Evolution R225DWS User manual

R225DWS
Original Instructions
Original written in UK English Date Published: 16 / 04 / 2018

2
www.evolutionpowertools.com
INTRODUCTION
(1.2) This Instruction Manual was
originally written in English.
(1.3) IMPORTANT
Please read these operating and safety
instructions carefully and completely.
For your own safety, if you are uncertain
about any aspect of using this equipment
please access the relevant Technical Helpline,
the number of which can be found on the
Evolution Power Tools website. We operate
several Helplines throughout our worldwide
organization, but Technical help is also
available from your supplier.
WEB www.evolutionpowertools.com
(1.4) Congratulations on your purchase
of an Evolution Power Tools Machine.
Please complete your product registration
‘online’ as explained in the A5 online
guarantee registration leaet included
with this machine. You can also scan the QR
code found on the A5 leaet with a Smart
Phone. This will enable you to validate your
machine’s guarantee period via Evolutions
website by entering your details and thus
ensure prompt service if ever needed. We
sincerely thank you for selecting a product
from Evolution Power Tools.
EVOLUTION LIMITED GUARANTEE.
Evolution Power Tools reserves the right to
make improvements and modications to
the product design without prior notice.
Please refer to the guarantee registration
leaet and/or the packaging for details
of the terms and conditions of the
guarantee. The guarantee below is
applicable to machines destined for
the UK mainland market only. Other
markets may have specic requirements,
additions or exclusions applied. Consult
your dealer for details of the guarantee
applied in your area/country. All
Evolution guarantees are in addition to
your statutory rights.
(1.5) Evolution Power Tools will, within the
guarantee period, and from the original date of
purchase, repair or replace any goods found to
be defective in materials or workmanship. This
guarantee is void if the tool being returned
has been used beyond the recommendations
in the Instruction Manual or if the machine
has been damaged by accident, neglect, or
improper service. This guarantee does not
apply to machines and / or components which
have been altered, changed, or modied
in any way, or subjected to use beyond
recommended capacities and specications.
Electrical components are subject to respective
manufacturers’warranties. All goods returned
defective shall be returned prepaid freight
to Evolution Power Tools. Evolution Power
Tools reserves the right to optionally repair or
replace it with the same or equivalent item.
There is no warranty – written or verbal – for
consumable accessories such as (following list
not exhaustive) blades, cutters, drills, chisels
or paddles etc. In no event shall Evolution
Power Tools be liable for loss or damage
resulting directly or indirectly from the use
of our merchandise or from any other cause.
Evolution Power Tools is not liable for any
costs incurred on such goods or consequential
damages. No ocer, employee or agent of
Evolution Power Tools is authorized to make
oral representations of tness or to waive any
of the foregoing terms of sale and none shall
be binding on Evolution Power Tools.
Questions relating to this limited
guarantee should be directed to the
company’s head oce, or call the
appropriate Helpline number.

3
www.evolutionpowertools.com
EN
MACHINE SPECIFICATIONS
MACHINE METRIC IMPERIAL
Motor (230-240V ~ 50Hz) 710W 3A
Speed No Load 600-1500min-1 600-1500rpm
Weight 5.8kg 12.8lb
Dust Port Diameter 35mm 1-5/16 In.
Tool Dimensions - Contracted (H x W x L) 230 x 250 x 1450mm 9 x 13-13⁄16 x
57-1/16 In.
Tool Dimensions - Extended (H x W x L) 230 x 250 x 1970mm 9 x 13-13⁄16 x
77-9/16 In.
Cable Length 4m 13ft 1-7⁄16 In.
SANDING AREA CAPACITIES METRIC IMPERIAL
Sanding Pad Diameter 215mm 8-7/16 In.
Sanding Disc Diameter 225mm 8-7/8 In.

4
www.evolutionpowertools.com
Handling
• Handle the machine with care, allowing
the machine to do the work.
• Avoid using excessive physical eort on
any of the machines controls.
• Consider your security and stability, and
the orientation of the machine during use.
Work Surface
• Consider the work surface material;
its condition, density, strength,
rigidity and orientation.
WARNING: The vibration emission during
actual use of the power tool can dier from the
declared total value depending on the ways
in which the tool is used. The need to identify
safety measures and to protect the operator
are based on an estimation of exposure in the
actual conditions of use (taking account of all
parts of the operating cycle, such as the times
the tool is switched o, when it is running idle,
in addition to trigger time).
(1.8)
LABELS & SYMBOLS
WARNING: Do not operate this machine if
warning and/or instruction labels are missing
or damaged. Contact Evolution Power Tools
for replacement labels.
Note: All or some of the following symbols
may appear in the manual or on the product.
(1.9)
Symbol Description
VVolts
AAmperes
Hz Hertz
min-1 Speed
~Alternating Current
noNo Load Speed
Wear Safety Goggles
Wear Ear Protection
Wear Dust Protection
Read Instructions
CE Certification
Double Insulated
Triman - Waste Collection
& Recycling
Waste Electrical &
Electronic Equipment
Warning

5
www.evolutionpowertools.com
EN
(1.10) INTENDED USE OF
THIS POWER TOOL
WARNING: This product is a Hand Held Dry
Wall Sander and has been designed to be
used in conjunction with a dust extraction
and collection system. Only use accessories
designed for use in this machine and/or those
recommended specically by Evolution
Power Tools Ltd.
When tted with appropriate abrasive paper
this machine can be used for sanding:
Dry Walls.
Dry Ceilings.
Dry Floors.
It can also be used to remove paint coatings,
adhesive and loose plaster etc.
PROHIBITED USE OF
THIS POWER TOOL
WARNING: This product is a Hand Held Dry
Wall Sander and must only be used as such. It
must not be modied in any way, or used to
power any other equipment or drive any other
accessories other than those mentioned in this
Instruction Manual.
WARNING: This machine must NOT be
used on any surface which is suspected to
contain lead or asbestos.
If the presence of either of these
substances is even suspected, have the
work-place inspected by the appropriate
local authority department.
Lead can be found in some old painted
surfaces, and is highly toxic when
disturbed.
Asbestos is highly dangerous and has
to be dealt with by highly trained and
specially equipped removal teams.
Consult your local authority for further
advice and guidance.
SAFETY PRECAUTIONS
(1.13) WARNING: This machine is not
intended for use by persons (including
children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning the safe
use of the machine by a person responsible
for their safety and who is competent in its
safe use.
Children should be supervised to ensure
that they do not have access to, and are not
allowed to play with, this machine.
(1.14) ELECTRICAL SAFETY
This machine is tted with the correct
moulded plug and mains lead for the
designated market. If the mains lead or the
plug are damaged in any way, they must be
replaced with original replacement parts by a
competent technician.
(1.15) OUTDOOR USE
WARNING: For your protection if this tool is to
be used outdoors it should not be exposed to
rain, or used in damp locations. Do not place
the tool on damp surfaces. Use a clean, dry
workbench if available. For added protection
use a residual current device (R.C.D.) that will
interrupt the supply if the leakage current to
earth exceeds 30mA for 30ms. Always check
the operation of the residual current device
(R.C.D.) before using the machine.
If an extension cable is required it must be a
suitable type for use outdoors and so labelled.
The manufacturers instructions should be
followed when using an extension cable.
(2.1) POWER TOOL GENERAL
SAFETY INSTRUCTIONS
(These General Power Tool Safety Instructions
are as specied in BS EN 60745-1:2009 &
EN 61029-1:2009)
WARNING: Read all safety warnings and
instructions. Failure to follow the warnings
and instructions may result in electric shock,
re and/ or serious injury.
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
battery-operated (cordless) power tool.

6
www.evolutionpowertools.com
(2.2) 1) General Power Tool Safety
Warnings [Work area safety]
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gasses or dust. Power
tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away
while operating power tool. Distractions
can cause you to lose control.
(2.3) 2) General Power Tool Safety
Warnings [Electrical Safety]
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs
and matching outlets will reduce the risk of
electric shock.
b) Avoid body contact with earthed
or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or
wet conditions. Water entering a power tool
will increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat,
oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply. Use
of an RCD reduces the risk of electric shock.
(2.4) 3) General Power Tool Safety
Warnings [Personal Safety].
a) Stay alert, watch what you are doing
and use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the inuence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust masks, non-skid
safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the o-position before
connecting to power source and or
battery pack, picking up or carrying the
tool. Carrying power tools with your nger on
the switch or energising the power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or key left attached to a rotating part
of a power tool may result in personal injury .
e) Do not overreach. Keep proper footing
and balance at all times. This enables better
control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure that these are
connected and properly used. Use of dust
collection can reduce dust-related hazards.
(2.5) 4) General Power Tool Safety
Warnings [Power tool use and care].
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better
and safer at a rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on or o. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the power tool from the
power source and/or battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventative
safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons

7
www.evolutionpowertools.com
EN
unfamiliar with the power tool or these
Instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of moving parts and any other
condition that may aect the power tools
operation. If damaged, have the power
tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations dierent from those intended
could result in a hazardous situation.
(2.6) 5) General Power Tool Safety
Warnings [Service]
a) Have your power tool serviced by
a qualied repair person using only
identical replacement parts. This will ensure
that the safety of the power tool is maintained.
(2.7) HEALTH ADVICE
WARNING: When using this machine, dust
particles may be produced. In some instances,
depending on the materials you are working
with, this dust can be particularly harmful.
If you suspect that paint on the surface
of material you wish to cut contains lead,
seek professional advice. Lead based paints
should only be removed by a professional
and you should not attempt to remove it
yourself. Once the dust has been deposited
on surfaces, hand to mouth contact can result
in the ingestion of lead. Exposure to even
low levels of lead can cause irreversible brain
and nervous system damage. The young and
unborn children are particularly vulnerable.
You are advised to consider the risks
associated with the materials you are working
with and to reduce the risk of exposure. As
some materials can produce dust that may be
hazardous to your health, we recommend the
use of an approved face mask with replaceable
lters when using this machine.
You should always:
• Work in a well-ventilated area.
• Work with approved safety equipment,
such as dust masks that are specially
designed to lter microscopic particles.
(2.8) WARNING: the operation of any power
tool can result in foreign objects being thrown
towards your eyes, which could result in
severe eye damage. Before beginning power
tool operation, always wear safety goggles or
safety glasses with side shields or a full face
shield where necessary.
ADDITIONAL SAFETY INSTRUCTIONS
WARNING: Read completely all safety
instructions. Failure to follow these
instructions could result in serious personal
injury. Pass these instructions on to any other
operators and ensure that they are adequately
trained in the use and adjustment of this
machine.
• Read the Instruction Manual completely
and carefully. Learn the applications and
limitations, as well as the specic potential
hazards relating to the use of this machine.
Pass this manual on to any other operator(s)
who may use this machine.
• Wear safety glasses or a face shield when
operating this machine. Everyday spectacles
do not have impact resistant lenses and
therefore cannot be regarded as safety
glasses.
• Protect your lungs. Wear a dust mask that
is capable of ltering microscopic dust
particles.
• Wear close tting work clothing, and
remove any dangling jewellery, chains or
belts etc that could become entangled in
rotating machinery.
• Protect your hearing. Wear suitable ear
defenders.
• Inspect the machines power cord regularly,
and if it is damaged in any way have the
cord replaced with a genuine replacement
part tted by a qualied technician.
• Check for any other damage. Any damage
found must be repaired before the machine

8
www.evolutionpowertools.com
is used again. Check for misalignment or
binding of moving parts, and any condition
that may aect the machines operation.
Any replacement parts should be Evolution
Power Tool approved, and tted by a
qualied and competent technician.
• Check for any missing parts. Any missing
parts must be replaced with genuine
replacement parts and tted by a qualied
technician.
• Do not abuse the power cord. Do not use
the power cord to carry the machine or to
pull the plug from the power outlet.
• Keep the power cord away from heat
sources, oil, sharp edges, and always be
aware of the power cords routing within the
workplace.
• Do not use this machine while tired or
under the inuence of drugs, alcohol or
medication (consult your Doctor).
• Any extension cord used with this machine
must be in good condition and capable of
carrying the current required to operate this
machine safely and eciently.
• Ensure that the workplace is adequately
illuminated.
• Do not allow familiarity with this machine
to make you careless or to ignore basic
workshop safety protocols. A careless
fraction of a second could be sucient to
cause severe injury.
• Keep the work area well ventilated. If
possible open some windows and put an
exhaust fan in one of them to move air from
the inside to the outside.
• Use a dust extraction and collection
machine that is compatible with this
machine. Follow the instructions provided
by the manufacturer of the dust extraction
machine.
• Check to ensure that the mains supply is the
same as the voltage given on the machines
rating plate.
• Remove the power cord plug from the
mains supply outlet when changing
an abrasive disc or carrying out any
other maintenance procedures and/or
adjustments.
(4.1) GETTING STARTED
UNPACKING
Caution: This packaging contains sharp
objects. Take care when unpacking. Remove
the machine, together with the accessories
supplied from the packaging. Check carefully
to ensure that the machine is in good
condition and account for all the accessories
listed in this manual. Also make sure that all
the accessories are complete. If any parts
are found to be missing, the machine and its
accessories should be returned together in
their original packaging to the retailer. Do
not throw the packaging away; keep it safe
throughout the guarantee period. Dispose
of the packaging in an environmentally
responsible manner. Recycle if possible. Do
not let children play with empty plastic bags
due to the risk of suocation.
(4.2) ITEMS SUPPLIED
Description Quantity
Instruction Manual 1
Drywall Sander 1
Oval Extension Tube 1
Flexible Dust Extraction Hose
with integral protection stand 1
Hose End Connectors
(1 x Fitted, 2 x Supplied) 3
Auxiliary ‘D’ Handle 1
Circular Abrasive Sanding
Discs (Assorted Grits) 6
Allen Keys (S5 & S6) 1
Carbon Brushes 1 pair

9
www.evolutionpowertools.com
EN
MACHINE OVERVIEW
1. SWIVELLING SANDING HEAD
2. EXTENSION TUBE
3. HAND GRIP AREAS
4. LED RING LIGHT
5. MOTOR
6. LED PROJECTOR LIGHT
7. AUXILIARY D HANDLE
8. MOTOR ‘ON/OFF’ SWITCH
9. MOTOR SPEED CONTROL
10. HOSE END CONNECTORS X3
11. DUST EXTRACTION HOSE
4
3
5
29
10
76
78
911
1
8

10
www.evolutionpowertools.com
ASSEMBLY AND PREPARATION
SHORT REACH MODE
WARNING: Only conduct the following procedures with the
machine disconnected from the main power supply.
Fitting the Flexible Dust Extraction Hose.
• Loosen the sleeve nut. (Fig. 1)
• Insert the Flexible Dust Extraction Hose into the machines main
dust extraction tube/handle, and push it fully‘home’. (Fig. 2)
• Tighten the sleeve nut to fasten the Flexible Extraction Hose
into the machine.
Note: The integral protection stand allows the machine
(when not in use) to be stood upright against a wall or similar.
The Flexible Hose is protected from being crushed or kinked by
the stand. (Fig. 3)
LONG REACH MODE
• Loosen the sleeve nut. (Fig. 1)
• Remove the Flexible Dust Extraction Hose if tted.
• Slide the Extension Tube into the machines main dust
extraction tube/handle.
Note: The Extension Tube which slides into the main dust
extraction/handle of the machine has a slightly oval cross-
section. To help insertion and correct location of the Extension
Tube, gently rotate it as you push it into place.
• Slide the Extension Tube into the main dust extraction/
handle until the 1.9m pictogram just disappears from view.
• Slide the Extension Tube Ferrule up and into the main
extraction tube/handle. (Fig. 4)
• Tighten the sleeve nut to secure the Extension Tube and
ferrule into their service positions. (Fig. 5)
• Fit the‘D’ handle clamp around the Extension Tube.
Note: This clamp is hinged. By removing the pinch bolt (Fig. 6)
the clamp can be ‘opened’and placed around the Extension Tube.
The clamp can then be‘closed’ around the Extension Tube, the
pinch bolt replaced and tightened to secure the clamp in place.
• Fit the‘D’ handle to the clamp using the two (2) socket
headed hex screws.
Note: We recommend that the‘D’ Handle clamp is positioned
directly behind and is touching the Extension Tube ferrule. This
locates the ‘D’ handle in the most convenient position for the
majority of operators.
Fig. 2
Fig. 3
Fig. 4
Fig. 1

11
www.evolutionpowertools.com
EN
Note: The design of the‘D’ handle is such that ergonomic
positioning of the handle on the clamp is possible. This
ensures comfortable operation for both right-handed and
left-handed users.
• Insert the Flexible Extraction Hose fully into the end of the
Extension Tube and tighten the sleeve nut to secure it in
place. (Fig. 7)
• The ‘free’end of the Dust extraction Hose can now be connected
to a suitable dust extraction and collection machine.
Note: Follow the instructions provided by the manufacturer of
the dust extraction machine being used.
Note: A selection of Hose End Connectors is provided. These
should ensure that this machine can be connected to most
commercially available dust extraction machines.
To Change a Hose End Connector
• Locate the two (2)‘lugs’which t into the two (2) ‘notches’in
the Hose End Mounting Ring.
• Using a at bladed screwdriver, gently and carefully press
the ‘lugs inwards, and at the same time ease the Mounting
Ring away from the Hose End Connector. The Hose End
Connector will release from the Mounting Ring.
• Snap a new Hose End Connector onto the Mounting Ring.
• Check that the ‘lugs’ have deployed into the‘notches’.
ATTACHING AN ABRASIVE DISC TO THE SANDING PAD
Note: The Motor Driven Sanding Pad located in the swivelling
Sanding Head of the machine, is tted with a‘hook and loop’
attachment system.
The ‘loops’ on the back of the abrasive discs engage with the
‘hooks’on the surface of the Sanding Pad.
To attach an abrasive disc:
• Ensure that the Sanding Pad is clean and free from any dirt
or debris.
• Press the new abrasive disc onto the Sanding Pad with the
palm of a hand.
• Ensure that the holes in the new abrasive disc align with the
dust extraction ports in the Sanding Pad. (Fig. 8)
To remove an abrasive disc:
• Simply grip the edge of the abrasive disc and gently peel it
from the Sanding Pad.
Fig. 6
Fig. 7
Fig. 8
Fig. 5

12
www.evolutionpowertools.com
THE MACHINES CONTROLS
• The ‘ON/OFF’ slide switch (Fig. 9) is a latching type. Slide it
forward to start the motor. Push forward and down on the
central section of the switch to latch it in the‘ON’position
• Push down on the rear central section of the slide switch to
release the switch and turn the motor‘OFF’. The switch will
automatically return to the‘OFF’position
• The speed control dial (Fig. 10) is located forward of the‘ON/OFF’
switch. Rotate this control dial to alter the speed of the motor.
• The Sanding Head LED Light switch is positioned on top of a
housing located to the RH (Right Hand) side of the Sanding
Head casing. (Fig. 11a) This light will provide illumination to
the immediate area being worked upon.
• The LED Projector Light (Fig. 11b). The ‘ON/OFF’ Rocker
switch is located on the body of the light, underneath and to
the rear. This Light will provide extra illumination to the area
about to be worked upon.
• A ring located just to the front edge of the integral protection
stand can be rotated slightly.
• Rotating this ring will reveal an air bleed port. (Fig. 12)
• Revealing this air bleed port in part or in full, allows the
operator to adjust the airow from the Sanding Head to a
connected dust extraction machine.
• The operator should adjust this control to give the most
eective dust extraction from the Sanding Head.
WARNING: Even with an eective dust extraction/collecting
machine attached to this machine the operator should still
employ all relevant PPE procedures and processes. If working
‘on site’consult the person responsible for Health & Safety on
the site for extra guidance.
OPERATIONAL GUIDANCE AND ADVICE
Body and Hand Positioning
• This machine is a two (2) handed machine. Soft grip hand
hold areas are provided along the machine.
• An auxiliary ‘D’ handle is provided and is particularly useful
when the machine is congured in Long Reach Mode.
• Position your hands along the machine to provide the best
and most comfortable combination of ‘reach’and ‘leverage’
for the particular operation being undertaken.
• Keep your hands away from the swivelling Sanding Head.
• Do not stretch or overbalance. Reposition yourself so that
you do not have to stretch.
Fig. 11 a
Fig. 11 b
Fig. 9
Fig. 10

13
www.evolutionpowertools.com
EN
OPERATOR STANCE
• The operator should adopt a comfortable stance with their
feet apart and rmly balanced.
• Both feet should be on the ground or oor. It is not
acceptable to have one foot on the oor and the other on a
stand or ladder rung etc, as this precludes the operator from
achieving a proper balanced stance.
Caution: If‘reach’or access considerations necessitate the use by the
operator of a stand-on platform, such a platform must be suitable,
in good condition with all the safety features serviceable and stable
in use e.g. a folding inside scaold or‘hop-on’work platform.
WARNING: The operator must NEVER overstretch.
THE ARTICULATED SANDING HEAD
The Sanding Head is attached to the main body of the machine
by a type of Universal Joint. This allows the Sanding Head to
swivel in multiple directions.
When in use the abrasive disc can eectively‘oat’ over the
work surface. This action enables the operator to sweep the
work surface from top to bottom or from side to side with
minimal changes to their stance and foot position. This aords
greater security and better balance for the operator.
SANDING
Operational Advice
• Congure the machine to the‘Reach Mode’required.
• Connect the required Sanding Head to the machine.
• Connect a suitable dust extraction and collection machine to
the Drywall Sander.
• Turn on the extraction unit.
• Adopt a comfortable stance holding the Sander by the two
most convenient and comfortable hand grips.
• Turn on the Sanding Head LED Light.
• Turn on the Sander, and if required the projector LED Light.
• Position the Sanding Head lightly against the work surface,
and apply just enough pressure to align the Sanding Head
with the work surface.
• Gently apply more pressure to engage the abrasive disc onto
the work surface.
• Move the Sander across the work surface in long overlapping
sweeps. Apply only enough pressure to keep the abrasive disc at
against the work surface. Excessive pressure should be avoided as
it can cause swirl marks and unevenness in the work surface.
Fig. 12

14
www.evolutionpowertools.com
• Keep the Sander in constant motion whilst the abrasive disc
is in contact with the work surface. Use a steady, sweeping
motion, allowing the rotating abrasive disc to ‘oat’ over the
work surface. Moving the Sander erratically or concentrating
for too long on one area can also cause swirl marks or
unevenness in the work surface.
WARNING: Do not allow the rotating abrasive disc to contact
sharp objects such as protruding nails, screws etc or architectural
wall ttings such as electrical boxes or switch plates etc. Damage
to the Sander or the wall ttings could result.
MAINTENANCE
The Sanding Head Brush Skirt (Fig. 13)
The Brush Skirt surrounds the Sanding Pad to which the abrasive
discs are applied. The Brush Skirt serves two (2) main purposes:
• It extends below the surface of the abrasive discs so that it
contacts the work surface rst, orientating the Sanding Head.
This helps prevent the rotating abrasive disc from‘gouging’
the work surface on rst contact.
• It helps contain the dust particles within the swivelling
Sanding Head until the airow from an attached extraction
machines sucks the dust away.
Over time, depending upon the frequency of use and the type
of material sanded, the bristles on the Brush Skirt will become
degraded and worn. The bristles on the Brush Skirt must be
complete with no gaps or portions missing.
A new Brush Skirt has a bristle length of approximately 15mm.
Replace the Brush Skirt when the length of the bristles is
approximately 8mm, or when the bristles no longer extend
below the surface of an installed sanding disc.
To replace the Brush Skirt
WARNING: Only attempt this procedure with the machine
disconnected from the mains power supply.
• Remove any attached abrasive disc to reveal the Sanding
Pad and the centrally located Hex Headed Socket Screw that
attaches the Pad to the motors drive spindle.
• Holding the Sanding Pad with the palm of one hand (Fig. 14),
insert the supplied 5mm Hex Key into the head of the central
screw. Loosen and remove the screw. Remove the Sanding Pad
from the motors drive spindle.
• Use a cross-head screwdriver and remove the six (6) self
tapping screws and the special xing clips. (Fig. 15) that
Fig. 14
Fig. 13
Fig. 15

15
www.evolutionpowertools.com
EN
secure the Brush Skirt and lens into the Sanding Head.
• Carefully pull and ease the Brush Skirt and lens from the
Sanding Head.
• Installation of a new Brush Skirt is basically the reversal of the
removal process.
• During installation of a new Brush Skirt take care to not over
tighten the six (6) self tapping screws. These should be rmly
tightened but be careful not to strip the threads within the
tapped holes.
• Ensure that the special xing clips are correctly positioned.
• Reinstall the Sanding Pad on the motors drive spindle and
secure in place with the Hex Headed Socket Screw.
Note: Changing the Brush Skirt will expose the interior of the
Sanding Head. The operator should take the opportunity to
examine, clean and remove any debris from within the Sanding
Head, or from the exhaust ports and exhaust tubes fastened or
contained within it.
(6.1) WARNING: Any maintenance must be carried out with
the machine switched o and disconnected from the mains/
battery power supply.
Check that all safety features and guards are operating correctly
on a regular basis. Only use this machine if all guards/safety
features are fully operational.
All motor bearings in this machine are lubricated for life.
No further lubrication is required.
Use a clean, slightly damp cloth to clean the plastic parts of the
machine. Do not use solvents or similar products which could
damage the plastic parts.
WARNING: Do not attempt to clean by inserting pointed
objects through openings in the machines casings etc. The
machines air vents should be cleaned using compressed dry air.
Excessive sparking may indicate the presence of dirt in the
motor or worn out carbon brushes.
(6.2) If this is suspected have the machine serviced and the
brushes replaced by a qualied technician.
(6.4) ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check
with your Local Authority or retailer for recycling advice.

16
www.evolutionpowertools.com
EC DECLARATION OF CONFORMITY
In accordance with EN ISO 17050-1:2004
The manufacturer of the product covered by this Declaration is:
UK: Evolution Power Tools Ltd, Venture One, Longacre Close, Holbrook Industrial Estate, Sheeld, S20 3FR.
FR: Evolution Power Tools SAS, 61 Avenue Lafontaine, 33560, Carbon-Blanc, Bordeaux, France.
The manufacturer hereby declares that the machine as detailed in this declaration fulfils all the
relevant provisions of the Machinery Directive and other appropriate directives as detailed below.
The manufacture further declares that the machine as detailed in this declaration, where applicable,
fulfils the relevant provisions of the Essential Health and Safety requirements.
The Directives covered by this Declaration are as detailed below:
2006/42/EC. Machinery Directive.
2014/30/EU. Electromagnetic Compatibility Directive.
The Restriction of the Use of certain Hazardous
Substances in Electrical Equipment (RoHS) Directive.
2012/19/EU. The Waste Electrical and Electronic Equipment (WEEE) Directive.
And is in conformity with the applicable requirements of the following documents:
EN 60745-1: 2009+A11: 2010, EN 60745-2-3: 2011+A2: 2013 +A11: 2014+ A13: 2015,
PAH Requirement AfPS GS 2019:01 PAK,
EN ISO 12100: 2010, EN 55014-1: 2017,
EN55014-2:2015, EN61000-3-2:2014, EN61000-3-3:2013, EK9-BE-88:2014
Product Details
Description: R225DWS 225mm Dry Wall Sander
Evolution Model No: 0780001 / 0780002 / 0780003 / 0780004
Brand Name: EVOLUTION
Voltage: 230V ~ 50/60 Hz
Input: 710W
The technical documentation required to demonstrate that the product meets the requirements
of directive has been compiled and is available for inspection by the relevant enforcement
authorities, and verifies that our technical file contains the documents listed above
and that they are the correct standards for the product as detailed above.
Signed: Print: Matthew Gavins: Group Chief Executive.
Date: 01/04/2016
Name and address of technical documentation holder.
UK: Evolution Power Tools Ltd, Venture One, Longacre Close, Holbrook Industrial Estate, Sheeld, S20 3FR.
FR: Evolution Power Tools SAS, 61 Avenue Lafontaine, 33560, Carbon-Blanc, Bordeaux, France.
2011/65/EU. &
2015/863/EU.

17
www.evolutionpowertools.com
EN
NOTES

18
www.evolutionpowertools.com
Notes

19
www.evolutionpowertools.com
Notes

Discover Evolution Power Tools
Visit: www.evolutionpowertools.com or download
the QR Reader App on your smart phone and scan
the QR code (Right).
UK
Evolution Power Tools Ltd
Venture One
Longacre Close
Holbrook Industrial Estate
Sheffield
S20 3FR
[phone]
US
Evolution Power Tools LLC
8363 Research Drive
Davenport
Iowa
52806
+1 866-EVO-TOOL
EU
Evolution Power Tools SAS
61 Avenue Lafontaine
33560
Carbon-Blanc
Bordeaux
+ 33 (0)5 57 30 61 89
V6
