EWM Pico 300 cel SVRD User manual

Operating instructions
EN
Welding machine
Pico 300 cel pws
Pico 300 cel pws vrd 12V
Pico 300 cel pws svrd 12V
099-002044-EW501
Observe additional systemdocuments!
14.10.2022

General instructions
WARNING
Read the operating instructions!
The operating instructions provide an introduction to the safe use of the products.
•Read and observe the operating instructionsforall systemcomponents, especially the sa-
fety instructions and warning notices!
•Observe the accidentprevention regulations and any regionalregulations!
•The operating instructions must be kept at the location where the machine is operated.
•Safety and warning labelson the machine indicate any possible risks.
Keep these labelsclean and legible at all times.
•The machine has been constructed to state-of-the-art standardsin line with anyapplicable
regulations and industrial standards. Only trained personnel may operate,service and re-
pair the machine.
•Technical changesdue to further development in machine technologymay lead to a dif-
fering welding behaviour.
In the event of queries on installation,commissioning, operationor specialconditions at the
installation site,or on usage,please contactyour salespartneror our customer service
departmenton [phone].
A list of authorised sales partners can be found at www.ewm-group.com/en/specialist-dealers.
Liability relating to the operation ofthisequipmentis restricted solely to the function of the equipment. No
other form of liability,regardless of type, shall be accepted. This exclusion of liability shall be deemed ac-
cepted bythe user on commissioning the equipment.
The manufacturer is unable to monitor whether or not these instructions or the conditions and methods
are observed during installation, operation, usage and maintenance of the equipment.
An incorrectly performed installation can resultin materialdamage and injure personsas a result. For this
reason, we do not accept any responsibility orliability for losses, damages or costs arising fromincorrect
installation, improper operation or incorrect usage and maintenance or any actionsconnected to this in
any way.
© EWM AG
Dr. Günter-Henle-Strasse 8
56271 Mündersbach Germany
Tel.: [phone], Fax: -244
Email: [e-mail]
www.ewm-group.com
The copyright to this document remainsthe property of the manufacturer.
Copying,including extracts, only permitted with written approval.
The content of this documenthas been prepared and reviewed with all reasonablecare. The information
provided issubject to change; errors excepted.
Data security
The user is responsible for backing up data of all changes fromthe factory setting. The user is liable for
erased personal settings. The manufacturer does not assumeany liability for this.

Contents
Notes on using these operating instructions
099-002044-EW501
14.10.2022
3
1 Contents
1Contents....................................................................................................................... 3
2For your safety.............................................................................................................. 6
2.1 Noteson using these operating instructions ............................................................... 6
2.2 Explanation of icons ............................................................................................... 7
2.3 Safety instructions.................................................................................................. 8
2.4 Transport and installation.......................................................................................11
3Intended use................................................................................................................13
3.1 Applications..........................................................................................................13
3.2 Overview of device types........................................................................................13
3.2.1 Cellulose electrode types (cel)...................................................................13
3.2.2 Polereversing switch (pws).......................................................................13
3.2.3 Voltage reducing device............................................................................13
3.3 Documents which also apply...................................................................................14
3.3.1 Warranty................................................................................................14
3.3.2 Declaration of Conformity..........................................................................14
3.3.3 Welding in environments withincreased electrical hazards.............................14
3.3.4 Servicedocuments (spare parts and circuitdiagrams)...................................14
3.3.5 Calibration/Validation...............................................................................14
3.3.6 Partof thecompletedocumentation............................................................15
4Machine description –quick overview...........................................................................16
4.1 Front view/ rearview.............................................................................................16
4.2 Machine control –Operating elements......................................................................18
4.2.1 Welding datadisplay................................................................................19
4.2.2 Welding current actual valuedisplay...........................................................19
5Design and function.....................................................................................................20
5.1 Transport and installation.......................................................................................20
5.1.1 Machine cooling ......................................................................................20
5.1.2 Workpiece lead, general...........................................................................20
5.1.3 Ambient conditions..................................................................................21
5.1.4 Transport belt..........................................................................................21
5.1.4.1 Adjusting the lengthof thecarrying strap........................................21
5.1.5 Noteson the installation of welding current leads..........................................22
5.1.6 Stray welding currents..............................................................................23
5.1.7 Mains connection.....................................................................................24
5.1.7.1 Mains configuration.....................................................................24
5.2 MMA welding........................................................................................................25
5.2.1 Connecting the electrode holder and workpiece lead.....................................25
5.2.2 Welding task selection..............................................................................26
5.2.2.1 Arcforce (welding characteristics)..................................................26
5.2.2.2 Welding currentpolarity reversal (polarity reversal)..........................26
5.2.3 Hotstart..................................................................................................27
5.2.3.1 Hotstart time..............................................................................27
5.2.3.2 Hotstartcurrent..........................................................................27
5.2.4 Antistick.................................................................................................27
5.3 TIG welding..........................................................................................................28
5.3.1 Shielding gas supply (shielding gas cylinderfor welding machine)...................28
5.3.1.1 Pressure regulator connection......................................................28
5.3.2 Connecting a TIG welding torch with rotating gasvalve.................................29
5.3.3 Welding task selection..............................................................................30
5.3.4 Gas test –setting the shielding gas volume.................................................30
5.3.5 Arc ignition.............................................................................................30
5.3.5.1 Liftarc.......................................................................................30
5.4 Remotecontrol.....................................................................................................30
5.4.1 RT1 19POL............................................................................................30
5.4.2 RTF1 19POL..........................................................................................31
5.4.3 RT PWS1 19POL....................................................................................31
5.4.4 RTA PWS2.............................................................................................31
5.5 Dirt filter...............................................................................................................31

Contents
Notes on using these operating instructions
4
099-002044-EW501
14.10.2022
5.6 Voltage reducing device.........................................................................................32
5.7 Machine configuration menu...................................................................................32
5.7.1 Arcforcecorrection (welding characteristics)................................................32
5.7.2 Arc length restriction (USP).......................................................................32
5.7.3 Welding current actual valuedisplay...........................................................33
6Maintenance, care and disposal....................................................................................34
6.1 General...............................................................................................................34
6.1.1 Cleaning.................................................................................................34
6.1.2 Dirt filter.................................................................................................34
6.2 Maintenance work, intervals....................................................................................35
6.2.1 Daily maintenance tasks...........................................................................35
6.2.2 Monthly maintenance tasks.......................................................................35
6.2.3 Annual test (inspection and testing during operation).....................................35
6.3 Disposing of equipment..........................................................................................36
7Rectifying faults...........................................................................................................37
7.1 Errormessages (power source)...............................................................................37
7.2 Resetting welding parameters to the factory settings ..................................................38
8Technical data.............................................................................................................39
8.1 Pico 300cel pws...................................................................................................39
9Accessories.................................................................................................................40
9.1 Welding torch, electrode holderand workpiece lead ...................................................40
9.2 19-pole remote control...........................................................................................40
9.2.1 Connection cables...................................................................................40
9.2.2 Extension cable.......................................................................................40
9.3 Options................................................................................................................40
9.4 General accessories..............................................................................................40
10 Appendix.....................................................................................................................41
10.1 Parameteroverview –setting ranges.......................................................................41
10.2 Searching for adealer............................................................................................42

Contents
Notes on using these operating instructions
099-002044-EW501
14.10.2022
5

For your safety
Notes on using these operating instructions
6
099-002044-EW501
14.10.2022
2 For your safety
2.1 Noteson usingthese operatinginstructions
DANGER
Working or operatingprocedures which must be closely observedto prevent imminent
serious and even fatal injuries.
•Safety notesinclude the "DANGER"keyword in the heading with a general warning symbol.
•The hazard is also highlighted using a symbol on the edge of the page.
WARNING
Working or operatingprocedures which must be closely observedto prevent serious
and even fatal injuries.
•Safety notesinclude the "WARNING" keyword in the heading with a general warning sym-
bol.
•The hazard is also highlighted using a symbol in the page margin.
CAUTION
Working or operatingprocedures which must be closely observedto prevent possible
minor personalinjury.
•The safety information includes the "CAUTION" keyword in its heading with a general warn-
ing symbol.
•The risk is explained using a symbol on the edge of the page.
Technical aspects which the user must observe to avoid materialor equipment damage.
Instructions and lists detailing step-by-step actions forgiven situations can be recognised via bullet
points, e.g.:
•Insert the welding current lead socketinto the relevantsocketand lock.

For your safety
Explanation of icons
099-002044-EW501
14.10.2022
7
2.2 Explanationoficons
Symbol
Description
Symbol
Description
Indicates technical aspects which the
usermust observe.
Activateand release/ Tap / Tip
Switch offmachine
Release
Switch on machine
Press and hold
Incorrect / Invalid
Switch
Correct / Valid
Turn
Input
Numerical value –adjustable
Navigation
Signal lightlights up in green
Output
Signal lightflashesgreen
Time representation (e.g.:wait 4 s / ac-
tuate)
Signal lightlights up in red
Interruption in the menu display (other
setting options possible)
Signal lightflashesred
Tool not required/do not use
Signal lightlights up in blue
Tool required/use
Signal lightflashes blue

For your safety
Safetyinstructions
8
099-002044-EW501
14.10.2022
2.3 Safetyinstructions
WARNING
Risk of accidents due to non-compliance with the safety instructions!
Non-compliance with the safety instructions can be fatal!
•Carefully read the safety instructions in this manual!
•Observe the accidentprevention regulations and any regionalregulations!
•Inform persons in the working area that they mustcomply with the regulations!
Risk of injury from electrical voltage!
Voltages can cause potentially fatal electric shocks and burns on contact. Evenlow vol-
tages can cause a shock and lead to accidents.
•Never touch live components such as welding current sockets orstick, tungsten or wire
electrodes!
•Always place torchesand electrode holdersonan insulated surface!
•Wear the full personal protective equipment (depending on the application)!
•The machine may only be opened by qualified personnel!
•The device must not be used to defrost pipes!
Hazard when interconnectingmultiple power sources!
If a number of power sources are to be connected inparallel or inseries,only a techni-
cal specialistmay interconnect the sources as per standard IEC 60974-9:2010:Installa-
tion and use and German Accident PreventionRegulationBVG D1 (formerlyVBG 15)or
country-specific regulations.
Before commencingarc welding, a test must verify that the equipment cannot exceed
the maximum permitted opencircuit voltage.
•Only qualified personnel mayconnectthe machine.
•Whentaking individual power sourcesout of operation, all mainsand weldingcurrent leads
must be safely disconnected fromthe welding systemas a whole. (Hazard due to reverse
polarity voltage!)
•Do not interconnect welding machines with pole reversing switch (PWSseries) or machines
for AC welding since a minor error in operation can cause the welding voltagesto be com-
bined, whichis not permitted.
Risk of injury due to radiationor heat!
Arc radiation can lead to skin and eye injuries.
Contactwith hotworkpieces and sparks can leadto burns.
•Use hand shield or welding helmetwith the appropriate safety level(dependson the appli-
cation).
•Wear dry protective clothing (e.g.hand shield,gloves,etc.) in accordancewith
the applicable regulations of your country.
•Persons who are not directly involved should be protected with a welding curtain or suitable
safety screen against radiation and the risk of blinding!

For your safety
Safetyinstructions
099-002044-EW501
14.10.2022
9
WARNING
Risk of injury due to improper clothing!
During arc welding, radiation, heat and voltage are sourcesof risk that cannot be
avoided. The user has to be equipped with the complete personalprotectiveequipment
at all times. The protective equipment has to include:
•Respiratory protection againsthazardoussubstances andmixtures (fumesand vapours);
otherwise implement suitable measures such as extraction facilities.
•Welding helmetwith properprotection against ionizing radiation (IR and UV radiation)and
heat.
•Dry welding clothing (shoes, gloves and bodyprotection) to protect against warm environ-
ments with conditions comparable to ambient temperatures of 100 °Cor higher and arcing
and work on live components.
•Hearing protection against harming noise.
Explosion risk!
Apparently harmless substances inclosed containers may generate excessive pressure
when heated.
•Move containers with inflammable or explosive liquids away fromthe working area!
•Never heat explosive liquids, dusts or gases by welding or cutting!
Fire hazard!
Due to the high temperatures, sparks,glowing parts and hotslagthatoccur during
welding, there is a risk of flames.
•Be watchful of potential sources of fire in the working area!
•Do not carryany easilyinflammableobjects, e.g. matches or lighters.
•Ensure suitable fire extinguishersare availablein the working area!
•Thoroughly remove any residue of flammable materialsfrom the workpiece priorto starting
to weld.
•Only further process workpieces after theyhave cooled down. Do not allow themto contact
any flammable materials!

For your safety
Safetyinstructions
10
099-002044-EW501
14.10.2022
CAUTION
Smoke and gases!
Smoke and gases can lead to breathing difficultiesandpoisoning.In addition,solvent
vapour (chlorinated hydrocarbon) may be convertedinto poisonous phosgene due to
the ultraviolet radiationof the arc!
•Ensure that there is sufficient freshair!
•Keep solventvapouraway fromthearc beam field!
•Wear suitable breathing apparatus if appropriate!
Noise exposure!
Noise exceeding 70 dBA can causepermanent hearing damage!
•Wear suitable ear protection!
•Persons located within the working area must wear suitable earprotection!
According to IEC 60974-10, weldingmachines are divided into two classes of
electromagnetic compatibility (the EMC class can be found in the Technical
data) > see 8 chapter:
Class A machines are not intended for use in residential areas where the power supply comes
from the low-voltage public mainsnetwork. When ensuring the electromagnetic compatibility of
class A machines, difficultiescan arise in these areasdue to interference not onlyin the supply
lines but also in the formof radiated interference.
Class B machines fulfil the EMC requirementsinindustrial aswell as residential areas, inclu-
ding residential areas connected to the low-voltage public mainsnetwork.
Setting up and operating
When operating arc welding systems, in some cases, electro-magnetic interference can occur
although all of the welding machines comply with the emission limits specified in the standard.
The user is responsible for any interference caused by welding.
In orderto evaluate any possible problems with electromagnetic compatibility in the
surrounding area, the user mustconsider the following: (see also EN 60974-10 AppendixA)
•Mains, control,signaland telecommunication lines
•Radios and televisions
•Computers and other controlsystems
•Safetyequipment
•The health of neighbouring persons, especially if they have a pacemaker or weara hearing
aid
•Calibration and measuring equipment
•The immunity to interference of other equipment in the surrounding area
•The time of day at whichthe welding workmust be carried out
Recommendationsfor reducing interference emission
•Mains connection, e.g.additional mainsfilteror shielding with a metal tube
•Maintenance of the arc welding system
•Welding leads should be as shortas possible and run closely together along the ground
•Potential equalization
•Earthing of the workpiece. In cases where it is not possibleto earth the workpiece directly,
it should be connected by meansof suitable capacitors.
•Shielding from other equipment in the surrounding area or the entire welding system
Electromagnetic fields!
The power source may cause electricalor electromagnetic fieldsto be producedwhich
could affect the correct functioning of electronic equipment such as IT or CNC devices,
telecommunication lines, power cables,signallines and pacemakers.
•Observe the maintenance instructions > see 6.2 chapter!
•Unwind welding leadscompletely!
•Shield devices or equipment sensitive to radiationaccordingly!
•The correct functioning of pacemakers may be affected (obtain advice from a doctor if nec-
essary).

For your safety
Transport and installation
099-002044-EW501
14.10.2022
11
CAUTION
Obligations of the operator!
The respective national directives and laws must be complied with when operating the
machine!
•Implementationof national legislation relating to framework directive 89/391/EEC on the int-
roduction of measures to encourage improvements in the safety and health of workersat
work and associated individual guidelines.
•In particular, directive 89/655/EEC concerning the minimum safety and health requirements
for the use of work equipment by workers atwork.
•The regulations applicable to occupationalsafety and accident prevention in the country
concerned.
•Setting up and operating the machine as per IEC 60974.-9.
•Brief the user on safety-conscious workpractices on a regularbasis.
•Regularly inspect the machine as per IEC 60974.-4.
The manufacturer's warranty becomes void if non-genuineparts are used!
•Only use system components and options (power sources, welding torches, electrode hold-
ers, remote controls, spareparts and replacement parts, etc.) from our range of products!
•Only insertand lock accessory components into the relevant connection socketwhen the ma-
chine is switched off.
Requirements for connection to the public mains network
High-performance machines can influence the mains quality by taking current from the mains
network. For some types of machines, connectionrestrictions or requirements relating to the
maximum possible line impedance or the necessary minimum supply capacity at the interface
with the public network (Point of Common Coupling, PCC) can thereforeapply.In this respect,
attention is also drawn to the machines' technical data.In this case,it is the responsibility ofthe
operator, where necessary in consultation with the mains networkoperator,to ensure that the
machine can be connected.
2.4 Transportandinstallation
WARNING
Risk of injury due to improper handlingof shielding gas cylinders!
Improper handling andinsufficient securing of shielding gascylinders can cause seri-
ous injuries!
•Observe the instructions fromthe gas manufacturer and any relevant regulations concern-
ing the use of compressed air!
•Do not attach any element to the shielding gascylinder valve!
•Prevent the shielding gascylinder fromheating up.

For your safety
Transport and installation
12
099-002044-EW501
14.10.2022
CAUTION
Risk of accidents due to supply lines!
During transport, attached supply lines (mains leads, controlcables,etc.) can cause
risks, e.g. by causingconnectedmachines to tip overand injure persons!
•Disconnect all supplylines before transport!
Risk of tipping!
There is a risk of the machine tipping over andinjuring persons or being damaged itself
during movement and set up.Tilt resistance is guaranteed upto an angle of 10° (ac-
cording to IEC 60974-1).
•Set up and transport the machine on level, solid ground.
•Secure add-on parts using suitable equipment.
Risk of accidents due to incorrectly installedleads!
Incorrectly installed leads (mains, control andweldingleads or intermediate hose pack-
ages ) can present a tripping hazard.
•Lay the supply lines flat on the floor(avoid loops).
•Avoid laying the leads on passage ways.
Risk of injury from heated coolant and its connections!
The coolant used and its connection or connection points can heat up significantly
during operation(water-cooled version). When openingthe coolant circuit, escaping
coolant may cause scalding.
•Open the coolant circuitonly when the power source or cooling unit is switched off!
•Wear proper protective equipment(protective gloves)!
•Seal open connections of the hose leadswith suitable plugs.
The units are designed for operation inan upright position!
Operation in non-permissible positions can cause equipment damage.
•Only transport and operatein an upright position!
Accessory components and the power source itself can be damaged by incorrect connection!
•Only insertand lock accessory components into the relevant connection socket when the
machine is switched off.
•Comprehensive descriptions can be found inthe operating instructions for the relevant ac-
cessory components.
•Accessory components are detected automatically after the power source is switched on.
Protective dust caps protect the connectionsockets and therefore the machine against dirt and
damage.
•The protective dust cap must be fitted if there is no accessory componentbeing operated on
that connection.
•The cap must be replaced if faulty or if lost!

Intended use
Applications
099-002044-EW501
14.10.2022
13
3 Intended use
WARNING
Hazards due to improper usage!
The machine has been constructed to the state of the art and any regulations andstand-
ards applicable for use in industry andtrade. It may onlybe used for the welding proce-
dures indicated at the rating plate. Hazards may arise for persons,animals andmaterial
objects if the equipment is not used correctly. No liability is accepted for any damages
arising from improper usage!
•The equipmentmust onlybe used in line with itsdesignated purpose and bytrained or
expert personnel!
•Do not improperly modify orconvert theequipment!
3.1 Applications
Arc welding system forMMA DC welding withpole reversing switch for quick polarity switching and, as
secondary process, TIG DC welding with lift arc (contact ignition).
3.2 Overviewof devicetypes
3.2.1 Cellulose electrode types (cel)
CEL device typesare equipped with special Arcforce characteristics.
These device types facilitate welding with cellulose electrode typeswhich is safe for vertical-down
welding, especially in the loweroutput range.
3.2.2 Pole reversing switch (pws)
With PWS device types,the polarity of the welding current connections (pole reversal) can be changed
using a changeoverswitch on the machine or on the remote control.
Useful function with frequently changing electrode typeswithout time-consuming reconnection of the
welding current connections (also directly atthe operating point, in combination with a PWSremote con-
trol).
3.2.3 Voltage reducing device
Only machine variants with the (VRD/SVRD/AUS/RU) code are equipped with a voltage reduction device
(VRD). The VRD is used for increased safety,especially in hazardous environments such as shipbuilding,
pipe construction or mining.
A VRD is mandatory in somecountries and required by many on-site safety instructions for power
sources.
The VRD > see 4.2 chapter signal light is illuminated when the voltage reduction device is operating wit-
hout fault and the output voltage isreduced to a value specified in the relevantstandard (see technical
data > see 8 chapter).

Intended use
Documents which also apply
14
099-002044-EW501
14.10.2022
3.3 Documentswhichalsoapply
3.3.1 Warranty
For more information referto the "Warranty registration" brochure supplied and our information regarding
warranty, maintenanceand testing at www.ewm-group.com!
3.3.2 Declaration of Conformity
This product correspondsin its design and construction to theEU directives listed in the decla-
ration. The product comeswith a relevantdeclaration of conformityin the original.
The manufacturer recommends carrying outthe safety inspection according to nationaland in-
ternational standards and guidelinesevery 12 months.
3.3.3 Welding in environments with increased electrical hazards
Power sources with thismarking can be used for welding in an environment with increased
electrical hazard (e.g. boilers).Forthis purpose, appropriate national orinternational regulations
must be followed.The power source must not be placed in the danger zone!
3.3.4 Service documents (spare parts and circuit diagrams)
WARNING
No improper repairsand modifications!
To prevent injuries and damage to the machine, only competent personnel(authorised
service personnel) are allowed to repair ormodify the machine.
Unauthorised manipulations will invalidate the warranty!
•Instruct competent personnel (authorised service personnel) to repair the machine.
Original copies of the circuit diagrams are enclosed with the unit.
Spare parts can be obtained from the relevant authorised dealer.
3.3.5 Calibration/Validation
An original certificate is enclosed with the product. The manufacturer recommends calibration /validation
at intervals of 12 months.

Intended use
Documents which also apply
099-002044-EW501
14.10.2022
15
3.3.6 Part of the complete documentation
This documentis part of the complete documentation andvalidonly incombination withall other
parts of these instructions! Read and observe the operating instructions for allsystem
components, especially the safety instructions!
The illustration showsa general example ofa welding system.
Figure 3-1
Item
Documentation
A.1
Powersource
A.2
Electrode holder/welding torch
A.3
Remote control
A
Completedocumentation

Machine description –quick overview
Front view/ rearview
16
099-002044-EW501
14.10.2022
4 Machine description – quick overview
4.1 Front view/ rear view
Figure 4-1

Machine description –quick overview
Front view/ rearview
099-002044-EW501
14.10.2022
17
Item
Symbol
Description 0
1
Carrying strap > see 5.1.4.1 chapter
2
Carrying handle
3
Machine control > see 4.2 chapter
4
Cooling air inlet
5
Connection socket, 19-pole
Remote control connection
6
Welding current polarity switch > see 5.2.2.2 chapter
Switch for quick switching of welding current polarity.
"+" welding current polarity at connection socket electrode holder.
"-" welding current polarity at connection socketelectrode holder.
7
Connection socket, electrode holder
The welding current polarity (“+” or “-”) are based on the setting of the “Welding current
polarity changeover switch”.
8
Connection socket, workpiece lead
The welding current polarity (“+” or “-”) are based on the setting of the “Welding current
polarity changeover switch".
9
Main Switch
Switching the machine on or off.
10
Mains connection cable > see 5.1.7 chapter
11
Cooling air outlet
12
F4
Fuse
Solenoid switch pole reversal fuse
13
F5
Fuse
Solenoid switch pole reversal fuse
14
Machine feet

Machine description –quick overview
Machine control –Operating elements
18
099-002044-EW501
14.10.2022
4.2 Machinecontrol–Operatingelements
The parameters and their setting rangesare described in chapter Parameters Overview - Setting Ran-
ges > see 10.1 chapter.
Figure 4-2
Item
Symbol
Description 0
1
Welding data display (3-digit)
Displays the welding parameters and the corresponding values > see 4.2.1 chapter
2
Collective interference signal light
Forerror messages, > see 7 chapter
3
Excess temperature signallight
In case of excess temperature, temperature monitorsde-activate the power unit,and
the excess temperature control lamp comeson.Once the machine has cooled down,
welding can continue without any further measures.
4
sec
Hotstart time signal light
5
AMP%
Hotstart current signal light
6
AMP
Main current signal light
Imin to Imax (1 A increments)
7
Welding parameter setting rotary transducer
Setting of welding current and other welding parameter and their values
8
VRD
Voltage reduction device (VRD) signal light > see 5.6 chapter
9
Select welding parameters button
This button isused to select the welding parametersdepending on the welding process
and operating mode used.
10
“Arcforce” button (welding characteristics) according to electrode type
11
Welding procedure push-button
---------- TIG welding
--------- MMA welding

Machine description –quick overview
Machine control –Operating elements
099-002044-EW501
14.10.2022
19
Item
Symbol
Description 0
12
Switch display button
AMP-----Welding current display
VOLT----Welding voltage display
4.2.1 Welding data display
All relevant welding parameters with their valuesare shown depending on the welding procedure selected
and the associated functions. Machine parameters and errorcodes are shownas well in a unique man-
ner. The meaning of the parameters and values shown is explained in the relevantchapterfor the func-
tion.
4.2.2 Welding current actual value display
The welding current in the welding datadisplay isdisplayed as nominal value at the factory. The welding
current display can be determined by switching the parameter to actualvalues in the respective ex-
pert menu:
MMA welding
TIG welding
•In idle mode (when no welding currentis flowing) the nominalvalue isdisplayed
•If welding current is flowing, the welding data display is switched to the actual value
•After welding, the nominal value is displayed again

Design and function
Transport and installation
20
099-002044-EW501
14.10.2022
5 Design and function
5.1 Transportandinstallation
WARNING
Risk of accident due to impropertransport of machines that must not be lifted!
Do not liftor suspend the machine! The machine can drop and causeinjuries!The
handles, straps or brackets are suitable for transport by handonly!
•The machine must not be suspended or lifted using a crane.
The units are designed for operation inan upright position!
Operation in non-permissible positions can cause equipment damage.
•Only transport and operatein an upright position!
Accessory components and the power source itself can be damaged by incorrect connection!
•Only insertand lock accessory components into the relevant connection socketwhen the
machine is switched off.
•Comprehensive descriptions can be found inthe operating instructions for the relevant ac-
cessory components.
•Accessory components are detected automatically after the power source is switched on.
5.1.1 Machine cooling
Insufficientventilation resultsin a reduction in performance and equipmentdamage.
•Observe the ambient conditions!
•Keep the cooling air inlet and outlet clear!
•Observe the minimumdistanceof 0.5 m fromobstacles!
5.1.2 Workpiece lead, general
CAUTION
Risk of burning due to incorrect welding current connection!
If the welding current plugs (machine connections) are not locked or if the workpiece
connection is contaminated(paint,corrosion), these connections and leads can heat up
and cause burns when touched!
•Check welding current connectionson a daily basis and lock by turning to the right when
necessary.
•Clean workpiece connection thoroughlyand secure properly. Do not use structuralparts of
the workpiece as welding current return lead!
