clear CMOS Button ..................................................................................35
RESET and POWER Button .......................................................................35
Post Port Debug LED and LED Status Indicators ................................................36
Post Port Debug LED ................................................................................36
LED Status Indicators ...............................................................................36
Jumper Settings ..............................................................................................37
PCIE Disable Jumper ................................................................................37
Voltage Measure Point ..................................................................................... 38
EVGA Control Panel ECP ..................................................................................39
Configuring the BIOS ..........................................................................................46
Enter BIOS Setup ............................................................................................47
Main Menu......................................................................................................47
Standard CMOS Features Menu ........................................................................50
Date and Time.............................................................................................51
SATA Channel..............................................................................................51

EVGA X58 CLASSIFIED3 Motherboard
5
Halt On .......................................................................................................53
Memory ......................................................................................................53
Advanced BIOS Features .................................................................................54
Hard Disk Boot Priority.................................................................................55
First/Second/Third Boot Device.....................................................................55
Boot Other Device .......................................................................................55
Boot Up NumLock Status..............................................................................56
Security Option............................................................................................56
Full Screen LOGO Show ...............................................................................56
Integrated Peripherals Menu ............................................................................ 57
OnChip PATA/SATA Device...........................................................................58
Onboard Device...........................................................................................59
USB Device Settings.....................................................................................60
Power Management Setup Menu ...................................................................... 61
ACPI Function..............................................................................................61
ACPI Suspend Type .....................................................................................62
Run VGABIOS if S3 Resume .........................................................................62
Soft-Off by PWR-BTTN .................................................................................62
Wake-Up by PCI Card ..................................................................................62
USB KB Wake-Up From S3 ...........................................................................62
Resume by Alarm ........................................................................................62
POWER ON Function....................................................................................63
Hot Key Power On .......................................................................................63
PWRON After PWR-Fail ................................................................................63
PnP/PCI Configuration Menu ............................................................................64
Init Display First ..........................................................................................64
Resources Controlled By...............................................................................65
IRQ Resources.............................................................................................65

EVGA X58 CLASSIFIED3 Motherboard
6
PCI/VGA Palette Snoop ................................................................................65
INT Pin 1/2/3/4/5/6/7/8 Assignment.............................................................66
Maximum Payload Size.................................................................................66
PC Health Status Menu .................................................................................... 67
SmartFan Function.......................................................................................68
Frequency/Voltage Control Menu......................................................................69
Extreme Cooling ..........................................................................................69
Memory Feature ..........................................................................................70
Voltage Control............................................................................................71
CPU Feature ................................................................................................74
CPU Clock Ratio...........................................................................................75
CPU Host Frequency (Mhz)...........................................................................75
CPU Uncore Frequency (Mhz) .......................................................................76
Spread Spectrum .........................................................................................76
PCIE Frequency (Mhz) .................................................................................76
Save Profile .................................................................................................76
Load Profile .................................................................................................76
Installing Drivers and Software ...........................................................................77
Windows XP/Vista Drivers Install ......................................................................78
Appendix A. POST Codes .....................................................................................79
EVGA Glossary of Terms ......................................................................................86

EVGA X58 CLASSIFIED3 Motherboard
7
List of Figures
Figure 1. EVGA X58 CLASSIFIED3 Motherboard Layout......................................16
Figure 2. Chassis Backpanel Connectors ...........................................................17
Figure 3. Power Supply Connectors ..................................................................23
Figure 4. Standard CMOS Features Menu..........................................................50
Figure 5. Advanced BIOS Features Menu ..........................................................54
Figure 6. Integrated Peripherals Menu..............................................................57
Figure 7. Power Management Setup Menu........................................................61
Figure 8. PnP/PCI Configuration Menu..............................................................64
Figure 9. PC Health Status Menu......................................................................67
Figure 10. Frequency/Voltage Control Menu .......................................................69
Figure 11. Memory Feature Menu ......................................................................70
Figure 12. Voltage Control Menu........................................................................71
Figure 13. CPU Feature Menu ............................................................................74

EVGA X58 CLASSIFIED3 Motherboard
8
Before You Begin…
Thank you for purchasing the EVGA X58 Classified3 Motherboard. This board is
designed to take the already excellent performance of the EVGA lineup and push it into
the future by adding support for SATA 6Gbps and USB 3.0. Also we have included
EVBot support to facilitate your tweaking needs.
As always with this board you also get the added bonus of EVGA’s industry leading 24/7
technical support in case you ever have any issues or questions.
Parts NOT in the Kit
This kit contains all the hardware necessary to install and connect your new
EVGA X58 Classified3 motherboard. However, it does not contain the
following items that must be purchased separately to make the motherboard
functional.
Intel Core i7 microprocessor:
Cooling fan for the microprocessor
System memory support
Graphics Card
Power Supply
EVGA assumes you have purchased all the necessary parts needed to allow for
proper system functionality.

EVGA X58 CLASSIFIED3 Motherboard
9
Intentions of the Kit
This kit provides you with the motherboard and all connecting cables necessary to
install the motherboard into a PC case. If you are building a PC, you will use most
of the cables provided in the kit. If however, you are replacing a motherboard, you
will not need many of the cables.
When replacing a motherboard in a PC case, you will need to reinstall an operating
system even though the current drives have an operating system.

EVGA X58 CLASSIFIED3 Motherboard
10

EVGA X58 CLASSIFIED3 Motherboard
11
EVGA X58 CLASSIFIED3
Motherboard
Thank you for buying the EVGA X58 CLASSIFIED3 Motherboard. This
motherboard offers the tools and performance PC users’ demand. When
combined with two or three SLI-Ready NVIDIA GeForce graphics cards, you
get innovative NVIDIA SLI Technology for enhanced system performance.
Motherboard Specifications
Size
EATX form factor of 12 inches x 13 inches
Microprocessor support
Intel Core i7 processor
Operating systems:
Supports Windows XP, Windows Vista, and Windows 7 32bit/64bit
Contains INTEL X58 and ICH10R chipset
System Memory support
Supports triple channel DDR3-1600+. Supports up to 24GBs DDR3
memory.
USB 2.0 Ports
Supports hot plug
Twelve USB 2.0 ports (Eight rear panel ports, four onboard USB headers)
Supports wake-up from S1 and S3 mode
Supports USB 2.0 protocol up to a 480 Mbps transmission rate
USB 3.0 Ports
Two USB 3.0 ports (on I/O panel.)
Backwards compatible USB 2.0 and USB 3.0 support.

EVGA X58 CLASSIFIED3 Motherboard
12
Supports transfer speeds up to 5Gbps
Six(6) onboard SATA II Ports + 2 onboard SATA3 ports
300MBps data transfer rate
Six SATA II connectors from south bridge with support for RAID 0,
RAID 1, RAID 0+1, and RAID 5
Two (2) SATA3 600MBps onboard ports from Marvell 88SE9128 Chipset
Onboard LAN
Dual LAN interface built-in onboard
Supports 10/100/1000 Mbit/sec Ethernet
Onboard 1394
Support hot plug
Two 1394a ports (one rear panel port, one onboard header) with rate of
transmission at 400 Mbps
Onboard Audio
Realtek High-Definition audio
Supports 8-channel audio
Supports Jack-Sensing function
Four PCI Express Support
Four (4) PCI-E 2.0 x16 Slots
Supports 4 GB/sec (8 GB/sec concurrent) bandwidth
Green Function
Supports ACPI (Advanced Configuration and Power Interface)
Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(Suspend to disk - depends on OS), and S5 (soft - off)
Expansion Slots
One PCI slot
One PCI Express x1 slot
Four PCI Express x16/x8 slots

EVGA X58 CLASSIFIED3 Motherboard
13
Unpacking and
Parts Descriptions
Unpacking
The EVGA X58 CLASSIFIED3 motherboard comes with all the necessary
cables for adding a motherboard to a new chassis. If you are replacing a
motherboard, you may not need many of these cables.
Be sure to inspect each piece of equipment shipped in the packing box. If
anything is missing or damaged, contact your reseller.
All parts shipped in this kit are RoHS-compliant (lead-free) parts.
Equipment
The following accessories are included with EVGA X58 CLASSIFIED3 motherboard.
The EVGA X58 CLASSIFIED3 Motherboard
This motherboard contains the Intel X58 and ICH10R chipset
and is SLI-ready for 2-way, Quad, 3-way, and 3-way SLI w/
PhysX configurations.
Visual Guide
Helps to quickly and visually guide you through the hardware
installation of the motherboard.
I/O Shield
Installs in the system case to block radio frequency
transmissions, protect internal components from dust, foreign
objects, and aids in proper airflow within the chassis.

EVGA X58 CLASSIFIED3 Motherboard
14
3 - 2-Port SATA Power Cables
Allows a Molex power connector to adapt to a SATA power
connector.
1 - 2-Port USB and 1-Port 1394 bracket
Provides one (1) additional IEEE1394a port to the back panel of
the chassis and provides two additional USB ports to the back
panel.
6 - SATA Data Cables
Used to support the SATA protocol and each one connects
to a single drive to the motherboard.
1 - IDE-ATA 133 HDD Cable
Passes data between the IDE connection on the motherboard
and IDE device.
1 - 2-way SLI Bridge
Bridges two (2) graphic cards together which allows for
2-Way SLI.
1–3-way SLI Bridge
Bridges three (3) graphic cards together which allows for 3- Way
SLI.
1–3-way SLI with PhysXTM Bridge
Bridges three (3) graphic cards with Physics card together which
allows for 3-Way SLI with PhysXTM technology.
1- Installation CD
Contains drivers and software needed to setup the
motherboard.

EVGA X58 CLASSIFIED3 Motherboard
15
Intel X58 Express Chipset
Motherboard
The EVGA X58 CLASSIFIED3 Motherboard with the Intel X58 and ICH10R
chipset is a SLI-ready motherboard. Figure 1 shows the motherboard and
Figure 2 shows the back panel connectors.

EVGA X58 CLASSIFIED3 Motherboard
16
1. CPU Socket 1366
11. P80P connector
21. PCI Express 2.0 slots
2. Intel X58 Chipset
12. Front panel connector
22. PCI slot
3. CPU Fan connector
13. Debug LED Display
23. PCI Express x1 slot
4. DDR3 DIMM slots 1 –6
14. USB headers
24. Front panel Audio connector
5. Intel ICH10R Chipset
15. CMOS battery
25. Backpanel connectors (Figure 2)
6. 24-pin ATX power connector
16. 1394a connector
26. 8-pin ATX_12V power connector
7. Fan connectors
17. CMOS clear button
27. SATA3 600MBps Ports
8. PCIE x16 disable jumpers
18. Power button
9. IDE connector
19. Reset button
10. Serial-ATA (SATA) connectors
20. PC Speaker
Figure 1. EVGA X58 CLASSIFIED3 Motherboard Layout
21
1
4
3
7
9
6
13
21
22
23
21
25
21
11
24
2
14
10
16
12
15
3
21
10
5
8
18
17
7
7
7
26
20
19
27
7

EVGA X58 CLASSIFIED3 Motherboard
17
1. PS/2 Keyboard Port
2. USB 2.0 ports (Eight)
3. CMOS Clear Button
4. EVBot Port
5. USB 3.0 Ports
6. 1394a (Firewire) port
7. Dual Lan Port with LEDs to indicate status.
8. Audio Port 2-Channel 6-Channel 8-Channel________
Blue Line-In Line-In Line-In
Green Line-Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Mic In
Orange Center/Subwoofer Center/Subwoofer
Black Rear Speaker Out Rear Speaker Out
Grey Side Speaker Out
Figure 2. Chassis Backpanel Connectors
1
2
5
2
2
3
4
2
6
7
Activity LED Status
Description
Off
No data transmission
Blinking (Green)
Data transmission
Speed/Link LED Status
Description
Yellow
1000 Mbps data rate
Green
100 Mbps data rate
Off
10 Mbps data rate
8
7

EVGA X58 CLASSIFIED3 Motherboard
18
Hardware Installation
This section will guide you through the installation of the motherboard. The
topics covered in this section are:
Preparing the motherboard
Installing the CPU
Installing the CPU fan
Installing the memory
Installing the motherboard
Connecting cables
Safety Instructions
To reduce the risk of fire, electric shock, and injury, always follow basic
safety precautions.
Remember to remove power from your computer by disconnecting the
AC main source before removing or installing any equipment from/to the
computer chassis.

EVGA X58 CLASSIFIED3 Motherboard
19
Preparing the Motherboard
The motherboard shipped in the box does not contain a CPU or memory. You
need to purchase these to complete this installation.
Installing the CPU
Be very careful when handling the CPU. Make
sure not to bend or break any pins inside the
socket. Hold the processor only by the edges
and do not touch the bottom of the processor.
Use the following procedure to install the
CPU onto the motherboard.
1. Unhook the socket lever by pushing down
and away from the socket.
2. Put your finger on the tail of the load
plate and press the tail down
3. Lift the load plate. There is a protective
socket cover in the socket to protect the
socket when there is no CPU installed.
4. Remove the protective socket cover from
the CPU Socket.
Remove the processor from its protective cover,
making sure you hold it only by the edges.
It is a good idea to save the cover so that
whenever you remove the CPU, you
have a safe place to store it.

EVGA X58 CLASSIFIED3 Motherboard
20
5. Align the notches in the processor
with the notches on the socket.
6. Lower the processor straight down
into the socket with out tilting or
sliding it into the socket
Make sure the CPU is fully seated and
level in the socket.
7. Close the load plate over the CPU and
press down while you close and
engage the socket lever.
8. The CPU installation is complete.
Installing the CPU Fan
There are many different fan types that can be used with this motherboard.
Follow the instruction that came with your fan assembly. Be sure that the fan
orientation is correct for your chassis type and your fan assembly.
Align notches with notches on the CPU
