Family Safety Products Siren Pro Series 3 HS71512 User manual

1
Safety Siren Pro Series3
Radon Gas Detector
Table of Contents
Facts and Concerns Regarding Radon Gas 2
Location of the Detector 2
Areas to Avoid 3
Installation 3
Display Features 3
Short-Term Display 4
Long-Term Display 4
Start-Up 4
Audible Alarm 5
Menu Button Operation 5
Long-Term / Short-Term 5
Test 5
Alarm Mute On / Off 6
Reset / Clear Memory 6
Calibration Certificate 7
Error Messages 8
Err3 8
Continued 11
Err4 8
Specifications 9
Warranty 10
Factory Evaluation 7
Model Numbers
HS71512 USA
HS79712 Canada

2
Facts and Concerns Regarding Radon Gas
Radon is a radioactive gas that is colorless, odorless, and
tasteless and is impossible to detect without the use of
sensitive test equipment. Radon is a naturally occurring gas
produced by the breakdown of uranium in soil, rock, and
water. When allowed to accumulate to high levels, it can be
hazardous to long-term health. The Surgeon General has
warned that radon is the second leading cause of lung cancer
in the United States. Only cigarette smoking causes more
lung cancer deaths.
HS71512 - USA
The EPA presently suggests that corrective action be taken to
reduce the radon levels in your home if measured over the
long term at 4.0 pCi/L or greater. For more information
regarding radon gas, please visit the EPA web site at
http://www.epa.gov/radon/index.html
HS79712 - Canada
The Minister of Health recommends that remedial measures should
be undertaken in a dwelling whenever the annual average radon
concentration exceeds 200 Bq/m3in the normal occupancy area.
For more information regarding radon gas, please visit the Health
Canada website at: http://www.healthcanada.gc.ca/radon.
Location of the Detector
The detector should be placed in the lowest living area of the
home in a location where it will not be disturbed. The
audible alarm should be able to be heard from areas
frequented on a daily basis. A second detector placed in a
basement room rarely used, is also a good means to
determine the level of radon in the home.
Location of the detector should be at least 3 feet from
windows, doors, or any other potential openings in the
exterior walls. The location of the detector should be at least
1 foot from the exterior wall and at least 20 inches from the
floor. No other object should be placed within 4 inches of
the detector.

3
Areas to Avoid
•Near drafts caused by heating, ventilating, and air
conditioning vents, doors, fans and windows.
•Near excessive heat, such as fireplaces and direct
sunlight, and areas of high humidity.
•Near televisions, computers, radios, all cell phones and
cordless phones, or other electrical equipment.
•Near curtains, furniture, or other items that may inhibit
the flow of air through the ventilation slots.
•In general, the detector should not be located in
kitchens, laundry rooms, closets, or bathrooms.
Installation
The Safety Siren Pro Series3 Radon Detector is designed to
plug into a standard 120-volt household outlet using the
attached power cord. The detector may be placed face-up on
a tabletop, counter top, or any flat surface where the ventilation slots
will not be blocked. The detector must be kept dust free.
A proper airflow must be maintained through the detector to
obtain an air sampling representative of the local environment.
WARNING: Do not plug the detector into a wall outlet
controlled by a light switch.
WARNING: Risk of severe electrical shock. There
are no user serviceable parts inside the detector. Do
not remove the back cover. Removal of the back
cover will void your warranty.
Display Features
HS71512 (USA)
The numeric LED display shows the level of radon gas in
Pico Curies per liter (pCi/L). The display range is 0.0 to 999.9.
HS79712 (Canada)
The numeric LED display shows the level of radon gas becquerel
per cubic meter (Bq/m3). The display range is 0 to 9999.
The Safety Siren Pro Series 3 Radon Detector display is designed
to notify the user of the level of radon gas on either a short-term
or long-term basis, and is updated every hour if there is a change
in the level of radon gas. Both long-term and short-term measurements
are running simultaneously and are accessed by use of the menu
button (see Menu Button Operation).
•Do not place directly on metal, granite, or slate

4
Short-Term Display
The display for the short-term reading is an average of the
levels of radon gas over the past seven days. The short-term
reading allows the user to monitor short-term fluctuations in
the home and provide a better feel for problems relating to
seasonal and weather related variations in the radon levels. A
green LED next to the letter “S” indicates this reading. When the
short-term measurement reaches 4.0 pCi/L (200 Bq/m3) or
greater, for 30 consecutive days or more, the audible alarm
will sound (see Audible Alarm).
Long-Term Display
The display for the long-term reading is an average of the
levels of radon gas for the length of time that the detector has
been powered up or last reset. This reading relates to the
average radon level that you would be exposed to if you were
in the continual presence of the Safety Siren Pro Series3
Radon Detector. A green LED next to the letter “L”
indicates this reading. When the reading on the long-term
reaches a level of 4.0 pCi/L (200 Bq/m3)or greater an audible
alarm will sound immediately.
Start-Up
Upon initial power-up, the display will momentarily show an
internal code including letters and numbers. This code is
used to determine if the detector is calibrated for use within
the USA or Europe. The detector will conduct a self-test and
the audible alarm will sound four chirps. The display will
then read “--”. The two dashes will remain until sufficient
samples have been taken to create an accurate reading. For
the short-term and long-term readings, samples need to be
taken for 2 days (48 hours) before an accurate reading can be
displayed.
Upon initial power-up, the display will momentarily show an
internal code including letters and numbers. The detector
will conduct a self-test and the audible alarm will sound four
chirps. The display will then read “--”. The two dashes will
remain until sufficient samples have been taken to create an
accurate reading. For the short-term and long-term readings,
samples need to be taken for 2 days (48 hours) before an
accurate reading can be displayed.
Please note: pCi/L refers to USA model HS71512.
Bq/m3refers to Canada model HS79712.

5
Audible Alarm
HS71512 (USA)
4.0 pCi/L is the level set by the EPA as the threshold at which
action should begin to correct the radon problem within the home
The detector will alarm in both long-term and short-term modes.
HS79712 (Canada)
200 Bq/m3is the level set by the Minister of Health as the
threshold at which remedial measures should begin.
The detector will alarm when:
•Short-term displays 4.0 pCi/L (200 Bq/m3) or greater
for 30 consecutive days, or
•Long-term displays 4.0 pCi/L (200 Bq/m3) or greater
(alarms immediately, no 30 day delay)
When the detector goes into an alarm state, the buzzer will
sound 4 short chirps. This sound will be repeated every hour
until the level on the long-term reading drops below 4.0 pCi/L
(200 Bq/m3) or until the user mutes the alarm. Instructions for
this function can be found under Menu Button Operation.
Menu Button Operation
The menu button controls 4 different functions for the radon
detector. These functions are controlled by the length of time
that the button is pushed in.
1. Long-Term / Short-Term
This function is used to change the display
between the short-term and long-term readings.
Press the menu button in for one second. The
display will change the instant the menu button is
released with the LED indicator light lit next to
the “S” or “L” to indicate which reading is now
being viewed. If the menu button is held in for
longer than 3 seconds, the display will not change.
2. Test
This function is used to test the audible alarm. Press
and hold the menu button in for 5 seconds. The alarm will
sound 4 chirps as if it is in an alarm condition. Release
the menu button once the alarm begins to sound.
Please note: pCi/L refers to USA model HS71512.
Bq/m3refers to Canada model HS79712.

6
3. Alarm Mute On/Off
This function allows the user to silence the
audible alarm. While in an alarm condition,
press and hold the menu button for 15 seconds.
As you pass through the test phase as indicated
above, the alarm will sound 4 chirps. The display
will read “Aoff”. Release the menu button as
soon as “Aoff” is displayed. When the menu
button is released, the display will return to
normal condition.
the on position. If desired, the alarm can be
reactivated by repeating the same process. When
reactivating the alarm, the display will read “Aon”
Please note: This function is only active when the
detector is in an alarm condition.
4. Reset/Clear Memory
This function allows the user to clear and reset the
memory for the short and long- term readings.
This should be done anytime the detector is
moved to a different location. Disconnect power
for a minimum of 4 hours. Press and hold the menu
button for 20 seconds. The display will read “CL”.
When the menu button is released, the “CL” will
flicker until the memory has been completely cleared.
Once the memory has been cleared, the display will
read “--“ for 48 hours until enough samples have been
taken to provide an accurate reading.
Please note: While using this function, the
detector will pass through the test and alarm
functions as described above.
A brief description of the Menu Button
Functions
can be found on the back of the
detector.
Please note: pCi/L refers to USA model HS71512.
Bq/m3refers to Canada model HS79712.
If the long-term reading returns
to a safe level, the audible alarm will be reset to

7
Note: To prolong the life of the sensor and to ensure proper
readings, unplug the detector, vacuum the ventilation slots
on the detector, using the upholstery attachment on your
vacuum every 3 months
Calibration Certificate
If you are a licensed radon measurement professional using
this device for home inspections, etc., the U.S. EPA recommends
a calibration and background check be performed annually. To
request an annual calibration:
•Contact FSPI at 800-748-0298 or 616-530-6540 to request
a FE# (factory evaluation authorization number). At that time,
please be prepared to pay with a credit card. Units received
without FE# will be returned to sender, freight collect.
•Package the detector carefully to ensure that no damage occurs
during shipment. Write the FE# you received on the outside of the
package near the address label. Do not include the power supply.
•Send the unit to Family Safety Products, Inc. 2879 Remico St. SW,
Grandville, MI 49418, freight prepaid. The fee for factory evaluation
is $35. Factory evaluation time is approximately two weeks. Family
Safety Products, Inc. will send the unit back, freight prepaid
(additional freight charges may apply to shipments outside the U.S.).
•Contact FSPI at 800-748-0298 or 616-530-6540 to request
a CA# (calibration authorization number). At that time,
please be prepared to pay with a credit card. Units received
without CA# will be returned to sender, freight collect.
•Package the detector carefully to ensure that no damage occurs
during shipment. Write the CA# you received on the outside of the
package near the address label. Do not include the power supply.
•Send the unit to Family Safety Products, Inc. 2879 Remico St. SW,
Grandville, MI 49418, freight prepaid. The fee for calibration is
$75. Calibration time is approximately two weeks. Family Safety
Products, Inc. will send the unit back, freight prepaid (additional
freight charges may apply to shipments outside the U.S.).
Factory Evaluation
Manufacturer recommends a biennial factory evaluation of this
device to recertify that the device meets factory minimum standards.
Note for Radon Measurement Professionals
Note for Home Owners
Annual calibration is optional for the private use of this
device. A homeowner requesting a periodic calibration must
follow the same procedure outlined above. Same charges apply.

8
Err3 Noise Error
This error is normally from electrical noise
interference. This error can be caused by
computers, televisions, fluorescent lights, cell
phones, cordless phones or other electrical items.
The detector needs to be moved to a different
location away from the item causing the interference.
To clear this message (Err3) from the detector,
unplug detector for five minutes, power back up
and reset/clear memory to start new test.
Err4 Sensor Error
This error occurs if the sensor fails the self-test. If
this error code appears, the detector should be
unplugged for five minutes and powered back up.
If the Err4 reappears, please call our customer
service department at 800-748-0298 or 616-530-6540.
WARNING: Risk of Electrical Shock! Do not
remove the back cover. Sensor requires 250VDC
and may cause severe electrical shock. Removal of
the back cover will void your warranty.
Please Note:
To offer protection to your furniture, we have included 4
Please Note:
Noise error can also be caused by power surges from power
outages or brown-outs. Using a surge protector can minimize this
noise error. Do not use a battery backup device in conjunction
with the detector.
non-slip rubber pads to be applied to the back of the detector
at each corner.
Error Messages
Every 24 hours, the detector will do a self-test. If there is a
failure in this self-test an error message will appear in the
display window.

9
Specifications
Power Source
Adapter 120Vac, 60Hz
Input for Gas
Detector 18VDC, 200mA
Sensor Voltage 250VDC
Sensor Diffused-Junction Photodiode
Full Scale Reading 0.0 to 999.9 pCi/L
(0 to 9999 Bq/M3)
Operating Environment 0°C (32°F) to 40°C (104°F)
Storage Environment -20°C (-4°F) to 85°C (185°F)
Audible Alarm 85dB at 10cm
Beeps every hour if long-term
readings are 4.0 pCi/L (200 Bq/m3)
or greater, or short-term reads
4.0 pCi/L (200 Bq/m3) or greater
for 30 consecutive days. May be
muted by the user.
Averaging Frequency Levels will be updated on the
display every hour.
Short-Term Average over the past 7 days.
Long-Term Average from the time of last
reset. Maximum sampling time
of 5 years. The detector will
automatically reset after 5 years
of accumulated data.
Accuracy +/- 20% or 1.0 pCi/L (37 Bq/m3)
whichever is greater
Dimensions 4.7” x 3.1” x 2.1”
Please note: pCi/L refers to USA model HS71512.
Bq/m3refers to Canada model HS79712.

10
One Year Limited Warranty
Family Safety Products, Inc. warranties this product to the
original retail purchaser, to be free from defects in material
and workmanship except as otherwise provided herein. This
warranty is not transferable and is effective from the date of
original retail purchase.
Units returned to Family Safety Products, Inc. that are
determined to be within the warranty period and found to be
defective, will be repaired or replaced free of charge to the
original purchaser. If you suspect that your detector is
defective, please follow the instructions found under
Procedures for Warranty Service.
Procedures for Warranty Service:
1. Contact Family Safety Products, Inc. by phone
at 800-748-0298 or 616-530-6540, by email at
[email protected] or by mail at 2879 Remico St.
SW, Grandville, MI 49418 to receive a return
authorization (RA) number. Products returned
without an RA number will be refused and returned to
the purchaser.
2. Include with the detector the RA number, your name,
address, phone number and description of the problem
you are experiencing. All returns must also include a
copy of the original purchase receipt showing the date
of purchase.
3. Package the detector carefully to ensure that no damage
occurs during return shipment. Write the RA number
you received on the outside of the package near the
address label.
4. Send the package, postage prepaid, to Family Safety
Products, Inc. 2879 Remico St. SW, Grandville, MI
49418.

11
This Warranty Does Not Cover:
1. Cost of shipping the product to Family Safety Products.
2. Normal wear, scratches or fading of product.
3. Damage caused by abuse, misuse, tampering with the
product including the removal of the back cover.
4. Damage caused by failure to follow installation and use
directions found in this manual.
5. Consequential damages, incidental damages or
expenses, including damages to property and personal
injury.
This warranty is limited to the provisions clearly stated
herein. Any implied warranties, warranties of
merchantability, warranties of fitness for a particular use are
excluded.
If any of this warranty is prohibited by federal, state or local
law, that cannot be preempted, that provision shall not be
applicable. This warranty gives you specific legal rights and
you may also have other rights that vary from state to state.

12
Family Safety Products, Inc.
2879 Remico St. SW
Grandville, MI 49418
616-530-6540
www.fspi-radon.com
090-MN-RADPRO3A
