EVOC NPC-8208 User manual

Legal Information
Warnings
Please pay attention to the tips within the manual so as to avoid personal injury or
property losses. The tips for personal injury are indicated in warning triangles while
the tips only related to property losses have no warning triangles. The warning tips are
listed as follows with the hazardous scale from severe to slight.
Danger
If handled carelessly, death or severe human injury will occur.
Warning
If handled carelessly, death or severe human injury might occur.
Caution
Warning triangle indicates that slight human injury might occur if handled
carelessly.
Note
Unexpected result or status might occur, if not handled according to the tips.
Professional Personnel
The product/system covered by the manual can only be handled by qualified and
professional personnel. During operation, please follow the respective instructive
manuals, especially the safety warnings. The professional personnel have been trained
and possess relevant experiences; therefore, he/she could be aware of the risks of the
product/system and avoid possible damages.
EVOC Product
Please pay attention to the following instructions:
Warning
EVOC product can only be used according to the descriptions within the manual,
including the contents and the relevant technical documents. If the products or
components from other companies are required, please get the recommendation
and grant from EVOC first. Proper transportation, storage, assembly, installation,
debugging, operation and maintenance are prerequisite to ensure product safety
and normal operation; therefore, please ensure permitted environment conditions
and pay attention to the tips within the manual.

Copyright Notice
Information offered in this manual is believed to be correct at the time of printing, and
is subject to change without prior notice in order to improve reliability, design and
function and does not represent a commitment on the part of the manufacturer. In no
event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of improper installation and/or use, or inability to
use the product or documentation.
This user manual is protected by copyright. No part of this manual may be reproduced,
stored in any retrieval system, or transmitted, in any form or by any means,
mechanical, electronic, photocopied, recorded or otherwise, without the prior written
permission from the manufacturer.
Trademarks
EVOC is a registered trademark of EVOC Intelligent Technology Co., Ltd. Other
product names mentioned herein are used for identification purposes only and may be
trademark and/or registered trademarks of their respective companies.
Warranty Terms:
The warranty on the product lasts for two year. If the user has additional requirements,
the contract signed between the two sides shall prevail.
Please visit our website: http://www.evoc.com for more information,
or send an email to the Technical Support Mailbox [email protected]
(International) or [email protected] (Domestic) for consultation.
Hotline: [phone]

About this manual
Scope of the Manual
The manual is appropriate for EVOC NPC-8208.
Convention
The term “the PC” or “the Product” within the manual usually stands for EVOC
NPC-8208.
Instructions
Safety instructions
To avoid property losses or individual injury, please pay attention to the safety
instructions within the manual. The warnings within the manual are marked with
warning triangle , whose existence is dependent upon the scale of the
potential hazard.
History
The version of this manual:
Version Time
B00 2016.3
C00 2016.9

Safety Instructions
General Safety Instructions
Caution
Before you have read related safety instructions, please do not expand your device.
This device is compliant with related safety requirements. If you have any doubt
about the effectiveness of installation in the planned environment, please contact your
service representative.
Repair
The PC can only be repaired by authorized personnel.
Warning
Unauthorized opening of the PC and improper repair may cause serious damage to
the PC or endanger users’ personal safety.
System Expansion
Only system expansion devices designed for this PC can be installed. Installing other
expansion devices may damage the system and violate regulations on radio
interference suppression. To know the system expansion devices that can be installed,
please contact technical support team or local distributor.
Caution!
If the PC is damaged due to improper installation or replacement of system
expansion devices, the warranty for the product will become invalid.
Battery
The battery can only be replaced by qualified personnel.
Caution!
If the battery is not replaced according to the instructions, it may have the danger
of explosion. It can only be replaced by the same type of battery or batteries
recommended by the manufacturer. The used battery must be disposed according
to local laws and regulations.
Warning!
Danger of explosion or release of hazardous substances may exist! Therefore,
please do not put the Li-ion battery into fire, weld it onto cell body, open,
short-circuit or reverse polarity of the battery, and do not heat it up to above
100℃. Dispose the battery according to the rules, and avoid direct sunlight,
moisture and condensation.

ESD Instructions
The following label can be used to identify the modules that contain electrostatic
sensitive devices:
When operating the modules that contain electrostatic sensitive devices, please follow
the instructions below:
When operating the modules that contain electrostatic sensitive devices, make
sure to release static electricity on your body (for example, by touching a
grounded object).
All the devices and tools should not contain ESD.
Before installing or removing modules that contain ESD, make sure to pull out
the power plug and remove the battery.
When assembling modules that contain ESD, always handle them by their edge.
Please do not touch any connector pin or conductive part on the modules that
contain ESD.

Contents
1. Product Introduction .................................................................................................1
1.1 Overview .......................................................................................................1
1.2 Specifications ................................................................................................2
1.3 Operating Instructions ...................................................................................6
1.3.1 External Functions.............................................................................6
1.3.2 Internal Layout ..................................................................................7
1.3.3 Operation Control..............................................................................7
1.4 Status LED ....................................................................................................8
2. Application Scheme ..................................................................................................9
2.1 Transportation................................................................................................9
2.2 Storage...........................................................................................................9
2.3 Opening the Box and Initial Examination....................................................10
2.3.1 Opening the Box..............................................................................10
2.3.2 Markings for PC Identification........................................................10
2.4 External Environment Conditions ...............................................................11
3. Product Installation.................................................................................................12
3.1 Installation Information ...............................................................................12
3.2 Mounting Method........................................................................................12
3.2.1 19″Rack Mount ..............................................................................12
4. PC Connection........................................................................................................13
4.1 Things to Know before Connection.............................................................13
4.2 Product Grounding ......................................................................................13
4.3 Connecting the Device to Power .................................................................14
5. Debugging ..............................................................................................................15

5.1 Operating System ........................................................................................15
5.2 Port Definition.............................................................................................15
5.2.1 COM Ports ......................................................................................15
5.2.2 Network Port ...................................................................................16
5.2.3 USB Port .........................................................................................16
6. Software Introduction .............................................................................................17
6.1 BPI Overview ..............................................................................................18
6.2 FMI Overview .............................................................................................20
6.3 eManager Software......................................................................................21
6.3.1 Operating Environment ...................................................................22
6.3.2 Function...........................................................................................22
6.3.3 Firmware Management....................................................................26
6.4 eDisk............................................................................................................28
6.4.1 Driver Program................................................................................29
6.4.2 Installation/Uninstallation of eDisk Driver Program under Windows
.................................................................................................................29
6.4.3 Using Method of eDisk under Windows..........................................30
6.4.4 Using Method of eDisk under Linux...............................................30
6.5 eCon-XPE System .......................................................................................31
6.5.1 Enhanced Write Filter (EWF)..........................................................31
6.5.2 Logo Self-defined Software.............................................................34
7. Installing Expansion ...............................................................................................37
7.1 Opening the PC............................................................................................37
7.2 Installation/Removal CFAST Card..............................................................38
8. PC Maintenance......................................................................................................40

8.1 Removal/Installation of Hardware Assembly ..............................................40
8.1.1 Carry out Maintenance ....................................................................40
8.1.2 Preventative Maintenance ...............................................................40
8.1.3 Replacing Backup Battery...............................................................41
8.2 Installing the Drivers ...................................................................................42
9. Dimensions Drawing ..............................................................................................43
9.1 Dimensions Drawing Overview...................................................................43
9.2 Product Outline Dimensions Drawing.........................................................43
9.3 Installation Dimensions Drawing ................................................................44
9.3.1 Product Installation Dimensions Drawing.......................................44
10. Appendix...............................................................................................................45
10.1 Troubleshooting and Solutions ..................................................................45
10.2 Common Alarm Information Analysis and Solution..................................47
10.3 ESD Guideline...........................................................................................48
10.4 Abbreviations.............................................................................................50
10.5 Terminology Glossary ...............................................................................61

Product Introduction
NPC-8208 · 1 ·
1. Product Introduction
1.1 Overview
NPC-8208 is a medium/high-end network application platform based on X86
architecture. The PC contains Intel® Q170 or C236 chipset, and supports Windows7,
Windows8, Windows8.1, Windows10, Windows Server 2008/R2, Server2012/R2 and
above Linux (kernel 2.6 or above) operating systems.
The PC adopts standard 2U, 19-inch rack mount and modular structure design, and
supports two drawable HDD bracket, 2.5-inch or 3.5-inch SATA HDD, and supports
four front drawable ENS family network modular cards based on PCI-E, such as: 2
electrical ports, 2 optical ports, 4 electrical ports, 4 optical ports, 8 electrical ports, 8
optical ports, 4 optical ports and 4 electrical ports, 20 GbE, 40 GbE and many other
kinds of ENS modular cards used for optical port or electrical port expansion. The
product also supports single power supply or redundant power supply, and can meet
various network security application requirements in the market.
NPC-8208 can be widely used in firewall, anti-virus wall, load balance,
Internet-based behavior management and audit, application delivery, flow
management, VPN, DNS, IDS/IPS, UTM and other applications.

Product Introduction
· 2 · NPC-8208
1.2 Specifications
Item Definition
Microprocessor
Supports LGA1151 package Intel 6th-generation i3, i5,
i7, Xeon E3-1200 v5 family CPU
Chipset Intel® Q170 or C236
Memory
The product provides four 288Pin DDR4 memory
slots, supports Un-buffered ECC or ECC (according
to CPU used), and dual-channel function. The
maximum memory capacity supported by a single
memory slot is up to 16GB while the total memory
capacity supported is up to 64GB.
Display
Supports VGA display (optional); supports hot
swap function
Supports DVI display (optional)
Supported minimum resolution: 640×480
@60Hz; supported maximum resolution:
1920×1200 @60Hz
Main Functional Index
Network
1 x 10/100/1000Mbps LAN port, LAN1 supports
Wake-On-LAN; LAN1 supports network PXE boot

Product Introduction
NPC-8208 · 3 ·
Storage
Supports two drawable HDD cases, 2.5-inch or
3.5-inch SATA HDD
Onboard 1 x CFAST card slot
Expansion bus
Expansible to one PCIE X8 card; supports
120mm height; 300mm length; compatible with
PCIE3.0 standard
Expansible two four 4 EVOC standard ENS
modular cards.
Note: Either PCIE X8slot or ENS1 can be used.
External IO ports
1 x COM port (RJ45), supporting serial port
redirection
1 x LAN port
2 x USB 2.0 ports
External
dimensions
(excluding
mounting ear)
440mm(W) × 88.1mm(H) × 550mm(D)
Net weight About 13.9Kg (Excluding package and accessories)
Color Diamond black
Major Performance Index
Temperature
Operating temperature: 0℃～45℃
Storage temperature: -10℃～60℃

Product Introduction
· 4 · NPC-8208
Humidity
Constant heat and humidity: 40℃, 30% ～90%
(non-condensing)
EMC
Radio Disturbance: GB 9254-2008 Class(A)
Conduction Emission: GB 9254-2008 Class(A)
GB/T 17626.2.2006 ESD Level(2)
GB/T 17626.4-2006 Burst Immunity Level(2)
GB/T 17626.5-2008 Surge(impact) immunity
Level(2)
RELIABILITY
MTBF≥50000h
MTTR≤0.5h
Safety Meets basic requirements for GB4943
Mechanical and
environmental
adaptability
Anti-vibration: 5-200Hz/1.0g acceleration,
amplitude 0.5mm (power-on status)
Anti-shock: 10g acceleration, 11ms duration
Noise: ≤55dB
Power feature
Input voltage/frequency: 220VAC/50Hz
Power consumption of the PC: 83.2W (standby
status)
Power consumption of the PC: 116W (operating
BurnIntest 100%)

Product Introduction
NPC-8208 · 5 ·
Note:
3，NPC-8208 supports RAID card option (RAID card model: ERM-1221T)
4，NPC-8208 contains CPU with no more than 80W power consumption, 250W
power supply as standard configuration. If 80W or above CPU needs to be used
(such as i5-6600K, i7-6700K) or the PC is used together with large power
consumption PCIE card, power supply with larger power consumption must be
used.
3. For NPC-8208 complete PC, modular cards supported by ENS slot:
ENS-4841E ENS-4803S ENS-4203S+ ENS-2421E ENS-4823ES EF-EIO-097ENS
ENS1 × × √√× ×
ENS2 √√√√√×
ENS3 √√× √√√①②
ENS4 √√× √√√①
Notes:
1. In the table above, “√” means corresponding ENS slot supports the modular card;
“×” means corresponding ENS does not support the modular card.
2. The mark ①means BIOS setup needs to be adjusted if the modular card is to be
supported.
The mark ②means the expanded SATA on the card is not supported when
corresponding ENS slot uses the modular card.

Product Introduction
· 6 · NPC-8208
1.3 Operating Instructions
1.3.1 External Functions
Front View Location Description
1 I/O module
2 ENS module
bracket
3 HDD Group
Rear View Location Description
1 Cooling fan
2 Converter board
bracket
3 Bypass switch
4 Ground screw
5
350W power
supply module
(optional)

Product Introduction
NPC-8208 · 7 ·
1.3.2 Internal Layout
Internal Layout of the PC Location Description
1 Travel switch
2
Redundant power
supply module
(optional)
3 Cooling fan
4 Motherboard
1.3.3 Operation Control
Caution
When the PC executes hardware reset, data may be lost.
Control Button Location Description
1 On/Off button used to
switch on/off the PC.
2
Reset button
A pointed object or a clip
can be used to operate
the reset button. Pressing
this button will trigger
hardware reset

Product Introduction
· 8 · NPC-8208
1.4 Status LED
Display Meaning LED Description
Off Disconnected from power
POWER Displaying PC status
Green PC is operating
Off No access
HDD Displaying hard drive
status Yellow Being accessed

Application Scheme
NPC-8208 · 9 ·
2. Application Scheme
2.1 Transportation
Well-packaged products are suited for transportation by truck, ship, and plane. During
transportation, products should not be put in open cabin or carriage. During
transshipping, products should not be stored in open air without protection from the
atmospheric conditions. Products should not be transported together with inflammable,
explosive and corrosive substances and are not allowed to be exposed to rain, snow
and liquid substances and mechanical force.
2.2 Storage
Products should be stored in package box when it is not used. And warehouse
temperature should be 0°C ~ 40°C, and relative humidity should be 20% ~ 85%. In
the warehouse, there should be no harmful gas, inflammable, explosive products, and
corrosive chemical products, and strong mechanical vibration, shock and strong
magnetic field interference. The package box should be at least 10cm above ground,
and 50cm away from wall, thermal source, window and air inlet.
Caution!
Risk of destroying the device!
When shipping the PC in cold weather, please pay attention to the extreme
temperature variation. Under this circumstance, please make sure no water
drop (condensation) is formed on the surface or interior of the device. If
condensation is formed on the device, please wait for over twelve hours before
connecting the device.

Application Scheme
· 10 · NPC-8208
2.3 Opening the Box and Initial Examination
2.3.1 Opening the Box
Please pay attention to the following issues when opening the box:
●Do not discard the original packing material. Please keep the original packing
material for re-transportation.
●Please keep the documentation at a safe place. The documentation, which is a part
of the device, is required for initial device debugging.
●When doing the initial examination, please check whether there are distinct
damages to the device caused during the transport.
●Please check whether the delivery contains the intact device and all of the
independently ordered accessories. Please contact the customer service when any
unconformity or transportation damages occur.
2.3.2 Markings for PC Identification
Attention
When the product needs to be repaired or after it has been stolen, these codes can
be used to identify the PC. Please do not rip them off.
Serial number: located on the chassis body (as shown below)

Application Scheme
NPC-8208 · 11 ·
2.4 External Environment Conditions
The following conditions should be considered when planning the project:
The weather and mechanical environment conditions specified in the operation
manual should be observed.
Please avoid extreme environment conditions. The PC should be protected
against dust, moisture and heat.
Please avoid direct exposure to sunlight.
Please make sure that other assemblies and side of cabinet are at least 50mm
and 100mm away from the top and below the PC respectively.
Please do not block the ventilation hole of the PC.
The installation position requirement for the PC should be always observed.
The connected or installed I/O should not generate reverse voltage of more than
0.5V inside the PC.

Product Installation
· 12 · NPC-8208
3. Product Installation
3.1 Installation Information
Before installing the PC, please read the installation instructions below:
Attention
When carrying out installation in the switch cabinet, please observe assembly
guidelines and related DIN/VDE requirements, or specific regulations of the
country/region.
3.2 Mounting Method
■19″Rack Mount □Desktop □Embedded Panel
□Wall Mount □VESA Standard Arm □Portable
□Others___________
3.2.1 19″Rack Mount
Step: As shown in the left picture,
use screws to fasten the PC onto the
cabinet
Note: The PC must be placed on the
supporting board or guiding rail. Do
not fasten the PC only by the screws
on the front panel.
