Exuav FlyTower F4 User manual

www.exuavrc.com
FlyTowerF4InstructionsV1.0

Warning
Instructionsforuse
1,PleaseinstallANT(mustbeDONE)before  debuggingortestingVTX（andOSD）,orleadtoVTXnot
workingproperly.
2,PleaseusepropertoolstoinstallFlyTower.ItiseasytodamagethePCBcomponentsbyusingsharp
tools.(warning:Bearinmindthatscrewsdonotinstalltootight between every layer, so as not to
destroythePCBandelectroniccomponents).
3,WhendebuggingandtestingflightcontrolPleaseremoveallthepropeller;Trynottotestindoors,So
asnottocausesafetyaccidents.Installthepropellerbeforeatestflight,pleasecheckagain.
4,PleasecheckandadjustESCplatewelding,thusbringsallthe losses and problems, or you

www.exuavrc.com
shouldfacetheconsequences.
5,Please do not fly your drone near the crowd, for all the losses from the crashed aircraft, you
shouldfacetheconsequences.
6,For your safety, please do not use more than 4s battery, Usingmorethan4sbatterywouldcause
safetyrisk,wewillnotundertakeanyresponsibility.
7,Beforepoweron,pleasecheckthepositiveandnegativepoleagaintomakesurewhetherthereisa
shortcircuit.(youalsohavetocheckthatwhetherthereisashortcircuitbetweenyourmotorcables
andyoudrone’sbody).
8,PleaseuseoriginalscrewsandfixingstoinstallFlyTower.
Productspecifications
PDB Integrated
BatteryMonitoringIntegrated
FCPower Integrated
OperatingVoltage 2-4SLipo
Maximum continuous operating
current
4*40A
Maximum instantaneous operating
current
4*45A(5S)
Oneshort 125/42/Dshot 150/300/600YES
BlheliSuiteConfigurable YES
Firmware VisionBLHeli_S/Dshot 150/300/600 16.5(L_H_00)
BoardSize 36*36mm
4in1ESC

weight 10g
FirmwareVision BateFlight 3.1(OMNIBUS F4SD)
Configure BetaFlight
VTXPower 25/200/400mW(MAX800mW)
CH 40CH
OSDFirmware Bateflight OSD
VideoCameraVoltage Anystandby5VVideoCamera
BoardSize 36*36mm
FC&VTX
Board
weight 11.4g
AnyBoardweight 21.4g
totalweight 28.7g
Installationheight(Addair-coolingfin) 15mm/20mm
Screws M3*18mm
BlackAnts
FlyTowerF4
RecommendedRackPlateThickness Notmorethan3MM（3mmabovetheappropriate
extensionofthescrew）
TheFlyTowerF4boarddesignedbasedOMNIBUS(BateFlight)FCandwashighlyintegrated
withOSD,BEC,4in1BLHeli_S/Dshot 600ESCandVTX(25/200/400mW).Itgivesyouallthefeatures
whatyouneedinFPV,whichmakesyoueasilygetintoFPVRacing.


www.exuavrc.com
★Practical‐Easytoaccessconnectors
★Configurable‐Choosetouseconnectors
★Stackable‐Mountour4in1ESC
★Compact‐Only36x36x15mm.(Addair‐coolingfinMAX36*36*20MM)
★Weight‐28.7gramsand2stackboards
★Professional‐Symmetrical,NeatandTidyandEasytoinstallinanyracingdrone
★36x36mmboardwith30.5mmmountingholes
★STM32F405MCU,RunsBetaflightfirmware(supportedfromv3.0)
★SDcardslot
★UseMPU6000asAcc&gyroOverSPIBus
★STM32 controls OSD chip over SPI in DMA mode, less CPU using, faster rate
★MicroUSBsocket
★1x6pinsJST‐SHsockets(PPM,PWM,SERIALRX,GPIO,ADC,3V,5V,GND)
★Theon‐boardpinsareeasilyconnectedtoournext4in1ESC&PDBboard
★InternalVTX(40CH)(25/200/400MWadjustablepowervideotransmission)
★1x4pinsJST‐SHsocketswithBUZZER&WS2811RGBLED
★1x4pinsJST‐SHsocketforVideo&Audiotransmission
★1IPXsocketseasyconnecttheexternalantenna
★4x3Padsformotoroutput
★1x2Padsforbatterineasysolder


1,Betaflight

https://github.com/Betaflight
Thehardwareconnectiondiagram
1,4in1Board

www.exuavrc.com


2,FCboardToplayer


www.exuavrc.com

3,FCBottomlayer


www.exuavrc.com

How to use the onboard USB port updated firmware
in GUI on windows
To flash the firmware you have to enter the so called DFU mode. On Windows 10 I
had to use a tool called Zadig (download and start it) to be able to switch drivers for
DFU mode to work. In order to switch drivers you have to take the following steps.
Down: http://zadig.akeo.ie/

www.exuavrc.com
•Push BOOT button on the flight controller.
•Plug-in the USB cable (the red LED should not be as bright as normally).
•Fire up Zadig and hit “Options”and then “List All Devices”.
•From the list choose “STM32 BOOTLOADER”.
•Under “Driver”choose “WinUSB”on the right and hit “Reinstall Driver”.
•Close Zadig, disconnect the flight controller, close all Google Chrome instances.
Schematicdrawingsoftwaresettings

HowtouseandupgradeFCfirmware

www.exuavrc.com

HowtosetS.BUS/PPM/DSMXRCIN

www.exuavrc.com


www.exuavrc.com


www.exuavrc.com


OSDsettingandubgradefirmware

www.exuavrc.com

ESCuseandupgradefirmware
1.Open


www.exuavrc.com
2,Choose

3,Chooseaport


www.exuavrc.com
4,ConnentUSBcabletoFlyTowerF1FCBoard
5,Connect
6,ConnetBATPowertoESCboard
7,CheckESCInformation
8,CheckFlashShow

9,Formoreinformationview


www.exuavrc.com
10,UpgradeFlashforESC

11,ChooseESCFirmwareandupgrade



VTXuseandsettings
1,VTX key switch Instructions (print on VTX on FC and VTX boardhasasmallerror),justfollowthis
picture:

www.exuavrc.com
2,Channelswitch:shortpressSK,CH1-CH8intheregroup,thecurrentchannellightsflash1HZ ，and
shortclicktojumptothenextCH.Forexample,thecurrentstateofCH1,shortpressSK,CH1flash.And
thenpressSK,jumptoCH2flash,continuetopressSK,CH3flash. This process to do the cycle of
CH1-CH8(4lightsshowthe8CHchannels,detaileddescriptionofthefollowingtable).5secondslater
thesettingwillexitwithouttouchingSK.
3,Frequencygroupswitch:longpress2secondsSK,A-Ewherethebandgroupslowflash1HZ,andthen
clickontheSKforalongtime,afterthereleasewilljumptothenextgroup.Forexample,thecurrent
workingstateisAgroupCH1status.LongpressSKtwosecondsandreleasetheAslowflash1HZ,and
thenlongbytwosecondsSKrelease,jumptoBslowflash1HZ.Thesecondprocessissameasabove.Do
A-Epolling,notehere:(A-B-C-DtoindicatethattheEband,A-B2lightsallbright).Similarly,donot
touchtheSK,5secondsaftertheautomaticexitsettings.Followupwilllaunch60channelBC,CD,AC,
AD,BDchannels,etc.
4,Powerswitch:fastshortpressSKtwo,thenA-Efrequencygroupundertheconditionoffullbright
light,quickpressattwounderSK,thenbegantoswitchpower,thecorrespondingpoweris25mW
200mW400mWfrequencylight:bright1istheminimumpower,bright2isamediumpower,the3is
brightthemaximumpower.



www.exuavrc.com

Detailchannelandfrequencytable ：
CH11brightlights 5865 CH11brightlights 5733
CH22brightlights 5845 CH22brightlights 5752
CH33brightlights 5825 CH33brightlights 5771
CH44brightlights 5805 CH44brightlights 5790
CH51，2brightslight 5785 CH51，2brightslight 5809
CH62，3brightslight 5765 CH62，3brightslight 5828
CH73，4brightslight 5745 CH73，4brightslight 5847
BandA
Abright
lights
CH81，2，3，4brightslight 5725
BandB
Bbright
lights
CH81，2，3，4brightslight 5866
CH11brightlights 5705 CH11brightlights 5740
CH22brightlights 5685 CH22brightlights 5760
CH33brightlights 5665 CH33brightlights 5780
CH44brightlights 5645 CH44brightlights 5800
CH51，2brightslight 5885 CH51，2brightslight 5820
CH62，3brightslight 5905 CH62，3brightslight 5840
CH73，4brightslight 5925 CH73，4brightslight 5860
BandC
Cbright
lights
CH81，2，3，4brightslight 5945
BandD
Dbright
lights
CH81，2，3，4brightslight 5880
CH11brightlights 5658
CH22brightlights 5695
CH33brightlights 5732
CH44brightlights 5769
CH51，2brightslight 5806
CH62，3brightslight 5843
CH73，4brightslight 5880
BandE
ABbright
lights
CH81，2，3，4brightslight 5917

