EyeTech DES-S Series Manual

Hybrid (S) Install Manual
Digital Surveillance Solution
Version 1.0.9.02
Phone; 877-2eyetech (239-3832) or 909-989-1040
E-mail; [email protected]om
Website; www.eyetechdigital.com

Content
Main Function Setup Features Page
Major Features 4
Major Application Sites 5
System Components 6
System Specification Board Specification/System Configuration 7~8
System Description and External Parts Connection 9
Live View Live Monitoring View 10
Log In/Logout 11
Automatic Log Out 12
Control <Live View Screen> 13~14
Setup <Initial Screen Display>(Default Screen) 15~17
Description of each Icon in <Live Screen Window> 18~21
How to use Audio/Audio Setup/Audio in Live View 22~25
Alarm In/Out (How to connect Sensor/Relay) 26~28
Alarm In/Out (How to Setup Sensor/Relay) 29
Alarm In/Out (How to Setup Relay Schedule) 30~31
Alarm In/Out (Check the working Status) 32
How to control Image Quality 33
System Information and Manual Backup 34~35
LogViewer 36
How to setup Camera Name and OSD 37~38

Content
Live View Covert Camera (Hide Screen) 39
PTZ Control : PTZ Control Devices 40
PTZ Control : How to use RS232C 41
PTZ Control : How to use EIO USB Serial Converter 41
PTZ Control : How to use DI/DO Serial Converter 42
PTZ Control : How to Setup 43
PTZ Control : How to Control PTZ Camera 44~45
PTZ Control : How to Setup and Control <Preset> 46
PTZ Control : How to Setup and Control <Touring> 47~48
Search & Playback How to use <Instant Playback> and <Instant Playback Player> 49
How to use <Search and Playback> 50
1CH Search/Multi CH Search 51~53
Combination Search/Panorama Search 54~55
Zoom/Book Mark/Area Zoom/Print Image 56~59
Smart Search/Save as <Jpeg & AVI> file 60~67
Backup in CD/DVD/Image Tool 68~69
Backup Manual /Schedule/Concurrent Backup 70~72
View Backup by <Backup View> 73~74
System Setup System Setup/Port Setup, 75~77
Direct Web/IP Product Setup (Fixed IP) 78~80

Content
System Setup IP product Setup (Dynamic IP) 81~82
Setup DVR in Dynamic IP(DIMS) 83~84
DIMS and WEB DVR 85~89
System Setup : Device Setup Device Setup 90~91
Device Setup, Motion Recording, Recording Schedule 92~95
Holiday Recording Schedule/Sensor/Relay, TDS Setup 96~100
System Setup : Display Setup Display Setup/TV-Out 101~103
System Setup : Event Setup Event Setup/Motion Notify Setup 104~106
Sensor Notify/ Remote Notify 107~111
CMS Setup/Working 112~115
System Setup : User Setup User Management Setup 116~117
Appendix 1. Image Analyst 118~119
2. How to setup and use IP Router/Linksys Router 120~123
3. Recover <Image DB> 124~125
4. Direct Backup 126
5. Copy <DAT> files 127
6. How to use 2-Way Audio 128~135
7. Go out to Window Mode 136
8. DVR SW and Folder description 137
9. Exe File description 138~140

DES-S Series User Manual
4
Major Features
Clear Image Quality
No Tearing and De-interlace
In Live and Playback
High Performance , Compression
Software Modified Mpeg4
ADPCM Audio
Stable System
Less CUP load around 30%
No Fragment File System
User Friendly
Various Event Control
GUI and Tool Tip
Easy Install CD
Various Applications
NCMS, DTVS, Web DVR
DMS(DVR Management System)
SDK for 3rd party Integration
DES-S Series
Synchronized Audio
In Live, Search and Backup
(AVI, Backup view)
Network
Various IP products
(including Major IP brands like Axis)
Analog Camera
Differences between ordinary PC DVR and Eyetech PC DVR Major Features of DES-S Series PC DVR
Simply It is Hybrid DVR
Analog + IP
Major feature of Securus Hybrid DVR

DES-S Series User Manual
5
Applied Areas for Securus Hybrid DVR
Parking Lot, Building Management,
Unattended Controlling Center, Factory
Line Surveillance
Access Control, etc
Chain Store, Convenient Shop, Super
Market, Big restaurant, Gas Station.
* Can integrate with POS
(Point of Sales)
IBM, Apartment Management etc Bank, Automatic Devices , Public and
GOV building and project
* Can integrate with ATM (Auto Teller
Machine in Bank)
Mobile Surveillance PDA , Smart phone Viewer
Major Application Sites
Not only Recoding through Analogue data but also using powerful Network and IP Functions,
users can apply this to various sites like below.
Applied Areas

DES-S Series User Manual
6
DVR System (1SET) Power Cable / KEY
User Manual Screws
Installation CD
-Manual
-Driver
-Setup S/W
-Others
Keyboard/ Mouse
OS License Label( Windows XP or 7 )
Others components( Different according to System)
System Components
DVR Set Components

DES-S Series User Manual
7
Board Specification
System Specification
Model GED-S5500 GED-S4000 GED-S2000
GENERAL
Video Input 20 CH (16 plus 4 IP camera) 16 CH (16 minus 4 IP camera) 20 CH (16 plus 4 IP camera)
Video Output 1 XGA, 1 Composite (Mux), 4 Spot-out (option) 1 XGA, 1 Composite (Rotation),
1 Spot-out
Alarm Input 16 4 (default) , 16 (option)
Alarm / Relay Output 4 Alarm / Relay Output
Audio Input 16 2 (default)+16 (option)
Loop-out L-out 16 X 1 (option)
Control Device Mouse, Keyboard, Virtual Keyboard
Archiving USB (Stick, HDD, DVD), CD-RW, DVD-RW
PTZ Control RS 422/485, USB serial converter
DISPLAY
Codec Modified MPEG 4
Resolution : NTSC 720 X 480 , 720 X 240 , 360 X 240 704 X 480 , 704 X 240 , 352 X 240 704 X 480 , 704 X 240 , 352 X 240
Resolution : PAL 720 X 576 , 720 X 288 , 360 X 288 704 X 576 , 704 X 288 , 352 X 288 704 X 576 , 704 X 288 , 352 X 288
Live Monitoring (NTSC/PAL) Real Time 120/100 @ CIF
Live Screen Division 1,4,6,9,10,16,21,25 1,4,6,9,10,16 1,4,6,9,10,16,21
Recording FPS (NTSC/PAL) 480/400 @ CIF, 240/200 @ 2 CIF,
120/100 @ 4 CIF 120/100 @ CIF, 60/50 @ 2 CIF, 30/25 @ 4 CIF 120/100 @ CIF, 60/50 @ 2 CIF, 30/25 @ 4 CIF
Playback Screen Division 1,4,9,16
Playback Digital Zoom Yes

DES-S Series User Manual
8
System Configuration
System Specification
8
Max 8CH
Now Available
Our Own + Vivotek + Axis
Network
LAN/WAN
Analog Camera DES-S Series DVR (Option) Storage Server (NAS or DAS)
Remote Client (NCMS Lite)
Remote Live/Search/Setup
/Simultaneous Multi DVRs connection
Remote Client
(NCMS Pro)
Plus
E-Map/Event Scenario
/Health Checking
(Option)
Web DVR (Support Dynamic IP)
Remote Live/Search/PTZ Control
Analog
IP (TCP/IP)
IP Cameras or Video Server
Max 32CH
PDA Viewer (in Wireless LAN)

DES-S Series User Manual
9
1. Connect External Parts with DVR (Camera, monitor, K/B, mouse, etc)
2. Power Connection
<NB> Before power connection, please check <110Vac/ or 220Vac>.
3. Power on Front Panel
4. Check DVR is running rightly.
System Description and External Parts Connection
System Specification

DES-S Series User Manual
10
Live View
Live Monitoring View
Screen Division &
Control
Camera & Alarm
Information
Exit DVR
TDS , Live Audio,
Image Control and
ETC
Login
Recording Data Search
P/T/Z control
Live View Window
DVR setup

DES-S Series User Manual
11
Log In/Log Out
Live View
Virtual Keyboard
Default Account
ID: admin
Password: 1111
<N.B > Factory Default account is for administrator.
So we recommend to setup new <account and password> in“Setup”=>”User” and delete default account
(To delete default <admin> account, must setup new account as <Administrator >)

DES-S Series User Manual
12
Go to <Setting => System=> Set advance system>
When setup <Log Out Time>, users log out automatically after setup <log-out> time.
(This applies only there is no operation in <Live Monitoring Window> during setup <log-out> time.)
Logout Time
<N.B > When this <Log-Out> time is not <check-
in>, users can operate DVR without more <Log-
In>. But this means user have to click <Log-In>
Icon to <Log-out> again.
Automatic Log-out
Live View

DES-S Series User Manual
13
Control <Live View Screen>
Live View
Just double Click
Change to 4 CH Screen(previous Screen)
Users can manage <Live View Screen> just by <Drag & Drop>
Just double Click
Change to Full Screen
To change Cameras on screen,
just <Drag & Drop> by Mouse

DES-S Series User Manual
14
Control <Live View Screen Division>
Live View
Function Button
Screen
Division
Full Screen
Manual Page
Change
Automatic
Page Change
1 CH 4 CH 36CH
Page Change (Go to Next Cameras in 4CH Division)
When clicking camera in <Tree
Menu,> go to Camera Pages in
each <Screen Division>

DES-S Series User Manual
15
Setup <Initial Live View Screen Display Division>
Go to <Setup => Display=> Default Screen>
To show< Full Screen> in
Initial <Live View Screen>
, please check in this box
Setup <Initial Screen Display> (Default Screen)
Live View

DES-S Series User Manual
16
Users can assign cameras to wanted <Screen Division Panel> without the restrict of camera sequence .
Menu Tree for
connected Camera
<NB>When some cameras are not assigned , those are not shown in <Live View
Screen>, but DVR does recording those cameras.
Moreover, if users use HYR BD, TV-Out does not show those cameras.
Just <Drag & Drop> cameras to
<Screen Division> Panel
Assigned Camera
(Green)
Not assigned Camera
(Grey)
When Mouse comes here, it
shows the camera information
Setup <Initial Screen Display> (Default Screen)
Live View

DES-S Series User Manual
17
To delete camera, just click right button of
mouse and select <Clear>
To delete all assigned cameras
When double click <not
assigned camera>(Grey),
it is assigned to each
camera number
Users can delete cameras in <Default Screen Division>.
Setup <Initial Screen Display> (Default Screen)
Live View

DES-S Series User Manual
18
Description of each icon of <Live Screen Window>
Live View
It shows each information of connect cameras and IP products
Rightly assigned Camera
(Green)
Not assigned
Camera (Grey)
Video Loss
(Red)
Reconnecting IP products
(Yellow)
Video Loss
(Red)
Rightly assigned Camera
(Green)
Disconnected IP products
(Red)

DES-S Series User Manual
19
Description of each icon of <Live Screen Window>
Live View
Can check and control of IP products status and connection in Live Window Menu Tree
Can select
Connect/Disconnect
IP products
When Network is disconnect, DVR tries to connect 3 times for certain time, after this time DVR does not try anymore.
Click right button of
mouse
