Extron electronics SW HD 4K PLUS Series User manual

User Guide
SW HD 4K PLUS Series
HDMI Switchers
HDMI Switchers
68-2940-01 Rev. D
12 19
Preliminary

Safety Instructions
Safety Instructions • English
WARNING:This symbol, , when used on the product, is intended to
alert the user of the presence of uninsulated dangerous voltage within the
product’s enclosure that may present a risk of electric shock.
ATTENTION: This symbol, , when used on the product, is intended
to alert the user of important operating and maintenance (servicing)
instructions in the literature provided with the equipment.
For information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide, part number 68-290-01, on the Extron
website, www.extron.com.
Sicherheitsanweisungen • Deutsch
WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer darauf
aufmerksam machen, dass im Inneren des Gehäuses dieses Produktes
gefährliche Spannungen herrschen, die nicht isoliert sind und die einen
elektrischen Schlag verursachen können.
VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in
der im Lieferumfang enthaltenen Dokumentation besonders wichtige
Hinweise zur Bedienung und Wartung (Instandhaltung) geben.
Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,
EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie in
den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer
68-290-01) auf der Extron-Website, www.extron.com.
Instrucciones de seguridad • Español
ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,
avisa al usuario de la presencia de voltaje peligroso sin aislar dentro del
producto, lo que puede representar un riesgo de descarga eléctrica.
ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa
al usuario de la presencia de importantes instrucciones de uso y
mantenimiento recogidas en la documentación proporcionada con el
equipo.
Para obtener información sobre directrices de seguridad, cumplimiento
de normativas, compatibilidad electromagnética, accesibilidad y temas
relacionados, consulte la Guía de cumplimiento de normativas y seguridad
de Extron, referencia 68-290-01, en el sitio Web de Extron, www.extron.com.
Instructions de sécurité • Français
AVERTISSEMENT : Ce pictogramme, , lorsqu’il est utilisé sur le
produit, signale à l’utilisateur la présence à l’intérieur du boîtier du
produit d’une tension électrique dangereuse susceptible de provoquer
un choc électrique.
ATTENTION : Ce pictogramme, , lorsqu’il est utilisé sur le produit,
signale à l’utilisateur des instructions d’utilisation ou de maintenance
importantes qui se trouvent dans la documentation fournie avec le
matériel.
Pour en savoir plus sur les règles de sécurité, la conformité à la
réglementation, la compatibilité EMI/EMF, l’accessibilité, et autres sujets
connexes, lisez les informations de sécurité et de conformité Extron, réf.
68-290-01, sur le site Extron, www.extron.com.
Istruzioni di sicurezza • Italiano
AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad
avvertire l’utente della presenza di tensione non isolata pericolosa
all’interno del contenitore del prodotto che può costituire un rischio di
scosse elettriche.
ATTENTZIONE: Il simbolo, , se usato sul prodotto, serve ad avvertire
l’utente della presenza di importanti istruzioni di funzionamento e
manutenzione nella documentazione fornita con l’apparecchio.
Per informazioni su parametri di sicurezza, conformità alle normative,
compatibilità EMI/EMF, accessibilità e argomenti simili, fare riferimento
alla Guida alla conformità normativa e di sicurezza di Extron, cod. articolo
68-290-01, sul sito web di Extron, www.extron.com.
I


Copyright
© 2018-2020 Extron Electronics. All rights reserved. www.extron.com
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or
ExtronElectronics (see the current list of trademarks on the Terms of Use page at www.extron.com):
Registered Trademarks (®)
Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, Flat Field, FlexOS, Glitch Free. Global
Configurator, GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink,
MediaPort, NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch,
StudioStation, SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VideoLounge, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP,
XTPSystems, and ZipClip
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), Auto-Image, AVEdge, CableCover, CDRS(ClassD
Ripple Suppression), Codec Connect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator,
DSPConfigurator, DSVP(Digital Sync Validation Processing), eLink, EQIP, Everlast, FastBite, Flex55, FOX, FOXBOX, IP Intercom
HelpDesk, MAAP, MicroDigital, Opti-Torque, PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent,
Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free, SpeedNav, Triple-Action Switching, True4K, Vector 4K , WebShare, XTRA, and
ZipCaddy

FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause interference. This interference must be corrected at the expense of the user.
ATTENTION:
• The Twisted Pair Extension technology works with unshielded twisted pair (UTP)
or shielded twisted pair (STP) cables; but to ensure FCC Class A and CE
compliance, STP cables and STP Connectors are required.
• La technologie extension paires torsadées fonctionne avec les câbles paires
torsadées blindées(UTP) ou non blindées(STP). Afin de s’assurer de la
compatibilité entre FCC ClasseA et CE, les câbles STP et les connecteurs STP
sont nécessaires.
NOTES:
• (This 1st paragraph is for TP ONLY, delete for all others products) This unit was
tested with shielded I/O cables on the peripheral devices. Shielded cables must be
used to ensure compliance with FCC emissions limits.
• (if only this paragraph is used, reformat to single NOTE format.) For more
information on safety guidelines, regulatory compliances, EMI/EMF compatibility,
accessibility, and related topics, see the Extron Safety and Regulatory
Compliance Guide on the Extron website.
VCCI-A Notice
この装置は、クラスＡ情報技術装置です。 この装置を家庭環境で使用すると、電波妨害を引き
起こすことがあります。 その場合には使用者が適切な対策を講ずるよう要求されることがあります。
ＶＣＣI－Ａ

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
WARNING: Potential risk of severe injury or death.
AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
CAUTION: Risk of minor personal injury.
ATTENTION : Risque de blessuremineure.
ATTENTION:
• Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
E X! *X1&*X2)*X2#*X2! CE}
NOTE: For commands and examples of computer or device responses used in this
guide, the character “0” is the number zero and “O” is the capital letter “o.”
Computer responses and directory paths that do not have variables are written in the font
shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in slanted form as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are
written in the font shown here:
From the File menu, select New.
Click the OK button.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
Extron Glossary of Terms
A glossary of terms is available at http://www.extron.com/technology/glossary.aspx.

Contents Contents
Introduction ...............................................1
About this Guide.................................................. 1
The SW HD 4K PLUS Series Switchers ............... 1
Features .............................................................. 1
Application Diagram ............................................ 3
Installation.................................................4
Installation Overview ............................................ 4
Rear Panel Features ............................................ 5
Wiring the Power Connector (SW2 and SW4
HD 4K PLUS Only) ............................................. 7
Wiring for RS-232 Control ................................... 9
Wiring the CONTACT/TALLY Connectors........... 10
SW2 and SW4 CONTACT/TALLY
Connectors................................................... 10
SW6 and SW8 CONTACT IN/TALLY OUT
Connectors................................................... 11
Connecting Using a Show Me Cable ............. 12
LockIt HDMI Cable Lacing Bracket Installation... 12
Operation.................................................13
Front Panel Features.......................................... 13
Operations......................................................... 15
Powering on the Switcher.............................. 15
Selecting an Input.......................................... 15
Auto-input Switching ..................................... 16
Resetting ....................................................... 16
EDID Minder .................................................. 17
Remote Configuration and Control .......... 18
Using Simple Instruction Set (SIS) Commands... 18
Host-to-switcher Communications ................ 18
Switcher-initiated Messages .......................... 18
Error Responses............................................ 19
Using the Command and Response Table ......... 19
Symbol Definitions ......................................... 19
Command and Response Table for SIS
Commands ...................................................... 23
Downloading the SW HD 4K PLUS Firmware .... 32
Accessing the Product Configuration
Software........................................................... 34
Downloading and Installing PCS .................... 34
Starting PCS.................................................. 37
Internal Web Page ...................................38
Accessing the Web Page................................... 38
Web Page Overview .......................................... 39
Communication Settings Panel ...................... 39
Device Info Panel ........................................... 40
Date/Time Settings Panel .............................. 41
Configure This Device Panel .......................... 43
Passwords Panel........................................... 43
Reference Information.............................44
Mounting the SW HD 4K PLUS Switchers ......... 44
Tabletop Use ................................................. 44
Rack Mounting .............................................. 44
Furniture Mounting......................................... 45
viiTechnical Publications Standards and Styles • Contents

Technical Publications Standards and Styles • Contents viii

SW HD 4K PLUS Series • Introduction 1
Introduction
This section gives an overview of the Extron SW HD 4K PLUS Series switchers. Topics
include:
• About this Guide
• The SW HD 4K PLUS Series Switchers
• Features
• Application Diagram
About this Guide
This guide describes the SW HD 4K PLUS Series switchers and discusses how to install,
configure, and operate them.
In this guide, the terms “SW HD 4K PLUS Series,” “SW HD 4K PLUS,” and “switcher” refer
to both the SW2 HD 4K PLUS and the SW4 HD 4K PLUS switchers. “SW2,” “SW4,” “SW6,”
and “SW8” are used to refer to the specific model.
The SW HD 4K PLUS Series Switchers
The Extron SW HD 4K PLUS series are two, four, six, and eight input HDMI switchers that
support 4K video signals up to 60 Hz. They switch 4K @ 60 Hz signals between multiple
HDMI source devices to a single display. The switchers support computer and video
resolutions up to 4K @ 60 Hz and 1080p @ 60 Hz, data rates up to 18 Gbps, HDR, 12-bit
Deep Color, 3D, Lip Sync, and HD lossless audio formats.
The SW HD 4K PLUS Series offers control via front panel buttons, USB, Extron Product
Control Software (PCS), Ethernet, RS-232, contact closure, and auto-input switching for
integration with any control system. Front panel LED indicators provide immediate visual
confirmation of HDCP authentication and signal presence for each input and output.
Features
• Switches HDMI video and embedded multi‑channel digital audio
• Inputs — Two, four, six, or eight female HDMI type-A connectors
• Output — 1 female HDMI type-A connector
• Computer and video resolutions up to 4K @ 60 Hz — Supports resolutions up
to 4096x2160 @ 60 Hz, with 4:4:4 chroma sampling at 8 bits of color, including
1080p @ 60 Hz Deep Color.
• EDID Minder — Automatically manages EDID communication between connected
devices, ensuring all sources power up properly and reliably output content for display.
• Automatic input cable equalization to 25 feet (7.6 meters) when used with
Extron HDMI Pro Series cable — Actively conditions incoming HDMI signals to
compensate for signal loss when HDMI cables, low quality HDMI cables, and source
devices with poor HDMI signal output are used.

SW HD 4K PLUS Series • Introduction 2
• HDCP 2.2 compliance — Ensures display of content-protected 4K video media and
maintains interoperability with earlier versions of HDCP.
• User‑selectable HDCP authorization — Allows individual inputs to appear HDCP
compliant or non-HDCP compliant to the connected source. This is beneficial if the
source automatically encrypts all content when connected to an HDCP-compliant
device. Protected material is not passed in non-HDCP mode.
• HDMI 2.0b specification features — Include data rates up to 18 Gbps, HDR, Deep
Color up to 12 bit, 3D, and HD lossless audio formats.
• HDCP authentication and signal presence LED indicators
• Ethernet monitoring and control — Enables control and proactive monitoring over a
LAN, WAN, or the Internet.
• Automatic color bit depth management — Automatically adjusts color bit depth
based on the display EDID, preventing color compatibility conflicts between source and
display.
• High Dynamic Range (HDR) video support — Enables greater contrast range
and wider color gamut by providing the necessary video bandwidth, color depth, and
metadata interchange capability for HDR video.
• Provides +5 VDC, 250 mA power on the output for external peripheral devices
• Extron Product Configuration Software — Provides a convenient method of
configuring multiple products using a single software application.
• Multiple control options including front panel, RS‑232, USB, contact closure,
and Ethernet.
• Contact closure remote control with tally output — Allows for remote selection of
an input channel. +5 VDC is provided to light an LED to indicate the currently selected
input.
• Includes LockIt®HDMI cable lacing brackets.
• HDMI to DVI Interface Format Correction — Automatically reformats HDMI source
signals for output to a connected DVI display.
• Front panel security lockout — Prevents unauthorized use in non-secure
environments. In lockout mode, all functions are available through RS-232 and PCS
control.
• External universal power supply included — The highly reliable, energy-efficient
power supply (replacement part #70-769-01) provides worldwide power compatibility
with high reliability and low power consumption for reduced operating costs. It features
three 12 volt DC outputs, and includes a ZipClip 100 Mounting Kit to securely mount an
Extron power supply onto most surfaces, including tables and lecterns.
• Provides +5 VDC, 250 mA power on the output for external peripheral devices.

SW HD 4K PLUS Series • Introduction 3
Application Diagram
The following diagram shows a typical application for a SW4 HD 4K PLUS.
SW4 HD 4K PLUS
0.5A MAX
POWER
12V
1234
LAN
C T C T +V
12
CTCT
3 4
Tx Rx G
RS-232
INPUTS OUTPUT REMOTE
POWER
12V
--AMAX
G
Tx Rx RTSCTS
COM1
G
Tx Rx
COM2
VC G
VOL RELAYS
1 2 C
1 2 3 4 G
DIGITALI/O
PWR OUT = 6W
eBUS
+V+S - S G
LAN
IPCP PRO 250
IR/S
S G
Extron
Extron
HelpSystem
Off
Display
Room
Control
Off
Mute
Screen
Lighting
December15,2013 - 7:58 AM
Audio
Control
Volume
Mute
Tuner
123
VCR
Laptop PC DVD Doc
Cam
Tuner
On
Channel
Last
Presets
More
Presets
3
2
1
6
5
4
9
8
7
Enter
0
Laptop
DSS Receiver
4K Media Player
4K Display
Extron
SW4 HD 4K PLUS
Four Input HDMI
4K/60 Switcher
PC
HDMI
HDMI
Ethernet
Ethernet
Ethernet
Extron
TLP Pro 720T
7" Tabletop
TouchLink Pro
Touchpanel
Extron
IPCP Pro 250
IP Link Pro Control
Proceesor TCP/IP
Network
Figure 1. SW4 HD 4K PLUS Application Diagram
1

SW HD 4K PLUS Series • Installation 4
Installation
This section describes the installation and setup of the SW HD 4K PLUS Series switchers.
Topics include:
• Installation Overview
• Rear Panel Features
• Wiring the Power Connector (SW2 and SW4 HD 4K PLUS Only)
• Wiring for RS‑232 Control
• Wiring the CONTACT/TALLY Connectors
• LockIt HDMI Cable Lacing Bracket Installation
Installation Overview
To install and set up the SW HD 4K PLUS Series switcher:
1. Turn off all equipment and disconnect it from the power source.
2. (Optional) Mount the switcher on a rack shelf or furniture (see Mounting the
SW HD 4K PLUS Switchers on page 44).
3. Connect HDMI input sources to one or more of the SW HD 4K PLUS input
connectors.
NOTE: LockIt cable lacing brackets, one for each HDMI input and output
connector, are provided with the SW HD 4K PLUS series. These brackets can
be used to secure the HDMI cables to the rear panel connectors to reduce
stress on the HDMI connectors and prevent signal loss due to loose cable
connections. For information on attaching the LockIt brackets, see LockIt
HDMI Cable Lacing Bracket Installation on page 12.
4. Connect an HDMI output device to the output connector. By default, the EDID of this
device is stored at the HDMI inputs.
5. Connect control devices. Connect your computer to one of the following
SW HD 4K PLUS ports to configure and control the switcher via SIS commands:
• RS‑232 port — 3-pole captive screw connector for serial RS-232 control (see
Wiring for RS‑232 Control on page9 for connection procedures)
• Config port — USB mini-B connector for USB control
• LAN port — RJ-45 connector for Ethernet control
6. Power on the output display.
7. Connect power to the switcher (see Powering on the Switcher on page15).
8. (Optional) Configure the EDID Minder (see EDID Minder on page17).
9. Power on the source devices.

SW HD 4K PLUS Series • Installation 5
Rear Panel Features
SW2 HD 4K PLUS
-- A MAX
POWER
12V
1 2
LAN
CTCT+V
12
Tx Rx G
RS-232
INPUTS OUTPUT REMOTE
FB
ACE
G
D
SW4 HD 4K PLUS
-- A MAX
POWER
12V
1 2 3 4
LAN
CTCT
34
CTCT+V
12
Tx Rx G
RS-232
INPUTS OUTPUT REMOTECONTACT / TA LLY
GG
F
B
AC E
D
APower connector ERS‑232 connector
BInput connectors FLAN (Ethernet) connector
COutput connector GContact closure input and tally output ports
D+V connector
Figure 2. SW2 and SW4 HD 4K PLUS Rear Panels
H
H
H
E
E
E
D
D
D
F
F
F
SW6 HD 4K PLUS
Tx Rx G
GCT GC
G
1
2
3
4
CT TGC G
6
CT
TGCT
5
+V
RS-232
CONTACT IN/TALLY OUT
INPUTS
1 2 3 4 5 6
100-240V 0.2A MAX
50/60 Hz
OUTPUT
REMOTE
LAN
RESET
SW8 HD 4K PLUS
Tx Rx G
GCT GC
G
1
2
3
4
CT TGC G
68
CT TGC
TGCT GC
57
T+V
RS-232
CONTACT IN/TALLY OUT
INPUTS
1 2 3 4 5 6 7 8
100-240V 0.2A MAX
50/60 Hz
OUTPUT
REMOTE
LAN
RESET
A
A
AB
B
B
D
D
D
CC
H
H
H
E
E
EF
F
F
GG
APower connector ERS‑232 connector
BInput connectors FLAN (Ethernet) connector
COutput connector GContact closure input and tally output ports
D+V connector HReset button
Figure 3. SW6 and SW8 HD 4K PLUS Rear Panels
A Power connector —
• SW2 and SW4 — Plug the provided external 12 VDC, 1.5 A power supply into this
2-pole, 3.5 mm captive screw connector and into an AC power outlet.
• SW6 and SW8 — Connect this male IEC connector to an AC power source.
2
3

SW HD 4K PLUS Series • Installation 6
BInput connectors — Connect HDMI video input sources to these female Type A HDMI
connectors.
NOTE: LockIt cable lacing brackets are provided with the SW HD 4K PLUS units.
These brackets secure the HDMI cables to the rear panel connectors and reduce
stress on the connectors, preventing signal loss due to loose cable connections
(see LockIt HDMI Cable Lacing Bracket Installation on page 12 for more
information).
COutput connector — Connect an HDMI display device to this female HDMI A
connector.
The EDID information is read from the connected output device via this connector and is
written to memory on each input whenever the output device is connected to this port
and powered on.
NOTE: The EDID information is also read and stored whenever power is recycled to
the connected output device or when the output device is replaced.
D+V connector — The +V pin (SW2 and SW4) or the 3-pin connector (SW6 and SW8)
constantly outputs +5 VDC with 200 mA total (shared between pins). Use this pin when
power is needed for external Tally LEDs, such as Extron Show Me cables.
ERS‑232 connector — Use this 3-pole, 3.5 mm captive screw connector for RS-232
communication with the switcher (including firmware updates).
To enable RS‑232 control, connect the Tx (transmit), Rx (receive) and G (ground) pins
to the serial port of your computer (see Wiring for RS‑232 Control on page9).
FLAN (Ethernet) connector — Use an RJ-45 cable to connect this jack to a LAN for
control of the switcher via Ethernet.
• Use a straight-through cable for connection to a switch, hub, or router.
• Use a crossover cable or a straight-through cable for connection directly to a PC.
Wire the connector as shown in the image below.
RJ-45
Connector
Insert Twisted
Pair Wires
Pins:
12345678
Straight-through Cable
(for connection to a switch, hub, or router)
End 1 End 2
Pin Wire Color Pin Wire Color
1 white-orange 1 white-orange
2 orange 2 orange
3 white-green 3 white-green
4 blue 4 blue
5 white-blue 5 white-blue
6 green 6 green
7 white-brown 7 white-brown
8 brown 8 brown
Crossover Cable
(for direct connection to a PC)
End 1 End 2
Pin Wire Color Pin Wire Color
1 white-orange 1 white-green
2 orange 2 green
3 white-green 3 white-orange
4 blue 4 blue
5 white-blue 5 white-blue
6 green 6 orange
7 white-brown 7 white-brown
8 brown 8 brown
T568B T568AT568BTIA/EIA-T568B
Figure 4. Wiring for Ethernet Control
GContact closure input and tally output ports —
• SW2 — The CONTACT/TALLY panel contains one 5-pole captive screw connector
with two pairs of pins labeled C(contact) and T(tally), and a +V pin that supplies
power to an optional indicator device.
SW4 — The CONTACT/TALLY panel contains one 5-pole connector with two pairs
of pins labeled Cand T, and a +V pin that supplies power to an optional indicator
device. It also has a 4-pole captive screw connector with two more C-Tpin pairs.
(Optional) Connect a push-button contact closure device to a Cpin and to the G
(ground) pin of the 3-pole RS-232 connector (see figure2, E, on the previous
page). Connect an indicator device, such as an LED, to tally output pin Tof the
same pin pair, to identify the currently selected input when the front panel buttons
are not visible.
4

SW HD 4K PLUS Series • Installation 7
• SW6 and SW8 — The CONTACT IN/TALLY OUT panel contains six (SW6) or eight
(SW8) 3-pole captive screw connectors, each with a C(contact), T(tally), and G
(ground) pin.
(Optional) Connect a push-button contact closure device to the Cand Gpins of
one of the 3-pole connectors (see figure3, G, on page 5). Connect an indicator
device, such as an LED, to tally output pin Tof the same connector, to identify the
currently selected input when the front panel buttons are not visible.
See Wiring the CONTACT/TALLY Connectors on page10 for more information.
HReset button —The Reset button initiates three modes of reset for the switcher. For
the different reset levels, press and hold the button while the switcher is running or
while you power up the switcher (see Resetting on page16 for details).
NOTE: The factory configured passwords for all accounts on this device have been
set to the device serial number. In the event of an absolute system reset, the
passwords convert ot the default, which is no password.
Wiring the Power Connector (SW2 and SW4 HD 4K PLUS Only)
A 12 VDC, 1.5 A, pre-wired power supply is provided with the SW2 and SW4 HD 4K PLUS.
If, instead, you intend to use a different power supply, follow the instructions beginning on
the next page to wire the provided 2-pole captive screw connector to your power supply.
CAUTION: The wires must be kept separate while the power supply is plugged in.
Remove power before wiring.
ATTENTION : Les deux cordons d’alimentation doivent être tenus à l’écart l’un
de l’autre quand l’alimentation est branchée. Couper l’alimentation avant de faire
l’installation électrique.
ATTENTION:
• Always use a power supply supplied and or specified by Extron. Use of an
unauthorized power supply voids all regulatory compliance certification and may
cause damage to the supply and the end product.
• Utilisez toujours une source d’alimentation fournie ou recommandée par Extron.
L’utilisation d’une source d’alimentation non autorisée annule toute conformité
réglementaire et peut endommager la source d’alimentation ainsi que le produit
final.
• If not provided with a power supply, this product is intended to be supplied by a
power source marked “Class 2” or “LPS” and rated at 12 VDC and a minimum of
1.5 A.
• Si ce produit ne dispose pas de sa propre source d’alimentation électrique, il doit
être alimenté par une source d’alimentation de classe 2 ou LPS et paramétré à 12
V et 1.5 A minimum.
• The installation must always be in accordance with the applicable provisions of
National Electrical Code ANSI/NFPA 70, article 725 and the Canadian Electrical
Code part 1, section 16. The power supply shall not be permanently fixed to
building structure or similar structure.
• Cette installation doit toujours être en accord avec les mesures qui s’applique
au National Electrical Code ANSI/NFPA70, article725, et au Canadian Electrical
Code, partie1, section16. La source d’alimentation ne devra pas être fixée de
façon permanente à une structure de bâtiment ou à une structure similaire.

SW HD 4K PLUS Series • Installation 8
ATTENTION:
• Power supply voltage polarity is critical. Incorrect voltage polarity can damage the
power supply and the unit. The ridges on the side of the cord (see figure5) identify
the power cord negative lead.
• La polarité de la source d’alimentation est primordiale. Une polarité incorrecte
pourrait endommager la source d’alimentation et l’unité. Les stries sur le côté du
cordon permettent de repérer le pôle négatif du cordon d’alimentation.
• To verify the polarity before connection, plug in the power supply with no load and
check the output with a voltmeter.
• Pour vérifier la polarité avant la connexion, brancher l’alimentation hors charge et
mesurer sa sortie avec un voltmètre.
• The length of the exposed (stripped) copper wires is important.
The ideal length is 3/16 inch (5 mm). Longer bare wires can short together. Shorter
wires are not as secure in the connectors and could be pulled out.
• La longueur des câbles exposés est primordiale lorsque l’on entreprend de les
dénuder. La longueur idéale est de 5mm (3/16inches). S’ils sont un peu plus
longs, les câbles exposés pourraient se toucher et provoquer un court circuit. S’ils
sont un peu plus courts, ils pourraient sortir, même s’ils sont attachés par les vis
captives.
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling
spaces or in wall cavities.
• Sauf mention contraire, les adaptateurs AC/DC ne sont pas appropriés pour une
utilisation dans les espaces d’aération ou dans les cavités murales.
1. Cut the DC output cord to the length needed.
2. Strip the jacket to expose 3/16 inches (5 mm) of the conductors.
3. Slide the leads into the supplied 2-pole captive screw plug, and use a small screwdriver
to secure them.
4. To verify the power cord polarity before connecting the plug, connect the power supply
with no load and check the output with a voltmeter.
5. Use the supplied tie wrap to strap the power cord to the extended tail of the connector.
Captive Screw Connector
Tie Wrap
Heat
Shrink 1/8"
(3 mm)
7/8"
(22 mm)
3/16"
(5 mm) Max.
Figure 5. Wiring the Power Connector (SW2 and SW4 Only)
5

SW HD 4K PLUS Series • Installation 9
Wiring for RS-232 Control
Use a female 9-pin D-to-bare wire RS-232 cable or a universal control cable (UC50' or
UC100') to connect your computer or control system to the RS-232 pins of the Remote
connector.
1. Wire the unterminated end of the RS-232 cable to the provided 3-pole captive screw
plug as described below. Connect the transmit, receive, and ground wires of the cable
to the first three pins on the connector, starting at the left:
• Connect the transmit wire to pin 1 which plugs into the Tx (transmit) port.
• Connect the receive wire to pin 2 which plugs into the Rx (receive) port.
• Connect the ground wire to pin 3 which plugs into the G(ground) port.
2. Plug the 3-pole connector into the Remote receptacle on the rear panel of the switcher.
3. Connect the other end of the cable to the appropriate computer or control system
connector.
Figure 6 shows how to wire this shared connector for RS-232.
Computer or
Control Syste
m
RS-232 Port
SW HD 4K PLUS Series Switcher
Rear Panel
Remote Port
NOTE: If you use cable that has a drain
wire, tie the drain wire to ground at both ends.
Ground (G)
Transmit (Tx)
Receive (Rx) Transmit (Tx)
Receive (Rx)
Tx Rx G
RS-232
Figure 6. Remote Connector Pin Assignments
6

SW HD 4K PLUS Series • Installation 10
Wiring the CONTACT/TALLY Connectors
To enable input switching via contact closure, connect a push-button contact closure device
to a Contact connector (see figures 2 and 3, G, on page 5).
To identify the currently selected input when the front panel buttons are not visible, connect
a device such as an LED to the CONTACT/TALLY connector (G) and to the +V connector
(D). When the input you are using is selected, the corresponding Tally Out pin shorts to
ground, activating the connected indicator.
SW2 and SW4 CONTACT/TALLY Connectors
The CONTACT/TALLY panel on the SW2 and SW4 models contains one (SW2) or two (SW4)
female captive screw connectors, each with two pairs of pins labeled Cand T.
1
1
1
444
CTCT
34
CTCT+V
12
Tx Rx G
RS‑232
REMOTECONTACT / TA LLY
222333555
Figure 7. Contact/Tally and Remote RS‑232 Ports on SW2 and SW4 Models
Each pin pair is labeled with the number of the HDMI input associated with it. (For example,
in figure 7, 1, the number 1indicates the contact and tally pins for input 1.) Wire devices to
these connectors as follows:
1. SW2 — Wire and connect the provided 5-pole plug to the 5-pole CONTACT/TALLY
captive screw connector on the rear panel.
SW4 — Wire and connect the provided 5-pole plug to the CONTACT/TALLY
connector on the left (containing pin pairs 1 and 2), and wire and connect the provided
4-pole plug to the connector on the right (pin pairs 3 and 4).
2. Connect contact input and tally output devices to the pin pair for each input:
• To enable input switching via contact closure, connect a push-button contact
closure input device to pin C(2) and to the G(ground) pin (5) of the 3-pole
RS-232 connector.
• To identify the currently selected input when the front panel buttons are not visible,
connect an indicator device, such as an LED, to tally output pin Tof the same pair
of pins (3).
When the input you are using is selected, the corresponding tally out pin shorts to
ground, which activates the connected indicator.
3. Insert the power wires for the contact indicator devices into the +V connector (4).
4. Press the button on the contact closure device to switch the connected input to the
output.
7

SW HD 4K PLUS Series • Installation 11
SW6 and SW8 CONTACT IN/TALLY OUT Connectors
The REMOTE panel on the SW6 and SW8 models contains six (SW6) or eight (SW8) 3-pole
captive screw connectors, each with three pins labeled C, G, and T, for contact closure
and tally indicator devices. The panel also contains a 3-pole captive screw connector with
three +V pins that provide power to the contact indicator devices connected to the tally (T)
ports. (The REMOTE panel also contains the RS-232 connector, which is not used for contact
closure on these models.)
Tx Rx G
GCT GC
G
1
2
3
4
CT TGC G
68
CT TGC
TGCT GC
57
T+V
RS-232
CONTACT IN/TALLY OUT
REMOTE
1
1
12
2
2
Figure 8. CONTACT IN/TALLY OUT Ports on SW6 and SW8 Models
1. Connect contact input and tally output devices to one or more of the 3-pole CONTACT
IN/TALLY OUT connectors (see figure 8, 1) as desired:
• To enable input switching via contact closure, connect a push-button contact
closure input device to pins C(contact) and G(ground).
• To identify the currently selected input when the front panel buttons are not visible,
connect an indicator device, such as an LED, to tally output pin Tof the same
3-pole connector.
When the input you are using is selected, the corresponding tally out pin shorts to
ground, which activates the connected indicator.
2. Attach the power wires for your connected contact indicator devices to any of the three
ports of the +V connector (2).
3. Press the button on the contact closure device to switch the connected input to the
output.
8

SW HD 4K PLUS Series • Installation 12
Connecting Using a Show Me Cable
The CONTACT/TALLY connectors can also be used with Extron Show Me cables. Figure 9
shows how to wire a Show Me cable to a contact input. For each Show Me cable:
CONTACT/TALLY
Connector
Black
Red
Show Me
Cable
CTCT+V
12
SW2 and SW4 HD 4K PLUS
CONTACT IN/TA LLY OUT
Connector
Black
Red
Show Me
Cable
CTG
1
G
2
CT
SW6 and SW8 HD 4K PLUS
Figure 9. Connecting Contact and Tally Ports Using a Show Me Cable
• Connect the red pigtail to the Cpin corresponding to the input being used.
• Connect the black pigtail to the Tpin of the same input.
LockIt HDMI Cable Lacing Bracket Installation
The Extron LockIt lacing bracket secures a
standard HDMI cable to most HDMI devices.
NOTE: The HDMI device must have an
HDMI connection mounting screw for
this bracket to be used.
To securely fasten an HDMI cable to a device:
1. Plug the HDMI cable into the panel
connection.
2. Loosen the HDMI connection mounting screw
from the panel enough to allow the LockIt
lacing bracket to be placed over it. The screw
does not have to be removed.
3. Place the LockIt lacing bracket on the screw
and against the HDMI connector, then tighten
the screw to secure the bracket.
4. Loosely place the included tie wrap around
the HDMI connector and the LockIt lacing
bracket as shown.
5. While holding the connector securely
against the lacing bracket, tighten the tie
wrap, then remove any excess length.
ATTENTION:
• Do not overtighten the HDMI connection mounting screw. The shield to which
it is fastened is very thin and can easily be stripped.
• Ne serrez pas trop la vis de montage du connecteur HDMI. Le blindage auquel
elle est attachée est très fin et peut facilement être dénudé.
9
3
3
4
1
2
