Extech Instruments lcr200 User manual

User's Guide
Digital LCR Meter
Model LCR200
D
actoolsupply.com
actoolsupply.com
actoolsupply.com
Extech LCR200 Passive Component LCR Meter

2 LCR200-EU-EN V1.5 11/13
Introduction
Congratulations on your purchase of Extech's Model LCR200 LCR meter. This meter will
accurately measure capacitors, inductors and resistors using the test frequencies of 100Hz, 120Hz
1 kHz, 10 kHz and 100 kHz. The dual display will simultaneously display the associated quality
factor, dissipation or phase angle value using a series or parallel equivalent circuit.
This meter is shipped fully tested and calibrated and, with proper use, will provide years of reliable
service.
Features
* 19,999/1,999 count dual LCD display.
* Auto LCR smart check and measurement.
* Serial/Parallel modes are selectable.
* Ls/Lp/Cs/Cp with D/Q/RP/ESR parameters.
* DC Resistance.
* Five test frequencies are available: 100Hz/120Hz/1kHz/10kHz/100kHz.
*Test AC signal level : 600mV rms typically.
* Test range : ( ex. F = 1 KHz )
L : 0.00uH to 2000.0H
C : 0.0pF to 2.000 mF
R : 0.000to 200.0 M
* Multi-level battery detector.
* LCD with green backlight.
actoolsupply.com
actoolsupply.com

3 LCR200-EU-EN V1.5 11/13
Meter Description
1. Display
2. Power Adapter Socket
3. Frequency
Button
4. Button
5. CAL
Button
6. Backlight
Button
7. , D/Q/Button
8. REL/%/ Button
9. Input terminals (pin terminals)
10. Input terminals (banana terminals)
11. Hold Button
12. RS232 Port (not active on this model)
13. L/C/R
Button
14. Enter Button
15. , SER/PAR Button
16. Sort Button
17. Setup
Button
18. Power
Button
19. Stand
(rear)
20. BatteryCompartment (rear)
D
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
actoolsupply.com
actoolsupply.com

4 LCR200-EU-EN V1.5 11/13
Operation
Setup
1. Press the Power button to turn the meter on.
2. The meter will turn on in the default mode: AUTO LCR and 1kHz
3. APO will be active with auto shutoff every 5 minutes unless an AC adaptor is used.
LCR primary parameter selection
1. The meter will turn on with auto parameter selection enabled and with the ”APO” (auto power
off), “Auto” (autoranging) and “LCR” (auto-parameter) icons appearing at the top of the
display.
2. To manually select the parameter, press the L/C/R button to step through and select the
parameter needed. Each button press will sequentially display:
Auto-LCR Auto Range Auto Parameter
Auto-L Auto Range Inductance
Auto-C Auto Range Capacitance
Auto-R Auto Range Resistance
DCR DC Resistance
3. The value of the primary parameter will be displayed in the upper display and the secondary
parameter in the lower display.
D/Q/θsecondary parameter selection
1. The meter will turn on with auto parameter selection “LCR” enabled. .The primary and
secondary parameter will be automatically selected based on the value of the measured
impedance.
2. To manually select the secondary display, first select the primary display.
3. Press the D/Q/button to select the secondary parameter:
L D, Q, ESR(RP) or 
C D, Q, ESR(RP) or 
R none
DCR none
4. The value of the secondary parameter will be displayed in the lower display
Series or Parallel
1. When the L/C/R function mode is selected and ‘AUTO” is enabled, the default measurement
in serial or parallel mode is auto selected. A parallel equivalent circuit (Lp, Cp or Rp) will be
selected if the impedance is greater than 10k. A series equivalent circuit ( Ls, Cs or Rs) will
be selected if the impedance is less than 10k.
2. Press the SER/PAR button as needed to change the default selection.
Frequency
Press the FREQ button to change the test frequency. The selections are: 100Hz, 120Hz, 1kHz,
10kHz and 100kHz.
Data Hold
Press the HOLD button to freeze the reading in the display. Push the HOLD key again to cancel
the hold mode and return to normal operation.
actoolsupply.com
actoolsupply.com

5 LCR200-EU-EN V1.5 11/13
Relative / % Function
The REL/% mode allows for % deviation measurements from a stored reference value.
1. Setup the meter with the parameters required for the test to be performed.
2. Insert the reference component into the test fixture and wait for a stable reading.
3. Press the REL/% button to store the value. The icon will appear in the display.
4. For all subsequent measurements, readings on the lower display will indicate the %
difference between the currently measured component and the stored value.
5. Press and hold the REL/% button for >2 seconds to exit the mode.
Sorting
The sorting mode is used to select components within a % limit of a reference value.
1. Insert the reference component and set the test parameters. “LCR” auto-parameter is not
allowed in the sorting mode.
2. With the desired reading in the display, press the SORT button to establish the reference
value. The main display will indicate “PASS” and the lower display will indicate the value of
the component. The default sorting % is +/- 1%.
Note: If the reference value is above 2000 counts or below 200 counts, sort will not work.
3. Press the SETUP button in sequence to change the Range, Reference Value, and the %
Tolerance.
a. Range: With the “RANGE” icon flashing, press the or button to change the range.
Press the ENTER button to store the setting and proceed to the Value setting.
b. Value Setting: Press the or button to select the flashing digit for adjustment. Press
the or button to adjust the value of the digit. Press the ENTER button to store the
setting and proceed to the Tolerance setting.
c. Tolerance setting: Press the or button to step through the available tolerance
selections:
± 0.25%
± 0.5%
± 1%
± 2%
± 5%
± 10%
± 20%
+80% -20%
Press the ENTER button to store the Tolerance setting.
4. Press the SORT button for > 2 seconds to exit the Sorting mode.
actoolsupply.com
actoolsupply.com

6 LCR200-EU-EN V1.5 11/13
Open/Short Calibration
In order to improve the accuracy for high/low impedance measurements, it is recommended to do
OPEN/SHORT calibration mode before the measurement. This removes stray impedances in test
leads or fixtures.
1. Press the CAL button for greater than 2 seconds to start the open/short calibration procedure
:
2. The “CAL” icon and “OPEn” appear in the display
3. With no component connected, press the CAL button. The display will count down from 30
and either “PASS” or “FAIL” will appear in the display.
4. Press the CAL button and “Srt” will appear.
5. Short the input and press the CAL button. The display will count down from 30 and either
“PASS” or “FAIL” will appear in the display.
6. Press the CAL button to exit the cal mode.
7. If PASS appeared for both the OPEN and SHORT modes, the calibration data will be stored.
8. If FAIL appeared for either calibration, the impedance was too large to zero out and the data
is not stored.
Backlight
Press the backlight button to turn the backlight on. Press again to turn it off.
Guard Terminal
The guard is used to improve noise immunity and reduce stray impedances. The optional test
fixtures utilize the guard feature.
Auto Power Off
In order to extend battery life﹐
APO will turn the meter off after 5 minutes of inactivity (no button is
pressed). The meter will alarm (beep) three times before the power is shut off. Press any button to
reset the APO and continue using the meter.
RS232 output port
The RS232 port is not active on this meter.
AC Adaptor
The meter can be powered from an AC adaptor (9VDC, 1A). When an AC adaptor is used, APO is
disabled. Purchase a Linear Power Supply (9V 1A) from a third party.
actoolsupply.com
actoolsupply.com

7 LCR200-EU-EN V1.5 11/13
Battery Replacement
The battery icon indicates the status of the 9V battery. A fresh battery will have three lines
above it. As the battery weakens, the number of lines will decrease. When the battery becomes
too weak to power the meter, “batt” will appear in the display and the meter will shut down.
To replace the battery:
1. Remove the two screws holding the rear bottom battery cover.
2. Remove and replace the 9V battery
3. Secure the cover with the two screws
All EU users are legally bound by the battery ordinance to return all used batteries to
collection points in your community or wherever batteries / accumulators are sold!
Disposal in the household garbage is prohibited!
Optional Accessories
LCR203 SMD Component Tweezers
Used to quickly measure and sort chip components.
LCR205 SMD Component Fixture
Used to accurately measure surface mount devices
actoolsupply.com
actoolsupply.com

8 LCR200-EU-EN V1.5 11/13
Specifications
Display LCD size : 66.8 X 52.8mm (2.6 x 2.1” ) backlit LCD
Test frequency 100Hz, 120Hz, 1KHz, 10 KHz, 100KHz
Dissipation factor 0.000 to 1999
Quality factor 0.000 to 1999
measurement ± 90°
Sorting tolerance ± 0.25%, ± 0.5%, ± 1%, ± 2%, ± 5% ± 10%, ± 20%, +80% -20%
Calibration Open/Short calibration
Power off Auto shut off saves battery life or manual off by push button
Operating temperature 0°C to 50°C (32 to 122°F)
Operating humidity < 85% R.H
Power Supply 006P DC 9V battery * Alkaline or Heavy duty type
Power consumption DC 35 mA approximately
Dimension 193 x 88 x 41mm (7.6 x 3.5 x 1.6”)
Weight 385 g (13.6 oz.) * meter only
Electrical Specifications (23± 5 ° C )
DC Resistance
Range Accuracy Remark
20  ± ( 0.5%rdg + 5digits ) After calibration
200  ± ( 0.5%rdg + 5digits )
2k  ± ( 0.5%rdg + 5digits )
20k  ± ( 0.5%rdg + 5digits )
200k  ± ( 0.5%rdg + 5digits )
2M  ± ( 0.5%rdg + 5digits ) After calibration
20M  ± ( 1.0%rdg + 5digits ) After calibration
200M  ± ( 2.0%rdg + 5digits) After calibration
AC Resistance
RangeAccuracy Accuracy Remark
100Hz/120Hz 1000Hz
20  ± ( 1% + 5digits ) ± ( 1%rdg + 5digits )
A
fter calibration
200  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
2k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
20k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
200k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
2M  ± ( 1.0%rdg + 5digits ) ± ( 1.0%rdg + 5digits )
A
fter calibration
20M  ± ( 1.0%rdg + 5digits ) ± ( 2.0%rdg + 5digits )
A
fter calibration
actoolsupply.com
actoolsupply.com

9 LCR200-EU-EN V1.5 11/13
Range Accuracy Accuracy
10kHz 100kHz
20  ± ( 1.0%rdg + 5digits ) ± ( 2.0%rdg + 5digits ) After calibration
200  ± ( 0.5%rdg + 5digits) ± ( 0.5%rdg + 5digits )
2k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
20k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
200k  ± ( 0.5%rdg + 5digits ) ± ( 0.5%rdg + 5digits )
2M  ± ( 1%rdg + 5digits ) ± ( 2.0%rdg + 5digits ) After calibration
20M  ± ( 2.0%rdg + 5digits ) --------------------- After calibration
* If the impedance is larger than 10k, Rp is shown on the display.
* If the impedance is less than 10k, Rs is shown on the display.
Capacitance ( Cp/Cs ) : D ≦ 0.1
Range Accuracy Accuracy Remark
100Hz/120Hz 1000Hz
20pF ± (2.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
200pF ± (1.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
2000pF ± (0.8%rdg + 5digits ) ± (0.8%rdg + 5digits ) After calibration
20nF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
200nF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
2000nF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
20uF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits )
200uF ± (0.5%rdg + 5digits ) ± (0.5%rdg + 5digits ) After calibration
2000uF ± (1.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
20mF ± (2.0%rdg + 5digits ) ------------------------ After calibration
Capacitance ( Cp/Cs ) : D ≦ 0.1
Range Accuracy Accuracy Remark
10kHz 100kHz
20pF ± (1.0%rdg + 5digits ) ± (1.0%rdg + 5digits ) After calibration
200pF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits ) After calibration
2000pF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits) After calibration
20nF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits )
200nF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5d igits)
2000nF ± (0.5%rdg + 5digits ) ± (0.5%rdg+ 5digits )
20uF ± (0.8%rdg + 5digits ) ± (0.8%rdg+ 5digits )
200uF ± (1.0%rdg + 5digits ) -------------------------- After calibration
* If the impedance is larger than 10k, Cp is shown on the display.
* If the impedance is less than 10k, Cs is shown on the display.
actoolsupply.com
actoolsupply.com

10 LCR200-EU-EN V1.5 11/13
Inductance ( Lp/Ls ) : D ≦ 0.1
Range Accuracy Accuracy Remark
100Hz/120Hz 1000Hz
20uH ± (1% + 5d ) ± (1% + 5d ) After calibration
200uH ± (1% + 5d ) ± (1% + 5d ) After calibration
2000uH ± (0.8% + 5d ) ± (0.8% + 5d )
20mH ± (0.5% + 5d ) ± (0.5% + 5d )
200mH ± (0.5% + 5d ) ± (0.5% + 5d )
2000mH ± (0.5% + 5d ) ± (0.5% + 5d )
20H ± (0.5% + 5d ) ± (0.5% + 5d )
200H ± (0.5% + 5d ) ± (0.8% + 5d ) After calibration
2000H ± (1% + 5d ) ----------------------- After calibration
Range Accuracy Accuracy Remark
10kHz 100khz
20uH ± (1% + 5d ) ± (1% + 5d ) After calibration
200uH ± (0.8% + 5d ) ± (0.8% + 5d ) After calibration
2000uH ± (0.5% + 5d ) ± (0.5% + 5d )
20mH ± (0.5% + 5d ) ± (0.5% + 5d )
200mH ± (0.5% + 5d ) -----------------------
2000mH ± (0.5% + 5d ) -----------------------
Note:
* If the impedance is larger than 10k, Lp is shown on the display.
* If the impedance is less than 10k, Ls is shown on the display.
actoolsupply.com
actoolsupply.com
