F&F TR-08 User manual

- 1 -
TR-08
Mains transformer
TR-08 is used to supply electrical and electronic devices that
do not require a stable, filtered supply voltage independent of
changes in the network voltage.
The transformer system includes a PTC posistor as over-
current protection.
»
1.Turn off the power.
2.Connect the mains cables to the input terminals (1-2) of the
transformer.
3.Connect the receiver to the output terminals (5-6) of the trans-
former
Purpose
Mounting
F&F Filipowski sp. j.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax [phone]
www.fif.com.pl; e-mail: [e-mail]
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.

- 2 -
For complete protection of the receiver, it is recommen-
ded to connect an additional 1.5 A overcurrent protec-
tion (e.g. BZ-1 fuse module) on the secondary side.
Wiring diagram

- 3 -
power supply 230 V AC
output voltage 8 V AC
11 V AC for Io= 0
maximum load current (AC-1) 1 A
output power 8 VA
thermal protection PTC posistor
terminal 2.5 mm² screw terminals (cord)
4.0 mm² screw terminals (wire)
tightening torque 0.5 Nm
working temperature -10÷40°C
dimensions 2 modules (35 mm)
weight 271 g
mounting on TH-35 rail
ingress protection IP20
The F&F products are covered by a warranty of the 24 months
from the date of purchase. Effective only with proof of purchase.
Contact your dealer or directly with us.
F&F Filipowski sp. j. declares that the device is in conformity
with the essential requirements of The Low Voltage Directive
(LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC)
Directive 2014/30/UE.
The CE Declaration of Conformity, along with the references to
the standards in relation to which conformity is declared, can be
found at www.fif.com.pl on the product page.
