F&F AZH-LED User manual

AZH-LED
Twilight switch,
hermetic
The AZH-LED is a twilight switch with a built-in light sensor, enc-
losed in a hermetically sealed housing and specially adapted to
switch on the LED lighting. By using a switching element that gu-
arantees correct operation with current pulses up to 160 A and
additional components responsible for surge suppression, the
AZH-LED will successfully manage to switch on and off the LED
lighting, despite its energy efficiency, generates strong current
surges when switched on, effectively destroying classic relays.
The twilight switch should be placed in a place with constant
access to natural light, which by changing its intensity will cau-
se the lighting to switch on and off. The time of switch-on of
the lighting can be set by the user using the potentiometer.
Rotation towards the "moon" – will switch on the lighting later,
rotation towards the "sun" – will switch it on earlier. The twili-
ght switch has a system that delays switching on and off of the
lighting, thus reducing the impact of various disturbances (such
Purpose
Functioning
F&F Filipowski sp. j.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax [phone]
www.fif.com.pl; e-mail: [e-mail]
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collecon, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.

- 2 -
as atmospheric discharges) on the operation of the machine.
1.Turn off the power supply.
2.Fix the twilight switch vertically (with the cable facing down) to
the ground with two screws in a place that is not illuminated
by the switched (or other) light source.
3.Connect the wires according to the diagram. Insulate well the
connection point of power supply cables with the cables of a
twilight switch or connect them in a hermetic distribution box.
4.Remove the rubber stopper that secures access to the poten-
tiometer.
5.Use a screwdriver to set the tripping threshold.
6.After adjustment, insert the rubber stopper back into place.
When checking the operation of the twilight switch, co-
ver the entire device tightly, for example with a cardbo-
ard box or a dark, thick fabric. Covering only the "eye"
of the probe, for example, with a finger, is not enough,
as the intensity of sunlight is very strong and penetra-
tes the photoelement through the plastic housing and
human body.
Mounting

- 3 -
power supply 195÷253 V AC
maximum load current (AC-1) 10 A
switch-on threshold (adjustable) 2÷1000 lx
histeresis approx. 15 lx
activation delay approx. 10 s
deactivation delay approx. 20 s
resistance to current shocks 160 A/20 ms
power consumption 0.56 W
terminal OMY 3×0.75 mm², l= 0.8 m
working temperature -25÷50°C
dimensions 50×67×26 mm
mounting surface
protection level IP65
Connection diagram
Technical data

- 4 -
E200408
tungsten halogen fluorescent energy-saving LED
1500 W 1000 W 500 W 300 W 300 W
The above data are indicative and will heavily depend on the
design of a specific receiver (that is especially important for
LED bulbs, energy-saving lamps, electronic transformers and
pulse power supply units), switching frequency and operating
conditions.
For more information visit: www.fif.com.pl.
The F&F products are covered by a warranty of the 24 months
from the date of purchase. Effective only with proof of purchase.
Contact your dealer or directly with us.
F&F Filipowski sp. j. declares that the device is in conformity
with the essential requirements of The Low Voltage Directive
(LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC)
Directive 2014/30/UE. The CE Declaration of Conformity, along
with the references to the standards in relation to which confor-
mity is declared, can be found at www.fif.com.pl on the product
page.
Power table
Warranty
CE declaration
