Ezgo LIBERTY User manual

OWNER’S MANUAL
10049626-A
ISSUED JULY 2023
EZGO.com
LIBERTY
with IntelliBrake™ Technology

1
OWNER’S MANUAL
2024 +
MANUFACTURER INFORMATION
Textron Specialized Vehicles, Inc.
1451 Marvin Griffin Road
Augusta, Georgia, USA 30906-3852
1-800-774-3946 Technical Assistance & Warranty
1-888-438-3946 Service Parts
011-706-798-4311 International
www.ezgo.com

2
WELCOME
Thank you for purchasing this vehicle. Before driving your new vehicle, read
this owner’s manual to familiarize yourself with safe driving practices, opera-
tion, features and controls.
This manual contains instructions for minor maintenance only. Information
about major repairs can be found in the service manual. Your dealer has thor-
ough knowledge of your vehicle and wants your total satisfaction with your
purchase. We recommend you return to your dealership for all of your service
needs during, and after the warranty period.
Repair or replacement parts can be purchased from your dealer or through
the manufacturer’s parts and accessories department.
These are original instructions as defined by 2006/42/EC.
The manufacturer maintains the right to change the design of the vehicle without
responsibility to make the changes on units purchased before changes were
made. The information in this manual can change without notice.
All information in this owner’s manual is based on the latest product information
at the time of publication. Due to constant improvements in the design and qual-
ity of production components, some discrepancies may be found between your
vehicle and the information presented in this publication. The content in this
publication is intended for reference use only. The manufacturer is not liable for
omissions or inaccuracies. Any reprinting or reuse of the content in this publica-
tion, whether whole or in part, is expressly prohibited.
Printed in USA

3
TABLE OF CONTENTS
INTRODUCTION
MANUFACTURER’S INTENDED USE ........................................................ 10
WARRANTY AND REGISTRATION............................................................ 10
BATTERY PROLONGED STORAGE .......................................................... 10
VEHICLE IDENTIFICATION NUMBERS .................................................... 11
PARTS AND SERVICE MANUALS ............................................................. 11
SAFETY
OWNER RESPONSIBILITY......................................................................... 13
Unauthorized Use ................................................................................. 13
Operating without Instruction ................................................................ 13
Alcohol or Drugs ................................................................................... 14
Passengers........................................................................................... 14
MAXIMUM WEIGHT CAPACITY ................................................................. 14
TIRE PRESSURE ........................................................................................ 14
OPERATOR SAFETY.................................................................................. 15
Before Operating .................................................................................. 16
LOAD OPERATION ..................................................................................... 16
REVERSE OPERATION.............................................................................. 16
DAMAGED VEHICLE................................................................................... 16
MAXIMUM SPEED....................................................................................... 17
TURNING..................................................................................................... 17
UPHILL OPERATION .................................................................................. 17
DOWNHILL OPERATION ............................................................................ 17
TIRES .......................................................................................................... 17
SLIPPERY TERRAIN................................................................................... 17
BATTERY CHARGING ................................................................................ 18
BATTERY DISPOSAL.................................................................................. 18
VEHICLE LIFTING....................................................................................... 18
VEHICLE MODIFICATION........................................................................... 19
MAINTENANCE SAFETY ............................................................................ 19

4
TABLE OF CONTENTS
SAFETY LABELS
OPERATION ................................................................................................ 21
OPERATION (CE)........................................................................................ 22
RUN/TOW SWITCH OPERATION............................................................... 22
PATENT NOTICE ........................................................................................ 22
ELECTRIC SHOCK (CE) ............................................................................. 23
BATTERY WARNING .................................................................................. 23
MAINTENANCE TOWING ........................................................................... 23
BRAKE RELEASE ....................................................................................... 23
FEATURES AND CONTROLS
KEY SWITCH / DIRECTION SELECTOR.................................................... 25
HEADLIGHT SWITCH ................................................................................. 25
STATE OF CHARGE (SOC) METER .......................................................... 25
HORN SWITCH ........................................................................................... 26
CUP HOLDERS ........................................................................................... 26
USB PORT................................................................................................... 26
BATTERY CHARGER PORT....................................................................... 26
STEERING WHEEL .................................................................................... 26
TURN SIGNAL............................................................................................. 26
BRAKE PEDAL ............................................................................................ 27
PARKING BRAKE ....................................................................................... 27
ACCELERATOR PEDAL ............................................................................. 27
GLOVE BOX / STORAGE COMPARTMENTS ............................................ 27
REARVIEW MIRROR .................................................................................. 28
SIDE MIRRORS........................................................................................... 28
HIP RESTRAINTS ....................................................................................... 28
SEATS ......................................................................................................... 29
CANOPY TOP AND WINDSHIELD ............................................................. 29
OPERATION
SAFETY ....................................................................................................... 31
BEFORE INITIAL USE................................................................................. 31

5
TABLE OF CONTENTS
Burnishing Brakes................................................................................. 31
PRE-RIDE INSPECTION............................................................................. 32
BATTERY CHARGER.................................................................................. 32
Off Board Charger ................................................................................ 33
On Board Charger ................................................................................ 33
PERFORMANCE FEATURES ..................................................................... 34
Speed Control....................................................................................... 34
Pedal-Up Braking.................................................................................. 34
Anti-Stall Feature .................................................................................. 34
High Pedal Disable Feature.................................................................. 35
Diagnostic Mode Feature...................................................................... 35
STARTING AND STOPPING THE VEHICLE .............................................. 35
Starting on a Hill ................................................................................... 35
ACCELERATING ......................................................................................... 36
BRAKING ..................................................................................................... 36
Coasting................................................................................................ 36
DRIVING PROCEDURE .............................................................................. 36
DRIVING WITH PASSENGERS .................................................................. 37
SLIPPERY SURFACES............................................................................... 37
UPHILL OPERATION .................................................................................. 38
Stalling on a Hill .................................................................................... 38
DOWNHILL OPERATION ............................................................................ 38
REVERSE OPERATION.............................................................................. 38
PARKING THE VEHICLE ............................................................................ 39
TOWING ...................................................................................................... 39
MAINTENANCE
SCHEDULED MAINTENANCE.................................................................... 42
SCHEDULED MAINTENANCE CHART ...................................................... 42
RECOMMENDED LUBRICANTS AND FLUIDS .......................................... 44
REPLACEMENT OF MAINTENANCE ITEMS ............................................. 44
LIFTING THE VEHICLE............................................................................... 44
Lifting Front .......................................................................................... 45

6
TABLE OF CONTENTS
Lifting Rear ........................................................................................... 46
Lowering Vehicle .................................................................................. 46
VEHICLE CLEANING AND CARE............................................................... 46
Washing the Vehicle ............................................................................. 46
Polishing the Vehicle ............................................................................ 47
TIRES .......................................................................................................... 47
Tire Pressure ........................................................................................ 48
Tire Repair ............................................................................................ 48
Tire Replacement.................................................................................. 49
WHEELS...................................................................................................... 49
Wheel Removal .................................................................................... 49
Wheel Installation ................................................................................ 49
LIGHTS ........................................................................................................ 50
Headlight Replacement ........................................................................ 50
Tail Light/Brake Light Replacement ...................................................... 50
FUSE REPLACEMENT................................................................................ 51
CONTROLLER SYSTEM TEST................................................................... 51
REAR AXLE................................................................................................. 51
Checking the Lubricant Level................................................................ 51
LUBRICATION ............................................................................................. 52
HYDRAULIC BRAKES................................................................................. 52
Hydraulic Brake Fluid............................................................................ 52
Check Brake Fluid Level....................................................................... 53
LITHIUM-ION BATTERY PACK................................................................... 53
BATTERY DISPOSAL.................................................................................. 54
BATTERY CHARGER MAINTENANCE ...................................................... 55
BATTERY PROLONGED STORAGE .......................................................... 55
Storage Preparation.............................................................................. 55
Setting State of Charge (SOC) ............................................................. 56
During Storage...................................................................................... 56
Extreme Low Temperature Storage...................................................... 56
Returning Vehicle to Service................................................................. 56
BATTERY FAULT DIAGNOSIS ................................................................... 57

7
TABLE OF CONTENTS
TRANSPORTING THE VEHICLE ................................................................ 57
Hauling the Vehicle............................................................................... 57
Towing the Vehicle ............................................................................... 58
Manual Release of IntelliBrake™.......................................................... 58
VEHICLE SPECIFICATIONS
LIBERTY ...................................................................................................... 61
MAINTENANCE LOG
RECORDS ................................................................................................... 63
APPENDIX
QUIQ CHARGER......................................................................................... 67

8
TABLE OF CONTENTS
This page intentionally left blank.

9
INTRODUCTION
INTRODUCTION
The following symbols appear throughout this manual and on vehicle labels.
Your safety is involved when these symbols are used. Become familiar with
their meanings before reading the manual.
DANGER indicates a hazardous situation that, if not
avoided, WILL result in death or serious injury.
WARNING indicates a hazardous situation that, if not
avoided, COULD result in death or serious injury.
CAUTION indicates a hazardous situation that, if not
avoided, COULD result in minor or moderate injury.
NOTICE provides key information by clarifying instruc-
tions.
The PROHIBITION SAFETY SIGN indicates an action NOT to take
in order to avoid a hazard.
The MANDATORY ACTION SIGN indicates an action that NEEDS to
be taken to avoid a hazard.
Failure to comply with warnings in this manual can
result in severe injury or death.
Read this entire manual carefully before operating
the vehicle. Do not attempt to operate the vehicle
until you have thorough knowledge of the controls
and features.
Regular inspections and maintenance, along with
good operating techniques, will help ensure your
safe enjoyment of the capabilities and reliability of
this vehicle.
This vehicle was designed and manufactured in the United States of America
(USA). The standards and specifications in the following information originate
in the USA unless otherwise indicated.
NOTICE

10
INTRODUCTION
MANUFACTURER’S INTENDED USE
This vehicle is designed and manufactured for off road use only. Use on pub-
lic streets, roads, or highways is illegal in most areas and increases the risk of
an accident involving other vehicles and people. This vehicle does not meet
FMVSS (Federal Motor Vehicle Safety Standards) for public street, road, or
highway use.
Check all laws and regulations before choosing an area to operate your vehi-
cle.
As manufactured, this vehicle meets or exceeds ANSI/OPEI Z-135 Personal
Transport Vehicles and SAE J2258 Light Utility Vehicles standards, and its
top speed is set at 19.5 mph (31 kph). In the factory configuration, it is
intended to be used on designated roadways, or within closed communities
where permitted by law or by regulatory authority rules.
This vehicle has been designed so that certain authorized service profession-
als are capable of setting the vehicle’s maximum level-ground speed to 25
mph (40 kph). When the maximum speed is set between 20 and 25 mph (32
to 40 kph), it complies with the requirements of SAE J2258 (so long as no
other changes or modifications have been made to the vehicle), but does not
meet ANSI/OPEI Z-135. In any configuration where the maximum speed
exceeds 20 mph (32 kph), it is only permitted to be used off-road, on private
property, or on private roadways where allowed. This vehicle does not meet
State or Federal LSV (Low Speed Vehicle) requirements and cannot be used
on public roadways of any kind when the maximum speed setting exceeds 20
mph (32 kph).
WARRANTY AND REGISTRATION
All information, including coverage, limitations, exclusions and how to obtain
warranty service is included in the literature package with the purchase of the
vehicle. It can also be obtained from your dealer
Register your new vehicle at www.ezgo.com.
Use Original Equipment Manufacturer (OEM) approved parts to keep the
vehicle warranty effective.
Tampering with or adjusting the controller to allow the vehicle to operate above
factory specifications will void the vehicle warranty.
BATTERY PROLONGED STORAGE
See BATTERY PROLONGED STORAGE on page 55 for safety information
and storage procedure.

11
INTRODUCTION
VEHICLE IDENTIFICATION NUMBERS
Record the vehicle identification numbers in the spaces provided below.
These identification numbers are required when ordering parts.
PARTS AND SERVICE MANUALS
The following manuals can be purchased through your dealer:
• service manual
• parts manual
Vehicle Model Number
Frame PIN
A
V
V
C
B
FRAME VIN PLATE
PART A
PART B
PART C

12
INTRODUCTION
This page intentionally left blank.

13
SAFETY
SAFETY
OWNER RESPONSIBILITY
Improper use, maintenance, or modification of this vehicle can lead to serious
injury or death.
Require proper use of your vehicle. Do not allow anyone to
operate your vehicle or ride as a passenger unless they are
properly instructed and you are sure they are willing to ride
responsibly. To prevent unauthorized use, always remove the
key when the vehicle is not in use.
For questions about the vehicle or the material in this manual, see the contact
information on page 1 or the back of this publication.
Unauthorized Use
This vehicle is for adult use only. Anyone below the age of 16 is
not permitted to operate the vehicle.
Anyone who does not have a valid driver’s license is not
permitted to operate the vehicle.
Operator must fit the vehicle. Be sure the operator is
able to:
• sit with their back against the seat
• have both feet flat on the floor and reach pedals
• have both hands on the steering wheel
Operating without Instruction
Operation of this vehicle without proper instruction increases
the risk of an accident. The operator must understand how to
operate the vehicle correctly in different situations and on differ-
ent types of roads.
All operators must read and understand the owner’s manual
and all warning and instruction labels before operating the vehi-
cle.

14
SAFETY
Alcohol or Drugs
Operation of the vehicle during or after consuming alcohol or
drugs can adversely affect operator judgment, reaction time,
balance and perception.
Never drink alcohol or use drugs or medications before or
during operation of the vehicle.
Passengers
It is the responsibility of the owner and/or operator to make sure passengers
meet the qualifications required to ride in the vehicle.
All passengers must fit the vehicle. Passengers must
be able to:
• sit with their back against the seat
• have both feet flat on the floor
MAXIMUM WEIGHT CAPACITY
Exceeding weight capacities can cause loss of vehi-
cle control and possible injury or death.
Do not exceed the maximum vehicle weight capacity (includes weight of oper-
ator, passengers, cargo, and accessories and trailer tongue weight).
TIRE PRESSURE
Improper or uneven tire pressure can cause loss of
vehicle control and possible injury or death.
Maintaining correct tire inflation pressure is essential for safe vehicle opera-
tion. Inflation pressure can vary within the recommended range to suit the
condition of the terrain.
Maximum Vehicle Weight Capacity 800 lb (363 kg)
TIRE
PRESSURE
RANGE
TERRAIN
CONDITIONS RECOMMENDATION
18-22 psi
(124-152 kPa)
Hard surfaces or
pavement
Inflate to higher pressure within the range;
never exceed maximum pressure indicated.
Soft terrain or
turf
Inflate to lower pressure within the range to
reduce potential damage to the terrain or turf.

15
SAFETY
OPERATOR SAFETY
Safe and responsible use of this vehicle is necessary to prevent dangerous
conditions for the operator, passengers and other people within the area of
operation. This section of the manual provides information on safe operation
of the vehicle. Make sure to read, understand and comply with all of this infor-
mation to decrease the risk of personal injury or death.
Failure to operate this vehicle as instructed can
cause collision, loss of control or rollover resulting in
severe injury or death. Follow all safety warnings in
this manual. See the OPERATION section beginning
on page 31 for operating procedures and additional
safety information.
• Read this entire manual and all product labels carefully. Follow the safety
information and operating procedures described.
• Operate the vehicle responsibly to prevent dangerous conditions for all
occupants and people in the area of operation.
• Do not drive with passengers until you have a minimum of two hours driving
experience on this vehicle.
• Keep feet, legs, hands, and arms inside the vehicle at all times.
• The driver must keep both hands on the steering wheel and feet on the floor
or pedals.
• Inspect the vehicle before each use to make sure it is in safe operating con-
dition. Perform the PRE-RIDE INSPECTION on page 32.
• A damaged vehicle or a vehicle that is not functioning properly is dangerous
and must not be operated until repairs are made.
• Always have the vehicle checked by an authorized dealer if it is involved in
an accident.
• Always put the key switch in the OFF position before exiting the vehicle.
• Remove the key when the vehicle is not in use to prevent
accidental starting or unauthorized use by unqualified drivers.
• Do not drive on excessively steep hills. Drive slowly and
deliberately. Use the brake to limit speed and maintain con-
trol. Sudden braking or turning can cause loss of vehicle con-
trol. Drive straight down hills; do not drive across hills.
• Operate only in approved areas. Follow all applicable safety rules for the
area.
• Before driving in reverse, make sure the area behind the vehicle is clear.
Accelerate slowly and avoid making sharp turns.
• Make sure the direction selector is in the correct position before pressing
the accelerator pedal.
• Decrease speed before and during turns.
• Decrease speed when driving on wet or slippery surfaces.
• Bring the vehicle to a complete stop before moving the direction selector.

16
SAFETY
• Do not exceed cargo or vehicle weight capacities. Do not exceed occupant
capacity. See VEHICLE SPECIFICATIONS on page 61 for the vehicle load
and seat capacity.
• If there is a risk of lightning, leave the vehicle and look for a safe location to
wait until the lightning has stopped.
Additional information about safety is included throughout this manual or can
be obtained from your dealer.
Before Operating
Perform the PRE-RIDE INSPECTION on page 32 before each use to ensure
the vehicle is in safe operating condition. Failure to inspect and confirm that
the vehicle is safe to operate increases the risk of an accident.
LOAD OPERATION
The weight of cargo and occupants affects vehicle operation. Carefully calcu-
late how the vehicle is loaded and how to safely operate it. Follow the instruc-
tions in this manual for loading guidelines and tire pressure.
Do not exceed vehicle weight capacities specified on page 14. As passenger
weight increases, cargo weight needs to be adjusted to ensure the maximum
weight capacity is not exceeded.
Tire pressure must be adjusted to accommodate the load being carried. See
Tire Pressure on page 14 for specifications.
Drive slowly and carefully to maintain control of the vehicle if driving under
any of the following conditions:
• passenger and/or cargo exceeds half the maximum weight capacity
• driving over obstacles
• towing
• climbing a hill
REVERSE OPERATION
Make sure the area behind the vehicle is clear before operating in reverse.
When clear and safe to operate in reverse, accelerate slowly and avoid mak-
ing sharp turns.
Refer to REVERSE OPERATION on page 38 for operational information.
DAMAGED VEHICLE
Driving a damaged vehicle is not safe. If the vehicle has been involved in any
type of accident, have it inspected by a qualified service dealer to verify that it
is safe for operation.

17
SAFETY
MAXIMUM SPEED
Maximum speed operation increases the risk of loss of control.
• Always drive at a speed that is appropriate for the terrain, visibility, operat-
ing conditions, and your skill and experience level.
• Use the brake to limit speed and maintain control of the vehicle.
TURNING
Improper or careless turning can cause loss of traction, loss of control, acci-
dent, or rollover.
• Do not turn quickly or at sharp angles.
• Do not turn at high speeds.
• Practice turning at slow speeds before attempting to turn at faster speeds.
UPHILL OPERATION
Do not drive up hills that are too steep for the vehicle or your driving abilities.
Loss of vehicle control can result from driving up hills incorrectly.
Refer to UPHILL OPERATION on page 38 operational information.
DOWNHILL OPERATION
Use the brake to limit speed and maintain control. Loss of vehicle control or
rollover can result from driving downhill incorrectly.
Refer to DOWNHILL OPERATION on page 38 for operational information.
TIRES
Operating the vehicle with incorrect tires or incorrect/uneven tire pressure can
cause loss of control or an accident. Always use the size and type of tires
specified for the vehicle.
See VEHICLE SPECIFICATIONS on page 61 for tire type and size.
Always maintain correct and even tire pressure as specified. See Tire Pres-
sure on page 14.
SLIPPERY TERRAIN
Driving on rough, wet, or loose terrain increases the risk of loss of traction or
control and accident or rollover. Drive slowly and use correct turning proce-
dures when operating on slippery surfaces.
Refer to Slippery Surfaces on page 37 for operational information.

18
SAFETY
BATTERY CHARGING
Charging should be done when ambient temperatures are between 40°F and
110°F (4°C and 42°C). The battery pack can be charged or topped off after
every use.
The battery management system (BMS) makes sure charging occurs at the
proper rate for the battery temperature. When the battery charger is con-
nected to the vehicle, the BMS determines the charge rate based on the bat-
tery temperature. The charger operates at the rates shown in the following
table.
The BMS adjusts the charge rate based on the temperature of the batteries.
Use only the OEM approved Lithium-Ion battery charger.
• Turn the key to the OFF position and remove it from the
switch.
• Inspect the charger cord for cracks, frayed wires or loose con-
nections; replace if damaged.
• Inspect the vehicle charger receptacle and charger plug for
dirt, debris or damage. Clean if necessary and replace immediately if dam-
age is found.
• Connect the charger to a wall receptacle. Do not use a multi-plug adapter or
power strip. Do not connect anything else to the same receptacle.
• Connect the charger to the vehicle receptacle.
When finished charging, disconnect the charger cord from the vehicle. If dis-
connecting before the charge cycle is complete, disconnect from the wall
receptacle first, then disconnect the charger cord from the vehicle.
BATTERY DISPOSAL
See BATTERY DISPOSAL on page 54 for safety and disposal information.
VEHICLE LIFTING
• The vehicle must be on a firm and level surface.
• Be constantly aware that the vehicle is not stable during the lifting process.
• Make sure the vehicle is stable on jack stands before getting underneath.
• Never get under a vehicle while it is on a jack only.
• Put wheel chocks in front of and behind the wheels that are not being lifted.
• Do not allow anyone on the vehicle when it’s being lifted or on jack stands.
Charge Rate Temperature
NO charging below 14° F (-10°C) or above 140°F (60°C)
Pre-charge
(charge at reduced rate, 6 amps)
between 14°F (-10°C) and 41°F (5°C)
between 104°F (40°C) and 140°F (60°C)
Full charging between 41°F (5°C) and 113°F (45° C)
