Fabuletta FKT001 User manual
User Manual
Electric Gooseneck Kettle
Model: FKT001
120Vac 60Hz 1200W
Package Contents
1 x Kettle Lid 1 x Electric Gooseneck Kettle
1 x Power Base 1 x User Manual
Specifications
Rated Power: 1200W Power Supply: AC 120V, 60Hz
Capacity: 1.05qt / 1.0L Temperature Range: 104 - 212°F / 40 - 100°C
Weight: 2.43 lb / 1.1kg Dimensions: 11.6 x 7.13 x 8.43 inch / 29.4 x 18.1 x 21.4 cm
Table of contents
IMPORTANT SAFEGUARDS -------------------------------------------------------- 1
ADDITIONAL IMPORTANT SAFEGUARDS ----------------------------------------- 2
GETTING TO KNOW YOUR KETTLE ------------------------------------------------ 3
• Kettle Diagram ----------------------------------------------------------------- 3
• Controls ------------------------------------------------------------------------- 4
BEFORE FIRST USE ---------------------------------------------------------------- 5
• Water Test ---------------------------------------------------------------------- 5
OPERATING YOUR KETTLE -------------------------------------------------------- 6
• Boiling Water ------------------------------------------------------------------- 6
• Suggested Brewing Temperature --------------------------------------------- 8
• Manual Setting Brewing Temperature ----------------------------------------- 8
• High Altitude Users ------------------------------------------------------------- 9
• Boil-Dry Protection ------------------------------------------------------------- 9
• Turn On/Off Always Hold Temperature ---------------------------------------- 10
• Temperature Conversion（°F to °C) ------------------------------------------- 10
• Turn On/Off The Beep Sound -------------------------------------------------- 11
CARE & MAINTENANCE ----------------------------------------------------------- 12
TROUBLESHOOTING -------------------------------------------------------------- 13
WARRANTY ----------------------------------------------------------------------- 14
WE’RE HERE TO HELP! ----------------------------------------------------------- 15
Table of contents
IMPORTANT SAFEGUARDS -------------------------------------------------------- 1
ADDITIONAL IMPORTANT SAFEGUARDS ----------------------------------------- 2
GETTING TO KNOW YOUR KETTLE ------------------------------------------------ 3
• Kettle Diagram ----------------------------------------------------------------- 3
• Controls ------------------------------------------------------------------------- 4
BEFORE FIRST USE ---------------------------------------------------------------- 5
• Water Test ---------------------------------------------------------------------- 5
OPERATING YOUR KETTLE -------------------------------------------------------- 6
• Boiling Water ------------------------------------------------------------------- 6
• Suggested Brewing Temperature --------------------------------------------- 8
• Manual Setting Brewing Temperature ----------------------------------------- 8
• High Altitude Users ------------------------------------------------------------- 9
• Boil-Dry Protection ------------------------------------------------------------- 9
• Turn On/Off Always Hold Temperature ---------------------------------------- 10
• Temperature Conversion（°F to °C) ------------------------------------------- 10
• Turn On/Off The Beep Sound -------------------------------------------------- 11
CARE & MAINTENANCE ----------------------------------------------------------- 12
TROUBLESHOOTING -------------------------------------------------------------- 13
WARRANTY ----------------------------------------------------------------------- 14
WE’RE HERE TO HELP! ----------------------------------------------------------- 15
IMPORTANT SAFEGUARDS
When using your kettle, basic safety precautions should always be followed.
Read all instructions before using.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
1. Do not touch hot surfaces. Use the handle.
2. Do not immerse cord, plug, kettle or base in water or other liquid.
3. Close supervision is necessary when this kettle is used by or near children.
4. Place the kettle on a dry, flat, stable surface.
5. Do not place the kettle on or near heat sources such as stovetops, microwave
oven, heated oven, radiators, etc.
6. Do not use the kettle if it is malfunctioning, or if any part, including the base,
cord, or plug, is damaged in any way. Do not try to repair the kettle. Contact
Consumer Support.
7. Using accessory attachments not recommended by the manufacturer may
result in fire, electric shock, or injury.
8. Do not use outdoors.
9. Do not use the kettle for other than intended use.
10. Unplug the kettle when it is not being used and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning.
11. Do not fill above the MAX water level. If the Kettle is over-filled, there is a risk
that boiling water may be ejected.
12. To avoid scalding, always make sure the lid is securely closed while the kettle
is operating. Do not cover the spout or the openings on the lid while the
kettle is in use.
13. To disconnect, use the On/Off Switch o turn the kettle off, then remove the
plug from the wall outlet.
1
Fabuletta.com
ADDITIONAL IMPORTANT SAFEGUARDS
Notes On The Cord
1. A short power-supply cord is provided to reduce the risks resulting from
becoming entangled in or tripping over a longer cord.
2. Longer extension cords are available and may be used if care is exercised in
their use.
3. If a long extension cord is used, the marked electrical rating of the extension
cord must be at least as great as the electrical rating of the kettle.
4. The extension cord should be a grounding-type 3-wire cord, and the longer
cord should be arranged so that it will not drape over the countertop or
tabletop where it can be pulled on by children or tripped over.
Electric Power
1. Before plugging the kettle into the wall outlet, check that the electrical
circuit is not overloaded with other appliances.
2. If the electrical circuit is overloaded with other appliances, your kettle may
not operate properly. Operate it on a separate electrical circuit.
Anti-scald
1. The body of kettle and the metal decorative ring of handle become hot during
heating, please use the handle for lifting, carrying and pouring kettle.
2. When pouring hot water, tilt the kettle slowly to control the flow of pouring.
Pouring too quickly could result in water coming out of the lid and cause
scald occurred.
3. Pour all hot water from the kettle before opening the lid to refill.
Figuer 1
[ See Figure 1 ]
2
Fabuletta.com
Lid
Handle
Kettle body
Power cord
with plug
Spout
Connector
Stainless steel Temperature Sensor
GETTING TO KNOW YOUR KETTLE
Kettle Diagram
M
A
X
3
Fabuletta.com
GETTING TO KNOW YOUR KETTLE
Controls
A. On/Off Button
• Turns the kettle on/off
• Press and hold for 5 seconds to turn on/off the beep sounds
B. Tea Button
• Set the kettle to presets, the ideal temperature for tea
• Set the kettle from 104°F to 212°F to serve other drinks
C. Coffee Button
• Set the kettle to presets, the ideal temperature for coffee
• Set your preferred temperature between 190°F - 205°F to suit your personal taste
D. Decrease Button
• Press to decrease the temperature by one degree while manually setting
temperature
E. Increase Button
• Press to increase the temperature by one degree while manually setting
temperature
F. LED Display
• Display the current water temperature and temperature unit
G. Hold Icon
• Display on while Hold Mode was selected
H. Heating Icon
• Display on while the kettle start heating
C B A
H
G
COFFEE
HOLD
HEAT
EF D
[See Page 8, Manually Setting Brewing Temperature]
[See Page 8, Manually Setting Brewing Temperature]
4
Fabuletta.com
Figuer 2 Figuer 3
BEFORE FIRST USE
Water Test
• Set the base on a dry, flat, steady surface. Plug cord into a grounded wall
outlet.
• Fill the kettle with water to the “MAX” line , then put the lid on the
kettle with vent holes facing towards handle and place kettle
back on its base.
• Press to turn on the kettle, then press to choose 212F, the maximum
temperature setting. The display will flash 4 times and the kettle will start
heating up the water.
• The kettle will automatically turn off once it has finished boiling the water.
Allow it to cool, then pour out the water. Rinse thoroughly 2–3 times with
cold water.
• Do not drink the water that is boiled during this test.
M
A
X
M
A
X
1
.
0
L
[ See Figure 2 ]
[ See Figure 3 ]
5
Fabuletta.com
Figuer 4 Figuer 5
160°F
175°F
185°F
195°F
212°F
205°F
200°F
OPERATING YOUR KETTLE
Boiling Water
Note:
• The gooseneck kettle has 7 presets, perfect for making tea and coffee. It
also features a customisable temperature setting to suit your personal
taste
• Always use filtered water for perfect pour over brewing
1. Add at least ½cup / 118 mL of filtered water to the kettle. Do not fill above
the “MAX” line. Wipe any water from the outside of the kettle and the base.
3. Press to turn on the kettle. All buttons and the display will light up.
2. Put the lid on the kettle with vent holes facing towards handle. Place kettle
back on the power base.
4. Press button and continue to press it to choose a preset temperature
setting for brewing tea. There are 5 recommended temperature presets for
optimal brewing of Delicate Tea（160°F）, Green Tea（175°F）, White Tea（185°F）,
Oolong Tea（195°F）, Herbal and Black Tea（212°F）.
Or, press button and continue to press it choose a preset temperature
setting for brewing coffee. There are 2 recommended temperature presets
for optimal brewing of Pour Over（205°F）and French Press（200°F）.
COFFEE
[ See Figure 4 ].
[ See Figure 5 ].
(See page 8, Manually Setting Brewing Temperature).
COFFEE
HOLD
HEAT
COFFEE
HOLD
HEAT
6
Fabuletta.com
HEAT
HOLD
HEAT
HOLD
OPERATING YOUR KETTLE
5. You can only select 1 preset at a time. Once the preset was selected, the
button will flash 4 times, and the kettle will start heating up the water. The
Heat Icon will display on.
6. Press the preset button again at any time before the kettle is finished heating.
This will turn on Hold Temperature mode, which will automatically keep the
kettle at the same temperature for 60 minutes after heating is finished.
The Hold Icon will appear on the display.
7. Once the water reaches your selected temperature, the kettle will beep 3
times and stop heating. The Heat Icon will disappear.
8. To manually interrupt the heating process, press the button at any time.
Note:
• If you take the kettle off the base while heating or Holding, all buttons will
flash, and the kettle will pause working. If you put the kettle back within 60
seconds, it will resume working. After 60 seconds, the kettle will turn off.
• If the kettle is heating without water in it, a boil-dry protection device will
automatically turn it OFF.
HOLD
HEAT
HEAT
[ See boil-dry protection explanation. ]
7
Fabuletta.com
OPERATING YOUR KETTLE
Suggested Brewing Temperatures
Manually Setting Brewing Temperature
• Press or button to choose a preset temperature. The last
temperature set point flashes on the display.
• Press or button to select your preferred temperature. Press once
to decrease or increase the temperature by one degree. Hold the button for
2 seconds to activate faster scrolling decrements or Increments.
• Once the display stops flashing the temperature is set and the kettle will
start heating up to the set point.
• The custom temperature range for Tea Button is from 104°F to 212°F,
and for Coffee Button is from 190°F to 205°F.
Pour Over Coffee
French Press
Delicate Tea
Green Tea
White Tea
Oolong Tea
Herbal Tea/Black Tea
Cocoa
Hot Cereal
Beverage
212°F / 100°C
212°F / 100°C
190°F / 88°C
175°F / 79°C
185°F / 85°C
195°F / 91°C
160°F / 71°C
200°F / 93°C
205°F / 96°C
Temperature
COFFEE
COFFEE
Note: You can custom your preferred temperature to suit your personal taste by
following the below setting.
8
Fabuletta.com
OPERATING YOUR KETTLE
• Once you have set the temperature set point, it is stored in memory and will
be recalled whenever you turn on the kettle. There is no need to set the
temperature every time unless you want to change the set point.
Boil-Dry Protection
Your kettle is equipped with boil-dry protection. If you start heating without
water in the kettle, the heat will automatically shut off and controls will be
disabled.
If an error code “E1” is appeared on the display and all buttons blink and the
kettle beeps. Please take the kettle off the base. Allow the kettle to cool and add
more water before using again.
High Altitude Users
At higher elevations, water boils at a lower temperature. Please check your local
altitude and the corresponding boiling point of the water, and then set the
maximum temperature of your kettle below the boiling point. For example:
Warming:
Setting the temperature above the boiling point is not recommended, there is a
risk that boiling water may be ejected and damage the kettle.
3,881ft/1,183m
9,225ft/2,820m
13,150ft/4,008m
Altitude
190°F / 88°C
196°F / 91°C
205°F / 96°C
Maximum Temperature
Setting for Boiling Water
9
Fabuletta.com
Figuer 6 Figuer 7
Figuer 8
OPERATING YOUR KETTLE
Turn On/Off Always Hold Temperature
Simultaneously press and hold the tea icon and coffee icon
until you see the HoLD and icon appear on the display, means the Always
Hold Temperature Mode was turned on. If only see a HoLd icon without ,
means the Always Hold Temperature Mode is off.
Temperature Conversion（°F to °C)
The temperature reading on the kettle is preset to
Fahrenheit but can be converted to Celsius.
Simultaneously press and hold the increase icon
and decrease icon for 3 seconds to
convert “°F” to “°C”.
When Always Hold Temperature is on, Hold Temperature Mode will automatically
turn on whenever you select a temperature preset.
If you don’t need the Hold Temperature Mode for this brewing, you can press the
preset button again to cancel it for once.
COFFEE
HOLD
[ See Figure 6 ]
[ See Figure 8 ]
[ See Figure 7 ]
HOLD
HOLD
10
Fabuletta.com
Figuer 9 Figuer 10
OPERATING YOUR KETTLE
Turn On/Off The Beep Sound
Press and Hold the On/off button until you see the icon b-ON or
bOFF appear on the display . The Icon b-ON means the beeps is
on and the icon bOFF means the beeps was turned off.
[ See Figure 9 ]
[ See Figure 10 ]
11
Fabuletta.com
Cleaning
1. Unplug the kettle and allow it to cool before cleaning
2. Wipe the kettle and base with a soft, damp cloth.
3. Dry the kettle and the base thoroughly after cleaning
Note: Never immerse kettle or power base in water
Descaling
Scale is a naturally occurring buildup of mineral deposits caused by impurities in
water or use of hard water. You should descale the kettle at least once a week if
you use it frequently. Regular descaling will increase the service life of the kettle,
allowing it to boil water faster with less energy.
1. Unplug the kettle and allow it to cool, pour out all water.
2. Fill the kettle with amixture of half white vinegar and half water to the
“MAX” marking
3. Leave to soak for at least 30 minutes. Boil the mixture.
4. Pour out the mixture, then wipe off any remaining scale with a non-abrasive
cloth, sponge, or cleaning brush.
5. Repeat as needed.
6. Empty Kettle and rinse with fresh water. Let dry thoroughly.
CARE AND MAINTENANCE
12
Fabuletta.com
TROUBLESHOOTING
Kettle is taking longer
than usual to boil
There are yellow mark or
rust dots on the heating
plate
Why my kettle always
turn on the Hold mode.
Why my kettle no beep
alarm suddenly.
“E1” code appears on
the display
“E2” code appears on
the display
Kettle will not turn ON
Questions
You added more water than usual or used ice water.
The lid of the kettle is not placed properly.
Plug the kettle into an independent outlet.
The kettle has a limescale problem. Please follow the
instruction of Descaling to descale.
The yellow mark or rust dots are caused by the
limescale problem. It’s a common problem inhard
waterareas, where the higher concentration of
magnesium and calcium leads to limescale.
Please follow up the instruction of Descaling to descale.
Please check if you turn ON the Always Hold
Temperature mode.
Turn it OFF per the instruction if needed (page 10)
Please check if you turn OFF the beep alarm accidentally.
Turn if ON if needed(page 11)
You turn on the kettle without water in it.
Please take the kettle away the base and allow it to
cool down to reset
The kettle has the temperature sensor problem.
Please contact Fabuletta Service Team.
Make sure the plug is securely inserted into the outlet
Insert the plug into a different outlet for checking
Reset the circuit breaker if necessary
Check if there is foreign between the kettle and base
Explanation/Solutions
13
Fabuletta.com
WARRANTY
The One-Year Limited Warranty is valid for products purchased from our
Fabuletta only, starting from the date of original retail purchase against defects
in quality and materials under normal, non-commercial use. According to the
requirements outlined in this instruction manual, subject to the following
conditions and exclusions.
What Is Covered
The repair or replacement of your Fabuletta appliance if your Fabuletta
appliance is found to be defective due to faulty materials, workmanship or
function within one year of purchase or delivery (if any part is no longer
available or out of manufacture, Fabuletta will replace it with a functional
replacement part). This warranty provides, at no extra cost to you, all labor
and parts necessary to ensure your machine is in proper operating condition
during the warranty period.
What Is Not Covered
Under your Fabuletta guarantee, Fabuletta shall not be liable for costs of repair
or replacement of a product incurred as a result of:
Accidental damage, faults caused by negligent use or care, misuse, neglect,
careless operation or handling of the Fabuletta appliance which is not in
accordance with this Fabuletta Operating Manual. Machines purchased from an
unauthorized dealer. Use of parts and accessories other than those produced or
recommended by Fabuletta. Repairs or alterations carried out by unauthorized
parties or agents. Use of the machine other than for normal domestic purposes
within the United States, e.g. for commercial or rental purposes.
Warranty Service
If you have a query about your Fabuletta appliance, please contact the
Please inform us your model name/number, purchase date, order number,
machine problem and your requirement. Your model number can be found on
rating plate. Please keep your purchase receipt in a safe place to ensure you
have this information. Service under this warranty will not extend the period of
this warranty.
14
Fabuletta.com
15
Fabuletta.com
WE’RE HERE TO HELP!
If you have any questions about our products, please contact our customer
support team.
* Please have your invoice and order ID ready before contacting Customer Support.
Thanks for your purchase!
Hope you will love it as much as we do.
Start your fabulous life with Fabuletta
www.Fabuletta.com
NOTES
16
Fabuletta.com
Table of contents
