Exit InTerra User manual

InTerra Round
InTerra
Trampoline
retain for future reference
User manual
Gebrauchsanweisung
Gebruikshandleiding
Mode d’emploi

2
InTerra
Trampolines

3
InTerra
Trampolines
English 4
Deutsch 22
Nederlands 40
Français 58

InTerra
Trampolines
4
1.0 Introduction
Congratulations on choosing a EXIT InTerra Trampoline!
Have fun, be active and play outdoors......
That’s what keeps driving us to develop innovative, quality toys for cool kids.
We do everything possible to develop safe products for children. As our products are
classed as toys, we comply with the toughest consumer safety regulations. Before
launching our products onto the market, we have independent tests carried out for
certication. We also continuously test our production runs and periodically have
independent tests performed again as a further check. Only products which live up to
the highest EXIT Toys standard are marked with and recognized by the EXIT-brand.
“We want to thank you for your custom and your condence in this product. We’re
sure your kids will have as much fun as we did during development. Being open-
minded, we really appreciate all comments and ideas which will help us improve our
products or develop new ones. You are invited to send your ideas to us at info@exit-
toys.com”
Please visit www.exittoys.com and discover more cool new products.
The EXIT Toys team

InTerra
Trampolines
5
2.0 Guidelines for safe use
Using your product as instructed in this manual will eliminate virtually all hazards.
However, please bear in mind that children have a natural urge to play and that this
may lead to unforeseen dangerous situations for which the manufacturer cannot be
held responsible. Teach your children how to use the product and point out possible
dangers to them.
Before assembling and using the product, please read and observe these
main warnings:
Max. User weight:•8ft: 90kg. 10ft: 100 kg.
12ft: 110kg. 14ft: 120 kg.
WARNING
To avoid serious injury:
In case of missing or broken parts, please contact place of
purchase for assistance.
•
Read and understand the manual before use.
•
The trampoline is to be assembled by an adult prior to use.
•
WARNING: Do not perform summersaults or other difficult jumps!
•
WARNING: Empty your pockets before use of the trampoline!
•
WARNING: Only for domestic use
•
WARNING: CHOKING HAZARD! - Small parts.
Not for Children under 3 years old.
•
WARNING: Only one user at a time; danger of collision!
•
Continuous adult supervision is required.•
Don’t use the trampoline when it’s wet.•
We are not liable for any injuries that may occur when
using the trampoline.
•

6
InTerra
Trampolines
2.1 Warnings for safe use:
• BEFORE YOU BEGIN USING YOUR TRAMPOLINE: Read and understand the infor-
mation provided in this manual. As with all physical sports and activities there is
the risk of participants receiving an injury. To ensure your future enjoyment and
the prevention of injury, be sure to follow appropriate safety rules and tips.
• ALWAYS CONSULT A DOCTOR/PHYSICIAN BEFORE PERFORMING ANY KIND OF
PHYSICAL ACTIVITY.
• ALWAYS CHECK YOUR TRAMPOLINE BEFORE USE, PAYING SPECIFIC ATTENTION
TO ALL THE BOLTS, JUMP MAT AND PADS POSITION. DON’T USE IF ANY PARTS
ARE MISSING OR LOOK LIKE THEY SHOW WEAR AND TEAR.
• ALWAYS ENSURE THAT THE TRAMPOLINE IS USED BY ONLY ONE PERSON AT A
TIME.
• ALWAYS ENSURE THAT WHENEVER THE TRAMPOLINE IS USED BY ANYONE AT
ANY SKILL LEVEL THAT DO SO UNDER SUPERVISION.
• Stop exercising immediately should you feel unwell or if you feel pain in your
joints and muscles. Dizziness is a sign of fatigue and you should stop bouncing
and lay down on the ground should you feel dizzy.
• When using this trampoline ensure appropriate clothing is worn, preferably
sports wear and socks .NEVER WEAR SHOES ON THE MAT.
• Please be warned that trampoline is spring based and will allow the user to jump
to a greater height than that on the ground, so please bear this in mind and
ensure that you are comfortable bouncing at low heights rst.
• Proper assembly, care and maintenance of product, safety tips, warnings, and
proper techniques for jumping on your trampoline are included in this manual for
your safety and an extended product life span. All users and supervisors should
therefore familiarize themselves with these instructions. Anybody who chooses
to use the trampoline must be aware of their own limitations with regards to
performing skills on this trampoline.
• Trampoline should be assembled on grass or BSI approved safety matting.

7
InTerra
Trampolines
2.2 Use of the trampoline
INITIALLY, you should get accustomed to your trampoline and understand how much
spring is in each bounce .The focus at this point should be body position and tech-
nique until each skill can be completed with ease and control.

• BEFORE YOU TRY TO JUMP TOO HIGH the technique
for stopping should be learnt as this will help prevent
injury should you feel you are jumping out of control.
• As the user lands on the bed, the knees should be bent
so that they stop and absorb the spring in the mat. The
position is shown in the image to the left. Arms are
held out for increased level of balance.
• This skill is used when the trampoline user wishes to
stop bouncing on the trampoline due to fatigue, loss of
control, etc.
SOMERSAULTS (FLIPS): DO NOT PERFORM somersaults of any type (backwards or
forwards)on this trampoline. If you make a mistake when trying to perform a somersault
,you could land on your head or neck.This will increase your chances of your neck or
back being broken ,which could result in death or paralysis
FOREIGN OBJECTS : DO NOT hold any foreign objects in your hand and DO NOT place
any objects on the trampoline while in use. DO NOT place the trampoline under over-
hanging objects like tree branches, wires, etc as these will increase your chances of
being injured.
POOR MAINTENANCE OF TRAMPOLINE: A trampoline in poor condition will increase
your risk of being injured. Please inspect the trampoline before each use for bent steel
tubes, torn mat, loose or broken springs and overall stability of the trampoline.
WEATHER CONDITIONS: Please be aware of the weather conditions when using the
trampoline. Don’t use the trampoline when it’s wet. If it is too windy, the user could lose
control.

8
InTerra
Trampolines
2.3 Tips to reduce the risk of accidents
In order to reduce the risk of accident the “TRAMPOLINE USER” should:
• Always remain in control of their jumps and body position at all times.
• Not attempt to perform skills that are beyond their own level of competence.
• Read and understand the jump by taking off and landing in the middle of the
trampoline.
• Always control their jump by taking off and landing in the middle of the trampo-
line.
• Always jump vertically and refrain from bouncing towards the springs in any
direction.
• Always consult a professionally certied trampoline instructor before attempting
anything beyond basic techniques.
In order to reduce the risk of accident the “SUPERVISOR” should:
• Fully understand and enforce all the safety rules and guidelines.
• Advise the trampoline user and provide knowledge in what they are doing right
and wrong to ensure the safety of trampoline user.
• Be aware and advise the trampoline user of all the safety warnings.
IMPORTANT: If the Trampoline can not be supervised there should be a
method for securing it and preventing anyone from using the product until
supervision is available.

9
InTerra
Trampolines
2.4 Trampoline Safety Instructions
ADVISORY PRECAUTIONS WHILST USING THE TRAMPOLINE
• Do not use trampoline if you have consumed alcohol or narcotic substances
• Never jump onto or off the trampoline and never use the trampoline as a means
to bounce onto or into another object.
• Always learn the basic bounce and master each type of bounce before trying
more difcult types of bounces .Review the basic skills section to learn how to do
the basics.
• To stop your bounce, ex your knees when you land on your feet.
• Always be in control when you are bouncing on the trampoline. A controlled jump
is when you land at the same spot that you took off from. If at any time you feel
out of control, stop bouncing immediately.
• Do not jump or bounce for prolonged periods of time of too high for a number of
jumps. Keep your eyes on the mat to maintain control. If you do not, you could
lose your balance.
• Never have more than 1 person on the trampoline at any one time.
ADVISORY PRECAUTIONS WHILST SUPERVISING TRAMPOLINE
IMPORTANT: Familiarise yourself with the basic jumps and safety rules .To prevent
and reduce the risk of injuries, ensure that all safety rules are enforced and the new
users learn the basic bounces before trying more advanced techniques .
• ALL USERS need to be supervised, regardless of skill level or age.
• Never use the trampoline when it is wet, damaged, dirty or wore out. The tram-
poline should be inspected before use.
• Keep all objects that could interfere during use away from the trampoline at all
times. Be aware of what is overhead, underneath and around the trampoline.
• To prevent unsupervised and unauthorized use, the trampoline should be secured
at all time.

10
InTerra
Trampolines
2.5 Accident classication & identication
USE OF ALCOHOL OR DRUGS:
DO NOT consume any alcohol or take any drugs (this includes medication that could
affect the users co-ordination) when using this trampoline. This is considered highly
dangerous since these foreign substances impair your judgements, reaction time and
overall physical co-ordination.
MULTIPLE USERS:
If you have multiple users (more than one person on the trampoline at any one
time), you increase the chance of being injured. Injuries can occur when you y off
the trampoline, lose control, collide with other jumper(s), or land on the springs.
STRIKING THE SPRING FRAME:
When playing on the trampoline, STAY in the centre of the trampoline mat. This will
reduce the risk of being injured by landing on the spring frame. Always keep the
frame pads covering the frame of the trampoline. DO NOT jump or step onto the
frame pad directly since it is not intended to support the weight of a person.
LOSS OF CONTROL:
DO NOT try difcult maneuvers until you have mastered the basics. If you do not fol-
low these guidelines, you increase the risk of someone being injured.

11
InTerra
Trampolines
3.0 Trampoline techniques
Basic Skills
BASIC SKILL 1: The basic bounce
BASIC SKILL 2: The Knee Drop
BASIC SKILL 3: The Seat Drop
IMPORTANT: Please consult a trained trampoline instructor before attempt-
ing any more advanced skills to ensure highest possible safety levels are
• Start from a standing position, with feet shoulder
width apart head up and eyes on the trampoline
bed.
• Swing arms forward and up above head in a circu-
lar motion.
• Bring legs and feet together in mid-air position
and point toes.
• Land back on the mat with feet shoulder width
apart (same as start position).
• Why not try moving onto the next skill once com-
fortable and procient.
• Start with a low basic bounce (BASIC SKILL 1) in
the normal position.
• Land with legs out straight in front of you, with
hands either side of your hips and back straight in
a strong body position.
• Use the bounce momentum aided with a push
from hands to return to a standing position.
• Once mastered at this height try bouncing a little
higher, but remember to always stay in control of
your height.

• Start with a low basic bounce (as detailed in BA-
SIC SKILL 1).
• Land on knees shoulder width apart, keeping back
straight and a strong body position using arms out
to the side or in front to maintain balance.
• Bounce back to basic bounce position by using
bounce momentum and swinging arms above
head.
• Once mastered at this height try bouncing a little
higher, but remember to always stay in control of
your height.



12
InTerra
Trampolines
Advanced Skills
ADVANCED SKILL 1: The basic bounce
ADVANCED SKILL 2: Hands and Knees to Front Drop
ADVANCED SKILL 3: The Front Drop
IMPORTANT: Should you wish to progress any further and learn more ad-
vanced techniques for trampoline, please consult a qualied and registered
instructor.
• Start with a low basic bounce (BASIC SKILL1) in
the normal position.
• Land on your hands and knees at the same time,
ensure that back is horizontal to the bounce mat
and hands & legs are shoulder width apart also.
• Use the momentum of bounce and push off hands
to regain the standing position.
• Once mastered at this height try bouncing a little
higher, but remember to always stay in control of
your height.
• Try moving onto the next skill once comfortable
and procient.
• Start with a low basic bounce (BASIC SKILL 1) in
the normal position.
• Maintain strong body position with back horizontal
to mat and straighten legs behind and fold arms in
front of face in mid-air ready to land on the mat in
a lying down position.
• Ensure the landing is done with all of body touch-
ing the mat at the same time.
• Push off hands and recover the standing position.
• Once mastered at this height try bouncing a little
higher, but remember to always stay in control of
your height.
• Land on your hands and knees at the same time,
ensure the back is horizontal to the bounce mat
and hands & legs are shoulder width apart also.
• Maintain strong body position with back horizontal
to mat and straighten legs behind and fold arms in
front of face in mid-air ready to land on the mat in
a lying down position.
• Ensure the landing is done with all of body touch-
ing the mat at same time.
• Push off hands and recover the standing position.
• Once mastered at this height try bouncing a little
higher, but remember to always stay in control
of your height . Trying moving onto the next skill
once comfortable and procient.




13
InTerra
Trampolines
4.0 General Information
• It is not necessary to break-down the trampoline during winter.
• Self-securing nuts and screws are suitable only for one time setting-up, and
must be replaced after breakdown of the trampoline and/or safetynet.
• It is recommended to place the trampolines on a at and level surface with at
least 2 m distance to other superstructures, or barriers, e.g. fence, garage,
house, tree branches, washing lines, or electrical cables.
• The trampoline shall not be placed over hard surfaces like asphalt, concrete etc.
• Exchange defective parts according to the supplier’s recommendation.
• Changes to the trampoline (e.g. addition of an accessory) must be done accord-
ing to the supplier’s instruction.
5.0 Trampoline Assembly
STEP BY STEP CONSTRUCTION
Only assemble by adult.
To assemble this trampoline all you need is our special spring loading tool provided
with this product. During periods of non-use, this trampoline can be easily disas-
sembled and stored. Please read the assembly instructions before beginning to
assemble the product.
Please refer to the table for part descriptions and numbers. The assembly instruc-
tion use these descriptions and numbers as reference .
Make sure you have all parts listed. If you are missing any parts, please contact
place of purchase.
Please use gloves to protect your hands from pinch points during assembly.
When you are ready to start, make sure that you have plenty of space and a
clean dry area for assembly.

14
InTerra
Trampolines
Parts list
Part.Nr. Description 8ft 10ft 12ft 14ft
1 Top tube with Socket 8 8 8 8
2 Leg 4 4 4 4
3 Anchor tube 4 4 4 4
4 Bolt M6x45mm 8 8 8 8
5 Nut M6 8 8 8 8
6 Mat 1 1 1 1
7 Spring 56 64 72 88
8Pad 1 1 1 1
9 Ground plug 4 4 4 4
10 Washer M6 8 8 8 8
11 Stake 16 16 16 16
12 Tools 1 set 1 set 1 set 1 set
13 Warning label 1 1 1 1
Enclosed are the current specications and product features available at time of printing, however, changes may
be made in equipment, availability, specications and features without notice.
(2)
(9)
(7)
(6) (8)
(1)
(4) (5)
(11) (13)(12)(10)
(3)

15
InTerra
Trampolines
STEP 1
Before assembling your trampoline,
dig a pit which suit for your trampo-
line, please refer to the table 1 for
the further information.
STEP 2
Lay two Top Tubes (1) with T-joint on
the ground in the positions as shown.
Make sure the Top Tubes are turned
so the small holes (spring holes) are
facing the ground.
Insert one end of the Top tube (1)
with T-joint into the other Top tube(1)
with T-joint as shown .
STEP 3
Insert the leg(2) into the T-joint
as shown, secure with M6 X45mm
Bolt(4) and M6 Nut(5) and M6 Wash-
er(10), the unt A will be attached.
Repeat steps 1 and 2 three additional
times to assemble three more leg
section
1
D1
Size EXIT InTerra D1øPit
ø8ft
ø10ft
ø12ft
(ø244cm)
(ø305cm)
(ø366cm)
ø194cm
ø255cm
ø316cm
min. 65cm
min. 70cm
min. 75cm
ø14ft (ø427cm) ø377cm min. 75cm
øPit
2
11
32
10 54
5
10
4
4
Large End
Small End
STEP 4
Note: This step requires two persons.
During this step, you will connect the
four assembled leg sections together.
Stand two leg sections and hold them
in the positions as shown. Slide the
large end of one of the remaining Top
Tubes onto the small end of the indi-
cated Top Tube on one of the leg sec-
tions. Insert the small end of the Top
Tube into the indicated Top Tube
with T-joint on the other leg section.
Repeat this step until all four leg sec-
tions
are connected. When this step is
completed, the frame will be fully as-
sembled and freestanding.

16
InTerra
Trampolines
WARNING!! : Please be careful where your hands and other parts of the
body are placed as the connector points and spring attachments can cre-
ate hand or body traps.
STEP 5
Caution: It is wise to wear
leather gloves while attaching
the Springs. Be careful where you
place your hands as the Springs
and frame joints can pinch.
Attach the Springs (7) as follows:
Hook one end of a Spring ( 7 ) into a
V-ring sewn on the Jump mat. Hook
a Spring tool (10) shown as the inset
drawing in next to the free end of
the Spring(7 ). Pull it by the spring
tool(12) unti l it reaches the frame.
Push the end of the Spring into a hole
in the frame. Unhook the Spring tool.
The rst spring will be attached
Follow the diagram to install each
spring in the correct order. after the
rst spring has been attached to both
mat and frame attach the second
spring to the opposite side of the
trampoline , make sure to count the
holes in the frame and V-rings of
the mat in the appropriate position.
Continue following the order until the
rst 8 springs have been attached. Be
sure to match the correct mat ring to
the correct frame hole. After the rst
8 springs have been attached con-
tinue to attach all remaining springs
to the mat and frame in any order.
Note:The spring has a large hook
which attaches to the frame and a
small hook which attaches to the
mat ring.
Safety Notice:
as you attach Springs, care-
fully count the V-rings and frame
holes. If a V-ring or a hole is
skipped, reattach the spring in
the proper position.
5
#1
#3
#2#4
#5
#7
#8
#6
7
V-ring
Frame
12
6
8ft
#1 #2 #3 #4 #5 #6 #7 #8
1 2814 42 7 21 35 49
1 3618 54 9 27 45 63
1 4422 66 11 33 55 77
12ft
1 3216 48 8 24 40 5610ft
14ft

17
InTerra
Trampolines
STEP 6
Insert the leg extension(3) into the
leg secure with the spring ball as
shown.
- mat and springs not shown -
STEP 7
Place your trampoline on the ground
and make sure the center of the
mat and pit are aligned, then sign
four points (A,B,CD) on the ground
where the leg extension(3) touch the
ground. then remove your trampo-
line.
Beat the Leg Sleeve(9) into the
ground from A,B,C,D as shown. then
place the trampoline above the pit
and insert the leg extension(3) into
the Leg sleeve(9).
Caution: Do not use the trampo-
line without the Frame Pad (8).
The Frame Pad is designed to
reduce the possibility of injuries
due to jumpers coming in contact
with the trampoline frame. If you
do not have a Frame Pad, contact
your dealer to obtain one. Prop-
erly install the Frame Pad before
using the trampoline.
6
3
3
3
3
7
A
B
9
C
D
9
3ground
ground
3
Pit
25cm
D2
Size InTerra D2
ø8ft
ø10ft
ø12ft
ø14ft
(ø244cm)
(ø305cm)
(ø366cm)
(ø427cm)
min. 85cm
min. 90cm
min. 92cm
min. 95cm

18
InTerra
Trampolines
STEP 8
Look underneath the trampoline.
Locate the straps attached to the
underside of the frame pad. Position
each outer strap so that one strap is
on each side of the frame as shown.
Tie the outside straps sewn to the
Pad Joints to each side of the frame
as shown and attach the inner straps
to the near V-rings.
Repeat this step with the remaining
straps (not shown).
Using the included plastic tie, attach
the warning label (13) to the frame
near the point where jumpers will
climb onto and off the trampoline.
STEP 9
Attach all the Stakes(11) to each slot
of the pad as shown.
Congratulations! Your trampoline is
now fully assembled (put together).
Make sure that all parts are
securely attached. Familiarize
yourself and all users with the
trampoline, with the safety pre-
cautions, use and instructional
materials, and care and mainte-
nance instructions in this manual
before using the trampoline.
8
13
Outer Straps
Frame
Inner Straps
V-ring
9
11

19
InTerra
Trampolines
6.0 CARE AND MAINTENANCE
This trampoline was designed and manufactured with quality materials and crafts-
manship. If proper care and maintenance is provided, it will provide all jumpers with
years of exercise, fun, and enjoyment as well as reduce the risk of injury. Please fol-
low the guidelines listed below:
This trampoline is designed to withhold a certain amount of weight and use. Please
make sure that only one person at any one time uses the trampoline. Jumpers should
either wear socks, gymnastics shoes, or be barefoot when using the trampoline.
Please be aware that street shoes or tennis shoes should NOT be worn while using
the trampoline. In order to prevent the trampoline mat from getting cut or damaged
please do not allow any pets onto the mat. Also, jumpers should remove all sharp
objects from their person prior to using the trampoline. Any type of sharp or pointed
objects should be kept off the trampoline mat at all times.
Maintenance instructions
It is particularly important to follow the following maintenance instructions at the beginning of
each season and periodically during the use season:
• It is necessary to determine whether all nuts and bolts are tight, and if necessary they are
tightened;
• It shall be veried that all spring-loaded connections (locking pin) are undamaged and not
move while playing;
• Any cover screws and sharp edges must be checked and replaced if necessary;
• The maintenance manual shall be kept
Always inspect the trampoline before each use for worn, abused or missing parts. A
number of conditions could arise that may increase your chances of getting injured.
Please be aware of:
• Punctures, holes, or tears in the trampoline mat
• Sagging trampoline mat
• Loose stitching or any kind of deterioration of the mat
• Bent or broken frame parts, such as the legs
• Broken, missing, or damaged springs
• Damaged, missing, or insecurely attached frame pad
• Protrusions of any types (especially sharp types) on the frame, springs, or mat
IF YOU FIND ANY OF THE PREVIOUS CONDITIONS, OR ANYTHING ELSE THAT
YOU FEEL COULD CAUSE HARM TO ANY USER, THE TRAMPOLINE SHOULD
BE DISASSEMBLED OR SECURED FROM USE UNTIL THE CONDITION(S) HAS
BEEN RESOLVED.

20
InTerra
Trampolines
7.0 Warranty
1. After the date of the purchase invoice, the owner of the EXIT Toys InTerra has a:
- 5-year warranty on the frame
- 2-year warranty on the springs
- 2-year warranty on the protective surround pad and the jump mat.
2. The warranty applies only to the material and construction defects with respect
to this product or its components.
3. The warranty becomes defunct if:
• This product is used incorrectly and/or carelessly and is used in such a way that
it does not comply with its purpose.
• This product is not assembled and maintained according to the instruction book-
let.
• Technical repairs to this product are not carried out professionally.
• Parts, which are mounted afterwards, do not comply with the technical specica-
tions of the product concerned or are mounted incorrectly.
• Defects are a result of climatic inuences such as corrosion, UV rays or normal
disintegration.
• The product is rented out or was made available to various unspecied persons
in any other manner.
4. EXIT Toys will repair or replace according to its choice all material and construc-
tion defects that have been ascertained by EXIT Toys during the warranty period.
5. The owner of the EXIT Toys Trampoline is only entitled to the warranty by pre-
senting the product for inspection at a EXIT Toys dealer. It should be handed to
the EXIT Toys dealer, accompanied by the original purchase invoice.
6. In case of material and construction defects that have been ascertained by EXIT
Toys, the product or its components will be repaired or replaced – according to
its choice – free of charge during the warranty period mentioned in Article 1.
7. If the claim for warranty is not justiable, all the costs are at the expense of the
owner.
8. This warranty cannot be transferred to third parties.
9. The trampoline is designed for personal use. It is not permitted to rent out or
place the trampoline in public areas like schools or day-care centres. The guaran-
tee and any other liabilities shall expire if the playhouse is rented out or used in
public areas.
