F&S PicoCOM1 Assembly Instructions

PicoCOM1
Hardware
Version 0.70 Date 2012.11.07
© by F & S Elektronik Systeme GmbH 2008
Preliminary
F & S Elektronik Systeme GmbH
Untere Waldplätze 23
D-70569 Stuttgart
Phone: [phone] Fax: [phone]

Table of Contents
1Arrangement of Connectors.....................................1
2Technical Data Connectors......................................2
3Connectors.................................................................3
3.1 Counting of the connector pins....................................3
3.2 IO-Pin limitations .........................................................3
3.3 Connector J1 ...............................................................4
4Dimensions PicoCOM1.............................................8
5Technical Data PicoCOM1........................................9

Seite 1
1 Arrangement of Connectors
Figure 1.1: Bottom View
J1
1

Seite 2
2 Technical Data Connectors
The PicoCOM1 is equipped with a
TycoElectronics 5177984-3 (8 pin, 0.8mm)
connector from ‘0.8mm Free Height (FH) Connectors’ series.
Matching connectors are:
5mm stacking height: TycoElectronics 5177983-3
9mm stacking height: TycoElectronics 5-5179009-3
13mm stacking height: TycoElectronics 5-5179010-3

Seite 3
3 Connectors
3.1 Counting of the connector pins
The connector plug of PicoCOM1 will be treated as follows.
Pin 1 is marked in Figure 1.1. The row with pin1 contains all
odd-numbered pins (1, 3, 5, 7 etc.), and corresponding to this,
the row without pin 1 contains all even-numbered pins (2, 4, 6,
8 etc.).
3.2 IO-Pin limitations
PicoCOM1 is equipped with 43 pins that can be used as digi-
tal-IO. Most of these pins are multiplexed, so you have to
make sure that these pins are used for one purpose only. For
example, if you intend to use IO0 to IO3 you have to make
sure that the COM2 is disabled.
Additionally there are some IO-Pins which are used internally
and whose primary function can’t be disabled completely.
These pins may carry active signals while the device is boot-
ing, which must be kept in mind when connecting external
hardware. For example even if you don’t intend to use COM3
in your application, Pin43 and Pin44 be configured as serial
line in the bootloader for a short period of time. will send
Pins that could toggle during boot are marked with a * in the
following table.

Seite 4
3.3 Connector J1
J1
Pin
Signal
Default Interface
Starter-Kit Interface
1
TX-
Ethernet TX-
Ethernet TX-
2
RX-
Ethernet RX-
Ethernet RX-
3
TX+
Ethernet TX+
Ethernet TX+
4
RX+
Ethernet RX+
Ethernet RX+
5
V33
+3.3V +-5% DC
+3.3V +-5% DC
6
V33
+3.3V +-5% DC
+3.3V +-5% DC
7
GND
Ground
Ground
8
GND
Ground
Ground
9
VBAT
+3..+3.6V DC (RTC back-
up battery)
+3..+3.6V DC (RTC backup
battery)
10
nRES
Reset In (open drain)
Reset In (open drain)
11
SHDN
Shutdown (active low)
Shutdown (active low)
12
WKUP
Wake Up
Wake Up
13
IO0
IO0
COM2 TXD
14
IO1
IO1
COM2 RXD
15
IO2
IO2
COM2 RTS
16
IO3
IO3
COM2 CTS
17
IO4
IO4
COM1 TXD
18
IO5
IO5
COM1 RXD
19
HDPA
USB Host 1 +
USB Host 1 +
20
HDMA
USB Host 1 -
USB Host 1 -
21
DDP
USB Device +
USB Device +
22
DDM
USB Device -
USB Device -
23
IO6 1)
IO6
USB CNX
24
IO7 1)
IO7
USB PWR

Seite 5
J1
Pin
Signal
Default Interface
Starter-Kit Interface
25
GND
Ground
Ground
26
nTRST
JTAG Reset
JTAG Reset
27
TMS
JTAG TMS
JTAG TMS
28
TDI
JTAG TDI
JTAG TDI
29
TDO
JTAG TDO
JTAG TDO
30
TCK
JTAG TCK
JTAG TCK
31
JTAGSEL
JTAG Select
JTAG Select
32
IO8 1)
IO8
I2C SDA
33
IO9 1)
IO9
I2C SCL
34
IO10 2)
IO10
SD DAT0
35
IO11
IO11
SD DAT1
36
IO12
IO12
SD DAT2
37
IO13
IO13
SD DAT3
38
IO14
IO14
SD CLK
39
IO15 2)
IO15
SD CMD
40
IO16
IO16
IRQ1
41
IO17 2)
IO17
IO17
42
GND
Ground
Ground
43
IO18 1)
IO18
COM3 TXD
44
IO19 1)
IO19
COM3 RXD
45
IO20
IO20
COM2 DSR
46
IO21
IO21
COM2 DCD
47
IO22
IO22
COM2 DTR
48
IO23
IO23
COM2 RI
49
IO24
IO24
COM1 RTS
50
IO25
IO25
COM1 CTS

Seite 6
J1
Pin
Signal
Default Interface
Starter-Kit Interface
51
CAN+
CAN+
CAN+
52
CAN-
CAN-
CAN-
53
HDPB
USB Host 2 +
USB Host 2 +
54
HDMB
USB Host 2 -
USB Host 2 -
55
IO26 3)
IO26
SPI MISO
56
IO27 3)
IO27
SPI MOSI
57
IO28 3)
IO28
SPI SPCK
58
IO29
IO29
SPI PCS0
59
IO30
IO30
SPI PCS1
60
IO31
IO31
SPI PCS2
61
GND
Ground
Ground
62
GND
Ground
Ground
63
IO32
IO32
IO32
64
IO33
IO33
IO33
65
IO34
IO34
IO34
66
IO35
IO35
IO35
67
IO36
IO36
IO36
68
IO37
IO37
IO37
69
IO38
IO38
IO38
70
IO39
IO39
IO39
71
ELED0
Ethernet LED
Ethernet LED
72
GND
Ground
Ground
73
GND
Ground
Ground
74
IO40
IO40
Analog In 1
75
IO41
IO41
Analog In 2
76
IO42
IO42
Analog In 3

Seite 7
J1
Pin
Signal
Default Interface
Starter-Kit Interface
77
LOUT
Line Out Left
Line Out Left
78
ROUT
Line Out Right
Line Out Right
79
LIN
Line In Left
Line In Left
80
RIN
Line In Right
Line In Right
1) These pins carry internal signals and may toggle during boot.
2) Like 1) theses pins carry internal signals. But this restriction is limited to
hardware revisions ≤1.20 only.
3) If using the CAN interface, these pins are restricted to SPI function.
See PicoCOM1 starterkit documentation for connection exam-
ples.

Seite 8
4 Dimensions PicoCOM1
Board thickness: 1.6 mm
Height of parts on top side: 3.0 mm
Height of parts on bottom side
(without connectors): 2.0 mm
Pin pitch of connector: 0.8 mm
Mounting hole diameter 2.8 mm
Figure 4.1: Top View
Figure 4.2: Bottom View
All values can have tolerances of ±0,5mm.

Seite 9
5 Technical Data PicoCOM1
Power Supply: +3.3V DC / ±5%
Current Consumption: < 400 mA
(<450mA in custom LDO version)
<2A on startup up to 2.5V
!! we recommend a 2A power source with fast rise time to
avoid startup problems !!
Inputs/Outputs: max. 43 I/O
RAM: 32 MByte SDRAM
Flash: 32 MByte Flash
CPU: Atmel AT91SAM9260 210 MHz
Operating Temperature: –20°C ... +85°C
Dimensions: 80 x 50 x 10 mm (l x w x h)
Weight: 50 gr.
