Extech Instruments DCP60 User manual

USERGUIDE




ModelDCP60and
ModelDCP60‐220
SwitchingModeDCPowerSupplies
60V/10AAdjustable







DCP60‐EU‐ENV1.49/13
2
IntroductionandFeatures
ThankyouforselectingtheExtechDCP60(110V)orDCP60‐220(220V)SwitchingPowerSupply.
TheDCP60ishighlyefficient,incorporatesupgradedSMPScircuitrywithsmallformfactor,benefits
fromanautomaticcross‐overforCCandCV,hasthree(3)Voltage/Currentpresets,andcanbe
remotecontrolled.TheDCP60isperfectforsolvingavarietyofloadingconditionsandapplications.

Dualaction(Course/Fine)tuningprovidessmooth,accurate,andquicksettingof
Voltage/Current
Setting,changing,andverifyingthecurrentlimitlevelisconvenientandcanbe
performedwithoutoutputpolespiking
TheRemoteControlfeaturepermitsoutputON/OFFandVoltage/Currentadjustments
TheUSBportoffersPCconnectivityforprogrammingandrunningramp/soakcycleswith
20programmablesetsofVoltage/Currentandvaryingtestdurations(upto999cycles)
ApplicationsandindustrieswheretheDCP60canbeemployedincludelaboratory,
telecommunications,productiontesting,fieldtesting,DCnetworkpowering,andmore
Three(3)userprogrammableVoltage/Currentsettingsofferquickrecalloffrequently
usedtestsettings

Thisdeviceisshippedfullytestedandcalibratedand,withproperuse,willprovideyearsofreliable
service.Pleasevisitourwebsite(www.extech.com)tocheckforthelatestversionofthisUser
Guide,ProductUpdates,andCustomerSupport.



DCP60‐EU‐ENV1.49/13
3
Safety
Thismanualcontainsimportantsafetyandoperationinstructionsforcorrectuseofthepower
supply.Readthroughthemanualandpayspecialattentiontothemarkingsandlabelsofthisunit
andequipmenttobeconnected.
Payspecialattentiontothesetwotypesofnoticesusedinthismanual:
WARNING:Failuretoobservethiswarningmaycauseinjurytopersonsanddamagetopower
supplyorconnectedequipment.
CAUTION:Failuretoobservethiswarningmayresultindamagetoequipmentand
improperfunctioningofthepowersupply.
WARNING
1. Donotusethispowersupplynearwater
2. Donotoperateortouchthispowersupplywithwethands
3. Donotopenthecasingofthepowersupplywhenitisconnectedtoacmains
4. Referallservicingtoqualifiedservicepersonnelonly
5. BeforereplacingtheACfuse,determinethecauseandclearupthecausefirst
6. ReplacetheACfusewiththesametypeandratingastheoriginalfuse
7. ThemaximumoutputvoltageoftheDCP60exceeds60VDC,avoidtouchingthemetal
contactpartsattheoutputterminals
CAUTION
1. Useagrounded3pinACsource
2. Thisunitisintendedforindooruseonly
3. Donotoperateorplacethisunitinahumid,dustylocation
4. Donotoperatethisunitindirectsunlightornearanyheatsource
5. BeforepluggingintolocalACmains,checkwiththeratinglabelatthebackoftheunit
6. Donotblockanyventilationopeningsoftheunit
7. Thisunitmustbeusedwithinthespecifiedrating;regularexcessivecontinuousloadingmay
causedamagetothepowersupply
8. Thegaugesizeoftheinputpowercablemustbeatleast0.75mm2andthetotallengthof
powercablemustnotexceed3m
9. InputFuseRecommended:T3AL250V(3ATime‐Lag)



DCP60‐EU‐ENV1.49/13
4
PowerSupplyDescription
FRONTPANEL
(1)LEDpanelmeterdisplaywithCC/CVIndictor
(2)RearControlIndicator(lightswhenusingPreset/RemoteControl/Setmode)
(3)OutputVoltageControlKnob(controlsboththemainandauxiliaryoutputvoltage)
(4)OutputCurrentControlKnob(controlsboththemainandauxiliaryoutputcurrentlimit)
(5)PowerON/OFFSwitch
(6)Aux.outputterminal(max5A);Thetotalratedcurrent(Aux.+Main)is10A
REARPANEL
(7)MainOutputTerminal(Ratedfor10A);Thetotalratedcurrent(Aux.+Main)is10A
(8)ModeSelectionSwitch(Normal,Preset,RemoteControl,SetModes)
(9)Recall–PresetVoltageSelectionSwitch
(10)RemoteControlTerminal
(11)CoolingFanAirIntakeGrille
(12)ACInputPlug
(13)USBport


DCP60‐EU‐ENV1.49/13
5
ControlModeSelections
Therearefourcontrolmodesforthepowersupply:NORMAL,PRESET,SETandREMOTECONTROL
modes.SlidetheModeSelectionSwitch(8)tothedesiredMode.Thepowersupplyisfactory
presettoNormalModewithmaximumcurrentlevelCC.

NormalMode
Thisisthefactorydefaultmode;thepowersupplyoutputVoltageandCurrentarecontrolledby
thedualactiongainknobs.
1. Pushtheknobstotogglethecoarseandfinetuning,noticethesubtlechangesin
brightnessoftherelatedLED.
2. Adjusttheknobstothedesiredvaluesusingcoarseandthenfinetuning.
3. Tocheckthepresetcurrentlevel,turntheCurrentKnoblightlyinanydirection.
4. Thedisplaywillresumeitsnormalbrightnessafterafewsecondstore‐affirmthe
adjustment.
Note:Thetotalratedcurrent(Aux.+Main)is10A

PresetMode
1. Inthismode,theRearControlLightisONtoindicatethatthepanelV&Icontrolsarede‐
activated.
2. TherearethreepresetoutputsP1/P2/P3availableusingtheRecallSelectionSwitch(9)
3. Thepresetvaluesarefactorysetasshowninthetablebelow.
4. Theusercanchangetheseoutputsettings;pleaserefertothenextparagraph.

RecallNo.OutputVoltage OutputCurrent
P15VMaximum
P213.8VMaximum
P355VMaximum

SetMode
EntertheSetModebypushingSwitch(8)totheSetModeslot;thepowersupplyisnowreadyto
bepreset.

TodefinethepresetoutputP1/P2/P3
1. MovetheRecallSwitch(9)topositionP1,P2orP3
2. Adjustthefrontpanelvoltagecontrolknobtosetthedesiredvoltagevalue
3. Adjustthefrontpanelcurrentcontrolknobtosetthedesiredcurrentlimitvalue
4. RepeattheprocedurefortheremainingrecalllocationsP1,P2,P3ifdesired.
5. MoveModeSwitch(8)fromSettoPresetpositiontoconfirmthesettings.

SetModeNotes:
Allpresetsaresavedafterthepowersupplyhasbeenswitchedoff.Alwayschecktheoutput
voltageofthePresetbeforeconnectingtoaLoad.Tocheckthepresetvalues:
1. MovetheModeSwitch(8)tothePresetpositionandthensettheRecallSwitch(9)toP1,
P2orP3.
2. TheVandIsettingsforthecorrespondingRECALLP1,P2,P3memorieswillbeshownon
thepanelmeter.

DCP60‐EU‐ENV1.49/13
6
RemoteControlMode
Tocontroltheoutputvoltageandcurrentbyremotecontrolconnector(10)pleaserefertothe
sectionentitledRemoteControl.

ResettoFactoryDefaultsettings
1. SwitchOFFthepowersupply
2. Pushandholdbothfrontpanelvoltageandcurrentcontrolknobsatthesametime
3. SwitchONthepowersupplyagain
4. Releasethefrontpanelvoltageandcurrentcontrolknobs

PCInterfaceControl
TocontrolthepowersupplyusingthesuppliedSoftware,refertothePCInterfaceControl
Section.


DCP60‐EU‐ENV1.49/13
7
Operation
Note:
TheDC60MaxOutputVoltageis60VDCandthetotalratedcurrent(Aux.+Main)is10A

PoweringtheSupply
ChecktheratinglabelofthepowersupplyandensurethatitcomplieswiththeACmainsvoltage
thatistobeused.ConnectthepowersupplytotheACMainsusingtheprovidedpowercord.
EnsurethattheModeSwitch(8)issettotheNormalModeposition.TheModelDCP60requires
a110VACpowersourceandtheDCP‐220requiresa220Vpowersource.

SwitchingthePowerSupplyONandSelf‐TestInformation
Thepowersupplywillperformaseriesofself‐testswhenitisswitchedon.TheLEDandother
indicatorsonthefrontpanelwillilluminateinsequence.Whenthecoolingfanisbeingchecked,
ahighspeedwindsoundcanbeheard.Aftertheself‐tests,theCV,VandALEDindicatorsarelit
displayingvoltageand0.0current.TofindtheCCcurrentlevel,turnthecurrentcontrolknob
oneclickineitherdirection.Thecurrentdisplayreturnsto0.0afterafewseconds.Thetable
belowdetailstheself‐testsequence:

Self‐testdisplaysTest

Softwareversion

Segmentcheck
C.V.Indicatorcheck
C.C.Indicatorcheck
Rearcontrolindicatorcheck
ReturntoC.V.

Starttocheck

Overvoltageprotectioncheck

Overloadprotectioncheck

Overtemperatureprotectioncheck

Fancheck

Outputoff(remotecontrolmode)

DCP60‐EU‐ENV1.49/13
8
Usingthecontrolknobs
Therotaryencodercontrolknobshavefineandcoarsetuningwith‘clicking’movement.Push
theknobstotogglebetweencoarseandfinetuning,noticethesubtlechangesinbrightnessof
therelatedLED.Adjusttheknobstothedesiredvaluesbyusingcoarseandthenfinetuning.
Thedisplaywillresumeitsnormalbrightnessafterfewsecondstoconfirmanadjustment.
ConnectingthePowerSupplyandrunningatest
1. Connecttheequipmentundertesttothepowersupply.Red(+)isconnectedtothepositive
polarityinputoftheequipmentandBlack(‐)isconnectedtothenegativepolarityinputof
theequipment.
2. SwitchONthepowersupplyfirst;thepanelmeter&greenCVIndicatorshouldilluminate.
3. Next,switchONtheequipmentundertest;thepanelmeter&greenCVIndicatorshould
remainlitingreen.
4. Testingcannowbegin.
5. Whenfinished,switchOFFtheequipmentundertestfirstandthenswitchoffthepower
supply.

SettingupthePowersupplyinConstantCurrent(CC)mode

1. Setcurrentknobtominimum
2. SetvoltageknobtoMaximum
3. Shortoutputleadstogether
4. Turnonthepowersupply
5. Turnupcurrentknobuntilyoureachthecurrentvalueyouwanttouse.
6. Turnoffthepowersupply
7. Un‐shorttheleads


DCP60‐EU‐ENV1.49/13
9
RemoteControlOperation
Therearetwomethodsforremotelycontrollingcurrentandvoltageadjustments.Currentmustbe
controlledforbothmethodsotherwisetheunitwilldefaulttoCCmode.

REMOTECONTROL–METHOD1:UsingtwoexternalDCvoltagesources

RemoteSocketPinAssignmentforexternalvariablevoltagesource
PINFUNCTIONSREMARKS
1InternalDC+5VLowerthan50mA
2Voltageadjust0to5VExternalVDC
3Currentadjust0to5VExternalVDC
4Ground
5OutputOFFShorttogroundforOFF
6N.A.
7N.A.
8N.A.

Checktheoutputvoltagerangeofthepowersupplybyvaryingtheexternalvoltagesource.
Shortcircuitthemainoutputwith10AWGwiretochecktheCCsettingonthedisplaywhile
varyingtheexternalvoltagesource.


REMOTECONTROL–METHOD2:Usingtwo0to5KOhmvariableresistors
RemoteSocketPinAssignmentforexternalvariableresistor
PINFUNCTIONSREMARKS
1InternalDC+5VOneendofresistor
2VoltageadjustVariablelegofresistor
3CurrentadjustVariablelegofresistor
4GroundOtherendofresistor
5OutputOFFShorttogroundforOFF
6N.A.
7N.A.
8N.A.

Checktheoutputvoltagerangeofthepowersupplybyadjustingthe5Kohmvariableresistor.
Shortcircuitthemainoutputwith10AWGwiretochecktheCCsettingonthedisplaywhile
adjustingthevariableresistor.

DCP60‐EU‐ENV1.49/13
10
RemoteControlOutputON/OFF
RemoteoutputON/OFFcontrolcanbeactivatedinanyofthemodesNormal,Preset,Set,and
Remote.Reviewtheconditionsbelow:

Bydefault,Pin5isopenandtheoutputisON.
ShortingPin5toPin4(ground)switchestheoutputOFF.
WhentheoutputisOFF,theC.V.&C.C.LEDswillflash.Thepresentoutputvoltageand
currentsettingwillbeshownonthepanelmeter.
Theusercanadjusttheoutputusingthevoltage&currentcontrolknobtothedesired
valuewhentheoutputisOFF.

Remark:Useonlythe8‐pinremoteplugprovidedandconnectwith22AWGwires.See
diagrambelow.

Note: Pin numbers are marked on the black area of the socket

DCP60‐EU‐ENV1.49/13
11
PCSoftwareProgram

QuickStartSoftwareInstallationInstructions

1.CreateanewfolderonthedesktopofthePC,whichistobeloadedwiththeDCP60software.
NamethefolderDCP60oranyeasilydistinguishablename.
2.InserttheDCP60PCInterfaceSoftwareCDintotheCD/DVDdrive.WhentheAutoPlaydialog
boxappears,select“Openfoldertoviewfiles”.
3.SelectallfilesontheCDanddrag/droporcopythemintothefolderthatwascreatedinStep
1.
4.ClosetheDCP60softwareCDfileandremovetheCDfromtheCD/DVDdrive.
5.OpenthedesktopfoldercreatedinStep1,thenopentheUSBCP210xDriversV6.5for
Win_XP_S2K3_Vista_7subfolder.
6.Double‐clickontheexecutablefileCP210xVCPInstaller.exefromwithintheUSBDrivers
folder.
7.Ensureyouranti‐virusornetworksecurityapplicationissettopermittheexecutionofthe
installerfile.
8.WhentheSiliconLabspromptappears,selectInstalltoloadthenecessarydriversontoyour
PC.AnolderversionofthedriversmayalreadyresideonyourPC;therefore,ifpromptedto
updatethedrivers,selectYes.
9.Oncethedrivershavebeenloaded/updated,restartthePC.
10.AfterthePChasbeenrestarted,openthedesktopfolderoncemore.Openthehcs
subfolderandlaunchthehcs.exeexecutablefile.
11.ConnectthePowerSupplytothePCviathesuppliedUSBcable.

SoftwareOverview

ThesuppliedPCsoftwareoffersthreemainfeatures:
ExternalTimedPrograms:AutomaticVoltage/Currentsteppingandprogramcycling
InternalPresetMemory:Threepre‐programmedfixedVoltage/Currentpresets
Datalogging:Automaticrecordingofvoltageandcurrentoutputswithprogrammable
samplerate

SupportedOperatingSystems:WindowsXP/Vista/7(32bits/64bits)
Driver:SiliconLabCP210xUSBdriver(IncludedinCDROMfolder“USBCP210xDriversV6.5for
Win_XP_S2K3_Vista_7”)

ExecutableProgram:run“DCP60\hcs\hcs.exe”


DCP60‐EU‐ENV1.49/13
12
MainInterfaceDisplay

TheMaininterfaceisdividedinto7panels.



1. Displaypanel:Indicatesreal‐timepowersupplyinformation.
2. MainConfigurationandDataloggerDisplaypanel:Usethispaneltoadjustgeneral
programsettingsandtoviewExternalTimedPrograms,InternalPresetMemorydata,
andDataloggerinformation.
3. VoltageandCurrentsettingpanel:Usethispaneltosettheoutputvaluesandtoswitch
theoutputOn/Off.
4. Datahandlingpanel:Usethispaneltosave,loadandprintdata.
5. ExternalTimedProgramDescriptionfield:EnteracustomizeddescriptionforanExternal
TimedSequence.
6. Programrunningcyclesettingpanel:Setthedesirednumberofrunningcyclesforthe
ExternalTimedSequence.
7. Informationpanel:DisplaystheMaximumvoltage/current,DataloggerSamplingtime
(rate),uppervoltage/currentlimits,andsoftwareversion.


DCP60‐EU‐ENV1.49/13
13
DisplayPanel

1. ActualOutputVoltage,Current,andPowervalues
2. C.V./C.C.Modestatus
3. Settingvalues
4. OutputON/OFFstatus




OutputSettingPanel



1. VoltageOutputsetting
2. CurrentOutputsetting
3. OutputON/OFFsetting
4. SET(confirm)outputvalues

DirectlytypethevalueintheVoltageandCurrentfieldsorusetheslidertosettheVoltageand
CurrentvaluesandthenpressSETtoconfirm.ClickONorOFFtosettheoutputstatus.

Note:OncetheSliderisactive,usethekeyboardleftandrightarrowkeystofineadjustthesetting.




DCP60‐EU‐ENV1.49/13
14
SettingTab

Onthe‘Setting’page,generalprogramsettingscanbeconfiguredaslistedbelow:

Selectthedesiredlanguage.
SelectthePCCOMPortnumbertowhichthepowersupplyistobeconnected.
Setthedataloggingsamplingtime(rate)usingtheslidebar.
Settheoutputvoltageupperlimit(UVL)valuetofurthersafeguardlowvoltage
applications.ThissetsthelimitsforallTabs.
Settheoutputcurrentupperlimit(UCL)valuetofurthersafeguardlowcurrent
applications.ThissetsthelimitsforallTabs.

ClicktheDEFAULTbuttontoresetsettingstofactorydefaultvalues.

PressOKtoconfirmsettings.



DCP60‐EU‐ENV1.49/13
15
ExternalTimedProgram
ExternalTimedProgramsarecompletelyPCcontrolled.ThePCautomaticallychangestheVoltage
andCurrentoutputs(andtheirtimeduration)basedonpre‐programmedsettings.

ClickontheEXTERNALTIMEDPROGRAMtabandthendoubleclickacelltosetavalue.
Forexample(seediagrambelow),Step2Voltage,slidethebartosetthedesiredoutputlevel

OncetheSliderisactive,youcanusethekeyboardleftandrightarrowkeystofineadjustthe
setting.

Setthedurationforthisstepasshownindiagrambelow.Therangeoftimeis0to9hours/59
minutes/59seconds.Double‐clickintothecellandthenintothetimebox.Clickontheup/down
arrowbuttons.Ifthetimeissetto‘0’thestepwillbeskipped.

Settherunningcycle(numberoftimestheentiresequencewillrun)asshownbelow(rangeis0to
999cycles).Usethesliderortypedirectlyinthefieldtosetthenumberofcycles.Setthecycle
valueto‘0’tocyclethesequenceindefinitely.


ClicktheRUNbuttontostartthecycle.ClicktheSTOPbuttontostopthecycle.ClicktheCLEAR
TABLEbuttontoclearallsettings.

Warning:WhentheSequencehascompletedtheoutputsettingswillreverttothesettings
displayedontheleftsideofthiswindow.Makesureyouhavethissetappropriatelytoprevent
damagetoyourUUT.

DCP60‐EU‐ENV1.49/13
16
InternalPresetMemory
ThePCinterface’sremotePresetcapabilitysimplifiesthetediousprocessofkeyingingroupsof
entries.SinceallthedataaredisplayedatthesametimeonthePCmonitor,thepossibilityof
enteringdataincorrectlyisgreatlyreduced.Dataofdifferentgroupscanbeclassified,stored,
exportedandretrievedforuseatanytime.
Retrieveddatawillappearredincoloriftheyexceedthepresetvoltage/currentlimits.

Click‘ClearTable’todeletealldataontheDisplayTabletopreparefornewdata.

Click‘ReadforPS’toretrievedatafromthePowerSupply.



DCP60‐EU‐ENV1.49/13
17
DataloggerWindow

1. Adjustslidertomovethedisplayedwaveformleftandright
2. Adjustslidertozoominandout
Note:OncetheSliderisactive,youcanuseyourkeyboardleftandrightarrowkeystofineadjust
yoursetting.

ThegraphicaldataloggerwindowisusedtodisplayoutputVoltage,Current,andPowerovertime.


DCP60‐EU‐ENV1.49/13
18
Save,Load,andPrintData

ExternalTimedProgramtab
ThebuttonsareusedtoSaveandLoadanExternalTimedProgramorPrintthecurrentsettings.
Ifdesired,addadescriptionintheProgramDescriptionfield.

ClicktosaveanExternalTimedProgramtoaCSVfile.
ClicktoopenandloadsettingsfromaCSVfile.
Clicktoprintthesettings.


InternalPresetMemorytab
ThebuttonsareusedtoSaveandLoadInternalPresetdataorPrintthecurrentsettings.
Ifdesired,addadescriptionintheProgramDescriptionfield.

ClicktosaveanInternalPresetMemorysettoaCSVfile.
ClicktoopenandloadasettingfromCSVfile.
Clicktoprintasetting.


Datalogtab
ThebuttonsareusedtoSaveandLoadaDatalogfileorPrintthecurrentsettings.
Ifdesired,addadescriptionintheProgramDescriptionfield.

SavethedatainCSVformatforlateranalysis.
OpenandloaddatafromCSVdocument.
Printthedata.

DCP60‐EU‐ENV1.49/13
19
SoftwareProgrammingCommandSet(Protocol)

Commandlineformat:
COMMAND<parameter1><parameter2>...[CR]

Commandcode&returnvalueFunctionExample
InputCommand:
GMAX[CR]
Returnvalue:
<voltage><current>[CR]
OK[CR]

GetPSmaximumVoltage&Currentvalue
<voltage>=???
<current>=???

Inputcommand:
GMAX[CR]
Returnvalue:
180200[CR]
OK[CR]
Meaning:
MaximumVoltageis18.0V
MaximumCurrentis20.0A
InputCommand:
VOLT<voltage>[CR]
Returnvalue:
OK[CR]

PresetVoltagevalue
<voltage>=000<???<Max‐Volt
*Max‐Voltvaluerefertoproduct
specification

Inputcommand:
VOLT127[CR]
Returnvalue:
OK[CR]
Meaning:
SetVoltagevalueas12.7V
InputCommand:
CURR<current>[CR]
Returnvalue:
OK[CR]

PresetCurrentvalue
<current>=000<???<Max‐Curr
*Max‐Currvaluerefertoproduct
specification

Inputcommand:
CURR120[CR]
Returnvalue:
OK[CR]
Meaning:
SetCurrentvalueas12.0A
InputCommand:
GETS[CR]
Returnvalue:
<voltage><current>[CR]
OK[CR]

GetPSpresetVoltage&Currentvalue
<voltage>=???
<current>=???

Inputcommand:
GETS[CR]
Returnvalue:
150180[CR]
OK[CR]
Meaning:
TheVoltagevaluesetat15V
andCurrentvaluesetat18A
InputCommand:
GETD[CR]
Returnvalue:
<voltage><current><status>[CR]
OK[CR]

GetPSDisplayvaluesofVoltage,Current
and
StatusofCC/CV
<voltage>=????
<current>=????
<status>=0/1(0=CV,1=CC)

Inputcommand:
GETD[CR]
Returnvalue:
150016001[CR]
OK[CR]
Meaning:
ThePSDisplayvalueis15Vand16A.
ItisinCCmode.
InputCommand:
GOVP[CR]
Returnvalue:
<voltage>[CR]
OK[CR]

GetpresetupperlimitofoutputVoltage
<voltage>=???

Inputcommand:
GOVP[CR]
Returnvalue:
111[CR]
OK[CR]
Meaning:
ThepresetupperlimitofoutputVoltage
is11.1V
InputCommand:
SOVP<voltage>[CR]
Returnvalue:
OK[CR]

PresetupperlimitofoutputVoltage
<voltage>=000<???<Max‐Volt
*Max‐Voltvaluerefertoproduct
specification

Inputcommand:
SOVP151[CR]
Returnvalue:
OK[CR]
Meaning:
PresetupperlimitofoutputVoltageas
15.1V

InputCommand:GetpresetupperlimitofoutputCurrentInputcommand:

DCP60‐EU‐ENV1.49/13
20
GOCP[CR]
Returnvalue:
<current>[CR]
OK[CR]

<current>=???

GOCP[CR]
Returnvalue:
111[CR]
OK[CR]
Meaning:
ThepresetupperlimitofoutputCurrent
is11.1A
InputCommand:
SOCP<current>[CR]
Returnvalue:
OK[CR]
PresetupperlimitofoutputCurrent
<current>=000<???<Max‐Curr
*Max‐Currvaluerefertoproduct
specification
Inputcommand:
SOCP151[CR]
Returnvalue:
OK[CR]
Meaning:
PresetupperlimitofoutputCurrentas
15.1A
InputCommand:
PROM<voltage0><current0>
<voltage1><current1>
<voltage2><current2>[CR]
Returnvalue:
OK[CR]

SaveVoltageandCurrentvalueinto3PS
memorylocations
<voltageX>=???
<currentX>=???
(Xismemorylocationnumberstartfrom0
to2)

Inputcommand:
PROM111111022122033133[CR]
Returnvalue:
OK[CR]
Meaning:
PresetMemory0as11.1Vand11.1A
PresetMemory1as2.2Vand12.2A
PresetMemory2as3.3Vand13.3A
InputCommand:
GETM[CR]
Returnvalue:
<voltage0><current0>[CR]
<voltage1><current1>[CR]
<voltage2><current2>[CR]
OK[CR]
GetsavedVoltageandCurrentvaluefrom3
PSmemoryloctions
<voltageX>=???
<currentX>=???
(Xismemorylocationnumberstartfrom0
to2)

Inputcommand:
GETM[CR]
Returnvalue:
111111[CR]
122122[CR]
133133[CR]
OK[CR]
Meaning:
PSreturnfollowingpresetvaluefrom
memorylocations;
Memory0is11.1Vand11.1A
Memory1is12.2Vand12.2A
Memory2is13.3Vand13.3A
InputCommand:
RUNM<memory>[CR]
Returnvalue:
OK[CR]

SetVoltageandCurrentusingvaluessaved
inmemorylocations
<memory>=0/1/2

Inputcommand:
RUNM1[CR]
Returnvalue:
OK[CR]
Meaning:
SetVoltageandCurrentusingvalues
savedinmemorylocation1
