Unified Security Gateway Quick Start Guide
© 2001—2008, FaceTime®Communications, Inc.
1
2
Unified Security Gateway Quick Start Guide
© 2001—2008, FaceTime®Communications, Inc.
Unified Security Gateway Quick Start Guide
© 2001—2008, FaceTime®Communications, Inc.
3
Cabling Unified Security Gateway
1. Connect the power cord to the power source.
2. Connect an Ethernet cable from the SPAN/TAP
port of your switch to Line1, which is the
monitoring interface of the security appliance.
3. Connect another Ethernet cable from the LAN
to Line2. The security appliance uses this port
for the proxy and management tasks. You need
to configure network settings for this port using
the steps listed in the Initial Setup section.
Power
Socket Mouse
Keyboard
Video
LINE 1
(Monitor Interface)
LINE 2
(Management/Proxy Port)
Initial Setup
1. Connect a monitor to the video input socket.
2. Connect a keyboard to the keyboard input
socket.
3. Switch on the power using the Power button
on the front panel.
The Boot screen appears. The screen times-out
after 3 seconds.
4. When prompted to configure the management
port (eth1), press Y.
5. Perform one of the following actions:
If you want to assign a static IP address:
a. Specify an IP address (for example,
10.0.2.201).
b. Specify the Netmask (for example,
255.0.0.0).
c. Specify the default gateway (IP) (for
example, 10.0.0.1).
d. Specify the Primary DNS server (for
example, 10.0.2.1).
e. Select OK.
If you want to assign a dynamic IP address:
a. Select DHCP.
b. Select OK.
The Linux terminal displays the IP address—
static or dynamic—assigned to the appliance.
Note down this IP address to access the Web-
based user interface of the security appliance.
Initial Configuration
1. Access the administrative user interface by
typing the following URL in the Web browser:
https://<IP Address>:8443/
2. Perform the following actions when your web
browser displays the following SSL-related
alerts:
Click OK if you see the Secure Connection
alert.
Click Yes when you get the digital certificate
alert.
3. Read the End User License Agreement (EULA)
and click Accept to accept the EULA.
4. On the System Administrative Password page,
type the administrative password for the
sysadmin user in the Password box and
confirm the password in the Confirm Password
box.
5. Log on to the user interface with the
administrative credentials.
6. Go to the Configuration tab » Server
Administration panel » click Network Settings
to open the Network Settings page.
7. Specify the following details:
Host Name of the security appliance.
The domain name to which the security
appliance belongs.
The Primary DNS server.
8. Go to the Configuration tab » Authentication
and Authorization panel » click
Authentication Settings to open the
Authentication Settings page.
9. Specify the Primary Domain Controller to which
the appliance must send user authentication
requests.
10. Upgrade to the latest Firmware image. This
allows you to run the security appliance using
the most recent release with the latest Malware,
IM, and P2P protocols, and report updates.
To obtain firmware updates, perform the
following steps:
a. Download the update package on to the
security appliance. You can schedule a
regular download of updates or download
the update package manually on to the
security appliance.
b. Upgrade the firmware.
For detailed instructions, see the ‘Obtaining
Firmware Updates’ section in the Unified
Security Gateway System Administrator’s
Guide.
11. Download the latest Anti-Malware filter updates:
a. Go to the Configuration tab » Maintenance
panel. Click Malware Updates to open the
Malware Updates page.
b. Type the following URL in the URL for
Updates box in the Update Settings
section:
http://usg.facetime.net/usg/urlupdates/
ftupdate
c. Click Get Latest Filters.
d. Click Install & Restart Now on the Malware
Filters Updates: Get Latest page.
12. Exempt trusted destination servers from being
analyzed by the security appliance. For
instructions, see to the Unified Security
Gateway System Administrator’s Guide.
Rear Panel of the Appliance
Note:If you do not specify an IP address, the IP
address 192.168.1.3 is automatically assigned to the
appliance.
Note:Ignore the Login prompt in the terminal
window and proceed with the instructions in the
Initial Configuration section.
Note:After you specify the Primary DNS server and
the domain name for the security appliance, the
FaceTime webfiltering database starts getting
downloaded on to the system.
Unified Security Gateway Quick Start Guide
© 2001—2008, FaceTime®Communications, Inc.
Unified Security Gateway Quick Start Guide
© 2001—2008, FaceTime®Communications, Inc.
© 2001—2008, FaceTime®Communications, Inc.
Verification
To verify whether the security appliance has been set
up successfully:
1. Select the Real time Usage View option on the
Dashboard tab.
2. Notice the counters in the Real-Time Traffic
Summary panel increase as security appliance
gets the data feed from the SPAN port.
Factory Default
To reset the configuration of the security appliance to
factory default settings:
1. Go to the Configuration tab »
Troubleshooting Toolspanel » click Shut
Down/Restart open the Shut Down/Restart
page.
2. Select Restart System.
3. Click Restart.The Boot screen appears on the
monitor connected to the security appliance.
The screen times-out after 3 seconds.
4. Press any key within 3 seconds.
5. Select Factory Default.
Web Filtering, Malware, IM, and P2P security
policies
Web Filtering, Malware, IM, and P2P usage
statistics
Any custom groups, employees, and buddy
names that were created in the system
Powering Off
The unit can be shut down using the Web-based
administration interface. Do the following to shut
down the unit:
1. Go to the Configuration tab »
Troubleshooting Tools panel » click Shut
Down/Restart to open the Shut Down/Restart
page.
2. Select Shut Down System.
3. Click Shut Down.
FaceTime Communications
1301 Shoreway, Suite 275, Belmont, CA 94002, USA
Customer Support
Phone: (650)631-6400
E-mail: Enterprise[email protected]
Documentation
For the latest version of
Unified Security Gateway System Administrator’s
Guide, visit:
http://usg.facetime.net/usg/
General Information: [email protected]
Press: [email protected]
Sales: [email protected]
Copyright 2001—2008, FaceTime® Communications, Inc. All
rights reserved.
Not for use or distribution without the express permission of
FaceTime Communications. FaceTime, the FaceTime logo
and Unified Security Gateway are trademarks of FaceTime
Communications, Inc. in the United States and other
countries. All other names mentioned in this document may
be trademarks of their respective owners.
Part Number:4B-10-QSG02-080616
Caution:When you select Factory Default
settings, the following configuration settings will
be deleted from the system:
Note:You can also power off the unit manually
by pressing the Power button on the
front panel for about 8 to 9 seconds.
