Ezidri ULTRA FD1000 DIGITAL User manual

1
The EZIDRI range of Food Driers have been manu-
factured to the highest standards. As with all house-
hold appliances care should be taken to ensure units
remain electrically safe and the following instructions
should be noted.
PLEASE READ ALL INSTRUCTIONS
1. When the unit is first switched on, ensure that the
fan in the centre of the base is rotating. This will
be apparent by both sight and sound. If not,
unplug the EZIDRI immediately and return it to
your local retailer.
2. The outer surface of the appliance may get hot
when it is operating.
3. To protect against electrical hazards:
(a) Do not immerse the Ezidri base, cord or plug
in water or other liquid.
(b) Do not pour or spill water or liquid down the
opening at the top or any other opening.
(c) When preparing roll-ups or purees, always fill
the solid sheet on an individual tray off the
EZIDRI base and then carefully transfer the
tray to the unit.
(d) When preparing roll-ups, ensure that the
puree is of such a heavy consistency, that it
will not spill over the solid sheet. The consis
tency should be such that a spatula is
required to spread the puree evenly.

2
(e) Do not move the unit whilst the produce is
being dried.
(f) Switch off the power and remove the plug
before cleaning. (see ‘Care of your EZIDRI’)
(g) The appliance is not intended to be oper
ated by means of an external timer or
separate remote- control.
4. Unplug the unit from the electrical outlet when
not in use.
5. Do not operate the appliance if it malfunctions
or has been damaged in any manner. Return
the appliance or send to an authorised service
agent for examination, repair or adjustment.
6. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a
hazard.
7. Do not use the EZIDRI or accessories for any
other purpose than that for which the appliance
has been designed for - i.e.: food drying.
8. Do not use accessory attachments not recom-
mended by the manufacturer.
9. Avoid using sharp instruments that could
damage the EZIDRI.
10. Do not use out doors.
11. Do not let cord hang over edge of table or
counter, or touch hot surfaces.
12. Do not place on or near a hot gas or electric
burner, or in a heated oven.

3
13. Always refer to the instruction Book supplied
and if in doubt contact your supplier or national
distributor for advice.
14. This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction con-
cerning use of the appliance in a safe way and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be made by children
unless they are older than 8 and supervised.
15. Keep the appliance and its cord out of reach of
children less than 8 years.
16. Details on how to clean surfaces in contact with
food as “CARE OF YOUR EZIDRI” of instruction
manual.
17. Children should be supervised to ensure that
they do not play with the appliance.
18. This appliance is intended to be used in house-
hold and similar applications such as:
- staff kitchen areas in shops, offices and others
working environments;
- farm houses;
- by clients in hotels, motels and other residen
tial type environments;
- bed and breakfast type environments.

4

1
ULTRA FD1000 DIGITAL - SNACKMAKER FD500 DIGITAL
2
4
Ezidri Ultra FD1000 and Snackmaker FD500 operating Instructions
Activated Almonds 48

2
35 years of food drier
EZIDRI Food Driers
Food Driers.
The unique heated airflow pattern, combined with technological advanced
circuitry, provide accurate and an even heated airflow temperature,
EZIDRI ULTRA FD1000 DIGITAL DRIERS - The Ultimate Food Drier
EZIDRI SNACKMAKER FD500 DIGITAL – Family Food Drier
Control of Temperature from 30ºC - 70°C and Timer from 1 – 48hr by Digital control.
With auto reduction to 30°C on completion of the set time. This is to ensure that
rehydration will not occur, especially when operated in humid conditions.
Control of Temperature from 30ºC - 60°C and Timer from 1 – 24hr by Digital control.

3
When operating the Ultra or Snackmaker always use use five trays even when
drying produse on one or more trays.This is to ensure that the unique heated
airflow system of the EZIDRI is fully utilized.

4
OPERATING INSTRUCTIONS
EZIDRI ULTRA FD1000 DIGITAL
& SNACKMAKER FD500 DIGITAL
OPERATING INSTRUCTIONS
1. Connect to mains power supply Buzzer will ‘beep’ once with red light
2. Press Power Button to ‘ON’ Buzzer ‘beep’, display shows
Temp. 30ºC and Timer 1hr
Unit is now in ‘standby mode’
3. Set Temperature Adjust as required in 5°C increments
4. Set Timer Adjust as required in 1hr increments
5. Press Power Button Unit commences operating.
The Temperature setting (in 5ºC adjustments) and the Timer setting (in 1 hour
additions). For quick adjustment the buttons can be held down for rapid change for
both the Time & the Temperature.
Note: ULTRA FD1000 – At the completion of the ‘Time Set’ the unit will revert to 30ºC
and continue to operate until the unit is switched off. A feature to offset ‘re-hydration’.
SNACKMAKER FD500 – At completion of the ‘Time Set’ the unit will automatically
turn off. In the event of a power failure, the ‘Time Set’ and ‘Temperature’ feature will
restart automatically at the previously setting.
The Temperature and/or the Time, cannot be altered while the unit is running.
To change settings, press the Power button, unit will stop, then make any adjustments
to Temp. or Timer and then press the power button again to recommence operating.
6. To Turn the Unit Off Press the power button for 2 seconds
Unit will stop operating but red light
will show that the power is still connected.
1. TEMPERATURE SETTING ADJUSTABLE – FD1000 30 – 70ºC
FD500 30 – 60°C
2. TIMER ADJUSTABLE – FD1000 1 – 48hrs
FD500 1 – 24hrs
3. RED INDICATING LIGHT Indicates when
Power is connected
4. POWER SWITCH On and Off
Temp Time

5
Temperature 30°C - 60°C
30°C - 70°C
Digital Control
Timer 1hr – 24hrs
1hr – 48hrs
Certification AS/NZ60335.2.9 +
AS/NZ60335.1.2+
EN60335.2.9+
EN62233:2008
CE -EN 60335-2-9+ - EU
GS Mark
Warranty 24 months
ULTRA FD1000
DIGITAL
SNACKMAKER
DIGITAL
EZIDRI DRIERS
All Materials
BPA Free
kg kg
15 Trays
15 Trays
30 Trays
30 Trays

6
ultra fd1000 digital
FD500 DIGITAL

7

8
POWER FAILURE: In the event of power failure, both of the units will resume
operation on previous settings for Temperature and the Timer.

9
ULTRA FD1000
DIGITAL
SNACKMAKER
DIGITAL
30°C - 40°C 30°C - 40°C
50°C 50°C
55°C 55°C
60°C 60°C

10

11

12

13

14

15

16
55°C
55°C
Set EZIRI SNACKMAKER FD500and EZIDRIFD1000 on 55C.
