FalconEye Electronics FEMDVR4G8BB User manual

4G/WIFI/GPS Live Viewing 1080P 3-8 Cam
MNVR Black box with SDD (3rd Gen)
Quick Start Guide
New Server Migration Reasons:
Old server can not meet the requirements of development for more 4G MDVR devices on the IP server.
Having to many devices on an older server causes buffering when viewing video. Enjoy our new server for
better service experience.
*Additional Quick Start Process available below if you have these discontinued 4G MNVR products
1st Gen 2nd Gen
*Note - All 4G MNVR devices will be using the NEW, IMPROVED, UPDATED IP SERVER & PORT #
NEW URL IP SERVER THAT WILL BE USED IS: http://113.96.131.200/808gps/login.html
Click or copy and paste IP Server link to your browser.
MUST ENABLE / ALLOW "FLASH" after you have entered new IP server URL into your browser

SPECIFICATION
ACCESSORIES
123
567
Power Cable I/O Cable Remote Control
8
4
Video Input Cable
MNVR Keys 4G / GPS / WIFI Antenna SDD CADDY SCREWS QR Code Manual Page
SPECIFICATION
Power Connection

1 Open MNVR Shell with included Keys 2 Twist screws and take out of the SDD
Caddy
3 Insert SDD Into SDD Caddy
Insert & attach screwsto SDD Caddy
Screws SDD and Insert SDD
Caddy
SDD Caddy Installation

CMS-Enable
Enter YOUR Device ID located on your black box labeled as
Account #
USE THIS Center IP- 113.096.131.200
Leave Center Domain blank
Center Port- 6608
4G/WIFI/GPS Live Viewing 1080P 3-8 Cam MNVR Black box with SDD (3rd Gen)
How to change/enter new IP server and port #:
Login- MDVR Menu=>Advance Tab=>COMM=>CMS Change the server IP and Port #'s=> SAVE-
Restart Device
Enter Device ID if it is not
entered already
Change Port to 6608
Change the Center IP to
to 113.096.131.200
Enter, copy&paste or CLICK http://113.96.131.200/808gps/login.html into browser to open the CMSV6 platform
Username: Labeled on your
black box
Password default is:000000
http://113.96.131.200/808gps/login.html

2nd Generation New Server Migration User Guide
How to change/enter new IP server and port #:
Steps: Login MDVR Main Menu=>Select Network Icon=>Select Server Icon=>Change server IP and Port
#=>Select SAVE - Restart Device
Change the Center IP to
to 113.096.131.200
Change Port to 6608
Change the Center IP to
to 113.096.131.200
Change Port to 6608
1st Gen New Server Migration User Guide
How to change/enter new IP server and port #:
Steps: Login MDVR Menu=>Select Network=>Server=>Change the server IP and Port #'s=> SAVE-
Restart Device
Change the Center IP to
to 113.096.131.200
Change Port to 6608
Change the Center IP to
to 113.096.131.200
Change Port to 6608
Step-02: Enter ”http://113.96.131.200/808gps/login.html” into browser to open the CMSV6 platform
Username: May have been
given to you or it may be
labeled on your black box
Password default is:000000
unless you previously
changed it.

THIS PROCESS IS ONLY IF YOUR SYSTEM HAS AN INTERNET CONNECTION AND IS ONLINE
Instructions Process to remote live view cameras on a desktop, laptop
Copy/Paste URL into web browser
1. Check the box on top left corner next to “your order number”
2. Select the “+” sign next to your device # and picture of truck logo to display CH1, CH2,CH3,CH4 - CH8
3. Right click on CH1, CH2, etc (depends on how many cameras you may have) video cam log and select Preview Main
Stream or Sub Stream
IOS and Android devices Mobile viewing
In the APP store, type the app name “CMSV7”
1. Account name: Was Given to you and may
start with: MNVR
2. Password: 000000 (unless you have changed it)
3. ENTER IP Address: 113.96.131.200
4. LOGIN
5. Select “Video”
6. Press “Play icon” to view each camera
We are here to answer any questions you may have. BEFORE
CALLING FOR TECH SUPPORT: REVIEW MANUALS ON THE
"EXTRA TAB" ON OUR PRODUCT PAGE.
1. BE PARKED OR AVAILABLE TO NAVIGATE THROUGH MNVR
BLACK BOX MENUS'S
2. REVIEW ALL INSTRUCTIONAL VIDEOS
3. REVIEW ALL MANUALS
MNVR Tech Support: Call, Text, or Email Falcon Electronics
office 9 am - 5pm CST 972.600.1320
[email protected]
1. Account name: Located on your black box
2. Password: 000000
3. Enter Code
4. Login
Make sure that Flash Web PC Settings are set “allowed”
1. Account name: Was Given to you and may start
with: MNVR
2. Password: 000000 (unless you have changed it)
3. Enter Code
4. Login
Make sure that Flash Web PC Settings are set “allowed”
1. Account name: Located on your black box
2. Password: 000000
3. ENTER IP Address: 113.96.131.200
4. LOGIN
5. Select “Video”
6. Press “Play icon” to view each camera
Process if you have these discontinued 4G MNVR products
Process if you have this
4G MNVR product
Process if you have this
4G MNVR product
http://113.96.131.200/808gps/login.html
Process for Gen 1 and Gen2 discontinued MNVR devices
