Exodraft SVD User manual

Your energy. Optimized.
Accessory - Quick Guide
SVD
UK |Read and save these instructions!
Disposal
Electrical and electronic equipment (EEE) often contain materials, components and substances
that may harm the environment or be hazardous to your health. Products (WEEE) marked with
the ‘crossed-out wheeled bin’ symbol should be disposed of separately from other waste at the
end of its life. Though legislation may differ from country to country we strongly advise that
electrical and electronic waste is separated from other waste and disposed of according to
national legislation to protect the environment and personnel that may come into contact with
waste.
How to use this manual
This manual has been prepared based on the specific product and
contains relevant technical information and installations guides.
Accessories and spare parts are not covered by this manual.
Please refer to the individual manuals of these components.
This installation manual does not contain any system design documentation.
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Errors and omissions excepted.
Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please read the manual before you start using the product and only use the product in
accordance with the manufacturer’s instructions. If in doubt, contact one of our specialized
dealers.
• All installations must be carried out by properly qualied personnel and in accordance
with national legislation and regulations.
• In order to avoid chimney  res, ensure that the chimney has been swept before mounting
the fan.
• Prior to servicing the product, disconnect the power and ensure that it cannot accidentally
be reconnected.
• Exodraft always recommends the use of a smoke alarm when a solid fuel replace is
installed.
Your energy. Optimized.
Product information
Exodraft vibrations dampers are an accessory kit for the Exodraft ange
system that reduces vibrations between the chimney fan and the chimney.
The Exodraft ange system has been developed for steel chimneys to ensure
that the chimney fan is placed on a at surface.
The Exodraft anges are available in various standard sizes that t most steel
chimneys.
Incorrect ring may result in problems with soot, chimney res, etc. which
might damage the product. Please check out this site for advice about lighting
and maintaining a re:
www.Exodraft.com
*For more details and informations about size and models,
see www.Exodraft.co.uk/product/accessories/ange/
3112041_SVD_UK |070623

Your energy. Optimized.
Installation
The installation is different for the different chimney fans. Fixate the ange to the chimney fan with the use of the vibration dampers supplied with the ange.
See the guides below for each type. For more information, see the FR+SVD (Flange & Vibrations dampers) manual on https://exodraft-manuals.com/
Installation - RS/RSHG model
RS og RSHG
Installation - RSV/RSVG model
RSV og GSV og RSVG
Installation - RSHT model
RS og RSHG
RS og RSHG
RS og RSHG
RS og RSHG
RS og RSHG
RHG
Installation - RHG model
