Ezgo 2Five User manual

B

WELCOME
Thank you for purchasing this vehicle. Before you drive the vehicle, read this Owner’s Guide. This guide
contains maintenance and operation information. The illustrations can show items that are optional for your
vehicle.
You can do most of the service procedures in this guide with common, automotive hand tools. If necessary,
contact your service representative for information about how to service the vehicle as shown in the Periodic
Service Schedule.
Repair or replacement parts are available from your E-Z-GO dealer or E-Z-GO Service Parts Department.
When you contact E-Z-GO about service or parts for your vehicle, the information below is needed.
VIN_____________________________________________________________________________________
Vehicle Model ____________________________________________________________________________
Manufacturing Date Code __________________________________________________________________
E-Z-GO 2Five is a motor vehicle that can only be operated by a licensed driver, and must be driven in
accordance with all State traffic laws and the insurance requirements for motor vehicles.

i
2Five OWNER’S GUIDE
ELECTRIC POWERED
LOW-SPEED VEHICLE
2Five TWO-PASSENGER
2Five FOUR-PASSENGER
STARTING MODEL YEAR 2016
ISSUED MAY 2015
646299

ii
CALIFORNIA Proposition 65 Warning
WARNING: Motor vehicles may contain fuels, oils and fluids, battery posts, terminals, and related accessories
which contain lead, lead compounds and other chemicals identified by the State of California to potentially cause
cancer, birth defects and other reproductive harm. These chemicals are found in vehicles, vehicle parts and
accessories, both new and replacements. During maintenance, these vehicles generate used oil, waste fluids,
grease, fumes and particulates, all identified by the State of California to potentially cause cancer, birth defects,
and other reproductive harm.
Never modify the vehicle in any way that will alter the weight distribution of the vehicle, decrease its stability or increase the speed
beyond the factory specifications. Such modifications can cause serious personal injury or death. E-Z-GO Division of Textron Inc.
prohibits and disclaims responsibility for any such modifications or any other alteration which would adversely affect the safety of
the vehicle.
E-Z-GO Division of Textron Inc. reserves the right to incorporate engineering and design changes to products in this manual, with-
out obligation to include these changes on units sold previously.
The information contained in this manual may be revised periodically by E-Z-GO, and therefore is subject to change without notice.
E-Z-GO DISCLAIMS LIABILITY FOR ERRORS IN THIS MANUAL, and SPECIFICALLY DISCLAIMS LIABILITY FOR INCIDENTAL AND
CONSEQUENTIAL DAMAGES resulting from the use of the information and materials in this Manual.
These are the original instructions as defined by 2006/42/EC.
CONTACT US:
E-Z-GO Division of Textron Inc.
1451 Marvin Griffin Road.
Augusta, Georgia, USA 30906-3852
North America:
Technical Assistance & Warranty PHONE: [phone]
FAX: [phone]
Service Parts PHONE: 1-888-GET-EZGO (1-888-438-3946)
FAX: [phone]
International: PHONE: [phone] FAX: [phone]

Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
NOTES
Owner’s Guide iii
This vehicle was designed and manufactured in the United States of America (USA).
The standards and specifications listed in the following text originate in the USA
unless otherwise indicated.
Use Original Equipment Manufacturer (OEM) approved parts to keep the warranty
effective.
If you do not correctly maintain the batteries, you will cancel the warranty. Refer to
the MAINTENANCE section for instructions on the correct maintenance of the bat-
teries.
BATTERY PROLONGED STORAGE
The batteries discharge over time. The rate of discharge changes according to the
ambient temperature, the age and condition of the batteries.
Completely charged batteries will not freeze in winter temperatures unless the
temperature is less than -75°F (- 60°C).
For winter storage, the batteries must be clean, completely charged and
disconnected from any electric drain.

Owner’s Guide
iv
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
NOTES
The battery charger can remain connected to the vehicle to keep a full charge on the
batteries while the charger is connected to an active electrical supply. If the power
to the electrical supply is disconnected or interrupted, the battery charger will con-
tinuously check the charge on the battery pack. A continuous check of the battery
pack will pull power from the battery pack and drain the batteries.
The batteries must be checked and charged again as required or at a minimum of
30-day intervals.
Check and keep correct fluid level in all battery cells during the storage period.
Correct fluid level is necessary for maximum battery performance.
BATTERY DISPOSAL
Lead-acid batteries are recyclable. Return discarded batteries to distributor, manu-
facturer or lead smelter for recycling. For neutralized spills, put residue in acid-
resistant containers with absorbent material such as sand. Dispose in accordance
with local, state and federal regulations for acid and lead compounds. Contact local
or state environmental authorized people for the disposal information.

TABLE OF CONTENTS
Owner’s Guide v
SAFETY
GENERAL ......................................................................................................................... 1
NOTICES, CAUTIONS, WARNINGS AND DANGERS ..................................................... 1
GENERAL OPERATION .................................................................................................. 6
MAINTENANCE .............................................................................................................. 10
VENTILATION ................................................................................................................. 11
SEAT BELTS ................................................................................................................... 12
Seat Belt Operation ............................................................................................ 14
REPORTING SAFETY DEFECTS .................................................................................. 15
LABELS AND PICTOGRAMS ......................................................................................... 16
GENERAL SPECIFICATIONS
APPROXIMATE VEHICLE DIMENSIONS ......................................................... 23
TURNING DIAMETER AND INCLINE INFORMATION ..................................... 27

Owner’s Guide
vi
TABLE OF CONTENTS
INTRODUCTION
FEATURES ..................................................................................................................... 29
General Information ............................................................................................29
Parking Brake .....................................................................................................30
OPERATING PROCEDURES
SERIAL NUMBER LOCATION ........................................................................................ 47
VEHICLE IDENTIFICATION NUMBER (VIN) ..................................................................48
VEHICLE DATA PLATE .................................................................................................. 49
BEFORE INITIAL USE .................................................................................................... 50
Brake Burnishing Procedure ...............................................................................51
SEAT BELT OPERATION ...............................................................................................52
ON-BOARD CHARGER WITH DC TO DC CONVERTER .............................................. 54
Understand the Charger ..................................................................................... 56
Maintenance Instructions ....................................................................................58

TABLE OF CONTENTS
Owner’s Guide vii
HOW TO OPERATE THE VEHICLE ............................................................................... 59
Regenerative Braking ......................................................................................... 62
Pedal-Up Braking ............................................................................................... 63
High Pedal Disable Feature ............................................................................... 63
Parking Brake ..................................................................................................... 63
Rear Seat and Cargo Platform Operation (if equipped) ..................................... 64
Starting and Driving ............................................................................................ 66
Starting Vehicle On A Hill ................................................................................... 66
Coasting ............................................................................................................. 67
Labels and Pictograms ....................................................................................... 67
Top And Windshield ........................................................................................... 68
MAINTENANCE
VEHICLE CLEANING AND CARE .................................................................................. 71
ENVIRONMENTAL CONCERNS .................................................................................... 73

Owner’s Guide
viii
TABLE OF CONTENTS
Battery Disposal ................................................................................................. 73
LIFTING THE VEHICLE .................................................................................................. 74
WHEELS AND TIRES ..................................................................................................... 77
Tire Repair .......................................................................................................... 78
Wheel Installation ...............................................................................................79
LIGHT BULB REPLACEMENT ........................................................................................81
Headlight Bulb Replacement .............................................................................. 81
Turn Signal Bulb Replacement ...........................................................................82
Taillight/Brake Light Bulb Replacement ..............................................................82
FUSE REPLACEMENT ...................................................................................................83
TRANSPORTING VEHICLE ............................................................................................83
In Case of Total Power Loss .............................................................................. 84
SERVICE AND MAINTENANCE ....................................................................................87
ROUTINE MAINTENANCE ............................................................................................90
Brake Master Cylinder ........................................................................................ 90

TABLE OF CONTENTS
Owner’s Guide ix
Tire Inspection .................................................................................................... 91
Rear Axle ............................................................................................................ 91
ERROR AND WARNING CODES ................................................................................... 92
CAPACITIES AND REPLACEMENT PARTS ................................................................. 93
HARDWARE ................................................................................................................... 94
BATTERY CHARGING AND MAINTENANCE ................................................................ 95
Safety ................................................................................................................. 95
Battery Disposal ................................................................................................. 97
Battery ................................................................................................................ 97
Battery Maintenance .......................................................................................... 98
At Each Charging Cycle ..................................................................................... 98
Monthly ............................................................................................................... 98
Electrolyte Level and Water ............................................................................... 99
Battery Cleaning ............................................................................................... 103
Battery Removal and Installation ...................................................................... 105

Owner’s Guide
x
TABLE OF CONTENTS
Prolonged Storage ............................................................................................107
Battery Charging ............................................................................................... 108
AC Voltage ....................................................................................................... 110
Fault Diagnosis .................................................................................................110
Hydrometer .......................................................................................................111
Using A Hydrometer .........................................................................................112
Battery Charger Maintenance ...........................................................................113
PERIODIC SERVICE SCHEDULE .........................................................................115
REGISTRATION AND WARRANTY .......................................................................121

Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
Owner’s Guide 1
SAFETY
GENERAL
For any questions about material in this manual, contact an authorized representative.
Read and understand all labels on the vehicle. Always replace any damaged or missing labels.
On steep hills it is possible for vehicles to coast at greater speeds. To prevent loss of vehicle control and
possible serious injury, speeds should be limited to no more than 25 mph.
Catastrophic damage to the drivetrain components due to excessive speed may result from driving the
vehicle above 25 mph. Damage caused by excessive speed may cause a loss of vehicle control, is costly, is
considered abuse, and will not be covered under warranty.
NOTICES, CAUTIONS, WARNINGS AND DANGERS
Read the NOTICES, CAUTIONS, WARNINGS and DANGERS. The person who services a vehicle needs
the mechanical skill and experience to see possible hazardous conditions. Incorrect service or repairs can
cause damage to the vehicle or make the vehicle dangerous to operate.

Owner’s Guide
2
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
A NOTICE indicates and describes information not related to personal injury.
A CAUTION indicates a dangerous condition that can cause injury that is not life threatening.
A WARNING indicates a dangerous condition that can cause death or serious injury.
A DANGER indicates a dangerous condition that will cause death or serious
injury.

Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
Owner’s Guide 3
This manual contains recommended maintenance procedures from the manufacturer. Follow these proce-
dures and fault diagnosis information to get the best service from the product. To decrease the risk of per-
sonal injury or property damage, obey all the information in this manual.
THE E-Z-GO 2Five SHALL BE OPERATED ONLY BY PERSONS WITH VALID DRIVERS LICENSES,
AND IN ACCORDANCE WITH APPLICABLE STATE REQUIREMENTS. THIS IS A LEGAL
REQUIREMENT AND IS IMPORTANT TO THE SAFE USE AND OPERATION OF THE PRODUCT.
All customers should adhere to this SAFETY RESTRICTION, in connection with the use of all E-Z-GO
products, new and used, in personal transportation applications.
Federal Low-Speed Vehicle Standard (FMVSS 571.500) can be obtained at Title 49 of the Code of Federal
Regulations, section 571.500, or through the Internet at the website for the U.S. Department of
Transportation - at Dockets and Regulation, then to Title 49 of the Code of Federal Regulations
(Transportation).
All vehicles can be used for a variety of tasks often beyond the original intended use of the vehicle; therefore,
it is impossible to anticipate and warn against every possible combination of circumstances that may occur.
No warning can replace good common sense and prudent driving practices.
Good common sense and prudent driving practices do more to prevent accidents and injury than all warnings
and instructions combined. E-Z-GO strongly suggests that all users and maintenance personnel read this
entire manual paying particular attention to the CAUTIONS, WARNINGS, and DANGERS contained therein.

Owner’s Guide
4
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
If you have any questions regarding this vehicle, contact your authorized E-Z-GO 2Five dealer or write to the
address on the back cover of this publication, Attention: Customer Quality Department.
E-Z-GO reserves the right to make design changes without obligation to make these changes on units
previously sold. The information contained in this manual is subject to change without notice.
E-Z-GO IS NOT LIABLE FOR ERRORS IN THIS MANUAL. E-Z-GO IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES THAT RESULT FROM THE USE OF, AND THE RELIANCE ON, THE
MATERIAL IN THIS MANUAL.
This vehicle is designed and manufactured in accordance with FMVSS 571.500.
Be sure that all electrical accessories are grounded directly to the battery (-) post. Never use the chassis or
body as a ground connection.
Refer to GENERAL SPECIFICATIONS for vehicle seating capacity.
Never modify the vehicle in any way that will alter the weight distribution of the vehicle,
decrease its stability, or increase the speed or extend the stopping distance beyond the
factory specification. Such modifications can result in serious personal injury or death.

Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
Owner’s Guide 5
Do not change the vehicle in any manner that changes the weight distribution, decreases stability, increases
speed or extends the necessary distance to stop more than the factory specification. E-Z-GO is not responsi-
ble for changes that cause the vehicle to be dangerous.
Vehicles that are capable of higher speeds must limit their speed to no more than the speed of other vehicles
when used in a golf course environment. Additionally, speed should be further moderated by the
environmental conditions, terrain, and common sense.

Owner’s Guide
6
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
GENERAL OPERATION
Read the following warnings before attempting to operate the vehicle.
When you leave the vehicle, turn the key to the OFF position and remove the key from
the vehicle.
Drive the vehicle only as fast as terrain and conditions allow. Consider the terrain and
traffic conditions. Consider environmental conditions that change the terrain and your
ability to control the vehicle.
Do not drive fast downhill. Sudden stops or change of direction can cause a loss of
control.
Use the brake to control the speed of the vehicle when you drive down a slope.
When possible, stay in approved areas and do not drive on steep slopes.
Always keep feet, legs, hands and arms inside vehicle.
Do not drive on rough terrain.

Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
Owner’s Guide 7
Before you drive in the reverse direction, make sure the area behind the vehicle is clear.
Make sure the direction selector is in the correct position before you press the
accelerator pedal.
Decrease speed before and during turns.
Make sure you completely stop the vehicle before you move the direction selector.
See ‘GENERAL SPECIFICATIONS’ for the vehicle load and seat capacity.

Owner’s Guide
8
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
SAFETY
Read the following text and warnings before you service the vehicle.
Normal use, wear or abuse can cause some components on the vehicle to fail. The manufacturer can not
know all possible component failures or the methods that failures can occur.
A vehicle in need of repair does not function properly and can be dangerous.
Be careful when you service the vehicle. Be aware of your safety and the safety of other people in the area.
Some components are heavy, spring loaded, corrosive, explosive, can cause high amperage or get hot.
Battery acid and hydrogen gas can cause injury. Do not put your hands, face, feet or body in a location that
can expose them to injury if an unexpected situation occurs.
Always use the correct tools shown in the tool list and wear safety equipment.
