Exhibitor's Handbook ZOOM-FLX-OD-BB User manual

Zoom Flex Outdoor Billboard
ZOOM-FLX-OD-BB
The Zoom™ Flex Outdoor Billboard is a strong, flexible billboard perfect for
outdoor promotions and events. Features include sturdy base plates on the inside of
the unit and tube frame construction with flexible fiberglass poles near the top,
which allow the display to move with the wind. Add sand bags for added stability.
dimensions:
- Sturdy and flexible outdoor billboard
- Indoor / outdoor use
- Tubular frame / fiberglass flexible poles
- Choice of single or double-sided graphics
features and benefits:
- Kit includes: frame, dye-sublimated graphic
- One year hardware warranty against
manufacturer defects
- Wind Rating: 14 MPH
We are continually improving and modifying our product range and reserve the right to vary the specifications without prior notice.
All dimensions and weights quoted are approximate and we accept no responsibility for variance. E&OE. See Graphic Templates
for graphic bleed specifications.
08/27/2019
Packing case(s):
1 OCB-2
34 - 55”l x 19”h x 8”d
864 - 1397mm(l) x 483mm(h) x 204mm(d)
Approximate total shipping weight:
37 lbs / 17 kg
Shipping
Hardware Graphic
Assembled unit:
106”w x 78.74”h x 32”d
2693mm(w) x 2000mm(h) x 813mm(d)
Approximate weight:
23 lbs / 11 kg
Refer to related graphic template for more
information.
Six month warranty.
Visit:
https://www.theexhibitorshandbook.com/
download-graphic-templates
Graphic material:
Dye-sublimation zipper pillowcase fabric
When included in a larger kit, a different
packaging solution will be listed to
accommodate all contents of the kit.
Individual packaging no longer provided.
Washing Instructions:
Cold water/Gentle Cycle
Hang Dry/Graphic will shrink in dryer
additional information:
This product may include the following
materials for recycle:
aluminum, select wood, fabric, cardboard,
paper, steel, and plastics.
2 person assembly recommended:

Tools, Components, & Connectors
ZOOM-FLX-OD-BB-FT x4 ZOOM-FLX-OD-BB-ASM-1 x2
ZOOM-FLX-OD-BB-ROD-A x2ZOOM-FLX-OD-BB-ASM-4 x2
ZOOM-FLX-OD-BB-ROD-C x4
ZOOM-FLX-OD-BB-ASM-2 x2
ZOOM-FLX-OD-BB-T3 x2
ZOOM-FLX-OD-BB-ASM-5 x2
ZOOM-FLX-OD-BB-T1 x2
Included In Your Kit
ZOOM-FLX-OD-BB-ASM-5 x2
ZOOM-FLX-OD-BB-I-BG x2
ZOOM-FLX-OD-BB-STAKE-KIT x8 ZOOM-FLX-OD-BB-H x1
ZOOM-FLX-OD-BB-CENTER CORD
ZOOM-FLX-OD-BB-ROD-D x2
2
Stake replacement
kit does not come
with hammer

Graphics
ZOOM-FLEX-OD-BB-G X1
Included In Your Kit
3

Exploded View
ZOOM-FLX-OD-BB
4
ZOOM-FLX-OD-BB-ROD-A

Labeling Diagram
ZOOM-FLX-OD-BB
5

Reference the exploded view and
labeling diagram to assemble
the right bottom base section
(section 1).
Once you have connected the
tubes and the feet slide the
canvas graphic onto the tubes of
the base via the pole pockets.
Reference the exploded view and
labeling diagram to assemble
the center section of the base
(section 3).
Assemble the base by attaching
all 3 sections together.
Repeat step 1 to assemble the
left bottom base section (section
2).
Step 1.
Step 3.
Step 2.
Kit Assembly
Step by Step
6

Gather the 6 Rod C’s and insert
them into the tubes that are
connected to the base of the
frame.
Assemble the top section of
fiber rod assemblies 1 & 2 along
with the 2 individual rod A’s in
the sequence shown connecting
them to the bottom rods (Rod
C’s) during this sequence.
Step 4.
Step 5.
Kit Assembly
Step by Step
7

8
Be sure to insert the top of the
middle rod through the open
loophole as shown in the images.
Connect Rod D’s to the middle
Rod C’s and the top assembly on
both sides as shown.
Step 6.
Attach the waterproof bags to
the two canvas sections via the
buckle straps.
Step 7.
Each bag can only hold up to
50lbs. max or half full. Any
heavier could damage frame
Slide the graphic over the frame.
Step 8.

Kit Assembly
Step by Step
9
Once graphic is in place, pull
hoop straps down and attach to
hook on base foot.
When zipping the bottom of the
graphic closed, make sure the
foot on the back side has been
placed through the pre-made
hole in the graphic before pulling
the graphic to the front.
Step 10.
Lay graphic over top of frame
then slowly pull down frame.
Attach hook and loop strap as
shown in picture below. Make
sure to leave the straps loose. 2
people suggested for this step to
prevent damaging graphic.
Step 9.
STRAPS

10
Kit Assembly
Step by Step
Once in place close the graphic
flap with the zipper.
Setup is complete.
Step 11.
Push/Hammer in stakes through
base foot holes to secure in
place.
Step 12. (Optional)

Connection Method 1: TC-30-C Connection Method 2: PMFC2 / PHFC2
First, gather needed components for assembly. Next press button on TC-30-C, then insert tube into
place. Once in place button should snap in place.
First, press button to insert the swage tube into the proper tube. The button will snap in place.
Connection is complete.
Connection Methods
