Dear Customer,
thank you for choosing the EVOLVEO Android Stick Q3 4K
We hope that it will bring you lots of fun and satisfaction
Description
A USB port
for connection of
dongle
wireless
keyboard or mouse
B
microUSB
C
microUSB
for power conne
ction from TV USB
port or 230 V charger
D microSDHC slot
for memory card
E
Function key
for firmware upgrade
Start
•For connection of this product to iFi, the location in the direct visibility of the most commonly
used Access points not beyond 6 meters is necessary. The iFi signal strength indicator is only
informative for this product. Having trouble with the iFi connection, reduce the distance from
the Access point.
•Connect your new EVOLVEO Android Stick Q3 4K to HDMI port on your TV. Power with the 230V
adapter or use the USB port on your TV (at least 1 A current output).
•EVOLVEO Android Stick Q3 4K supports the 2.4 GHz standard for wireless keyboard or mouse
connection.
WiFi connection
•Click on the icon and then click on „Settings” icon.
•Go back to the menu on the left side of the screen, until you reach the “ iFi” tab under
“ IRELESS AND NET ORK”. Then turn the switch in the upper right corner on and after a few
seconds, select your wireless network, enter your security password and wait until your
device connects to your home network.
Click on the back arrow at the bottom of your screen to return to the “Application” menu.
•Run the “Play Store” application. Login to your Google Account or create a new one, if not
having one.
APPLICATIONS
Click on the icon. The list of installed applications is displayed. Run the selected application by
a short click. Click, hold and drag the icon to create a shortcut on the home page. To delete from
the home page, drag the icon with the mouse to the top of the screen on the “Remove” icon.
You can add also following files on the home page:
1 Applications: Adding the application links, web pages bookmarks, favourite contacts, Map
localities, Gmail name tags, Playlists and many other items. Available links depend on the
installed applications.
2 Widgets: Adding of any number of various mini applications ( idgets) to your Home screen.
You can also download idgets from the Google Play
Settings
You can adjust the HDMI stick functions in this section.

EN
Backup and reset
Choose the factory reset to erase all user data.
EVOLVEO Android Stick Q3 4K uses the Android operating system which is not fully adapted to the
TV screen. For this reason, the quality and the range of display of some web pages with active
content (Flash, Video, ActiveX, Java etc.) or the installation of Android applications is limited or
impossible. Third party services may be changed, removed or interrupted without prior notice.
EVOLVEO is not responsible for the availability of services, content and completeness of the Android
menu on the screen translation.
Troubleshooting
Proble
m
Solution
The
device
can´t be
switched on
Check if the stick is properly inserted in
the
HDMI port, or check
charging.
The
device
restarts or
the
Home page is n
ot properly
displayed
Don
’
t use
the
USB port of your TV to charge, it may be not sufficient
enough, check the 230 V charger connection. Unplug the charger and
connect again into the HDMI port.
The sound can´t be heard
Check if you haven´t muted the sound
on the
Android bottom control
bar; the file or the playlist you want to play can also be damaged.
Check volume settings of your television.
The i
Fi connection can´t
be made
Check your iFi router. Make sure that you
have the i
Fi in your stick
enabled. Try also other devices (e.g. smartphone or notebook), if
problems with the access to your i-Fi persist. If the connection is
working choose the same connection also for the HDMI. Check if you are
connected to the proper network and if it has a sufficient range.
Do you still need an advice after reading this manual?
First read “Frequently Asked Questions” at www evolveo eu or contact the EVOLVEO technical
support. This product goes through the constant development and improving. Therefore it is
possible that the actual design, function or operations won´t fully correspond to conditions written
in this user manual. The possible difference isn´t the device defect and it is not the reason for the
warranty claim.
The warranty DOESN´T APPLY to:
•using the device for other purposes than it was designed to
•installation of another software than the one that was in EVOLVEO Android Stick Q3 4K installed, or that
which can be downloaded manually or automatically from the device menu
•electrical and mechanical damage caused by improper use
•damage caused by the natural elements as fire, water, static electricity, power surges and so on
•damage caused by an unauthorized repair
• damage of the guarantee seal or unreadable serial number of the device

EN
Disposal:
The symbol of crossed out wheelie bin on the product, within the literature or on the packaging
reminds you that in the European Union, all electric and electronic products, batteries and
accumulators must be stored as assorted waste after the end of their service life. Do not throw
these products into the unsorted municipal waste.
DECLARATION OF CONFORMITY
Hereby, the company ABACUS Electric s.r.o. declares that EVOLVEO Android Stick Q3 4K
(EAN: 8594161336860) is in compliance with the requirements of the norms and regulations,
relevant for the given type of device.
The complete text of Declaration of conformity can be found on ftp://ftp.evolveo.eu/ce
Copyright © 2015 ABACUS Electric s.r.o.
All rights reserved.
Design and specification can be changed without prior notice.
