RX-MP3-Player Instruction Manual
2
Directory
1Abstract ............................................................................................................... 3
1.1 Buttons......................................................................................................... 3
1.2 Audio Files ................................................................................................... 3
2Menu ................................................................................................................... 4
2.1 Menu structure ........................................................................................... 4
2.2 Delay ........................................................................................................... 5
2.3 Ch Settings.................................................................................................. 5
2.3.1 Main Box .............................................................................................. 5
2.3.2 Ch-Controll .......................................................................................... 5
2.3.3 Ch-Track............................................................................................... 5
2.4 Repeat ........................................................................................................ 5
2.5 Sys Settings.................................................................................................. 5
2.5.1 Sys Addr ............................................................................................... 5
2.5.2 Secure Key........................................................................................... 5
2.6 Restore Default........................................................................................... 6
2.7 Player Version ............................................................................................. 6
3Coding – MP3 .................................................................................................... 6
4Special functions ............................................................................................... 6
4.1 FSK- Modus.................................................................................................. 6
5Specifications .................................................................................................... 6
5.1 General Information .................................................................................. 6
5.2 Player........................................................................................................... 6
6Important ........................................................................................................... 7

RX-MP3-Player Instruction Manual
3
1 Abstract
1.1 Buttons
1.2 Audio Files
128 audio files can be used by the MP3-Player.
The name of the first audio file wanting to be played has to start with “001“, the
following naming after the “001” does not matter. The second file’s name has to start
with “002”, the third with “003” and so on.
When channel 1 / box 50 is going to be ignited, track 001 is going to start to play,
when channel 2 is going to be ignited, track 2 is going to start to play…
The first 60 sound files can be played directly. The rest of the sound files are only over
the „Skip Forward“function accessible.
Play / Pause
Stop
Forward / Rewind
Test LEDs
On / Off
Charge 12V Audio Out
Antenna
The console is used to play MP3 sound
files and can be controlled with radio.
Only MP3 files can be processed (there
are no hearable differences to a WAV-file
because of the 320kbps coding).
A CF-memory card is used as a data
carrier.

RX-MP3-Player Instruction Manual
4
2 Menu
The menu can be accessed by holding the STOP key and pressing the PLAY key.
Keys used for the menu: Play OK, confirm
Stop ESC, back
<< Minus
>> Plus
2.1 Menu structure
Menu
Delay 0-1005m
Ch Settings
Repeat OFF/ALL
Sys Settings
Restore Default
Player Version
Main Box 1-50 / all
Ch-Controll
Ch-Track
Sys Addr
Secure Key 0-99

RX-MP3-Player Instruction Manual
5
2.2 Delay
A sound delay (starting delay) can be adjusted. The adjustment shall be conducted
in “meter”. The delayed time will be displayed in “ms”.
2.3 Ch Settings
The channels can be programmed as desired.
2.3.1 Main Box
This box setting is used, when the box setting „main“ is used in the submenus „Ch-
Controll“ and „Ch-Track“ (standard: box 50).
2.3.2 Ch-Controll
Here the settings like Play, Pause Stop, can be modified.
Basic settings: Play/Pause Ch 61
Stop Ch 62
Skip << Ch 63
Skip >> Ch 64
Reset Ch 65
Start Soon Ch 66
Reset: The MP3-Player stopps playing and sets the track number back to “001”.
Start Soon: The timer is going to be started and showed on the display (information
for the sound engineer).
2.3.3 Ch-Track
The settings for a direct start of the sound files can be made here.
2.4 Repeat
If this function is used, the next sound file is going to be played automatically after
finishing the one playing at the time. After the last one is played, the first one is going
to be played automatically.
2.5 Sys Settings
2.5.1 Sys Addr
The system address can be adjusted in this submenu.
2.5.2 Secure Key
A radio coding can be set. All used devices have to be attuned to the same Secure
Key.

RX-MP3-Player Instruction Manual
6
2.6 Restore Default
Here the settings are going to be set back, except the Secure Key.
2.7 Player Version
The player’s firmware is shown. An outdated firmware can be upgraded.
3Coding – MP3
For the coding of the MP3 files a LAME encoder with 320kbps is recommended.
The player can work up all bit rates. A bit rate under 128kpbs is NOT recommended
because of the hearable bad audio quality.
4Special functions
4.1 FSK- Modus
When the TX-70K / TX-1400K is determined in FSK-armed state, the RX-MP3 can be
started with the „Z“button on the TX-70K / TX-1400K. To pause the music, a second
push on the „Z“button is necessary. With holding the “-“button and a push on the “Z”
button the music is going to stop. When that key combination is used again, the RX-
MP3-Player resets and the first track is going to be played, when the PLAY-button is
pushed.
5Specifications
5.1 General Information
Measurements: 220 x 155 x 67mm
Weight: 1,9kg
Operation time: 10h
Stand-by: 16h
Temperature range: -20°C to +65°C (protect from direct insolation!)
Coverage: 800m
5.2 Player
Outputs: 2x Cinch, 1x 3,5mm phone jack
Output level: 1,8Vpp
Distortion factor: 0,1%
S/N ratio: 87dB
Channel Offset: 70dB

RX-MP3-Player Instruction Manual
7
6Important
PLEASE NOTE:
DO NOT copy two or more files starting with the same track number on the CF card!
The MP3 Player CAN NOT receive radio signals while operating in the menu!
Most audio mixers do not have cinch outputs! To connect the RX-MP3-Player with a
mixer, you need an adaptor cable (cinch to XLR or cinch to 6.5 phone jack).
DO NOT place the MP3-Player nearer than 1 meter next to a computer, a
radio microphone or any other transmitter because it affects the reception.
Make a sound check in time before the show to assure that everything is working
correctly!
This document is also Safety- and Health Document.
