1. IntroductionandFeatures
ThankyouforselectingtheExtechDCP42SwitchingModePowerSupply.Thisnewlyre‐designed
laboratorygradepowersupplydiffersfromaconventionalpowersupplyinthatitcancalculate
andchangethevoltageandcurrentlimitpointsaccordingtotheavailablemaximumpower.
Thereforethemaximumlimitsofthevoltageandcurrentarechangeableaccordingtotherated
power.Aconventionalpowersupplyhasonlyasetmaximumvoltageandcurrentsuchthatallof
theoperatingV&Amustfallwithintheselimits.TheDCP42offerscostsavingandspacesaving
advantagesasoneconstant‐powerpowersupplycandotheworkofseveralconventionalpower
supplies.

TheDCP42ishighlyefficient,incorporatesupgradedSMPScircuitrywithsmallformfactor,benefits
fromanautomaticcross‐overforCCandCV,hasthree(3)Voltage/Currentpresets,andcanbe
remotecontrolled.TheDCP42isperfectforsolvingavarietyofloadingconditionsandapplications.
Featuresincludethefollowing:

Dualaction(Course/Fine)tuningprovidessmooth,accurate,andquicksettingof
Voltage/Current
Setting,changing,andverifyingthecurrentlimitlevelisconvenientandcanbe
performedwithoutoutputpolespiking
TheRemoteControlfeaturepermitsoutputON/OFFandVoltage/Currentadjustments
withouttheneedtotouchthefrontpanelofthepowersupply
TheUSBportoffersPCconnectivityforprogrammingandrunningramp/soakcycleswith
20programmablesetsofVoltage/Currentandvaryingtestdurations(upto999cycles)
TheDCrampandwaveformgeneratorcaneitherbepanelsetorsetbythesupplied
softwarewhichpreviewsthefinalwaveform.
ApplicationsandindustrieswheretheDCP42canbeemployedincludelaboratory,
telecommunications,productiontesting,fieldtesting,DCnetworkpowering,andmore
Three(3)userprogrammableVoltage/Currentsettingsofferquickrecalloffrequently
usedtestsettings.

Thisdeviceisshippedfullytestedandcalibratedand,withproperuse,willprovideyearsofreliable
service.Pleasevisitourwebsite(www.extech.com)tocheckforthelatestversionofthisUser
Guide,ProductUpdates,andCustomerSupport.



DCP42‐en‐GB_V1.512/14
5
2. Safety
Thismanualcontainsimportantsafetyandoperationinstructionsforcorrectuseofthepower
supply.Readthroughthemanualandpayspecialattentiontothemarkingsandlabelsofthisunit
andequipmenttobeconnected.
Payspecialattentiontothesetwotypesofnoticesusedinthismanual:
WARNING:Failuretoobservethiswarningmaycauseinjurytopersonsanddamagetopower
supplyorconnectedequipment.
CAUTION:Failuretoobservethiswarningmayresultindamagetoequipmentand
improperfunctioningofthepowersupply.
WARNING
Donotusethispowersupplynearwater
Donotoperateortouchthispowersupplywithwethands
Donotopenthecasingofthepowersupplywhenitisconnectedtoacmains
Referallservicingtoqualifiedservicepersonnelonly
BeforereplacingtheACfuse,determinethecauseandclearupthecausefirst
ReplacetheACfusewiththesametypeandratingastheoriginalfuse
ThemaximumoutputvoltageoftheDCP42exceeds60VDC,avoidtouchingthemetal
contactpartsattheoutputterminals
CAUTION
Useagrounded3pinACsource
Thisunitisintendedforindooruseonly
Donotoperateorplacethisunitinahumid,dustylocation
Donotoperatethisunitindirectsunlightornearanyheatsource
BeforepluggingintolocalACmains,checktheratinglabelatthebackoftheunit
Donotblockanyventilationopeningsoftheunit
Thisunitmustbeusedwithinthespecifiedrating;regularexcessivecontinuousloadingmay
causedamagetothepowersupply
Thegaugesizeoftheinputpowercablemustbeatleast0.75mm2andthetotallengthof
powercablemustnotexceed3m
InputFuseRecommended:T3AL250V(3ATime‐Lag)
ENVIRONMENTALCONDITIONSFOROPERATION
10‐80%R.H.(RelativeHumidity)
Altitudeupto2000m(6561ft.)
Installationcategory:CAT2
Pollutiondegree:2
Mainssupplyvoltagefluctuationupto±10%ofnormalvoltage


DCP42‐en‐GB_V1.512/14
6
3. PowerSupplyDescription

(1)LEDpanelmeterdisplaywithCC/CV/WIndictor
(2)RemoteControlIndicator(RemoteControl/USBmode)
(3)OutputVoltageControlKnob
(4)OutputCurrentControlKnob
(5)PowerON/OFFSwitch
(6)6buttonKeypad(withillumination):
‐PresetKeyd1,2&3
‐MenuKey(ShiftKey)
‐Lock/UnlockKey(A/WmeterKey)
‐OutputON/OFF(ΔV/ΔtKey)
(7)OutputSafetyJacks(Rated10A)
(8)USBRemoteControlport(Foraccesstocomputertoruncyclicaloperationwithprogrammable
voltage,current,periodtimeandcycle)
(9)RemoteSensingTerminal
Warning!Shortingtheremotesensingterminalorconnectingthesensingterminalwiththe
polarityreversedwilldamagethepowersupply
(10)RemoteControlTerminal
(11)ACInletsocket(withfuseholder)


DCP42‐en‐GB_V1.512/14
7
4. ControlModes
Therearefourcontrolmodesforthepowersupply:NORMAL,PRESET,SET,andREMOTECONTROL
modes.ThepowersupplyisfactorypresettoNormalModewithmaximumcurrentlevelCC.
4.1NormalMode
Thisisthefactorydefaultmode;thepowersupplyoutputVoltageandCurrentarecontrolledby
thedualactiongainknobs.
1. Pushtheknobstotogglethecoarseandfinetuning,noticethesubtlechangesin
brightnessoftherelatedLED.
2. Adjusttheknobstothedesiredvaluesusingcoarseandthenfinetuning.
3. Tocheckthepresetcurrentlevel,turntheCurrentKnoblightlyinanydirection.
4. Thedisplaywillresumeitsnormalbrightnessafterafewsecondstore‐affirmthe
adjustment.
4.2PresetMode
1. TherearethreepresetoutputsP1/P2/P3available.
2. PressthePresetbutton(1,2,or3)toenterthepresetmode(thebutton’slightwill
switchON).
3. Thepresetvaluesarefactorysetasshowninthetablebelowandareretainedevenafter
theunithasbeenpowereddown.
4. Theusercanchangetheseoutputsettingsusingthevoltageandcurrentknobs.

RecallNo.OutputVoltage OutputCurrent
P15VMaximum
P213.8VMaximum
P3 40VMaximum
4.3SetMode
EntertheSetModebypushingandholdingtheMENUbuttonfor3seconds.IntheSetModethe
usercanadjusttheΔV/Δtvalue,accesstheremoteControlmode,orperformaFactoryReset
recallfunction.Note:Ifnoselectionismadeafter10secondsthepowersupplydefaultstoits
priorsettings.

4.3.1SettingtheΔV/Δtvalue
a.PressandholdtheMENUbuttonfor3secondstoaccesstheSetMode.
b.TurntheVoltagecontrolknobuntilthepanelmeterdisplays“dudtSet”asshownbelowand
thenpresstheVoltagecontrolknobtoentertheΔV/Δtsettingmode.

c.AdjusttheVoltageandCurrentcontrolknobsasdesiredtosettheΔV/Δtvalue.Furtherdetails
areprovidedinthededicatedsectionforΔV/Δtmodelaterinthisguide.
d.Whenfinished,presstheVoltagecontrolknobtoconfirmandreturntoSetmenu
e.PresstheMenukeytoexittheSetmenu
f.TostarttheΔV/Δtfunction,presstheSHIFTbuttonandthenpresstheΔV/Δtbuttontorun,
g.TostoptheΔV/Δtfunction,presstheSHIFTbuttonandthenpresstheΔV/Δtbuttonagain.


DCP42‐en‐GB_V1.512/14
8
4.3.2ActivatingtheRemoteControlMode
a.PressandholdtheMENUbuttonfor3seconds.
b.TurntheVoltagecontrolknobuntilthepanelmeterdisplays“rCSet”asshownbelowand
thenpresstheVoltagecontrolknobtoconfirmentryintotheremotecontrolmode.

c.TurntheCurrentcontrolknobtoselectremoteYESorNO.
d.PresstheVoltagecontrolknobtoconfirmandtoreturntotheSetmenu.
e.PresstheMenubuttontoexittheSetmenu.
f.DetailsoftheremotecontrolmodearelocatedinthededicateRemoteControlsectionlaterin
thisguide.
Note:AfteractivatingtheRemoteControlMode,allfunctionkeyslocatedonthefrontpanelwill
belocked(theLock/UnlockbuttonlightswitchesON).

4.3.3DeactivatingtheRemoteControlMode
a. PresstheLock/Unlockbuttontounlockallofthefunctionkeys
b. Repeatstepsatocinthe‘ActivatingtheRemoteControlMode’sectionaboveandset
RemoteControltoNOandthenpressthevoltagecontrolknob.

4.3.4FactoryDefaultReset
a.PressandholdtheMENUbuttonfor3seconds.
b.TurntheVoltagecontrolknobuntilthepanelmeterdisplays“FACSSEt”asshownbelowand
thenpresstheVoltagecontrolknobtoconfirmentryintotheFactoryResetmode.

c.TurntheCurrentcontrolknobtoselectYesorNo.
d.PresstheVoltagecontrolknobtoconfirmandtoreturntotheSetmenu.
e.PresstheMenubuttontoexittheSetmenu.
f.ThePowerSupplywillrebootandreverttoitsFactoryDefaultsettings.









DCP42‐en‐GB_V1.512/14
9
5. Operation
Note:TheDCP42TotalOutputVoltageRangeis42VDCandtheTotalRatedCurrentis0to10ADC

5.1PoweringtheSupply
ChecktheratinglabelofthepowersupplyandensurethatitcomplieswiththeACmainsvoltage
thatistobeused.ConnectthepowersupplytotheACMainsusingtheprovidedpowercord.
5.2SwitchingthePowerSupplyONandSelf‐TestInformation
Thepowersupplywillperformaseriesofself‐testswhenitisswitchedON.TheLEDandother
indicatorsonthefrontpanelwillilluminateinsequence.Whenthecoolingfanisbeingchecked,
ahighspeedwindsoundcanbeheard.Aftertheself‐tests,theCV,VandALEDindicatorsarelit
andtheunitdisplaysvoltageand0.0current.TofindtheCCcurrentlevel,turnthecurrent
controlknoboneclickineitherdirection.Thecurrentdisplayreturnsto0.0afterafewseconds.
5.3UsingtheControlknobs
Therotaryencodercontrolknobshavefineandcoarsetuningwith‘clicking’movement.Push
theknobstotogglebetweencoarseandfinetuning,noticethesubtlechangesinbrightnessof
therelatedLED.Adjusttheknobstothedesiredvaluesbyusingcoarseandthenfinetuning.
Thedisplaywillresumeitsnormalbrightnessafterfewsecondstoconfirmanadjustment.
5.4ConnectingthePowerSupplyandrunningaTest
1. Connecttheequipmentundertesttothepowersupply.Red(+)isconnectedtothepositive
polarityinputoftheequipmentandBlack(‐)isconnectedtothenegativepolarityinputof
theequipment.
2. SwitchONthepowersupplyfirst;thepanelmeter&greenCVIndicatorshouldilluminate.
3. Next,switchONtheequipmentundertest;thepanelmeter&greenCVIndicatorshould
remainlitingreen.
4. Testingcannowbegin.
5. Whenfinished,switchOFFtheequipmentundertestfirstandthenswitchoffthepower
supply.
5.5KeypadLockoutfunction
1. PressLOCK/UNLOCKtolockorunlockallofthefunctionbuttonsandcontrolknobsonthe
frontpanel.
2. TheLOCK/UNLOCKbuttonlightswitchesONwhenthepush‐buttonsarelocked.
5.6ManualOutputON/OFF
1. PressOUTPUTON/OFFbuttontomanuallysettheoutputONorOFF.
2. TheOUTPUTON/OFFbuttonlightswitchesONwhentheoutputisON.
5.7Ammeter/WattmeterSelection
1. WiththeoutputONandallpresetsOFF,pressSHIFTandthenpressPRESET.
2. PresstheSHIFTbuttonagainandthenpresstheLOCK/UNLOCKbuttontochangefrom
AmmetermodetoWattmetermode.
3. TochangebacktoAmmetermodefromWattmetermode,presstheSHIFTbuttonandthen
presstheLOCK/UNLOCKbutton.

DCP42‐en‐GB_V1.512/14
10
6. SupplementalFunctions
6.1ΔV/ΔtFunction
Thereare3DCvoltagegeneratorsettings(A,B,andC).
Preset1=A
Preset2=B
Preset3=C
ΔVa‐b(fromvoltagelevelAtovoltagelevelB).
Δta‐b(timeinsecondsfromvoltagelevelAtolevelB,thistransittimeisadjustablefrom0to20
seconds)
6.1.2SettingtheDCgeneratorvoltagelevel
Thereare3generatorvoltagelevelspresets(A,B,andC).
PressthePresetbutton1,2and3andadjustthevoltagetothedesiredvalue.

6.1.2SettingtheΔt
Thereare6setsofΔtavailable,turningtheVoltagecontrolknobcyclesthroughthefollowing
sequence:AB→BA→AC→CA→BC→CB
UsingtheABsettingasanexample,turntheVoltagecontrolknobuntilA‐bappearsonthe
voltmeterdisplayandthenturntheCurrentcontrolknobtosettodesiredtransittimeΔt(5
secondsforexample).

6.1.3GeneratingRamp‐UporRamp‐DownDCoutputcycles
Rampupgeneratorexample:SetA=5V;B=10V;Δta‐b=5seconds
1. ConnectasuitableloadtotheoutputandturnONtheoutputbypressingthe“OUTPUT
ON/OFF”button;notetheoutputLEDindicator.
2. Push“Preset1”andnotetheoutputvoltageof5V.Press“Preset2”andnotethatthe
outputvoltagerisesto10Vin5secondsshowingarampupvoltage(theoutputwill
remainat10V).
3. Pressing“Preset1”willnowgeneratearampdownvoltagefrom10Vto5Vin5seconds
andwillremainatthe5Vlevel.

Note:Thefinaloutputvoltagelevelwillbethelastvoltagelevelgenerated.



DCP42‐en‐GB_V1.512/14
11
6.2FunctionA/B/CWaveformGenerator
Preset1=A
Preset2=B
Preset3=C
FUNC(A/B/C)setstheduration(from0to600seconds)thatthevoltagegeneratorremainsON
atthespecifiedoutputvoltagelevelbeforemovingtoanothervoltagelevel.

6.2.1SetFUNC(A/B/C):
1. EntertheΔV/Δtsettingfirst(RefertotheSetModesection4.3.)
2. TurntheVoltagecontrolknobtoselectthedesiredfunctionandthenturntheCurrent
controlknobtosetthetimeperiod(0to600seconds)forthechosenvoltagelevel.
3. PressingtheCurrentcontrolknobtogglescoarseandfinetuningofthetimeperiod.
4. Togeneratewaveforms,theFuncA/B/CbuttonisusedinconjunctionwithΔV/Δtbutton(the
timeperiodfromonevoltageleveltoanothervoltagelevel)
5. Usingtheabovefunctionssimultaneously,3reversiblepairs(AB&BA,BC&CB,AC&CA)can
beusedtogeneratewaveforms.

Example1:Pulsewaveformwith3secat10Vand1secat5V.
SetA(Preset1)=5V,setB(Preset2)=10V
SetFuncA=1secondbyturningtheCurrentcontrolknob
FuncB=3secondsusingthesameprocedureasabove
SetΔta‐b=0,SetΔtb‐a=0

6.2.2GeneratingWaveForm
TogeneratethewaveformpushSHIFTandthenpresstheΔV/Δtbutton
ThewaveformwillrepeatcyclicallyuntiltheSHIFTbuttonandthentheΔV/Δtbuttonispressed.

Example2:Trianglewaveform
SetA=5V,B=10V
SetΔta‐b=3seconds,SetΔtb‐a=3seconds
SetFunc.A=3seconds,SetFunc.B=3seconds

Note:Thewaveformgeneratorcanbeoperatedviatheremoteprogrammingsoftware(with
waveformpreviewandgraphicaldataloggingoutputpresentationfeatures).Detailsareprovided
inthesection4titled‘PCSoftwareProgram’.
PleaseverifythatthePresetkeysarebothlitandthatoneisflashing.Theflashinglightwilljump
fromonetotheother,AtoB,thenBtoA.ThewaveformwillrepeatcyclicallyuntilSHIFTand
thenΔV/Δtarepressedagain.Examples3,4,and5areprovidedinAppendixAlaterinthis
guide.

DCP42‐en‐GB_V1.512/14
12
6.3UpperVoltageandCurrentLimits
Whenthevoltageorcurrentattheoutputterminalexceedsthemaximumallowablelimits,the
outputwillautomaticallyswitchOFF.Thisadditionalprotectionfeatureisnecessaryforapower
supplywithsuchawiderangeofvoltageandcurrentcapabilities.
TosettheUVL:

1. TosettheUVL:PresstheSHIFTbuttonandthenpresstheVoltagecontrolknob.The
voltmeterwillshowthecurrentlimitsettingandtheAmmeterwillshowSuul.
2. TurntheVoltagecontrolknobtothedesiredlimitvalue.PressSHIFTtoconfirmandto
returntonormaloperation.
3. TosettheUCL,pressSHIFTandthenpresstheCurrentcontrolknob.TheAmmeterwill
showthecurrentlimitsettingandtheVoltmeterwillshowSUCL.
4. TurntheCurrentcontrolknobtothedesiredlimitvalue.PressSHIFTtoconfirmandto
returntonormaloperation.
Note:TheUVLandUCLsettingsdefaulttothemaximumoutputvalue.
6.4RemoteSensing
Note:ObservewarningsdisplayedbythePowerSupply,anincorrectdisconnectionsequence
willdamagethePowerSupply
Warnings:NevershorttheRemoteSensingTerminalandalwaysdisconnecttheRemoteSensing
Terminalfirst.
6.4.1Connection
1.Firstcompletethepowerconnectionsbetweenpowersupplyandequipment.
2.Checkandensurethatthepowerconnectionsaresecure.
3.MakeconnectionsbetweenRemoteSensingandequipment.

Warning!:NevershorttheRemoteSensingTerminalandneverconnecttheRemoteSensing
Terminalinreversepolarity

ThediagrambelowshowstheconnectionsforRemoteSensing,Poweroutput,andEquipment.
TheremotesensingwireshouldbeATLEAST22AWGwiresize.

6.4.2Disconnection
Warning!Incorrectdisconnectsequenceswilldamagethepowersupply
1.Firstdisconnecttheremotesensingconnections.
2.Thendisconnectthepowerconnectionsbetweenthepowersupplyandequipment.


DCP42‐en‐GB_V1.512/14
13
6.5RemoteControlOperation
Therearetwomethodsforremotelycontrollingcurrentandvoltageadjustments.Currentmust
becontrolledforbothmethodsotherwisetheunitwilldefaulttoCCmode.

6.5.1REMOTECONTROL–METHOD1:UsingtwoexternalDCvoltagesources

RemoteSocketPinAssignmentforexternalvariablevoltagesource
PINFUNCTIONSREMARKS
1InternalDC+5VLowerthan50mA
2Voltageadjust0to5V
3Currentadjust0to5V
4Ground
5OutputOFFShorttoground
6N.A.
7N.A.
8N.A.

Checktheoutputvoltagerangeofthepowersupplybyvaryingtheexternalvoltagesource.
Shortcircuitthemainoutputwith14AWGwiretochecktheCCsettingonthedisplaywhile
varyingtheexternalvoltagesource.


6.5.2REMOTECONTROL–METHOD2:Usingtwo0to5KOhmvariableresistors
RemoteSocketPinAssignmentforexternalvariableresistor
PINFUNCTIONSREMARKS
1InternalDC+5VOneendofresistor
2VoltageadjustVariablelegofresistor
3CurrentadjustVariablelegofresistor
4GroundOtherendofresistor
5OutputOFFShorttoground
6N.A.
7N.A.
8N.A.

Checktheoutputvoltagerangeofthepowersupplybyadjustingthe5Kohmvariableresistor.
Shortcircuitthemainoutputwith14AWGwiretochecktheCCsettingonthedisplaywhile
adjustingthevariableresistor.

DCP42‐en‐GB_V1.512/14
14
6.5.3RemoteControlOutputON/OFF
RemoteoutputON/OFFcontrolcanbeactivatedinanyofthemodesNormal,Preset,Set,and
Remote.Reviewtheconditionsbelow:

Bydefault,Pin5isopenandtheoutputisON.
ShortingPin5toPin4(ground)switchestheoutputOFF.
WhentheoutputisOFF,theC.V.&C.C.LEDswillflash.Thepresentoutputvoltageand
currentsettingwillbeshownonthepanelmeter.
Theusercanadjusttheoutputusingthevoltage&currentcontrolknobtothedesired
valuewhentheoutputisOFF.

Remark:Useonlythe8‐pinremoteplugprovidedandconnectwith22AWGwires.See
diagrambelow.

Note: Pin numbers are marked on the black area of the socket
7. PCSoftwareProgram
ThismeterhasthecapabilitytoconnecttoandcommunicatewithaPC.Toinstallandusethe
software,pleaserefertotheinstructionsprovidedonthesuppliedCD‐ROMand/ortheinstructions
providedintheHELPUtilitywithinthesoftwareprogram.

Checkthesoftwaredownloadpageofthewebsitewww.extech.comforthelatestversionofthePC
softwareanditsoperatingsystemcompatibility.
8. AutomaticOutputStepPrograms
TousetheAutomaticOutputSteputilitytheusermustfirstbecomefamiliarwiththePC
interfaceandthesuppliedsoftware.Toinstallandusethesoftware,pleaserefertothe
instructionsprovidedonthesuppliedCD‐ROMand/ortheinstructionsprovidedintheHELP
Utilitywithinthesoftwareprogram.Oncefamiliaritywiththesoftwareisachievedrefertothe
instructionsbelow:

TheunitcanbeexternallyprogrammedviaaPCtorun20steps,eachstepwithapreset
voltage/currentlimitingvalueandapresettimeperiodof1secondto99minutes.Thetimed
programcanbesettorunonecycleoruptoaninfinitenumberofcycles.


DCP42‐en‐GB_V1.512/14
15
8.1ExternalTimedProgramWindow


ClearTable:DeletealldataintheDisplayTableandpreparefornewdataentry.
Run(Stop):TorunandstoptheTimedProgram.
RunningCycle:Enterthenumberofdesiredrunningcycleshere.

Thenumericalrangeforcyclingis0‐999.Notethatthemaximumcyclescanbesetto‘infinite’
when“0”cyclesisentered.TheExternalTimedProgramallowstheusertosettheoutputeither
ONorOFFbyselectingtheboxesinthelastcolumn.

8.2OutputON/OFFfunction
OutputONTicked:OutputisONforthatstep
OutputONUn‐ticked:OutputisOFFforthatstep.

8.3AutomaticTimedOutputOperation
1.Clearolddatainthetablebyclicking[ClearTable].
2.Enterdatainthetableusing'Up‐Down‐Left‐Right'keysonPCkeyboardfornewlocations.
3.Datathatexceedtheratedvoltageandcurrentwillnotbeaccepted.
4.VoltagesthatexceedtheUVL(UpperVoltageLimit)willnotbeaccepted.
5.Ifretrievedorentered,datathatexceedthepresetUpperorLowerLimitsettingforvoltage/
current/timeperiodswillswitchtoredincolorandwillnotbeaccepted.
6.Whentherunningtimeperiodofanystepissettozerominutesandzeroseconds,thisstep
becomestheterminatingstepandthecyclewillendatthisstep.Intheaboveexamplethereare
4stepseachwitha2secondtimeperiod,ifstep3issettozerominutes&seconds,theprogram
willonlycyclestep1and2andwillnotgotostep4.
7.Enterthenumberofdesiredrunningcycles.
8.Click[Run]toruntheExternalTimeProgram.TheExternalTimedProgramfeatureallowsthe
usertosettheoutputeitherONorOFFbyselectingtheboxesinthelastcolumn.

DCP42‐en‐GB_V1.512/14
16
9. Appendix–AdditionalOperationalExamples
ExamplesofFuncA/B/CandWaveFormGeneratorFeatures

TheseexamplesarecontinuedfromExamples1and2inSection6.2earlierinthisguide.

Example3‐Irregularwaveform
SetA=5V,B=10V
SetΔta‐b=1second,SetΔtb‐a=2seconds
SetFunc.A=3seconds,SetFunc.B=3seconds


Example4‐Irregularwaveform
SetA=5V,B=10V
SetΔta‐b=2second,SetΔtb‐a=2seconds
SetFunc.A=2seconds,SetFunc.B=6seconds


Example5‐Irregularwaveform
SetA=5V,B=10V
SetΔta‐b=2second,SetΔtb‐a=0seconds
SetFunc.A=4seconds,SetFunc.B=3seconds


Example6‐Irregularwaveform
SetA=5V,B=10V
SetΔta‐b=4second,SetΔtb‐a=4seconds
SetFunc.A=2seconds,SetFunc.B=2seconds

DCP42‐en‐GB_V1.512/14
17
10.Specifications
Output
VariableOutputVoltage(LimitedtoO/P160W)0‐42VDC
VariableOutputCurrent(LimitedtoO/P160W)0‐10A
NominalOutputPower(42V/3.8A)160W
PresetOutputs
Preset1(P1)Voltage:5V±0.2V,Current:10A±0.2A
Preset2(P2)Voltage:13.8V±0.2V,Current:10A±0.2A
Preset3(P3)Voltage:20V±0.2V,Current:4.0A±0.2A
VoltageRegulation
Load(0‐100%RatedCurrent)≤50mV
Line(90‐264VACVariation)≤10mV
CurrentRegulation
Load(10‐90%RatedVoltage)≤50mA
Line(90‐264VACVariation)≤10mA
Ripple&Noise
Ripple&Noise(RMS)Voltage≤8mVrms
Ripple&Noise(peak‐peak)Voltage≤80mVp‐p
CurrentRipple&Noise(peak‐peak)≤50mA
MeterType&Accuracy
VoltageMeter4DigitLEDDisplay±(0.1%+5counts)
CurrentMeter4DigitLEDDisplay±(0.1%+5counts)
Resolution
OutputVoltageResolution0.02V
OutputCurrentResolution0.01A
SettingAccuracy
OutputVoltage±(0.2%+0.05)
OutputCurrent±(0.2%+0.05)
OutputRise&FallTime
OutputT‐ON(50%LoadCurrent)≤80ms
OutputT‐ON(100%LoadCurrent)≤1200ms
OutputT‐OFF(50%LoadCurrent)≤90ms
OutputT‐OFF(100%LoadCurrent)≤50ms
Power
OperationInputVoltageRange90–264VAC
OperationInputVoltageFrequencyRange45‐65Hz~
NoLoadInputCurrent
(230Vac/100Vac):≤220mA
FullLoadInputCurrent
(230Vac/100Vac):≤1.0A/2.3A
PowerConsumption
(230Vac/100Vac):≤190W/200W@42V/3.8A
Efficiency
(230Vac/100Vac):≥86%/84%@42V/3.8A

DCP42‐en‐GB_V1.512/14
18
SwitchingFrequency
45‐55KHz~
TrackingOverVoltageProtections
O/P0‐10V:SetVoltage+(1.0±0.3V)
O/P10‐42V:105‐125%ofsetvoltage
PowerFactor
ControlPowerfactorcorrection:>0.91atoptimalload
CoolingMethod
NaturalConvection
LeakageCurrent
≤2mA
Protections
Adjustableuppervoltagelimit,Adjustableuppercurrentlimit,ShortCircuit,Overload,
OverTemperature,TrackingOVP
InputFuse
T3.15AL250V

Safety&EMC
SafetyStandardCE:EN61010
WithstandingVoltageI/P‐O/P:3.0KVac,I/P‐F/G:1.5KVac,O/P‐F/G:0.5KVac
InsulationResistanceI/P‐O/P,I/P‐F/G,O/P‐F/G:100Mohm@500Vdc
EMCCE:EN55011
HarmonicsCurrentEmissionEN61000‐3‐2
VoltageFluctuations&FlickerEN61000‐3‐3
EMCImmunityEN61000‐6‐1

Environmental
WorkingTemperature0to+40°C(32to+104°F)
WorkingHumidity10‐80%RHNon‐condensing
StorageTemperatureandHumidity‐15to+70°C(5to158°F)10‐85%RHNon‐condensing
PollutionDegreeClass2

General
CaseMaterialPolycarbonateFrontPanelandElectro‐GalvanizedSteelEnclosure
CaseProtectionIP20
ConnectionDia.4.0mmSafetyJackx3(OutputPositive,NegativeandFunctionGround)
Dimensions(WxHxD)200x90x250mm(7.9x3.6x10inch)
Weight2.5kg(5.5lb)


DCP42‐en‐GB_V1.512/14
19
11.Troubleshooting
OUP:OverVoltageProtection
Thisunithasabuilt‐intrackingovervoltageprotectionfeature.Intheeventofoutputvoltage
becominggreaterthanthesetvalue(seespecifiedrangefromspecificationstable),protection
willbetriggeredandtheoutputpowerwillbecutoffandOUPwarningappearsasbelow.

Toresetthewarning,switchofftheunitandremoveallloading.
Switchtheunitbackonagainanditshouldresumenormaloperation.
Ifthisproblempersists,pleasecontactthecustomercaredepartmentorthepointofpurchase.

OTP:OverTemperatureProtection
Thereisathermosensorinsidetheunittomonitorandpreventtheunitfromundulyheating
internally.WhenanOTPerroroccurs,thereisnooutputandthefollowingwarningwillappear
ontheLEDdisplay.

Whenthiswarningappears,switchofftheunitandremoveallloading.
Checktheloadandoutputsetting.Allowtheunittocoolforatleast30minutes.
Checktoseeifanyventilationholesareblocked,alsocheckthatthereissufficientclearance
aroundthepowersupply.
Listencarefullyfortheshortwindsoundemanatingfromthecoolingfanwhentheunitis
switchedONagain.Ifthewindsoundisnotdetected,thefanmaybefaulty;donotusethe
powersupplyinthiscase,contactthecustomercaredepartmentortheagentfromthepointof
purchase.

OCP:OverCurrentProtection
NormallytheoverloadprotectionissustainedbytheCCconstantcurrentmode.WhentheCC
modefailsandgoesundetected,seriousdamagetothetestpieceorloadmayoccur.TheOCPis
usedtominimizetheextentofdamagetotheloadsintheeventofpowersupplyfailure.
Switchoffthepowersupplyassoonasthiswarningisseen(asshownbelow).

Toresetthiswarning,removeallloadingandpresstheOUTPUTON/OFFbutton.
Switchtheunitbackonagainanddoublecheckwithcaution.
Ifthisproblempersists,pleasecontactthecustomercaredepartmentorconsultwiththeagent
atthepointofpurchase.


Copyright©2014FLIRSystems,Inc.
Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform
www.extech.com
