MAV Series
A/V Matrix Switchers for Composite Video, S-Video, and Stereo Audio
a/V Matrix SwitcherS
deScriPtion
The Extron MAV Series of compact, space-efficient matrix switchers provide versatile switching
solutions for video system applications that route composite video and S-video signals with
stereo audio. There are 17 models in the MAV Series, ranging in I/O sizes from 4x4 to 8x8. They
are ideal for corporate boardrooms and meeting facilities, museums, university classrooms,
sports bars and restaurants, video conference and distance learning facilities, video production
suites, and many residential entertainment installations.
Video Features
All MAV Series switchers feature 150 MHz (-3 dB) video bandwidth, fully loaded, ensuring
signal quality in even the most complex system designs. In addition, all models are capable
of switching NTSC 3.58, NTSC 4.43, PAL, and SECAM video sources for worldwide capability.
MAV Series switchers also feature video genlock and vertical interval switching for smooth,
seamless transitions when switching between synchronous video sources, making them ideal
for many small video production applications.
Audio Features
The MAV Series includes matrix switchers capable of switching balanced or unbalanced
stereo audio signals, in both audio follow and audio breakaway modes. Audio input gain and
attenuation can be adjusted at the front panel or through serial control, eliminating noticeable
differences in audio level when switching between inputs. Many models are also available with
convenient RCA connectors for switching unbalanced stereo audio.
Control Features
Each of the 17 available MAV Series models comes standard with RS-232 control capability,
as well as Extron's exclusive QS-FPC™- QuickSwitch Front Panel Controller, which allows for
simple, touch-of-a-button input and output selection directly from the front panel. A special
Front Panel Security Lockout mode is available for use when a MAV Series matrix switcher must
be installed in an unsecured environment. For control from a remote location, the MAV Series
can also be controlled via the optional remote control panels. MAV models are also capable of
IR control with the optional IR 501 handheld IR remote control.
Software Features
All MAV Series matrix switchers are shipped with Extron's Windows®-based control software,
which provides a simple, graphical drag-and-drop interface for I/O configuration and other
customization functions. The control software also includes an emulation mode for configuring
an off-site matrix switcher. Once saved, the I/O configuration may be downloaded to the
MAV Series switcher through the serial port. Most MAV Series models also support the
download of the latest firmware revisions through the serial port, directly from Extron's Web
site at www.extron.com.
coMMon feAtureS
•150 MHz (-3 dB) video bandwidth, fully loaded — Ensures switching and distribution
of video signals without degradation. MAV Series matrix switchers provide a minimum
150 MHz (-3 dB) of video bandwidth at full performance capability when one input drives
all outputs.
• Compatible with NTSC 3.58, NTSC 4.43, PAL, and SECAM video — Provides for
worldwide compatibility.
• QS-FPC™- QuickSwitch Front Panel Controller — Provides a discrete button for
each input and output, allowing for simple, intuitive operation.
• View I/O mode — Easily view which inputs and outputs are actively connected.
• Global presets — Frequently used I/O configurations may be saved and recalled either
from the QuickSwitch Front Panel Controller or RS-232 serial control. This time-saving
feature allows you to set up I/O configurations and store them in memory for future use.
• Vertical interval switching provides glitch-free switching between multiple
genlocked sources
• Switches both balanced and unbalanced stereo audio — Unbalanced only on
RCA models
• Audio input gain and attenuation — Allows users to set the level of gain or
attenuation for each audio input channel, eliminating noticeable volume differences
when switching between sources.
• Audio breakaway — Provides the capability to break away an audio signal from its
corresponding video signal, allowing the audio channels to be operated as a separate
matrix swticher.
• RS-232 serial control port — Using serial commands, the MAV Series can be
controlled and configured via the included Windows-based control software, or
integrated into third-party control systems. Extron products use the SIS™- Simple
Instruction Set command protocol, a set of basic ASCII code commands that allow
for quick and easy programming. The RS-232 port also makes it easy to install
firmware updates.
• Control software — For RS-232 remote control from a PC, Extron ships our
Windows®-based with every matrix switcher. This icon-driven software uses a graphical,
drag-and-drop interface to make I/O configuration and other customization functions
simple and convenient. This software also offers an emulation mode for configuration
of an offsite matrix switcher; the I/O configuration may then be saved for future
downloading to the matrix switcher.
• Optional remote control — Optional X/Y control panels, bus control panels,
and keypads provide the flexibility to control a MAV Series matrix switcher from a
remote location.
• Optional IR 501 handheld IR remote control
• 1U, rack-mountable metal enclosure
• Front panel security lockout — Prevents unauthorized use when the matrix switcher
is installed in an unsecured environment where easy access is not desirable. In lockout
mode, a special button combination is required to operate the front panel.
• Internal international power supply — The 100-240VAC, 50/60 Hz, universal power
supply provides worldwide power compatibility.
295

100-240V0.3A
IN
OUT
SYNC
RS 232
3
4
5
6
7
8
1
2
1
2
3
4
5
6
7
8
INPUTSOUTPUTS
INPUTS
MAV88 AV
OUTPUTS
LR
7
LR
8
LR
5
LR
6
LR
3
LR
4
LR
1
LR
2
LR
7
LR
8
LR
5
LR
6
LR
3
LR
4
LR
1
LR
2
50-60Hz
DISTRIBUTIONAMPLIFIER
50-60Hz
FRONTPANEL
LOCKOUT
RS-232
PROTECT
CH1CH2
APA754
AUDIOPOWERAMPLIFIER
CLIP
NORM
SIGNAL
FRONTPANEL
LOCKOUT
RS-232
PROTECT
CH1CH2
APA754
AUDIOPOWERAMPLIFIER
CLIP
NORM
SIGNAL
DVD
DVD
Sound System
Sound System
Video Camera
Monitor Monitor
Projector
VCR
Extron
MAV 88 AV
Matrix Switcher
Extron
BBG 6A
Blackburst &
Audio Generator
Control
System
CD Player
Projector
100-240V0.3A
50-60Hz
78
7
7
7
7
7
L
R
SYNC
INPUTS OUTPUTS
125
38
6
47125
38
6
47
RS 232
MAV88SVARCA
7
3
4
5
6
7
8
1
2
1
2
3
4
5
6
7
8
INPUTSOUTPUTS
DVD-RW/-RRECORDING
PrecisionCinemaProgressive
DISTRIBUTIONAMPLIFIER
DVD-RW/-RRECORDING
PrecisionCinemaProgressive
FRONTPANEL
LOCKOUT
RS-232
PROTECT
CH1CH2
APA754
AUDIOPOWERAMPLIFIER
CLIP
NORM
SIGNAL
FRONTPANEL
LOCKOUT
RS-232
PROTECT
CH1CH2
APA754
AUDIOPOWERAMPLIFIER
CLIP
NORM
SIGNAL
Control
System
Monitors
DVD
VCR
Video
Camera
Extron
MAV 88 SVA RCA
Matrix Switcher
Projector
Projector
Extron
BBG 6A
Blackburst &
Audio Generator
CD Player
Sound
System
Sound
System
DVD
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
Continued
MAV Series
a/V Matrix SwitcherS
296

www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
Continued
MAV Series
a/V Matrix SwitcherS
MAV 88 V
8x8 Composite Video Matrix Switcher
unique feAtureS
•Inputs: Eight video on female BNC connectors
•Outputs: Eight video on female BNC connectors
MAV AV
Composite Video & Stereo Audio Matrix Switchers
unique feAtureS
•Inputs: Video on female BNC connectors; audio on captive screw
connectors
•Outputs: Video on female BNC connectors; audio on captive
screw connectors
MAV AV RCA
Composite Video & Stereo Audio
Matrix Switchers - RCA
unique feAtureS
•Inputs: Video on female BNC connectors; audio on RCA jacks
•Outputs: Video on female BNC connectors; audio on RCA jacks
MAV 88 AV
MAV 88 AV RCA
Model VerSion deScriPtion PArt #
MAV 88 V 8x8 Composite Video.................................................................................... 60-555-01
Model VerSion deScriPtion PArt #
MAV 44 AV 4x4 Composite Video & Stereo Audio ................................................................. 60-553-21
MAV 48 AV 4x8 Composite Video & Stereo Audio ................................................................. 60-605-21
MAV 84 AV 8x4 Composite Video & Stereo Audio ................................................................. 60-554-21
MAV 88 AV 8x8 Composite Video & Stereo Audio ................................................................. 60-555-21
Model VerSion deScriPtion PArt #
MAV 44 AV RCA 4x4 Composite Video & Stereo Audio - RCA.......................................................... 60-553-31
MAV 48 AV RCA 4x8 Composite Video & Stereo Audio - RCA.......................................................... 60-605-31
MAV 84 AV RCA 8x4 Composite Video & Stereo Audio - RCA.......................................................... 60-554-31
MAV 88 AV RCA 8x8 Composite Video & Stereo Audio - RCA.......................................................... 60-555-31
297

www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
Continued
MAV Series
a/V Matrix SwitcherS
MAV SVA
S-Video & Stereo Audio Matrix Switchers
unique feAtureS
•Inputs: Video on female 4-pin mini DIN connectors;
audio on captive screw connectors
•Outputs: Video on female 4-pin mini DIN connectors;
audio on captive screw connectors
MAV SVA RCA
S-Video & Stereo Audio
Matrix Switchers - RCA
unique feAtureS
•Inputs: Video on female 4-pin mini DIN connectors;
audio on RCA jacks
•Outputs: Video on female 4-pin mini DIN connectors;
audio on RCA jacks
MAV 88 SVA
MAV 88 SVA RCA
Model VerSion deScriPtion PArt #
MAV 44 SVA 4x4 S-Video & Stereo Audio............................................................................ 60-553-22
MAV 48 SVA 4x8 S-Video & Stereo Audio............................................................................ 60-605-22
MAV 84 SVA 8x4 S-Video & Stereo Audio............................................................................ 60-554-22
MAV 88 SVA 8x8 S-Video & Stereo Audio............................................................................ 60-555-22
Model VerSion deScriPtion PArt #
MAV 44 SVA RCA 4x4 S-Video & Stereo Audio - RCA .................................................................... 60-553-32
MAV 48 SVA RCA 4x8 S-Video & Stereo Audio - RCA .................................................................... 60-605-32
MAV 84 SVA RCA 8x4 S-Video & Stereo Audio - RCA .................................................................... 60-554-32
MAV 88 SVA RCA 8x8 S-Video & Stereo Audio - RCA .................................................................... 60-555-32
298

www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
www.extron.com
© 2008 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
USA West
+1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX
USA East
+1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX
China
+86.21.3760.1568 / +400.883.1568
+86.21.3760.1566 FAX
Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050 FAX
Dubai
+971.4.2991800
+971.4.2991880 FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664 FAX
MAV Series
a/V Matrix SwitcherS
Audio inPut (ALL MODELS EXCEPT MAV 88 V)
Number / Signal type
MAV 44/48 AV,
MAV 44/48 SVA................... 4 stereo, balanced/unbalanced
MAV 44/48 AV RCA,
MAV 44/48 SVA RCA ............. 4 stereo, unbalanced
MAV 84/88 AV,
MAV 84/88 SVA................... 8 stereo, balanced/unbalanced
MAV 84/88 AV RCA,
MAV 84/88 SVA RCA ............. 8 stereo, unbalanced
Connectors
MAV 44/48 AV,
MAV 44/48 SVA................... (4) 3.5 mm captive screw connectors, 5 pole
MAV 44/48 AV RCA,
MAV 44/48 SVA RCA ............. 4 pairs of RCA female connectors
MAV 84/88 AV,
MAV 84/88 SVA................... (8) 3.5 mm captive screw connectors, 5 pole
MAV 84/88 AV RCA,
MAV 84/88 SVA RCA ............. 8 pairs of RCA female connectors
Impedance........................ >18k ohms unbalanced, 24k ohms balanced, DC coupled
Nominal level .................... Configurable: +4 dBu (1.23 V, professional level) or
-10 dBV (316 mV, consumer level)
Maximum level .................. >+20 dBu (captive screw models) at 1% THD+N
>+14 dBu (RCA models) at 1% THD+N
Input gain adjustment .......... –18 dB to +10 dB, adjustable per input; default = 0 dB
Audio outPut (ALL MODELS EXCEPT MAV 88 V)
Number / Signal type
MAV 44/84 AV,
MAV 44/84 SVA................... 4 stereo, balanced/unbalanced
MAV 44/84 AV RCA,
MAV 44/84 SVA RCA ............. 4 stereo, unbalanced
MAV 48/88 AV,
MAV 48/88 SVA................... 8 stereo, balanced/unbalanced
MAV 48/88 AV RCA,
MAV 48/88 SVA RCA ............. 8 stereo, unbalanced
Connectors
MAV 44/84 AV,
MAV 44/84 SVA................... (2) 3.5 mm captive screw connectors, 10 pole
MAV 44/84 AV RCA,
MAV 44/84 SVA RCA ............. 4 pairs of RCA female
MAV 48/88 AV,
MAV 48/88 SVA................... (4) 3.5 mm captive screw connectors, 10 pole
MAV 48/88 AV RCA,
MAV 48/88 SVA RCA ............. 8 pairs of RCA female
Impedance........................ 50 ohms unbalanced, 100 ohms balanced
Gain error ......................... <±0.1 dB channel to channel
Nominal level .................... Configurable: +4 dBu (1.23 V, professional level) or
-10 dBV (316 mV, consumer level)
Maximum level (Hi-Z) ........... >+20 dBu, balanced; >+18 dBu, unbalanced at 1%THD+N at default settings
Maximum level (600 ohm) ..... >+19 dBm, balanced; >+13 dBm, unbalanced at 1%THD+N at default settings
control / reMote — Switcher
Serial control port............... RS-232, 9-pin female D connector
Baud rate and protocol......... 9600, 8 data bits, 1 stop bit, no parity
IR controller module ........... IR 501 remote control (optional)
Program control ................. Extron’s control/configuration program for Windows®
Extron’s Simple Instruction Set (SIS™)
GenerAl
Power.............................. 100 VAC to 240 VAC, 50/60 Hz, 15 watts, internal, universal
Rack mount ...................... Yes, with included brackets, part #70-077-03
Also furniture mountable with an optional under-desk mounting kit,
part #70-222-01
Enclosure type ................... Metal
Enclosure dimensions.......... 1.75" H x 17.4" W x 8.5" D (1U high, full rack wide)
4.4 cm H x 44.2 cm W x 21.6 cm D
(Depth excludes connectors. Width excludes rack ears.)
Product / Shipping weight..... 7.0 lbs (3.2 kg) / 10 lbs (5 kg)
SPecificAtionS
Video
Routing
MAV 44 Series .................... 4 x 4 matrix
MAV 48 Series .................... 4 x 8 matrix
MAV 84 Series .................... 8 x 4 matrix
MAV 88 Series .................... 8 x 8 matrix
Gain ................................ Unity
Bandwidth ........................ 150 MHz (-3 dB), fully loaded
Differential phase error ........ <0.1º at 3.58 MHz and 4.43 MHz
Differential gain error .......... <0.1% at 3.58 MHz and 4.43 MHz
Crosstalk.......................... <-50 dB @ 5 MHz
Switching speed................. 20 ms (max.)
Video inPut
Number / Signal type
MAV 44/48 composite
video models ...................... 4 composite video
MAV 44/48 S-video models ..... 4 S-video
MAV 84/88 composite
video models ...................... 8 composite video
MAV 84/88 S-video models ..... 8 S-video
Connectors
MAV 44/48 composite
video models ...................... 4 female BNC
MAV 44/48 S-video models ..... 4 female 4-pin mini DIN
MAV 84/88 composite
video models ...................... 8 female BNC
MAV 84/88 S-video models ..... 8 female 4-pin mini DIN
Nominal level .................... 1 Vp-p for Y of S-video, and for composite video
0.3 Vp-p for C of S-video
Minimum / Maximum levels. . . Analog: 0.4 V to 2.0 Vp-p with no offset at unity gain
Impedance........................ 75 ohms
Return loss ....................... Composite video: <-38 dB @ 0 to 10 MHz
S-video: <-25 dB @ 0 to 10 MHz
DC offset (max. allowable)....... 5 V
External sync (genlock) ......... 0.2 V to 0.4 Vp-p
Input coupling.................... AC coupling only
Video outPut
Number / Signal type
MAV 44/84 composite
video models ...................... 4 composite video
MAV 44/84 S-video models ..... 4 S-video
MAV 48/88 composite
video models ...................... 8 composite video
MAV 48/88 S-video models ..... 8 S-video
Connectors
MAV 44/84 composite
video models ...................... 4 female BNC
MAV 44/84 S-video models ..... 4 female 4-pin mini DIN
MAV 48/88 composite
video models ...................... 8 female BNC
MAV 48/88 S-video models ..... 8 female 4-pin mini DIN
Nominal level .................... 1 Vp-p for Y of S-video, and for composite video
0.3 Vp-p for C of S-video
Minimum / Maximum levels. . . 0.4 V to 2.0 Vp-p (follows input)
Impedance........................ 75 ohms
Return loss ....................... S-video: <-25 dB @ 5 MHz
Composite video: <-40 dB @ 5 MHz
DC offset .......................... 15 mV typical with input at 0 offset
Switching type................... Vertical interval
Sync
Genlock connectors............. 2 BNC female
Standards......................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Audio (ALL MODELS EXCEPT MAV 88 V)
Routing
MAV 44 Series .................... 4 x 4 stereo matrix
MAV 48 Series .................... 4 x 8 stereo matrix
MAV 84 Series .................... 8 x 4 stereo matrix
MAV 88 Series .................... 8 x 8 stereo matrix
Gain ................................ Adjustable; the default is unity
Frequency response ............ 20 Hz to 20 kHz, ±0.5 dB
THD + Noise...................... 1% @ 1 kHz, 0.3% @ 20 kHz at nominal level
S/N ................................. 90 dB at maximum output (unweighted)
Crosstalk.......................... <-65 dB @ 20 kHz, <-80 dB @ 1 kHz or below 60 Hz, fully loaded
Stereo channel separation . . . . >80 dB @ 20 Hz to 20 kHz
CMRR .............................. >75 dB @ 20 Hz to 20 kHz
299
