Extech Instruments MD10 User manual

MD10-en-US_v1.2 04/22
User Manual
Magnet Detector - Model MD10
Introduction
Thank you for selecting the Extech Instruments Model MD10 magnetic field detector. The MD10 can te
st solenoid valves in pneumatic/hydraulic control equipment, relays with coils, electrically controlled sol
enoid valves in vehicles/machinery/oil burners, and audio speaker coils. The MD10 responds toAC/D
C magnetic fields and permanent magnets.
Safety Information
!
Caution! Refer to the explanation in this Manual
Double Insulation or Reinforced insulation
CE Compliance
•This device must not be handled by children. It contains hazardous objects as well as small parts that can be swallowed.
•Do not leave batteries and packing material unattended; they can be dangerous for children.
•If unused for an extended period of time, remove the batteries from this device
•Expired or damaged batteries can cause cauterization on contact with the skin; use suitable hand gloves in such cases
•Ensure that the batteries are not short-circuited. Do not throw batteries into the fire.
Operating Instructions
CAUTION: Read, understand and follow Safety Rules and Operating Instructions in this manual before
using this product.
WARNING: Risk of Electrocution. Before use, always test the Magnet Detector on a known live circuit
to verify proper operation
WARNING: Risk of Electrocution. Keep hands and fingers on the body of the probe and away from
the probe tip.
1. Press and hold the test switch (3) and approach the testing area slowly with the probe tip (1).
2. When a magnetic field is sensed by the MD10, the blue probe light (2) will illuminate. Solid light in
dicates a strong field; flickering light indicates a weak field.
3. To switch ON the flashlight (7), press and hold the flashlight switch (6). Release the button to switc
h the flashlight OFF. If the flashlight does not switch ON please check the batteries. The battery co
mpartment is located on the rear of the MD10 (8).
NOTE: The detector is designed with high sensitivity. Static electricity, stray magnetic fields, or other
sources of energy may randomly trip the sensor. This is normal operation. Strong fields will yield a
fixed indication.
NOTE: It is not necessary to unscrew the test object from its mounting on the equipment in order to
carry out a test; a magnetic coil can even be tested through its protective covering.

MD10-en-US_v1.2 04/22
Battery Installation
1. Slide open the battery door compartment (8) while gently prying up/out at the pocket clip (4) using a small
screwdriver in the pocket clip access hole (5).
2. Insert two AAA batteries and replace the door.
Never dispose of used batteries or rechargeable batteries in household waste.
As consumers, users are legally required to take used batteries to appropriate collection sites, the
retail store where the batteries were purchased, or wherever batteries are sold.
Disposal: Do not dispose of this instrument in household waste. The user is obligated to take end-of-
life devices to a designated collection point for the disposal of electrical and electronic equipment.
Specifications
Power 2 x AAA 1.5V batteries
Magnetic Field ranges 63, 98, 401, 810 (Henry units)
Power Consumption 32mA maximum
Operating/Storage Temperature -10 to 50°C (14 to 122°F)
Relative Humidity 95% max. from 0 to 40°C (32 to 104°F)
Altitude 3000m (9842 ft.)
Pollution Degree II
Dimensions 159 x 21 x 25mm (6.25 x 0.8 x1”)
Weight 48g (1.7 oz.)
Copyright ©2022 FLIR Systems Inc.
All rights reserved including the right of reproduction in whole or in part in any form
ISO-9001 Certified
