Operation manual
SQ-6100 IrDA
UHF Handheld Microphone

1
SQ-6100 IrDA UHF Handheld Microphone
Parts and functions
1 Cartridge
2 Power switch
3 LCD
4 Setting button
5 Menu button
6 IrDA synchronizing button
7 Battery compartment
8 Color cap
9 Battery power LED
10 Charging port
Battery installation & indicator
●►○
●
When the transmitter is switched ON, a blue
LED will blink once to denote the batteries
installed are in good condition.
If the LED remains illuminated, it means the
batteries are weak and require replacement.
This transmitter requires 2 x AA batteries to
operate.
To install, remove the battery cover and slide
the batteries into the battery compartment &
replace the battery cover.
Note: Batteries contain a corrosive acid that may leak and damage the microphone when stored for a long
period. Batteries should be removed from the microphone before storing without use for more than 4 weeks.
Channel setting
1 Use MENU button to go to the
CHANNEL｜FREQUENCY page.
2 Press and hold the SET button for 3
seconds, then the upper-right channel
number will flash to allow changes to be
made.
3 Press SET / MENU buttons to change the
channel number. The corresponding
frequency will change accordingly.
4 3 seconds after selecting a channel, it will
be automatically saved.
9
1
2
4
5
6
7
8
3
10

2
Instructions
Channel synchronizing of the receiver and microphone
Align infrared areas of the receiver and microphone within 10~30cm.
Changing the receiver’s channel
1 Press the synchronizing button of the
microphone.
2 The microphone's LED will grow to denote
transmitting the frequency to the receiver
and synchronizing the channels.
Changing the microphone’s channel
1 Press the synchronizing button of the
receiver and the receiver will transmit the
frequency to the microphone and
synchronize the channels
2 The microphone's LED will grow to denote
its channel synchronized by the receiver.
If it doesn’t work check that you have the IR sensor panels aligned, that they are facing each
other, devices are within 10~30cm of each other, and try again.
Battery type setting
1 Use MENU button to go to the BATTERY
TYPE page.
2 Press and hold SET button for 3 seconds,
then the cursorwill flash to allow
changes to be made.
3 Press SET button to select either NiMH
(rechargeable battery) or AKLN (alkaline
battery).
4 3 seconds after selecting a battery type, it
will be automatically saved.
FREQSQ
RF
630000
VOL
SET
30cm
CH
FREQSQ
RF AF
AB
001
630000
VOL
CH
FREQSQ
RF AF
AB
0 0 1
630000
VOL
SDR-6120
WirelessReceiver SET SYNCSET SYNC
10~30cm

3
