Infinite Peripherals INFINEA X MINI User manual

INFINEA® X MINI
ABOUT YOUR INFINEA X MINI
FRONT SPEAKER
iOS ON/OFF BUTTON
VOLUME BUTTONS
NOTIFICATION LEDs
SPEAKER TOGGLE BUTTON
1.
2.
3.
4.
5.
HOME BUTTON
BATTERY STATUS BUTTON
TORX SCREWS
USB PORT
*AMBIENT LIGHT SENSORS
6.
7.
8.
9.
10.
iOS CAMERA OPENING
BARCODE SCANNER
STRAP LATCH
RFID ANTENNA
BATTERY LATCH
11.
12.
13.
14.
15.
SCAN BUTTONS
BATTERY COMPARTMENT
REAR SPEAKERS
CHARGING STATION
CONTACTS
16.
17.
18.
19.
ASSEMBLY
4. Carefully close the top cover.
5. Ensure to not pinch the wires, while maintaining the position of the protective rubber bumper.
6. Secure the cover by tightening (8) torx screws.
4
3. Insert the audio jack into the iOS device until it clicks into place.
1
1. Open the Infinea X Mini by
loosening the 8 Torx Screws, and
then glently flip open the top cover.
2. Slide the iPad mini onto the
lightning connector until it clicks
into place.
QUICK START GUIDE
3
11
12
14
15
16
16
13
17
1818 13
19
7
1 2
4
5
6
4
88
8
8
8
8
8
8
3
9
CAUTION: Ensure the rubber bumper is properly aligned and there are no gaps between the top and
bottom covers. Failure to do so compromises the liquid protection features of the Infinea X Mini. If you
have any questions about installation of the rubber bumper, please contact your sales representative.
*Also available in black
10 10
*Features may vary by part number.
2
5
6

1. Attach the charging cup to the bottom of
the Infinea X Mini.
2. Plug the USB end into an AC wall adapter
(
the AC adapter must support at least 2.1
amps ).
CHARGING
100% - 75%
74% - 50%
49% - 25%
24% - 10%
9% - 1%
Solid green
Blink green
Blink orange
Blink red
One LED blinks red/emergency
low battery
LED BATTERY STATUS
Integrating the Infinea X Mini into your iOS
application requires the use of the Infinite
Peripherals mobile device Software Developer’s
Kit (SDK). For the latest Infinite Peripherals
mobile device SDK, visit our developer portal
ipcmobile.com/developer.
QSG-10013 Rev. C
SDK
The Infinea X Mini portable barcode scanner
is designed specifically for use with iPad mini
by allowing the iPad mini to sync with iTunes®
through the Infinea X Mini while connected.
1. Ensure the Pass Through Sync option is
enabled in the SDK.
2. Connect the Infinea X Mini to a computer
using the Charging Cup.
ACCESSORIES
WARRANTY
Part Numbers: IX-I2DBTR-MR-XX, IX-I2DBTR-M4-XXX
Infinite Peripherals does not warrant, and is not
responsible for, any damage to the Infinea X Mini
(“Product”) or the assembled iOS product as
a result of liquid or solid particle intrusion into
the Product or damaged caused by dropping
the Product with the assembled iOS product.
If a material or workmanship defect arises with
regard to any Product, and a valid claim is
received within the Warranty Period, Infininte
Peripherals (at its discretion) will (1) repair the
Product using new or refurbished parts or (2)
replace the Product with a new or refurbished
Product. For purposes of this limited warranty,
“refurbished” means a product or part that
has been substantially returned to its original
specifications. In the event of a defect, these are
your exclusive remedies.
Please visit our Accessories page at ipcmobile.
com, or contact your Infinite Peripherals sales
representative for more information about
available chargers and battery packs for the
Infinea X Mini.
TROUBLESHOOTING
iOS device will not sync to iTunes
• Innea X Mini is not congured for sync.
Swipe gestures not detected by iOS device
• Top cover is not properly installed.
Audio playback not heard from front
speakers
• iOS device is not connected to audio jack.
• Innea X Mini front speaker cable is damaged
or disconnected.
Audio playback not heard from rear speakers
• iOS device is not connected to audio jack.
• Rear speaker not powered.
iOS device does not charge
• AC adapter may not meet charging
requirements.
• Pass Through Sync is enabled.
COMPATIBILITY
Made for:
• iPad mini™ 4 mobile digital device
• iPad mini™ 3 mobile digital device
• iPad mini™ 2 mobile digital device
Mobility Sales/Technical Center
Innite Peripherals, Inc.
17681 Mitchell N
Irvine, CA 92614
Toll-Free: [phone]
Oce: [phone]
Headquarters/Main Warehouse
Innite Peripherals, Inc.
2312 Touhy Ave.
Elk Grove Village, IL 60004
Toll-Free: [phone]
Oce: [phone]
Fax: [phone]
