Extron electronics DXP HD 4K Series User manual

User Guide
SW HD 4K Series
HDMI Switchers
HDMI Switchers
68-2884-01 Rev. B
03 16

Safety Instructions
Safety Instructions • English
WARNING: This symbol, , when used on the product, is intended to
alert the user of the presence of uninsulated dangerous voltage within the
product’s enclosure that may present a risk of electric shock.
ATTENTION: This symbol, , when used on the product, is intended
to alert the user of important operating and maintenance (servicing)
instructions in the literature provided with the equipment.
For information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide, part number 68-290-01, on the Extron website,
www.extron.com.
Instructions de sécurité • Français
AVERTISSEMENT: Ce pictogramme, , lorsqu’il est utilisé sur le
produit, signale à l’utilisateur la présence à l’intérieur du boîtier du produit
d’une tension électrique dangereuse susceptible de provoquer un choc
électrique.
ATTENTION: Ce pictogramme, , lorsqu’il est utilisé sur le produit, signale
à l’utilisateur des instructions d’utilisation ou de maintenance importantes
qui se trouvent dans la documentation fournie avec le matériel.
Pour en savoir plus sur les règles de sécurité, la conformité à la réglementation,
la compatibilité EMI/EMF, l’accessibilité, et autres sujets connexes, lisez les
informations de sécurité et de conformité Extron, réf. 68-290-01, sur le site
Extron, www.extron.com.
Sicherheitsanweisungen • Deutsch
WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer darauf
aufmerksam machen, dass im Inneren des Gehäuses dieses Produktes
gefährliche Spannungen herrschen, die nicht isoliert sind und die einen
elektrischen Schlag verursachen können.
VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in der
im Lieferumfang enthaltenen Dokumentation besonders wichtige Hinweise
zur Bedienung und Wartung (Instandhaltung) geben.
Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,
EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in
den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer
68-290-01) auf der Extron-Website, www.extron.com.
Instrucciones de seguridad • Español
ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,
avisa al usuario de la presencia de voltaje peligroso sin aislar dentro del
producto, lo que puede representar un riesgo de descarga eléctrica.
ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa
al usuario de la presencia de importantes instrucciones de uso y
mantenimiento recogidas en la documentación proporcionada con el
equipo.
Para obtener información sobre directrices de seguridad, cumplimiento
de normativas, compatibilidad electromagnética, accesibilidad y temas
relacionados, consulte la Guía de cumplimiento de normativas y seguridad de
Extron, referencia 68-290-01, en el sitio Web de Extron, www.extron.com.
Инструкция по технике безопасности •Русский
ПРЕДУПРЕЖДЕНИЕ: Данный символ, , если указан
на продукте, предупреждает пользователя о наличии
неизолированного опасного напряжения внутри корпуса
продукта, которое может привести к поражению электрическим
током.
ВНИМАНИЕ: Данный символ, , если указан на продукте,
предупреждает пользователя о наличии важных инструкций
по эксплуатации и обслуживанию в руководстве,
прилагаемом к данному оборудованию.
Для получения информации о правилах техники безопасности,
соблюдении нормативных требований, электромагнитной
совместимости (ЭМП/ЭДС), возможности доступа и других
вопросах см. руководство по безопасности и соблюдению
нормативных требований Extron на сайте Extron: www.extron.com,
номер по каталогу - 68-290-01.
安全说明 • 简体中文
警告：产品上的这个标志意在警告用户该产品机壳内有暴露的危险 电压，
有触电危险。
注 意： 产品上的这个标志意在提示用户设备随附的用户手册中有
重要的操作和维护(维修）说明。
关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍
使用的特性等相关内容，敬请访问 Extron 网站 www.extron.com，参见
Extron 安全规范指南，产品编号 68-290-01。
安全記事 •繁體中文
警告：若產品上使用此符號，是為了提醒使用者，產品機殼內存在著
可能會導致觸電之風險的未絕緣危險電壓。
注意： 若產品上使用此符號，是為了提醒使用者。
有關安全性指導方針、法規遵守、EMI/EMF 相容性、存取範圍和相關主題的詳
細資訊，請瀏覽 Extron 網站：www.extron.com，然後參閱《Extron 安全性與
法規遵守手冊》，準則編號 68-290-01。
安全上のご注意 • 日本語
警告: この記号 が製品上に表示されている場合は、筐体内に絶縁されて
いない高電圧が流れ、感電の危険があることを示しています。
注意:この記号 が製品上に表示されている場合は、本機の取扱説明書
に 記載されている重要な操作と保守(整備)の指示についてユーザーの
注意を喚起するものです。
安全上のご注意、法規厳守、EMI/EMF適合性、その他の関連項目に
つ い て は 、エ ク スト ロ ン の ウェ ブ サ イト www.extron.com よ り 『 Extron Safety
and Regulatory Compliance Guide』 ( P/N 68-290-01) をご覧ください。
안전 지침 • 한국어
경고: 이 기호 가 제품에 사용될 경우, 제품의 인클로저 내에 있는
접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을
경고합니다.
주의: 이 기호 가 제품에 사용될 경우, 장비와 함께 제공된 책자에 나와
있는 주요 운영 및 유지보수(정비) 지침을 경고합니다.
안전 가이드라인, 규제 준수, EMI/EMF 호환성, 접근성, 그리고 관련 항목에
대한 자세한 내용은 Extron 웹 사이트(www.extron.com)의 Extron 안전 및
규제 준수 안내서, 68-290-01 조항을 참조하십시오.

FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part15 of the FCC rules. The ClassA limits provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause interference. This interference must be corrected at
the expense of the user.
NOTES:
• This unit was tested with shielded I/O cables on the peripheral devices. Shielded
cables must be used to ensure compliance with FCC emissions limits.
• For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics see the “Extron Safety and
Regulatory Compliance Guide” on the Extron website.
Copyright
© 2016 Extron Electronics. All rights reserved.
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks®, registered service marks(SM), and trademarks(TM) are the property of
RGBSystems, Inc. or Extron Electronics:
Registered Trademarks (®)
Extron, AVTrac, Cable Cubby, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, Flat Field, FlexOS, Global Configurator, GlobalViewer,
Hideaway, Inline, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink, MediaPort, NetPA, PlenumVault, PoleVault, PowerCage,
PURE3, Quantum, SoundField, SpeedMount, SpeedSwitch, SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VersaTools, VN-Matrix,
VoiceLift, WallVault, WindoWall, XTP, and XTPSystems
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-RateFrameLock), ADSP(Advanced Digital Sync Processing), Auto-Image, CableCover, CDRS(ClassD Ripple Suppression),
DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator, DSPConfigurator, DSVP(Digital
Sync Validation Processing), eLink, Entwine, EQIP, FastBite, FOX, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, ProDSP,
QS-FPC(QuickSwitch Front Panel Controller), Room Agent, Scope-Trigger, ShareLink, SIS, SimpleInstructionSet, Skew-Free, SpeedNav,
Triple-Action Switching, True4K, Vector™ 4K , WebShare, XTRA, ZipCaddy, and ZipClip

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
CAUTION: Risk of minor personal injury.
ATTENTION : Risque de blessuremineure.
ATTENTION:
• Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
TIP: A tip provides a suggestion to make working with the application easier.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.

SW HD 4K Series • Contents v
Contents
Introduction............................................................ 1
About this Guide................................................. 1
About the SW HD 4K Series Switchers............... 1
Features ............................................................. 1
Application Diagram ........................................... 2
Installation.............................................................. 3
Installation Overview ........................................... 3
Rear Panel Features ........................................... 4
Wiring the Power Connector............................... 5
Wiring for RS-232 Control and Auto Switching ... 7
Connecting to the USB Port ............................... 8
Enabling Auto-Input Switching............................ 9
Wiring the Contact Closure Connectors............ 10
Wiring the Tally Out Port to Indicate the Input
Selection ......................................................... 10
LockIt HDMI Cable Lacing Bracket Installation
Guide .............................................................. 11
Operation.............................................................. 12
Front Panel Features......................................... 12
Operations....................................................... 13
Powering on the Switcher............................. 13
Selecting an Input......................................... 14
Resetting ...................................................... 14
Using the Optional IR 102 Remote Control ... 14
Locking and Unlocking the Front Panel
(Executive Mode) ......................................... 15
EDID Modes ................................................. 16
Remote Communication and Control ........... 17
Using Simple Instruction Set (SIS) Commands.. 17
Host-to-switcher Communications ............... 17
Switcher-initiated Messages ......................... 17
Error Responses........................................... 18
Symbol Definitions ........................................ 18
Command and Response Table for SIS
Commands .................................................... 20
Updating Firmware Using Firmware Loader ...... 24
Downloading and Installing
Firmware Loader........................................... 24
Downloading the SW HD 4K Firmware ......... 24
Loading the Firmware to the Switcher........... 25
Reference Information ...................................... 30
Mounting the SW HD 4K Switchers .................. 30
Tabletop Use ................................................ 30
Rack Mounting ............................................. 30
Furniture Mounting........................................ 31
Extron Warranty .................................................. 32

SW HD 4K Series • Introduction 1
Introduction
This section gives an overview of the Extron SW HD 4K Series switchers. Topics include:
• About this Guide
• About the SW HD 4K Series Switchers
• Features
• Application Diagram
About this Guide
This guide describes the SW HD 4K Series switchers and discusses how to install,
configure, and operate them.
In this guide, the terms “SW HD 4K Series” and “SW HD 4K” refer to the SW2 HD 4K and
SW4 HD 4K switchers.
About the SW HD 4K Series Switchers
The SW HD 4K Series are two and four input HDMI switchers for 4K video signals. They
switch 4K signals from multiple HDMI source devices to a single display. The switchers
support computer and video resolutions up to 4K and 1080p/60 with Deep Color, as well
as data rates up to 10.2 Gbps, 3D, Lip Sync, and HD lossless audio formats. All models
feature EDID Minder, which maintains continuous EDID communication with connected
devices and ensures that the HDMI sources power up properly and maintain correct video
output. The switchers provide automatic input cable equalization up to 50 feet (15 meters)
on Extron HDMI Pro Series cable. The SW HD 4K Series offers front panel, RS-232, IR,
contact closure, and auto-input switching control options for integration into various
environments.
The SW HD 4K switchers can be controlled via the front panel, the RS-232 interface,
USB, contact closure, or the optional IR 102 Remote Control. You can select inputs by
pressing the front panel buttons, pressing buttons on the IR 102, enabling auto-input
switching, attaching a jumper or a contact closure device to the Contact port, or entering
Simple Instruction Set (SIS) commands via RS-232 or USB.
Features
• Switches HDMI video and embedded multi‑channel digital audio
• Inputs: Two or four female HDMI type‑A connectors
• Output: 1 female HDMI type‑A connector
• Supports computer and video resolutions up to 4K, including 1080p/60 Deep
Color — Resolutions up to 4096x2160/30 with 4:4:4 chroma sampling at 8 bits
of color.
• EDID Minder automatically manages EDID communication between
connected devices — EDID Minder ensures that all sources power up
properly and reliably output content for display.

SW HD 4K Series • Introduction 2
• Automatic input cable equalization to 50 feet (15 meters) when used with
Extron HDMI Pro Series cable — Actively conditions incoming HDMI signals
to compensate for signal loss when using long HDMI cables, low quality HDMI
cables, and source devices with poor HDMI signal output.
• HDCP compliant — Ensures display of content‑protected media and
interoperability with other HDCP‑compliant devices.
• User‑selectable HDCP authorization — Allows individual inputs to appear
HDCP compliant or non‑HDCP compliant to the connected source, which is
beneficial if the source automatically encrypts all content when connected
to an HDCPcompliant device. Protected material is not passed in non‑HDCP
mode.
• HDCP authentication and signal presence LED indicators
• Automatic color bit depth management — The switcher automatically adjusts
color bit depth based on the display EDID, preventing color compatibility
conflicts between source and display.
• Provides +5 VDC, 250 mA power on the output for external peripheral devices
• Easy setup and commissioning with the Extron Product Configuration
Software — Conveniently configure multiple products using a single software
application.
• Multiple control options including front panel, RS‑232, USB, IR, contact closure,
and auto‑input switching
• Contact closure remote control with tally output — Allows for remote selection
of an input channel. +5 VDC is provided to light an LED to indicate the currently
selected input.
• Includes LockIt HDMI cable lacing brackets
Application Diagram
The following diagram shows a typical application for a SW4 HD 4K.
SW4 HD 4K
INPUTS
Tx Rx G
GC T GC
G
1
2
3
4
C T TGC
T +V
RS-232 AUTO
CONTACTIN/TALLY OUT
INPUTS OUTPUT
REMOTE
0.2A MAX
POWER
12V
1234
POWER
12V
--AMAX
G
Tx Rx RTSCTS
COM1
G
Tx Rx
COM2
V C G
VOL RELAYS
1 2 C
1 2 3 4 G
DIGITALI/O
PWROUT = 6 W
eBUS
+V+S - S G
LAN
IPCPPRO 250
IR/S
S G
Extron
Extron
Help System
Off
Display
Room
Control
Off
Mute
Screen
Lighting
December15,2013 - 7:58 AM
Audio
Control
Volume
Mute
Tuner
123
VCR
Laptop PC DVD Doc
Cam
Tuner
On
Channel
Last
Presets
More
Presets
3
2
1
6
5
4
9
8
7
Enter
0
Laptop
DSS Receiver
4K Media Player
4K Display
Extron
SW4 HD 4K
4K HDMI Switcher
PC
HDMI
HDMI
RS-232
Ethernet
Ethernet
Extron
TLP Pro 720T
7" Tabletop
TouchLink Pro
Touchpanel
Extron
IPCP Pro 250
IP Link Pro Control
Proceesor
TCP/IP
Network

SW HD 4K Series • Installation 33
Installation
This section describes the installation and setup of the SW HD 4K Series switchers.
Topics include:
• Installation Overview
• Rear Panel Features
• Wiring the Power Connector
• Wiring for RS‑232 Control and Auto Switching
• Connecting to the USB Port
• Enabling Auto‑Input Switching
• Wiring the Contact Closure Connector
• Wiring the Tally Out Port to Indicate the Input Selection
Installation Overview
To install and set up the SW HD 4K switcher:
1. Turn off all equipment and disconnect it from the power source.
2. (Optional) Mount the switcher on a rack shelf or furniture (see Mounting the
SW HD 4K on page 30).
3. Connect HDMI input sources to one or more of the SW HD 4K input connectors.
NOTE: LockIt cable lacing brackets, one for each HDMI input and output
connector, are provided with the SW HD 4K series. These brackets can
be used to secure the HDMI cables to the rear panel connectors to reduce
stress on the HDMI connectors and prevent signal loss due to loose cable
connections. For information on attaching the LockIt brackets, see the LockIt
HDMI Lacing Bracket Installation Guide on page 11.
4. Connect an HDMI output device to the output connector. By default, the EDID of
this device is stored at the HDMI inputs.
5. Connect control devices. Connect your computer to either of the following
SW HD 4K ports to configure and control the switcher via SIS commands:
• RS‑232 port — Pins 1, 2, and 3 of the 3-pole RS-232 connector for serial
RS-232 control (see Wiring for RS‑232 Control and Auto Switching on
page 7 for connection procedures)
• Config port — USB mini-B connector for USB control (see Connecting to the
USB Port on page 8 for connection procedures)
6. (Optional) Enable auto‑input switching. Use a jumper to connect the two pins
of the 2-pole captive screw connector, next to the 3-pole RS-232 connector (see
Enabling Auto‑Input Switching on page 9).
7. (Optional) Enable input switching by contact closure. Connect an input
device to a SW HD 4K Contact In connector (directly or through a contact closure
device) and, if desired, to a Tally Out connector (see Wiring the Contact Closure
Connectors on page 10).

SW HD 4K Series • Installation 4
8. Power on the output display.
9. Connect power to the switcher (see Powering On the Switcher on page 13).
10. (Optional) Configure the EDID Minder (see EDID Modes on page 16).
11. Power on the source devices.
Rear Panel Features
0.5A MAX
POWER
12V
SW2 HD 4K
12
INPUTS OUTPUT
Tx Rx G
GCT
G
1
2
CT
+V
RS-232 AUTO
CONTACT IN/TALLY OUT
REMOTE
E
A
DCB
F
D
Figure 1. SW2 HD 4K Rear Panel
0.5A MAX
POWER
12V
SW4 HD 4K
1
Tx Rx G
GCT GC
G
1
2
3
4
CT TGC
T+V
RS‑232 AUTO
CONTACT IN/TALLY OUT
2 3 4
INPUTS OUTPUT
REMOTE
E
A
C
BD
DF
Figure 2. SW4 HD 4K Rear Panel
A Power connector — Plug the provided external 12 VDC, 1 A power supply into this
2-pole, 3.5 mm captive screw connector and into an AC power outlet.
ATTENTION:
• Do not connect any external power supplies until you have read the Attention
notifications on page 6.
• Ne branchez pas de sources d’alimentation externes avant d’avoir lu les mises
en garde sur la page 6.
B Input connectors — Connect HDMI video input sources to these female Type-A
HDMI connectors.
NOTE: LockIt cable lacing brackets are provided with the SW HD 4K units. These
brackets secure the HDMI cables to the rear panel connectors and reduce
stress on the connectors, preventing signal loss due to loose cable connections
(see the LockIt HDMI Lacing Bracket Installation Guide on page 11).
COutput connector — Connect an HDMI display device to this female Type-A HDMI
connector.
The EDID information is read from the connected output device via this connector
and is written to memory on each input whenever the output device is connected to
this port and powered on.
NOTE: The EDID information is also read and stored whenever power is recycled
to the connected output device or when the output device is replaced.
A Power connector
B Input connectors
C Output connector
D Contact closure input/Tally
output connectors
E +V connectors (on the next page)
F RS‑232 and Auto switching
connectors (on the next page)

SW HD 4K Series • Installation 5
DContact closure input and Tally output ports
• Contact closure input — (Optional) Connect a push-button contact closure
device to a Contact In connector to enable input switching via contact
closure (see Wiring the Contact Closure Connectors on page 10 for more
information).
• Tally Out port — (Optional) To identify the currently selected input when the
front panel buttons are not visible, connect a device such as an LED to the Tally
Out connector and +V connector. When the input you are using is selected,
the corresponding Tally Out pin (T) shorts to ground, activating the connected
indicator (see Wiring the Tally Out Port to Indicate the Input Selection on
page 10 for more information).
E+V connectors — These pins constantly output +5 VDC with 200 mA total (shared
between pins). Use these pins when power is needed for external Tally LEDs, such as
with Extron “Show Me” cables.
FRS‑232 (3‑pole) and auto‑input switching (2‑pole) connector — Use this 3-pole,
3.5 mm captive screw connector for RS-232 communication with the switcher
(including firmware updates) and this 2-pole, 3.5 mm captive screw connector to
enable auto-input switching.
• To enable RS‑232 control, connect the Tx (transmit), Rx (receive) and G
(ground) pins to the serial port of your computer (see Wiring for RS‑232 Control
and Auto Switching on page 7).
• To enable auto‑input switching, short the two pins of this connector together.
In auto-input switch mode, the switcher automatically switches to the highest
numbered active input (see Enabling Auto‑input Switching on page 9).
Wiring the Power Connector
A 12 VDC, 1 A power supply is provided with the SW HD 4K. Follow the following
instructions to wire the 2-pole captive screw connector to your power supply:
CAUTION: The wires must be kept separate while the power supply is plugged in.
Remove power before wiring.
ATTENTION : Les deux cordons d’alimentation doivent être tenus à l’écart l’un de
l’autre quand l’alimentation est branchée. Couper l’alimentation avant de faire
l’installation électrique.
ATTENTION:
• Do not connect any external power supplies until you have read the Attention
notifications on page 6.
• Ne branchez pas de sources d’alimentation externes avant d’avoir lu les mises en
garde sur la page 6.
1. Cut the DC output cord to the length needed.
2. Strip the jacket to expose 3/16” (5 mm) of the conductors.
3. Slide the leads into the supplied 2-pole captive screw plug and secure them, using a
small screwdriver.
4. To verify the power cord polarity before connecting the plug, connect the power
supply with no load and check the output with a voltmeter.
Tx Rx G
RS-232 AUTO
SW HD 4K Series Switcher
Rear Panel Remote Port

SW HD 4K Series • Installation 6
5. Use the supplied tie wrap to strap the power cord to the extended tail of the
connector.
Captive Screw Connector
Tie Wrap
Heat
Shrink 1/8"
(3 mm)
7/8"
(22 mm)
3/16"
(5 mm) Max.
Figure 3. Wiring the Power Connector
ATTENTION:
• Always use a power supply supplied and or specified by Extron. Use of an
unauthorized power supply voids all regulatory compliance certification and may
cause damage to the supply and the end product.
• Utilisez toujours une source d’alimentation fournie ou recommandée par Extron.
L’utilisation d’une source d’alimentation non autorisée annule toute conformité
réglementaire et peut endommager la source d’alimentation ainsi que le produit
final.
• If not provided with a power supply, this product is intended to be supplied by a
power source marked “Class 2” or “LPS” and rated at 12 VDC and a minimum of
1.0 A.
• Si ce produit ne dispose pas de sa propre source d’alimentation électrique, il doit
être alimenté par une source d’alimentation de classe 2 ou LPS et paramétré à
12 V et 1.0 A minimum.
• The installation must always be in accordance with the applicable provisions of
National Electrical Code ANSI/NFPA 70, article 725 and the Canadian Electrical
Code part 1, section 16. The power supply shall not be permanently fixed to
building structure or similar structure.
• Cette installation doit toujours être en accord avec les mesures qui s’applique
au National Electrical Code ANSI/NFPA70, article725, et au Canadian Electrical
Code, partie1, section16. La source d’alimentation ne devra pas être fixée de
façon permanente à une structure de bâtiment ou à une structure similaire.
• Power supply voltage polarity is critical. Incorrect voltage polarity can damage the
power supply and the unit. The ridges on the side of the cord (see figure 3 on the
next page) identify the power cord negative lead.
• La polarité de la source d’alimentation est primordiale. Une polarité incorrecte
pourrait endommager la source d’alimentation et l’unité. Les stries sur le côté du
cordon permettent de repérer le pôle négatif du cordon d’alimentation.
• To verify the polarity before connection, plug in the power supply with no load
and check the output with a voltmeter.
• Pour vérifier la polarité avant la connexion, brancher l’alimentation hors charge et
mesurer sa sortie avec un voltmètre.
• The length of the exposed (stripped) copper wires is important.
The ideal length is 3/16 inch (5 mm). Longer bare wires can short together.
Shorter wires are not as secure in the connectors and could be pulled out.
• La longueur des câbles exposés est primordiale lorsque l’on entreprend de les
dénuder. La longueur idéale est de 5mm (3/16inches). S’ils sont un peu
plus longs, les câbles exposés pourraient se toucher et provoquer un court
circuit. S’ils sont un peu plus courts, ils pourraient sortir, même s’ils sont attachés
par les vis captives.

SW HD 4K Series • Installation 7
ATTENTION:
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air
handling spaces or in wall cavities.
• Sauf mention contraire, les adaptateurs AC/DC ne sont pas appropriés pour une
utilisation dans les espaces d’aération ou dans les cavités murales.
Wiring for RS-232 Control and Auto Switching
Use a female 9-pin D to bare wire RS-232 cable or a universal control cable (UC50' or
UC100') to connect your computer or control system to the RS-232 pins of the Remote
connector.
1. Wire the unterminated end of the RS-232 cable to the provided 3-pole captive screw
plug as described below. Connect the transmit, receive, and ground wires of the
cable to the first three pins on the connector, starting at the left:
• Connect the transmit wire to pin 1, which plugs into the Tx (transmit) port.
• Connect the receive wire to pin 2, which plugs into the Rx (receive) port.
• Connect the ground wire to pin 3, which plugs into the G (ground) port.
2. Plug the 3-pole connector into the RS-232 receptacle on the rear panel of the
switcher.
3. Connect the other end of the cable to the appropriate computer or control system
connector.
Figure 4 shows how to wire this shared connector for RS-232.
Tx Rx G
Computer or
Control Syste
m
RS-232 Port
SW HD 4K Series Switcher
Rear Panel Remote Port
NOTE: If you use cable that has a drain
wire, tie the drain wire to ground at both ends.
Ground (G)
Transmit (Tx)
Receive (Rx) Transmit (Tx)
Receive (Rx)
Figure 4. RS‑232 Connector Pin Assignments

SW HD 4K Series • Installation 8
Connecting to the USB Port
The mini-B USB port is located on the SW HD 4K front panel (see figure 5). Use this port
to configure the switcher via SIS commands.
1. Connect a USB A to mini-B cable between the USB Config port on the switcher front
panel and the USB port on a computer.
USB Cable
USB A
USB Mini-B USB 1
USB
Ports
Computer
SW4 HD 4K PLUS Front Panel
SW4 HD 4K Plus
HDMI SWITCHER
RCONFIG
AUTO
SWITCH
1
INPUTS
2 3 4
SIGNAL
INPUTS OUTPUT
1234
HDCP
Figure 5. USB Port Connection
2. If this is the first time you have connected an SW HD 4K to this USB port on your
computer, the Found New Hardware Wizard opens. On the first screen, specify
whether you want the computer to connect to Windows Update in order to search the
web for the driver that it needs to communicate with the switcher via the USB port.
This is not necessary if the USB driver already exists on your computer.
1
2
3
4
Figure 6. Found New Hardware Wizard Opening Screen
• Select the Yes, this time only radio button (see figure 6, 1) if you want your
computer to connect to Windows Update only this one time.
• Select Yes, now and every time Iconnect adevice (2) if you want the
computer to automatically connect to Windows Update to search the web every
time the switcher is connected to this USB port.

SW HD 4K Series • Installation 9
• Select No, not this time (see figure 6, 3, on the previous page) if you do not
want the computer to connect to Windows Update to search the web at this time
(for example, if the driver is already on your computer).
3. Click Next (4). On the next screen, select the Install the software
automatically (Recommended) radio button (see figure 7, 1), then click Next (2)
(you do not need to insert a disc).
1
2
Figure 7. Selecting the Radio Button to Install the USB Driver
Automatically
Your computer locates the driver needed for it to communicate with the SW HD 4K
via the USB port and loads it to the computer hard drive.
4. When the Completed screen appears, click Finish to close the wizard.
NOTE: This wizard appears only the first time you connect the SW HD 4K to each
USB port. You do not see the wizard again unless you connect the switcher to a
different USB port on your computer.
5. Configure the switcher as desired using SIS commands (see the Remote
Communication and Control section, beginning on page 17 for information on
available commands).
Enabling Auto-Input Switching
The SW HD 4K can automatically select the active, connected input based on detection
of an active video signal (TMDS clock activity). If two or more inputs are active, the
highest-numbered input port with an active signal is selected (for example, input 4 on
an SW4 HD 4K switcher). When auto-input switching is in effect, the green Auto Switch
LED on the front panel lights and the front panel input buttons are disabled.
To enable auto-input switching:
1. Cut a small piece of wire to use as a jumper.
2. Insert the ends of the wire into the Auto slots (slot 4 and 5) of the provided 2-pole
captive screw plug, connecting pins 4 and 5 together.
3. Use a small screwdriver to tighten the two screws above pin slots 4 and 5 of the plug
so that the jumper wire ends remain securely in place (see figure 4 on page 7).
4. Insert the plug into the 2-pole Auto captive screw connector on the rear panel (see
figures 1 and 2 on page 4).

SW HD 4K Series • Installation 10
The figure to the right shows an SW4 HD 4K with a jumper connecting pins 4
and 5 to enable auto-input switching.
Auto-input switching remains in effect as long as the jumper wire connects the
two Auto pins of the 2-pole captive screw Auto port.
Wiring the Contact Closure Connectors
To enable input switching via contact closure, connect a push-button contact
closure device to a Contact In/Tally Out connector (see figure 4 on page 4).
NOTE: The number of the Contact In/Tally Out port must match the number of the
HDMI In port.
1. Wire and plug one of the provided 3-pole connectors into a Contact In/Tally Out
connector representing the desired input number on the SW HD 4K (1 or 2 for SW2
models; 1, 2, 3, or 4 for SW4 models).
• Pin 1 = Contact closure input (C)
• Pin 2 = Contact and Tally Ground (G)
• Pin 3 = Tally output (T)
2. Insert the ground wire of the contact device into the Ground slot of the Contact/Tally
connector (pin 2).
3. Press the button on the contact closure device to switch the connected input to the
output.
Wiring the Tally Out Port to Indicate the Input Selection
To identify the currently selected input when the front panel buttons are not visible,
connect a device such as an LED to the Contact In/Tally Out connector (see Don
page 4) and +V connector (see Eon page 5). When the input you are using is selected,
the corresponding Tally Out pin shorts to ground, activating the connected indicator.
1. Wire and plug one of the provided 3-pole connectors into a Contact In/Tally Out
connector (see image at right).
• Pin 1 = Contact closure input (C)
• Pin 2 = Contact and Tally Ground (G)
• Pin 3 = Tally output (T)
2. Insert the power wire for the contact indicator device
into the +V connector.
GCT
1
CONTACT IN/TALLY OUT
GCT
1
CONT
ACT IN/TALLY OUT
+V
+V
Connector Connector
CONTACT IN/TALLY OUT
Connector
REMOTE
Black
Red
“Show Me” Cable
GCT
1
TIP: The Contact and Tally connectors can be used
with Extron “Show Me” cables. For each cable,
connect the red pigtail to the associated pin of the
Contact Closure input connector and the black
pigtail to the associated pin on the Tally Out con-
nector (see the diagram to the right).

SW HD 4K Series • Installation 11
3
3
4
1
2
LockIt HDMI Cable Lacing Bracket Installation Guide
The Extron LockIt lacing bracket makes it possible to simply and universally secure a standard
HDMI®cable to most HDMI devices.
NOTE: The HDMI device must have an HDMI connection mounting screw for this
bracket to be used.
To securely fasten an HDMI cable to a device:
1. Plug the HDMI cable into the panel
connection.
2. Loosen the HDMI connection mounting
screw from the panel enough to allow the
LockIt lacing bracket to be placed over it.
The screw does not have to be removed.
3. Place the LockIt lacing bracket on the
screw and against the HDMI connector,
then tighten the screw to secure the
bracket.
ATTENTION:
• Do not overtighten the connector
mounting screw. The shield it
fastens to is very thin and can
easily be stripped.
• Ne serrez pas trop la vis de
montage du connecteur. Le
blindage auquel elle est attachée
est très fin et peut facilement être
dénudé.
4. Loosely place the included tie wrap around the HDMI connector and the LockIt lacing
bracket as shown.
5. While holding the connector securely against the lacing bracket, tighten the tie wrap,
then remove any excess length.

SW HD 4K Series • Operation 12
Operation
This section describes the operation of the SW HD 4K Series switchers. Topics include:
• Front Panel Features
• Operations
Front Panel Features
SW2 HD 4K
HDMI SWITCHER
1
IR
CONFIG
SIGNAL
INPUTS
INPUTS OUTPUT
12
HDCP
2
AUTO
SWITCH
E
BCA D
F
Figure 8. SW2 HDMI Front Panel
SW4 HD 4K
HDMI SWITCHER
1
IR
CONFIG
SIGNAL
INPUTS
INPUTS OUTPUT
1234
HDCP
2 3 4
AUTO
SWITCH
F
BCAD E
Figure 9. SW4 HDMI Front Panel
A Auto Switch LED — This LED lights when auto-input switching is enabled (see
Enabling Auto‑Input Switching on page 9 for the procedure to set up automatic
input selection).
B IR receiver port — This sensor detects infrared signals from the optional IR 102
remote control at a distance of up to 30 feet and within 40 degrees off the axis (see
Using the Optional IR 102 Remote Control on page 14).
C Config port — Connect a USB cable (USB A to mini-B) between your computer
and this female USB mini-B port to configure and control the switcher via SIS
commands or the Universal Switcher Control Program and to update the firmware
(see Connecting to the USB Port on page 8).
D Input selection buttons and LEDs — Two for the SW2 HD 4K and four for the
SW4 HD 4K. Press one of these buttons to select an input to switch to the output.
The LED at the right of each button lights when the corresponding input is selected. If
auto-input switching is in effect, these buttons are disabled, but the LEDs continue to
light to indicate the selected input.
E Signal status LEDs
• Inputs — Two LEDs for the SW2 HD 4K and four for the SW4 HD 4K. Each
input has a corresponding numbered Signal LED, which lights when a source is
connected to the input connector and TMDS clock activity is detected on it.
A Auto Switch LED
B IR receiver Port
C Config Port
D Input selection buttons
E Signal Status LEDs
F HDCP Status LEDs (on the
next page)

SW HD 4K Series • Operation 13
NOTE: If the source device connected to the selected input is HDCP
encrypted (requires HDCP authentication), the corresponding signal LED
may not light unless HDCP has been authenticated.
• Output — Two LEDs for the SW2 HD 4K and four for the SW4 HD 4K. The
Output Signal LED lights when an active sink (output) device is connected to the
HDMI output.
The input buttons are also used to initiate a system reset (see Resetting on page 14)
and to enable and disable front panel lockout (see Locking and Unlocking the
Front Panel (Executive Mode) on page 15).
FHDCP status LEDs (see figure 9 on the previous page)
• Inputs — Each input has a corresponding numbered HDCP LED. If the
connected source requires HDCP, the corresponding LED lights when
authentication is successful.
NOTE: HDCP is authenticated on each input regardless of the currently
selected source.
• Output — The Output HDCP LED lights if the currently selected input requires
HDCP and the connected output device has been successfully authenticated.
NOTE: HDCP is re-authenticated on the output whenever a new input is
selected.
Operations
Powering on the Switcher
To power on the SW HD 4K:
1. Connect all input and output devices to the rear panel connectors on the switcher
(see Rear Panel Features on page 4 for the rear panel connections).
2. Power on the display.
3. Power on the SW HD 4K: Plug the power supply into the 2-pole captive screw
power connector on the switcher rear panel.
After approximately 4 seconds, the following happens:
• The unit performs a self-test, during which the front panel Auto Switch, Input,
Signal, and HDCP LEDs each blink once in sequence from left to right. When the
self-test completes, the LED for the most recently selected input remains lit.
• The switcher reads the available EDID information from the connected output
device and writes it to memory on each input. When power is removed, these
settings remain in memory and are in effect when power is reapplied.
ATTENTION:
• Do not connect any external power supplies until you have read the Attention
notifications on page 6.
• Ne branchez pas de sources d’alimentation externes avant d’avoir lu les mises en
garde sur la page 6.
4. Power on the input devices.

SW HD 4K Series • Operation 14
Selecting an Input
To switch an input to the output, you have the following options:
• Front panel buttons — Press the desired input button on the front panel (ensure
that auto-input switching is not enabled). The LED corresponding to the selected input
button lights.
• The appropriate front panel input LED lights to indicate the selected input. The
LED remains lit until a new input is selected.
• Only one input can be switched to the output at a time.
NOTE: Buttons are disabled in auto-switch mode.
• Contact closure — Plug one of the provided 3-pole captive screw connectors into
the rear panel Contact port. Wire either of the following to the port:
• Contact closure device: If a push-button contact closure device is attached to
the Contact port, press the button that is connected to the slot that corresponds
to the desired input.
• Jumper wire: On the connector attached to a Contact In/Tally Out port,
momentarily short one of the Contact Closure pins (C) to the ground pin (G) using
a jumper wire. Input is switched immediately when the jumper contacts both pins.
NOTE: If an input pin is latched permanently to the ground pin, input
switching by any other method is disabled while those pins are connected.
See Wiring the Contact Closure Connectors on page 10 for more information.
Other ways to select an input include using SIS commands (see the Input Selection
command on page 20) and optional IR remote control (see Using the Optional IR 102
Remote Control below).
Resetting
To reset the switcher to its factory default settings:
1. Press and hold the Input 1 button while powering on the unit.
2. Continue holding the Input 1 button until the power-up sequence completes.
Using the Optional IR 102 Remote Control
The optional hand-held IR 102 Remote Control lets you remotely perform functions that
are also available through the front panel buttons and SIS commands.
The IR receiver port on the front panel is located to the right of the Auto Switch LED. It
receives signals from the remote control if they are sent from within a 40-degree arc to
the right or left of the IR receiver sensor, and from no more than 30 feet (9 m) away (see
figure 10 on the next page).

SW HD 4K Series • Operation 15
SW4 HD 4K
HDMI SWITCHER
1
IR
CONFIG
SIGNAL
INPUTS
INPUTS OUTPUT
1234
HDCP
2 3 4
AUTO
SWITCH
SW4 HD 4K Switcher
IR 102 Remote Control
40 40
30’
Maximum
Channel
IR 102
0
1 2 3 4
5678
9+10
UniversalRemote
Figure 10. Area for Remote Signal Reception
Remote control buttons
On the IR 102 remote control, buttons 1 through 8 select
inputs.
A Input Selection buttons — Press buttons 1 and 2 to
select an input on the SW2 HD 4K or button 1 through 4
to select an input on the SW4HD 4K. Buttons 5 through 8
do not work with these models.
B Input mute button (0)— Press this button to deselect all
inputs, effectively muting the output.
Locking IR remote access
The SW HD 4K switchers can be set to lock out users from
using the IR 102 to control the switcher. Remote access can
be enabled and disabled via SIS commands (see the Front
Panel IR Receiver Enable and Disable commands on page 22). When remote access
is disabled, all switcher controls remain available through the SW HD 4K front panel.
Locking and Unlocking the Front Panel (Executive Mode)
Front panel lock mode disables all front panel controls, locking out users from those
functions (RS-232, USB, and IR control remain available). Locking the switcher enhances
security by protecting against inappropriate or accidental changes to settings. If a front
panel button is pressed during lock mode, all front panel LEDs blink once.
To lock or unlock the front panel, press and hold Input buttons 1 and 2 simultaneously for
3 seconds, then release. The front panel LEDs blink three times, indicating that executive
mode has been enabled or disabled (see figure 11).
12
Release buttons.
Pr
ess and hold simultaneously
for 3 seconds.
LEDs blink 3 times.
Figure 11. Enabling or Disabling Executive Mode
Universal Remote
INPUT/OUTPUT SELECTION
1234
5678
90 +10
IR 102
A
B
