Grizzly YM 203 User manual

WWW.MDETECTORS.COM GRIZZLYYM203
Contents
Operationandmaintechnical parameters 2
1.Introduction inthemetaldetector operation 2
2.Maintechnicalparameters 2
3.Seeker’sethicalcode 2
Preparation 3
1.Assemblingofthemetaldetector 3
2.Battery charging 4
3.Usageoftheheadphones 4
Compositionoftheequipmentandintroductioninthe
operationbuttons 5
1.Composition ofthemetaldetector 5
2.LED light indicator 6
3.Criticalsoundandon/off(TUNE)knob 6
4.Discrimination modebutton 6
5.GROUNDBALANCE knob 6
Detection 7
1.Preparation 7
2.Testingandoutdoor usage 8
Careandmaintenance 8
Specification 9

WWW.MDETECTORS.COM GRIZZLYYM203
2
Operationandmaintechnical
parameters:
1.Introductioninthemetal
detectoroperation:
TheYM203 GRIZZLYmetal
detector iscompact,solidandeasy
touse.
Herearesomeofits
characteristics:
- EARPHONEsocket –allowsyou
toconnectheadphonestothe
equipment (notincluded)
-sounddiscrimination–the
detector will produceconstant
audiotunedetectinganonferrous
metal,anddecreasingtunewhen
detectsferrousmetal.Itworks
whenit isseton“DISC”mode.
-Pointerindicator –showsthe
possiblekindofthedetectedmetal.
-LEDlightindication–producesa
lightsignalwhenametalis
detected.
-Soundindication–produces
soundsignalofaspecificfrequency
when detectingametal.
-Waterproofsearchingcoil–gives
youthepossibilitytousethewhole
lengthofthemetaldetector for
easieroperation.
NOTE:thesearchingcoilis
waterproofbut thecontrolpanelis
not!
-Adjustablehandle–allowsyouto
adjustthelengthofthetelescope
ofthemetaldetector for easier
usage.
2.Maintechnical parameters:
-transmissionfrequency :6.99KHz
-signalfrequency:437KHz
-weight:1.8 г.
-Charging:thereisacharging
deviceincludedintheequipment,
whichisusedtochargethe
rechargeablebatteriesofthemetal
detector.
-Ifyoutestaferrousmetal,the
detectiondepth isbigger.
-Thedetectiondepth (finding
metal)isdeterminedprimlybythe
shape,sizeandqualityofthemetal
detected. Thebiggerand
qualitativethemetalis,thebigger
thedetectiondepth is.
3.Seeker’s ethical code
everyseekershouldbeleadedby
theexampleyougive.Hereare
somerulesyoushouldfollowwhen
you useyourmetaldetector:
Youmustaskfor permissionthe
ownerof theplaceyouareseeking.
Youmustrespectotherpeople
rightsandproperty.
Youmustrespectall localand
nationallawswhenyouare
seeking.
Donotdestroyany archeological
objects!Donotseekin
archeologicalareas!Ifyoufinda
valuableobject,evenifyouarenot
sureifitisvaluable,contactto
respectivetheregionalor national
museum!

WWW.MDETECTORS.COM GRIZZLYYM203
3
Donotseek inanymilitaryareas!
Leavethegroundandvegetation
theway they were.Bury every hole
you havedig!
Usethemetaldetector only insafe
places!
Collectthewasteyoufindand
throwitonlyin thedetermined
locations.Donotleaveittobe
foundbythenextkeeper!
PREPARATION
1. Assemblingthemetal–
detector.
Assemblingthemetaldetector is
easyandyoudonotneedany
specialskillsandtoolstodoit.Just
followthesesteps:
-connectingthesearchingcoil:
Releaseandtakeoutthenut,
tightenupthesearchingcoil,put
thehandleofthemetaldetector in
thecrampofthesearchingcoil.Put
backthescrewin theholeand
tightenupthenut.Nowthe
searchingcoilisconnectedtothe
handle.
-adjustingthelength ofthe
handle:
a)Turnthelockingnut ofthe
handleclockwiseuntil itloosens.
b)Pulltheplastichandle,thatis
belowthehandleofthemetal
detector.Prolongor shortenthe
handle,sothatwhenyoustandup
holdingtheequipment,the
searchingcoiltobe2to5cm
abovethegroundlevel,with your
handloosen.Thentightenupthe
nut of thehandle.
-connectingthecableofthe
searchingcoil:
(1)Windupthecableofthe
searchingcoilaroundthehandle.
Leavethecablelooseenough,so
youcanadjustthesearchingcoil
whenyouoperateonrough
ground.
(2)Whenyouput theplugofthe
searchingcoilin theswichofthe
controlpanel,makesureallthe
pinsoftheplugarein the
respectiveholes.

WWW.MDETECTORS.COM GRIZZLYYM203
4
2. Chargingthebatteries:
Yourmetaldetector issupplied
with builtinbatteriesanddoesnot
needadditionalbatteries.
Ifthemetaldetector isturnedon,
turnitoff(theknobTUNEisalso
on/off button.Turnit anti–
clockwisetoturnoff the
equipment).Connectthecharging
devicejacktotheRECHARGE
socketofthemetaldetector.Then
connectthechargingdevicetothe
contact.Whenrechargesthered
light ofthechargingdeviceison.
Thechargingcontinues12to16
hours.Oncechargedthemetal
detector canfunctionupto45
hours.
Youcanprolongthetimethe
detector worksbyusing
headphones,thatneedlessenergy
thanthebuilt in speakers.
BATTERY TESTING: Whenthe
detector isturnedon,ifthebattery
statusindicator LOWBATison,if
theequipment doesnotstart,if the
soundisweakor difficulttoadjust,
rechargethebatteries.
3. Usageof theheadphones:
Youcanconnectapairof
headphones(notincludedinthe
equipment) tothemetaldetector.
Thiswayonlyyouwillhearthe
signalofthedetector.Using
headphonesalsoprolongsthelife
ofthebatteriesandmakeseasier
for youidentifyingthesoundsignal
youhear,for betterdetection.To
connecttheheadphonesput their
cableintothecorrespondingsocket
onthecontrolpanel.Thebuilt in
speakerturnsoffautomatically
whenyouconnecttheheadphones.
SAFEHEARING: in ordertoprotect
yourhearing, you mustfollowthese
adviseswhenyouusethe
headphones.
-adjustthesoundonthelowest
levelbeforeyoustartdetecting.
Thenstartadjustingitthewayyou
feelitbetter.
Donotput tohighthelevelofthe
sound. Itmaycauseyou
permanentloseofhearing
Onceyou haveadjustedthelevelof
thesound, donotincreaseit.With
thetimeyourearsadapttothe
levelofthesoundandsometimes
evensoundlevelthatseemstonot
disturbyou,couldresultharmful
for yourhearing.
SAFE MOVEMENT:
Donotusetheheadphonesona
placeswith heavy traffic.Although
someheadphonesallowyoutohear
othersounds,usingthemonplaces
with heavytrafficisriskytoo.

WWW.MDETECTORS.COM GRIZZLYYM203
5
COMPOSITIONOF THEEQUIPMENTANDINTRODUCTIONINTHE
OPERATIONBUTTONSS
1. Compositionof themetal detector
1.Searchingcoil
2.Screwandnutfor connectingthesearchingcoil
3.Lockingnutfor adjustingthelength of thehandle.
4.Controlpanel
5.Discrimination modebutton
6.Handle
7.Battery department
8.Handle

WWW.MDETECTORS.COM GRIZZLYYM203
6
Control panel:
2. LEDlightindicator:- A
greenlight shineswhenametalis
detected.
3. Discriminationmode
buttonPUSH:
ThebuttonPUSHhas two
positions:1whenthebuttonisup
(ALL METALposition),thenthe
metalsarenotdiscriminatedand
thedetector reactswith adeep
tonedsignal.2.thesecondposition
iswhenthebuttonispushed(on
positionDISC),thenthedetector is
in modethatdiscriminatesthe
metals.Sowhenitdetectsanon–
ferrousmetal,producesasolid
soundsignalandwhendetectsa
ferrousmetalyouhearan
interruptedsoundsignal.Besides
thatthedetector issuppliedwith a
pointersystem,whichisanother
way todiscriminatethemetals.The
systemhas amiddlepoint and
whenyoudetectaferrousmetal
thepintergoesleft–FERROUS,
andwhenyoudetectanonferrous
metalgoesright–NONFERROUS.
4. Criticalsoundandon/off
(TUNE) knob:
TheTUNEknobservesason/off
buttonandfor adjustingthecritical
soundtoo.Toturnthedetector off,
turnlefttheknob. Turntheknob
leftandyouwill hearalittleclick,
whichmeansthatthedetector is
turnedon.Keepturningrightand
youwill hearthesoundslowly
increasing. Adjustthebuttonto
hearaveryweaksound. Theweak
soundiscalledcriticalsound. The
detector ismostsensitivewhenthe
criticalsoundistuned.
5. GROUNDBALANCE knob
GROUNDBALANCEknobserves
toeliminatethemineralization
effectofthesoil.
Operation:
Turnonthemetaldetector –turn
theTUNEknobright.Liftthe
detector to40–50 cmofthe
ground:1.release
the“Discrimination”button(All
METAL); 2.turntheTUNEknob
maximum right.3.turnthe
GROUNDBALANCEknobtomiddle
position.4.Keepthedetector lifted
andyouwillhearloudand
uninterruptedsound. 5.Start
turningleftslowlytheTUNEknob
until thesoundbecomesweakor
barelyhearable.Thisisthecritical
soundandinthatpositionthe
detector has thebiggestdetection
depth.6.Thennearthesearching

WWW.MDETECTORS.COM GRIZZLYYM203
7
coilto10 –15 cmovertheground
level.Nowpay attentiontothis:
І.Ifthedetector produces
soundsignalas itgetsclosertothe
ground, dothis:liftthedetector
at40 -50 cmabovetheground
andturn“Groundbalance”
slightlyleft.Thennearthe
detector at10 –15 cmabovethe
groundlevelandwatchifitmakes
sound. Ifit doesnotproduceany
sound, YOUHAVESETITTOTHE
GROUND(it isreadytowork),ifit
producessoundagain,repeatthe
underlinedprocedure,untilthe
detector stopsmakingsoundwhen
it isclosetotheground. sound
ІІ.Iftheequipmentproduces
soundsignalas youliftit upfrom
thegrounddothefollowing–liftit
upat40–50 cmfromthe
groundandturn“Ground
balance”slightlytotheright.
Thennearthedetector at5-10cm.
abovethegroundlevelandifit
makessoundagainliftitbackup
andrepeattheprocedure.Ifthe
detector doesnotproduceany
soundwhen younearitor youliftit
fromtheground, YOUHAVESETIT
TOTHEDROUNDandit isreadyto
work.Ifthedetector produces
soundwhenyouliftit andwhen
younearittotheground, then
decreaseitssensitivityby slightly
turning theTUNEknobtotheleft.
Whenyouhavesetthe
equipment totheground, youcan
workwith it.Whenyousearchhold
strongthedetector andsweep
slowlythesearchingcoilat2-5cm
abovethegroundlevel.Thenyou
can startdetecting.
DETECTION
1.Preparation:
Afterchargingthebatteries,
turntheTUNEknobtotheright to
turnonthedetector.Thensetthe
criticalsound. Afterthatsetthe
detector tothegroundusingthe
GROUNDBALANCEknob. Thenthe
detector isreadytowork.You
shouldconnectthesearchingcoil in
aplacewherethereisnotany
metal.Whenyousearchholdthe
handleofthedetector andsweep
thesearchingcoilslowlyat2-5cm
overtheground. Whendetects
metal,thedetector reacts
producingsoundsignalandthe
controlpanelreadsthechange.
Takeoffall theclocks,metal
buttonsetc.thatyouarewearing
anddonotwearany bootswith
metalon them.
Note:
-thesearchingcoilwill notdetect
anythingifit’snotmoving

WWW.MDETECTORS.COM GRIZZLYYM203
8
2.Testandoperationoutdoors
(1) Findplotofgroundoutdoors,
wherethereisnotany metal.Put
downasampleoftheobjectthat
youwant thedetector tofind. If
youuseas asampleanyvaluable
object,marktheplacewhereyou
areburyingit in ordertofindit
later.
(2) Keepthesearchingcoilat2–
5cmabovethegroundandsweep
it slowlyleftandright overthe
placethatyouhaveburiedthe
object.
CARE ANDMAINTENANCE
1. ifthemetaldetector doesnot
workproperly,itispossiblethat
thebatteriesarelow,soyouhave
torechargethem.Theplugofthe
searchingcoilshouldnotbewet,
becausethedetector will loseits
capacity.Theplugcan beusedonly
afteritiscarefullydried. donot
usethedetectorwhenitrains
orwhenthesun shinestoo
strong.
2. Donotnearthesearchingcoil
toovensor otherhotobjects.
Everymetaldetector has warranty
thatallowsfree repairuntilitstime
limit.Thewarranty dropsoff ifthe
stampisremovedby theuser.
Usefuladvicesat
WWW.MDETECTORS.COM
•Usehigh qualityheadphones
•Practicealotandyouwillcreate
yourown style
•Ifyouhaveany difficultieswhen
youusethedetector,readagain
thisuser’sguide
Wrongsignal
RadioandTVwavescoulddisturb
yourdetector.Toavoidthem,
moveatsomeotherplace,reduce
thecriticalsoundandmoveslower.
Stronglymineralizedsoil andwet
sandusuallyprovokestaticand
clearsoundfromthedetector.In
thesecasesreducethecritical
soundandcontinuetosearch.
Ifintheotherhandyouare
carryingametaltoolthatyouwant
tousetodigthefoundobjects,YM
203 GRIZZLYwillproducesound
signaleverytimethesearchingcoil
nearsit.Socarrythetoolonyour
back or on yourbelt.
Practiceshowsthatyouneed40 –
50 workinghourswith thedetector
togetusedtoYM203GRIZZLY.
Logon http://www.mdetectors.com
togetallthenewsabout your
detector.

WWW.MDETECTORS.COM GRIZZLYYM203
9
Specifications:
•Transmissionfrequency:6.99KHz
•Signalfrequency:437KHz
•Weight: 1.8 g.
•Powersupply–accumulatingelements750мАh–11бр.x1.2V=
13.2V–builtin thedetector.
•1chargingdevicefor thebuiltinbatteries
•1x 33сm.Concentricsearchingcoil
•1x 27 сm.Concentricsearchingcoil
