User's Manual
Digital Photo Tachometer
Model 461893

461893-EN V1.4 8/13 2
Introduction
Congratulations on your purchase of the Extech 461893 hoto Tachometer. This device provides
non-contact measurements over a wide range (5 to 100,000 R M). A reflective mark on the object
to be measured is used as a target for the meter's integral light beam. Careful use of this meter will
provide years of reliable service.
Specifications
General Specifications
Meter circuitry Custom one-chip LSI microprocessor
Time base Quartz crystal
Display 5-digit (99999 count) 0.4" (10mm) multi-function LCD
Measurement 5 to 99,999 R M in 2 ranges
Range select Automatic
Data Recording LAST / MIN / MAX readings stored for later recall
Sampling time 1 second (over 60 rpm)
Target distance 2 to 6" (50 to 150mm) depending on ambient light
Operating Temperature 32°F to 122°F (0°C to 50°C)
ower Supply 4 x 1.5V 'AA' batteries
ower Consumption Approximately 150 mA
Weight 8.8 oz. (250 g) including battery
Size 6.7 x 2.8 x1.5" (170 x 72 x 37mm)
Accessories Reflective tape (23") and carrying case
Range Specifications
Measurement Range Resolution Accuracy
R M 5 to 999.9 R M
1,000 to 99,999 R M
0.1 R M
1 R M
+(0.05% + 1 digit)
+(0.05% + 1 digit)

461893-EN V1.4 8/13 3
Meter Description
1. Photo source
2. LCD Display
3. emory record button
4. Battery compartment on rear
5. easure button
Meter Operation
RPM Measurements
1. Apply a small piece of reflective tape to the object under test as shown below.
2. Point the meter's photo source at the tape on the object and press the easure button. Hold the
meter from 2 to 6" (50 to 150mm) from the reflective tape depending on ambient light.
3. Check that the onitor icon flashes on the LCD indicating that the meter is sensing a reflection
from the tape. If the monitor does not appear check that the light source is hitting the reflective
tape at a 90
o
angle.
4. Release the easure button when the display stabilizes (2 seconds approx.). Note the LCD
RP reading.
5. If the RP value is < 50, apply additional pieces of reflective tape (four pieces are shown
below). Divide the LCD reading by the number of reflective tapes to compute the actual RP
(Actual RP = Reading / 4).
Photo Tachometer
Rotating object
Reflective tape
Light source
and reflection

461893-EN V1.4 8/13 4
Memory Record and Recall
The meter automatically records the Minimum and Maximum readin s. These represent the lowest
and hi hest readin s measured from the moment the Measure button is pressed to the moment it is
released. The Last readin is also recorded; this is the last measurement taken before the Measure
button is released. These stored readin s can be displayed on the LCD usin the Memory button as
described below:
1. Press once and hold: The Last readin is displayed followed by "LA"
2. Press a ain and hold: The Maximum value is displayed followed by the word "UP"
3. Press a ain and hold: The Minimum value is displayed followed by "dn"
Special Measurement Considerations
1. The non-reflective area of the object under test must always be reater than the reflective tape
area.
2. If the shaft of the object under test is reflective, it should be covered with black tape or paint
before attachin reflective tape.
Battery Replacement
The low battery indication appears as "LO" on the display. To replace the batteries:
1. Slide the rear cover off the battery compartment in the direction indicated by the arrow.
2. Replace the four 1.5V 'AA' batteries and the battery compartment cover.
3. Remove the batteries if the instrument will be stored for lon periods of time.

461893-EN V1.4 8/13 5
Warranty
FLIRSystems, Inc. warrantsthisExtech Instruments brand device to befree of defects in parts and workmanship for one year
from date of shipment (a six month limitedwarranty appliesto sensorsand cables). If it should becomenecessary to return the
instrument for serviceduring or beyond thewarranty period, contact theCustomer Service Department for authorization. Visit
the website www.extech.com for contact information. A Return Authorization (RA) number must be issued beforeany product is
returned. The sender isresponsible for shipping charges, freight, insurance and proper packaging to prevent damagein transit.
Thiswarranty does not apply to defects resulting from action of theuser such asmisuse, improper wiring, operation outsideof
specification, improper maintenanceor repair, or unauthorized modification. FLIRSystems, Inc. specifically disclaimsany implied
warrantiesor merchantability or fitnessfor a specific purpose and will not beliablefor anydirect, indirect, incidental or
consequential damages. FLIR’stotal liability is limited to repair or replacement of theproduct. The warranty set forth above is
inclusive and no other warranty, whether written or oral, isexpressed or implied.
Calibration, Repair, and Customer Care Services
FLIRSystems, Inc. offersrepair and calibration servicesfor the Extech Instrumentsproductswe
sell. NISTcertification for most products isalso provided. Call the Customer Service Department for
information on calibration servicesavailable for thisproduct. Annual calibrationsshould be
performed to verify meter performance and accuracy. Technical support and general customer
service isalso provided, refer to the contact information provided below.
