EWM 4L T/P User manual

Conversion instructions
Retrofit option
GB
ON PS drive 4L T/P
Pivot support - Wire feeder pivots 360° on the welding machine
099-002112-EWM01 Observe additional system documents! 06.07.2012

General instructions
CAUTION
Read the operating instructions!
The operating instructions provide an introduction to the safe use of the products.
• Read the operating instructions for all system components!
• Observe accident prevention regulations!
• Observe all local regulations!
• Confirm with a signature where appropriate.
NOTE
In the event of queries on installation, commissioning, operation or special conditions at the
installation site, or on usage, please contact your sales partner or our
customer service department on [phone].
A list of authorised sales partners can be found at www.ewm-group.com.
Liability relating to the operation of this equipment is restricted solely to the function of the equipment. No other
form of liability, regardless of type, shall be accepted. This exclusion of liability shall be deemed accepted by the
user on commissioning the equipment.
The manufacturer is unable to monitor whether or not these instructions or the conditions and methods are
observed during installation, operation, usage and maintenance of the equipment.
An incorrectly performed installation can result in material damage and injure persons as a result. For this reason,
we do not accept any responsibility or liability for losses, damages or costs arising from incorrect installation,
improper operation or incorrect usage and maintenance or any actions connected to this in any way.
© EWM HIGHTEC WELDING GmbH · Dr. Günter-Henle-Str. 8 · D-56271 Mündersbach, Germany
The copyright to this document remains the property of the manufacturer.
Reprinting, including extracts, only permitted with written approval.
Subject to technical amendments.

Contents
Proper usage
099-002112-EWM01
06.07.2012 3
1 Contents
1Contents..................................................................................................................................................3
2Safety instructions.................................................................................................................................4
3Overview .................................................................................................................................................5
3.1 Proper usage .................................................................................................................................5
3.2 Diagram of the assembled option..................................................................................................5
3.3 System overview............................................................................................................................6
4Conversion .............................................................................................................................................7
4.1 Parts list.........................................................................................................................................7
4.2 Assembly .......................................................................................................................................8
4.2.1 Screwing the press arbor onto the cross arm ................................................................8
4.2.2 Fitting the adapter plate..................................................................................................9
4.3 Final assembly.............................................................................................................................10
5Technical data ......................................................................................................................................10

Safety instructions
Proper usage
4 099-002112-EWM01
06.07.2012
2 Safety instructions
DANGER
Do not carry out any unauthorised repairs or modifications!
To avoid injury and equipment damage, the unit must only be repaired or modified by
specialist, skilled persons!
The warranty becomes null and void in the event of unauthorised interference.
• Appoint only skilled persons for repair work (trained service personnel)!
WARNING
Validity of this document!
This document is only valid in combination with the operating instructions for the
power source being used (welding machine)!
• Read the operating instructions, in particular the safety instructions for the power source
(welding machine)!
Risk of accidents if these safety instructions are not observed!
Non-observance of these safety instructions is potentially fatal!
• Carefully read the safety information in this manual!
• Observe the accident prevention regulations in your country.
• Inform persons in the working area that they must observe the regulations!
CAUTION
Obligations of the operator!
The respective national directives and laws must be observed for operation of the
machine!
• National implementation of the framework directive (89/391/EWG), as well as the
associated individual directives.
• In particular, directive (89/655/EWG), on the minimum regulations for safety and health
protection when staff members use equipment during work.
• The regulations regarding work safety and accident prevention for the respective country.
• Setting up and operating the machine according to IEC 60974-9.
• Check at regular intervals that users are working in a safety-conscious way.
• Regular checks of the machine according to IEC 60974-4.

Overview
Proper usage
099-002112-EWM01
06.07.2012 5
3 Overview
3.1 Proper usage
WARNING
Hazards due to improper usage!
Hazards may arise for persons, animals and material objects if the equipment is not
used correctly. No liability is accepted for any damages arising from improper usage!
• The equipment must only be used in line with proper usage and by trained or expert staff!
• Do not modify or convert the equipment improperly!
These conversion instructions apply to the following welding machines only:
• alpha Q 351 / 551
• Phoenix 351 / 401/ 451 / 551
• Taurus 351 / 401/ 451 / 551
• Tetrix 351 / 451 / 551
• Tetrix 351 / 451 / 551 AC/DC
3.2 Diagram of the assembled option
NOTE
The illustration serves as an example only.
Figure 3-1

Overview
System overview
6 099-002112-EWM01
06.07.2012
3.3 System overview
1
2
4 53
Figure 3-2
Item Symbol Description 0
1
Power source
2
ON PS drive 4L T/P
Pivot support – 092-002112-00000
3
Hose support arm
4
Wire feeder - drive 4L (pivotable)
5
ON PS Trolly 55.2-2 drive 200/300C
Pivot support - 092-002634-00000

Conversion
Parts list
099-002112-EWM01
06.07.2012 7
4 Conversion
4.1 Parts list
NOTE
Before conversion, check that the retrofit kit is complete (see parts list).
6
77
8
8
4
3
2
1
5
Figure 4-1
Item 0 Quantity Description Item number
1 1 Threaded press arbor 094-007483-00005
2 1 Press arbor guide bushing (socket is pressed into the
metal sheet) 094-007371-00004
3 1 Pivot support 094-010361-00001
4 1 M6 plain washer 064-000583-00000
5 1 M6 Fan-type lock washer 064-000591-00000
6 1 Hexagon screw 064-000670-00000
7 4 M10 x 25 Lifting eye 094-000209-00001
8 4 Fan-type lock washer 064-000563-00000

Conversion
Assembly
8 099-002112-EWM01
06.07.2012
4.2 Assembly
4.2.1 Screwing the press arbor onto the cross arm
Figure 4-2
• Insert the press arbor into the cross arm through the guide bushing (threaded hole in the press arbour
is pointing downwards).
• Screw the press arbor onto the plain washer, fan-type lock washer and screw.

Conversion
Assembly
099-002112-EWM01
06.07.2012 9
4.2.2 Fitting the adapter plate
DANGER
Risk of injury due to unsuitable lifting eye!
In case of improper use of lifting eyes or the use of unsuitable lifting eyes, persons can
be seriously damaged by falling equipment or add-on components!
• The lifting eye must be completely screwed in!
• The lifting eye must be positioned flat onto and in full contact with the supporting surfaces!
• Check that the lifting eyes are securely fastened before use and check for any damage
(corrosion, deformation)!
• Do not use or screw in damaged lifting eyes!
• Avoid lateral loading of the lifting eyes!
22
1
Figure 4-3
Item 0 Quantity Description Item number
1 4 M10 x 25 Lifting eye 094-000209-00001
2 4 Fan-type lock washer 064-000563-00000
• Unscrew lifting eye.
• Position the adapter plate on the machine.
• Connect the adapter plate to the welding machine using the long lifting eyes and the fan-type lock
washers of this kit.

Technical data
Final assembly
10 099-002112-EWM01
06.07.2012
4.3 Final assembly
WARNING
Danger due to failure to carry out the final inspection!
Parts that are incorrectly fitted or that become loose are a source of danger.
• Check all mechanical connections to ensure that they are fitted correctly!
• Carry out the final inspection!
• Carry out the functional test!
5 Technical data
NOTE
The technical data given here completes or replaces the respective values in the
standard operating instructions.
• Weight: +4 kg
