eyeV Skyle User manual

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
1 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
Assembly instructions
by

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
2 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
Scope of delivery (Case only)
2x M2.5 Screws
2x USB-C extension cable
10x M3x8 Screws
2x Allen key
1x M3x30 Screw
Micro-USB Cable
2x M2.5 Screws
Skyle Frame
4x M4x10mm Screws
USB-C Hub
90° USB-C Adapter
*Please note that colours and appearance of the individual parts can change. The
functionality is not affected.
**WARNING! Choking Hazard Small parts! Not for Children under 3 years of Age.

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
3 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
Please note:
Skyle for iPad uses the Assistive Touch function of the iPad. Before you update your iPad, make
sure that the new version is compatible with eyetracker. For more information, please visit eyev.de
or contact us at s[email protected]
eyeV GmbH reserves the right to make modifications, improvements, corrections or other changes
without further notice to this document and any product described herein.
eyeV GmbH products are specifically not authorized for use as critical components in life support
devices or applications, where the use can be reasonably expected to result in significant injury
to the user.

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
4 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
1.
For this step is required:
-2x M2.5 Screws
-Backplate of the case
-Skyle eyetracker
Use the screws to attach the eye control to the rear wall.

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
5 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
2. (Optional) REHAdapt bracket
If you use a mount from Rehadapt, you can attach it as shown.

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
6 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
3.
Connect the eyetracker to the HUB with the supplied Micro-USB cable1.
Connect the USB-C to the iPad with the extension cable2and the angled connector3.
In this step, test the functionality of the eyetracker before closing the housing.
2. Extension cable 3. Angled connector
Micro-USB Cable

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
7 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
4.
Insert the small pins for operating the iPad buttons into the front cover of the case.

Published by eyeV GmbH
Alzeyer-Straße. 39, D-67549 Worms
www.eyev.de © 2019 eyeV GmbH. All rights reserved.
Visit online: https://eyeV.de
8 - Version 1.0| 2020-02-26 –*We reserve the right to make changes and misprints.
5.
Use the supplied screws to close the housing. The longer M3 screw comes to the
position marked in white. The shorter screws come to the positions marked in blue.
Long screw
Short screws
