Ewbank 940 Manual

Power Sweeper
Model 40
Care and Use Instructions
Customer Services, Ewbank Products Ltd, Billington Road, Burnley
Lancashire, BB11 5ED.
Tel: [phone]
www.ewbank.co.uk
940 Power Manual:Layout 1 2/3/09 09:03 Page 1

Rechargeable Power Sweeper
1. Use
This Power Sweeper is intended for the
sweeping of dirt and for indoor use only.
The Power Sweeper is not intended for the
sweeping of gravel-faced concrete, gravel and
similar surfaces, not for deep-pile carpets and
wet floor coverings or for commercial use.
Use only as described in this manual.
Do not allow the appliance to be used as a toy.
Do not let children use this device unsupervised.
Do not pick up burning or smoking objects such
as cigarettes, matches, or hot ashes.
2. Technical data
Voltage/frequency (charger)...........230 V~50Hz
Rated consumption (charger)......................4 W
Output (charger).......................9 V d.c. 200 mA
Operating time with full battery charge
(depending on floor covering)............25-30 min
Battery - working voltage...........................4.8 V
Charging time with empty battery.......12-16 hrs
Sound pressure level............................75dB(A)
3. Prior to initial
Before starting the device make sure that;
• The charger and its cable are in good
condition.
• Remove all packaging materials from the
product.
2
Ba
tt
er
y
char
g
in
g
/ Operatio
n
Removin Press and Pull the dirt container
g
the dirt containe
r
A
ssem
b
l
y
Removing the brush roller
940 Power Manual:Layout 1 2/3/09 09:03 Page 2

4. Assembling the Power Sweeper
• Assemble the handle by inserting the three
sections into each other and turn to secure.
• Screw the handle into the device mounting.
5. Battery Charging
The Power Sweeper is supplied with
an empty Ni- H rechargeable battery. ake
sure the battery is charged for 16 hours before
initial use, this will give optimum battery
performance. Charging processes thereafter
takes 12-16 hours.
To charge the battery
• switch off the device with the switch,
insert the plug of the charger in the charging
jack of the device
• then insert the mains plug in a 230 V~50Hz
socket.
The red charging lamp is illuminated during
the charging process. If this is not the case,
check the plug connections.
With fully charged battery the device provides
an operating time of 25-30 minutes.
Rechargeable Power Sweeper
7. Cleaning & Emptying
To maintain the efficiency of the Power
Sweeper, empty the dirt container after every
use.
• Press the unlocking button of the dirt
container to detach it from the device.
With a slight upward movement, pull the dirt
container horizontally from the device.
• Empty the dirt container and re-insert.
(see page 1)
How to clean the brush
If the brush roller cannot be turned any
longer because of dirt, threads or hair:
• Turn over the sweeper and hold it so that the
flat side with the brush roller faces you.
• Remove the cover on the right hand side of
the brush.
• Loosen the drive belt by pushing it to
the right.
• Lift the brush roller on the right hand side
and remove the guide attachment.
• Now pull the brush roller from the device to
the right hand side.
• Remove the dirt (on both sides of the bristle)
and clean the brush.
After cleaning, proceed as follows to
re-install the brush roller.
• Ensure the drive belt is around the motor
drive pulley.
• Insert the brush roller in the left hand slot
• Fit the guide attachment on the right hand
side of the brush.
• Pull the belt around the guide attachment.
• Insert the brush in the right hand side and
continue to pull the belt over the drive wheel.
• Fit the brush cover by first introducing the
lower lugs in the recesses and press the
cover in at the top.
Caution:
• Only use the enclosed charger
(9V d.c. 200 mA).
• Only operate the device with the enclosed
rechargeable battery. It could otherwise get
damaged.
• Do not attempt to remove the rechargeable
battery for charging.
• Do not attempt to open the rechargeable
battery jacket or dismantle the battery.
Caution:
• Never use the device with the dirt container
removed.
• Keep end of rotating brush, poles and other
openings away from your face and body.
3
6. Working with the Power Sweeper
• Press the switch to start or stop the Power
Sweeper.
• Guide the Power Sweeper over the floor.
Note: With some types of carpet the power
sweeper could rattle or bounce. In this case
work slowly and in the opposite direction.
940 Power Manual:Layout 1 2/3/09 09:03 Page 3

8.Removing the Battery
• Release the dustpan from the unit.
• Unscrew the screw located on the battery
panel.
• Pull the battery out from its housing.
• Unclip the two wires attached to the battery.
. Disposal
This device contains a Ni- H rechargeable
battery which must be disposed properly.
When the battery and the device are going to
be disposed, take the battery out of the device
and deposit at your local recycling point. Never
deposit in your domestic waste bin.
Rechargeable Power Sweeper
Caution:
• Ensure that the device is not inadvertently
switched on with the dirt container removed
or while cleaning the brush.
• Do not clean the device during the charging
process.
• Do not expose the Power Sweeper to
extreme temperatures or moisture.
• Do not store it near ovens, heating
elements, burners or in the bathroom.
• Never leave the device unattended while
switched on.
• Never throw the rechargeable battery and
the device into open flames or burn them!
4
Your Guarantee
This product is covered by a 12 month guarantee.
This does not cover normal wear and tear or abuse.
For guarantee purposes, please retain your original receipt as proof of purchase.
For spares, service and further information please contact;
Customer Services, Ewbank Products Ltd, Billington Road, Burnley, Lancashire, BB11 5ED
Tel: [phone]
www.ewbank.co.uk
M
Your attention is brought to new directives applicable to the disposal of this electrical
equipment,where in accordance with the legislation this product must not be disposed of
in your normal household waste. Instead it is your responsibility to dispose of this type of
waste by handing it over to special designated collection points for recovery and recycling.
This product is marked with a ‘Wheelie bin’ symbol with a cross on it to remind you of this
action. The objective of thisdirective is to help conserve resources and ensure that it is
recycled in a manner that protects human health and the environment. For more information
about where you can drop off your waste please contact your local authority, take back
facilities are free of charge.
INFORMATION ON THE DISPOSAL OF WASTE ELECTRICAL
EQUIPMENT KNOWN AS WEEE
EB0018 02/09
