FE PETRO STP-SCI Installation instructions

Franklin Fueling •3760 Marsh Rd. • Madison WI 53718 USA
Tel: [phone] • 800 225 9787 • Fax: [phone] •www.franklinfueling.com
Installation
and
Owner’s Manual
Software Revision 1.4
SMART CONTROLLER I™ STP-SCI

2
Important Safety Messages
FE Petro equipment is designed to be used to pump volatile hydrocarbon liquids such as gasoline and diesel fuel.
Installing or working on this equipment means working in an environment in which these highly flammable liquids are
present. This presents a risk of severe injury or death if these instructions and standard industry practices are
not followed. Read and follow this entire instruction booklet before installing or working on this equipment.
As you read these instructions, watch for the following safety symbols:
Follow all federal, state, and local laws governing the installation of this product and the entire
system. When no other regulations apply, follow NFPA 30, 30A, and 70 from the National Fire
Protection Association. Failure to do so could result in severe injury, death, serious property
damage and/or environmental contamination.
If the electrical circuit breakers are accidentally turned on while the STP-SCI is being installed,
electrical power could be applied to the STP-SCI, creating the risk of potentially lethal electrical
shock hazard. ALWAYS tag and lock breakers so they are not turned on accidentally.
Always disconnect both power supplies (110-250V Hook and the 208-240V input) before installing
or servicing. Failure to do so could result in severe injury or death.
Installer: This instruction booklet MUST be left with the owner of the service station at which the equipment is being
installed.
Station Owner: Retain these instructions for future use and provide them to persons servicing or removing this
equipment.
Warning
Caution
Warning
Warning
Warning
This symbol identifies a potentially hazardous situation which, if the instructions that follow it are not
adhered to, could result in death or serious bodily injury.
This symbol identifies a potentially hazardous situation which, if the instructions that follow it are not
adhered to, could result in serious property damage, including possible environmental contamination as a
result of the leakage of fuel from the equipment.

3
INSTALLATION INSTRUCTIONS
Read and become familiar with these instructions before doing installation.
1. Install STP per STP/IST Fixed and Variable Length Installation and Owner’s Manual.
2. Remove cover of STP-SCI and mount base to wall or other surface.
Note: The STP-SCI must be mounted indoors and can operate at ambient temperatures between 40°and105°F (4°-41°
C).
3. Connect input power of 208-240 VAC to L1 and L2 and Ground wire to terminals per Figure 2.
4. Connect dispenser hook signal to terminals, 110-250V supply and return per Figure 2.
5. Using an ohmmeter, verify the motor leads (M1 and M2) are not shorted to ground.
Damage to the STP-SCI may occur if motor leads are shorted together or to ground and power is
applied.
6. Connect motor leads to M1 and M2 and Ground wires to terminals per Figure 2.
7. For Stand Alone controller configuration set SW1 and SW2 poles 1-8 per Figure 1(Stand Alone configuration is
Factory setting). For Master-Slave and/or Alternating Circuit configurations, go to “Master-Slave/Alternating
Circuit” section, step 9.
8. All STP-SCI controllers must be calibrated. Continue to step 14 “Calibration” section to complete installation.
MASTER-SLAVE/ALTERNATING CIRCUIT
The Master-Slave feature allows the master to turn on additional STP’s when the first STP operating needs help due to
loading (flow rate) or an abnormal condition exists. The Alternating Circuit (AC) feature continuously alternates the lead
pump, thus turning on a different STP each time all dispensers are shut off and at least one dispenser is turned back on.
The Master-Slave/AC configuration combines the features of the Master-Slave and AC functions.
Note: • STP-SCI is not compatible with the STP-SC or the STP-SCB in Master-Slave, Alternating Circuit configurations.
• Master-Slave will not work with PMA33, PMA75B (50 Hz PMA), or PMAH150B (50 Hz PMA).
9. Wire STP-SCI controllers according to Figure 3 for Master-Slave, Figure 4 for AC or Figure 5 for Master-Slave & AC
Configurations. Connect Communication cable, RS 485, to terminals (+, G, and –) wire “+” together, “G” together and
“-“ together then wire the shielded cable drain wire to Ground (G) at one end only, Use at least 22 AWG three
conductor shielded cable with drain wire.
10. Connect dispenser hook signal to the STP-SCI designated as Master per Figures 3,4, and 5.
Note: Be sure L1, L2, M1, M2 and Grounds are installed at each STP-SCI.
11. Configure Master-Slave and Alternating Circuit features by setting SW2 poles 3 and 4 per Figure 1.
12. Create an address for each controller by setting SW1 poles 1-5 per Table 1. Each Controller must have its own
unique address.
13. Attach cover of controller to base and complete the “Calibration” section of the installation manual, step 14.
Note: There can only be one Master in a system and up to 31 slaves.
CALIBRATION
Note: Before calibration process can begin, fuel level in tank must be above the motor intake
1. It is recommended to close either the STP clamp valve or a ball valve at the STP discharge. Turn on power supply to
the STP-SCI. The green light indicator will come on steady, the red light indicator will flash eight times and the
audible alarm will beep eight times. This indicates the STP-SCI is Uncalibrated.
2. Put the controller in calibration mode by pressing and holding the reset button, the push-button on the right side of
the control box, until all three light indicators blink alternately. This will take approximately 10 seconds. Release the
reset button. For Master Slave and Alternating Circuit configurations put the master and all the slaves into
calibration mode before going to step 3.
3. Lift a handle on a dispenser to turn the pump on. After approximately 16 seconds the controller will take a “snapshot”
of the voltage, current and power. The three lights will quit alternating and only the green light will remain flashing.
This indicates the calibration is complete and the dispenser handle can be turned off. Remember to open the STP
clamp valve or ball valve when calibration is complete. If the controller does not calibrate the red light will flash and
Warning

4
the audible alarm will beep an abnormal condition code, see the “Troubleshooting Guide” section to identify and
correct the abnormal condition.
Important Information for Calibrating Controllers:
•All STP-SCI’s must all be calibrated prior to operation.
•All three indicator lights will flash alternately in calibration mode.
•The STP-SCI will calibrate only when the STP is free of abnormalities (faulty wiring, etc.), and a dispenser
handle is turned on within 10 minutes after calibration is initiated. Calibration must be done at zero flow.
False abnormal conditions will result if calibration is done with flow.
•If electronic line leak detection is used make sure the STP-SCI is in calibration mode (all three lights flashing
alternately) before the dispenser handle is turned on. If it is not, the STP-SCI will not turn on and the line
leak detector will sense a fault. When the line leak detector senses a fault, it will not provide a dispenser
hook signal to the STP-SCI and the STP-SCI will not calibrate until the line leak detector is reset.
•With blending dispenser systems calibrate all blended product STP-SCI’s simultaneously by selecting the
mid-grade handle at the dispenser.
•If power is lost to the controller the calibration data is retained.
Reset Button
SW 1
SW 2
L1 and L2
Incoming Power Supply
(50/60 Hz, Single Phase)
M1 and M2
To STP
Incoming Dispenser
Hook Terminals
RS 485
Communication Terminals
Grounding Terminals
Picture 1

5
Configuration Options
SW1 Poles SW2 Poles
1-5 6-8 1 2 3 4 5 6-8
Stand Alone
(Factory Setting) NA See Table 2 See Table 2 NA Off Off See Table 2 NA
Master Controllers
Master-Slave See
Table 1 See Table 2 See Table 2 NA On Off See Table 2 NA
Alternating Circuit NA Off On
Master-Slave &
Alternating Circuit NA On On
Slave Controllers
All Slaves See
Table 1 See Table 2 See Table 2 NA Off Off See Table 2 NA
Figure 1
SW1
Address Pole 1 Pole 2 Pole 3 Pole 4 Pole 5
Master Off Off Off Off Off
Slave - 1 On Off Off Off Off
Slave - 2 Off On Off Off Off
Slave - 3 On On Off Off Off
Slave - 4 Off Off On Off Off
Slave - 5 On Off On Off Off
Slave - 6 Off On On Off Off
Slave - 7 On On On Off Off
Slave - 8 Off Off Off On Off
Slave - 9 On Off Off On Off
Slave - 10 Off On Off On Off
Slave - 11 On On Off On Off
Slave - 12 Off Off On On Off
Slave - 13 On Off On On Off
Slave - 14 Off On On On Off
Slave - 15 On On On On Off
Slave - 16 Off Off Off Off On
Slave - 17 On Off Off Off On
Slave - 18 Off On Off Off On
Slave - 19 On On Off Off On
Slave - 20 Off Off On Off On
Slave - 21 On Off On Off On
Slave - 22 Off On On Off On
Slave - 23 On On On Off On
Slave - 24 Off Off Off On On
Slave - 25 On Off Off On On
Slave - 26 Off On Off On On
Slave - 27 On On Off On On
Slave - 28 Off Off On On On
Slave - 29 On Off On On On
Slave - 30 Off On On On On
Slave - 31 On On On On On
Table 1
SW2 SW1
Picture 2
ON
Picture 3
Factory Default Switch Settings
Factory setting is Stand Alone configuration with all selectable features off, Fault Read out,
Bypass, Auto Restart, Fault Shutdown, and Extended Run Disable

6
Switch Definitions
SW1 SW2
Pole Description Function Pole Description Function
1 Address 0 1 Fault Shut down For M/S and AC only. When ON an
Abnormal condition on any controller
it will shut down all STPs
2 Address 1 2 Unused Unused Switch
3 Address 2 3 Master/Slave** ON for Master controller
OFF for Slave(s) and Stand Alone
4 Address 3 4 Alternating
Circuit** ON for Master Controller
OFF for Slave(s) and Stand Alone
5 Address 4
Controller Addressing switches for
use with Master/Slave and
Alternating Circuit configurations
See Table 1
5 Extended Run
Disable* ON disables Extended Run Fault
OFF Extended Run detection active
6 Fault Read out*ON Displays the last 5 abnormal
conditions the controller encountered 6 Unused
7 Bypass*ON Bypasses diagnostics for 10
minutes. Use as Troubleshooting aid 7 Unused
8 Auto Restart*When ON, controller will attempt to
restart STP with Empty Tank error
when hook signal is applied.
8 Unused Unused switches
*See trouble shooting guide for detailed description
** See Figure 1 for configuration switch settings
Selectable features to aid Troubleshooting
See Figure 1 for location and See Switch Definitions table for brief description of the following features:
Fault Read Out Mode (SW1, Pole 6)
With this mode selected, switch in the ON position, the controller will display the last 5 abnormal conditions it
encountered. The controller will beep once and then the red LED will flash the most recent abnormal condition. It will
then beep twice and the red LED will flash the second to last abnormal condition. The controller will follow this sequence
through 5 beeps and then repeat the sequence. It will continue to repeat the sequence while in this mode. If there is less
then 5 abnormal conditions the controller will continue the beep sequence but the red LED will not flash after the beep.
With the appropriate equipment the last 5 abnormal conditions can be read through the RS485 port.
Bypass Mode (SW1, Pole 7)
With this mode selected, switch in the ON position, the controller will operate as a standard control box. It will not indicate
or shut down any abnormal condition with the exception of an over current condition (short or locked rotor). The controller
will stay in this mode for 10 minutes. After the 10 minutes the controller will revert to its normal operation. Pushing the
reset button will allow it to run another 10 minutes in the Bypass mode.
Auto Restart Mode (SW1, Pole 8)
With this mode selected, switch in the ON position, If the controller detects an empty tank/under load condition, it will shut
down the pump and it will attempt to start the pump when a hook signal is removed and reintroduced to the controller. If
the empty tank condition is still present the controller will shut down the pump. If the empty tank condition is corrected
(tank is refilled) the controller will run the STP and clear the abnormal condition. In M/S configuration, if the Master is in
the under load condition, it will wait until the Slave controller calls for help before attempting to restart.
Fault Shutdown Mode (SW2, Pole 1)
For Master-Slave and Alternating Circuit configurations only, this mode only needs to be selected on the Master
controller. When this mode is selected, switch in the on position, the entire system will shutdown if any of the controllers,
Master or Slaves, detect an abnormal condition. The system will not run until the abnormal condition is corrected and the
reset button is pushed or the Fault Shutdown mode switch is turned off and the reset button is pushed.
Extended Run Disable (SW2, Pole 5)
This switch, when in the ON position, will disable the Extended Run Fault detection of the STP-SCI. The Extended Run
Fault will shut off the STP if it has been running for 60 minutes without a change in product flow. A possible application of
this switch is in an emergency generator where the STP is running at all times.
Do not disable the Extended Run if the system requires the pump to be off for line leak detection
i.e. Mechanical Leak Detectors, Electronic Line Leak detection. Disabling the Extended Run Fault
and running the STP continuously could mask a leak in the system.
Table 2
Caution

7
TROUBLESHOOTING GUIDE
To aid field service personnel the STP-SCI is equipped with a microprocessor control that makes it possible for the unit to
diagnose abnormal operating conditions, and communicate them via LEDs on the front panel and by an audible alarm.
The following is a definition of all operation and abnormal operating codes.
Green light on steady Power (208-240V) is applied to the STP-SCI.
Green light flashing Pump Motor Assembly (PMA) is running.
Note: If the green light stays steady, even when a dispenser is energized, check the dispenser hook signal terminals on
the STP-SCI. Verify that 110 – 250VAC is across the hook terminal (see Figure 2). If the green light remains
steady, 110 – 250 VAC is present at the hook terminal and switch settings are correct, call FE Petro Technical
Service for assistance.
If the green light flashes, even when all the dispensers are turned off, there may still be power
present at the STP-SCI Hook Terminal. If this condition exists call FE Petro Technical Service for
assistance.
Red Light Flashing/
Alarm Beeping Abnormal condition. Determine the number of flashes/beeps and refer to the appropriate row
on the guide below.
Disabling the audible alarm
To silence the audible alarm, depress the push button briefly. This only silences the alarm; it does not reset the controller.
Reset
Before correcting an abnormal condition (red light flashing/alarm beeping), note the number of flashes/beeps, reset the
controller by depressing the push button on the side of the control box for between three and ten seconds (all indicator
lights will go out) and check for proper operation. If controller operates correctly, do not continue to service unless the
abnormal condition is still present. If the controller indicates the abnormal condition is still present correct the condition,
according to the troubleshooting guide, then reset the controller and check for proper operation. Contact FE Petro
Technical Service for further assistance, if applicable.
Warning

8
Flashes
/Beeps Condition Potential Causes Proposed Action
1 Under Load Low fuel level in the
storage tank
Or
Obstructions in Motor
Intake
Or
Calibrated with product
flow
Note: If Auto Restart Switch is set in the ON position once fuel is again above
the PMA end bell and the hook signal is reapplied the STP-SCI will
restart with out pushing the reset button.
1. Check fuel level in storage tank; schedule fuel delivery, when delivery is
complete and fuel level is above PMA end bell push reset button on STP-
SCI. Check for correct system operation. If fuel levels are within acceptable
range, the STP-SCI may need to be recalibrated if it was previously
calibrated with air in the lines or with product flow.
2 Low
Incoming
Voltage
Voltage fluctuations or
low input voltage Note: STP-SCI will automatically restart when the voltage returns to
acceptable operating range.
1. Use AC voltmeter to verify incoming voltage is within the 208-240VAC
acceptable range. If voltage is not within this range, contact an electrician to
correct problem. If voltage is within acceptable range and condition is still
present after resetting, recalibrate controller per “Calibration” section.
3 Overload Short in wiring from STP-
SCI to PMA
Or
Incorrectly wired through
capacitor
Or
Foreign material in PMA
or rotor within motor is
locked up
1. Check and verify wiring is correct from STP-SCI to motor (shorts or
incorrectly wired capacitor). If condition is corrected, check for proper
operation. If operating correctly, do not continue with next step. If condition
is still present, continue to next step.
PMA Replacement/Inspection
2. Disconnect input voltage at load center, lock and tag out circuit breakers.
3. (See PMA Replacement Instructions P/N 400289002, included with New
PMA) Disengage the 3/4” securing bolt of the electrical connector and swing
out of the way. Remove two 9/16” bolts from extractable portion of the
manifold.
4. Pull extractable part of the pump.
Note: Pump Motor Assembly shell can be damaged by blows from hard
surfaces, use care in removing.
5. Remove black end cap from PMA and attempt to spin rotor with a 3/16”
Allen wrench to determine if there’s any binding. If rotor does not spin freely
and/or there is physical damage (note this on a warranty claim form for FE
Petro use), proceed with step 7. If no binding or physical damage to PMA,
reinstall extractable by following the previous steps in reverse order and
then continue to the next step.
Note: PMA can have a locked rotor during startups if it has been exposed to
a corrosive environment, such as a tank ballasted in water.
6. Turn on power to the STP-SCI unit and verify correct system operation. If
condition is corrected, do not continue to next step. If condition is still
present, remove the extractable by repeating steps 2 through 4 and then
continue to next step.
7. Remove four 5/16” cap screws that connect the PMA with a ¼” Allen wrench
and remove the PMA from the motor discharge head.
Note: Prior to mounting a new PMA, check lead assembly (wires inside the
extractable portion to PMA) for shorted wires and proper alignment,
which may have caused the condition.
8. Replace with new PMA.
Note: Pump motor shell can be damaged by blows from hard surfaces, use
care in replacing.
9. Re-install extractable and secure by following reverse order of disassembly.
10. Turn on power to the STP-SCI unit and verify correct system operation.

9
Flashes
/Beeps Condition Potential Causes Proposed Action
4 Open Circuit Connection broken from
STP-SCI to PMA
Or
Locked Rotor w/ Thermal
Overload Open
Or
Incorrectly wired through
capacitor
Or
Relay Failure
1. Wait 5 minutes before pushing the reset button on the STP-SCI. This will
allow the motor thermal overload to reset if locked rotor has occurred.
Check for proper operation of system; if operating correctly do not continue
to next step. If condition is still present continue to next step.
2. Disconnect power at load center, lock and tag out circuit breakers.
3. Remove the two motor control outputs (M1 and M2) from the STP-SCI unit.
4. Using an ohmmeter (low range setting), place leads between two wires
going to the STP, this is the first step in determining where the open circuit
has occurred. Correct readings between M1 and M2 wires (orange and
black) should match that of the motor being used +/-1 ohms. These
readings can be found in TB004 or the STP/IST Fixed & Variable Length
Installation and Owner’s Manual. Readings between any of the motor wires
and ground should be an open circuit. If readings in this step are incorrect,
continue with the next step. If readings are correct go to step 7.
5. Check and verify capacitor wiring is correct in STP junction box. Refer to
the STP/IST Fixed & Variable Length Installation and Owner’s Manual for
wiring diagram or SB003. If condition has been corrected, do not continue
with next step. If wired correctly and condition is still present, continue with
next step.
6. Go to the submerged turbine and remove the cover at the top of the
extractable manifold. Remove the three wire nuts and continue conductivity
tests on the three wires going to the motor. Readings between any of the
motor wires and ground should be an open circuit. If readings are incorrect
and there are no problems with the lead assembly wiring, go to “PMA
Replacement/Inspection” in 3 flash section. If readings are correct, there is
problem with the wiring between the STP-SCI and this point, continue with
next step.
7. Remove the junction box cover and do conductivity test on wires in the
junction box after the capacitor through the extractable discharge head
(orange to orange, red to red, and black to black). If wires are not
conducting, replace the male and female connectors of the STP. See
STP/IST Fixed & Variable Length Installation and Owner’s Manual for
replacement parts. Check for proper operation. If operating correctly, do not
continue. If conductivity readings are correct and the condition is still
present, continue to next step.
8. Upper Board relay may be stuck open or damaged. Replace Upper Board
(Relay Assembly); see “Replacement Parts” section for part number. Turn
on power to the STP-SCI unit and verify correct system operation.
8 Uncalibrated New Installation Note: All STP-SCI’s must be calibrated prior to operation.
1. Calibrate STP-SCI per “Calibration” section.
If controller calibrates, do not continue to next step. If abnormal condition is
indicated, Count Flashes/beeps before pushing reset button. Follow
troubleshooting guide for the indicated condition. Correct condition and
recalibrate.
2. Check the following:
•Calibration is done at no flow (close STP clamp valve or ball valve in
line).
•Dispenser hook signal is applied within 10 min. of putting controller in
calibration mode.
•No open circuits between controller and motor.
•Lines have been purged of air.
•Locked Rotor
9 Extended
Run Continuous Hook Signal applied for more than 60
min. without pumping
product
1. Disconnect power at load centers, lock and tag out circuit breakers.
2. Check voltage across hook terminal with all dispenser handles off. There
should be no voltage applied. If voltage is present, contact an electrician to
correct the problem. After the problem has been corrected, turn on power to
the STP-SCI and verify system is operating correctly.
10 Relay Fault Relay contact failure The STP will continue to run after this fault indication is
displayed.
1. Disconnect power at load centers, lock and tag out circuit breakers.
2. Replace Upper Board (Relay Assembly), see “Replacement Parts” section.
3. Turn on power to the STP-SCI unit and verify correct system operation.
Contact FE Petro for additional troubleshooting information at 1-800-225-9787.
Caution

10
Figure 2
STP-SCI Stand Alone Wiring Diagram

11
Figure 3
STP-SCI Master/Slave Wiring Diagram

12
Figure 4
STP-SCI Alternating Circuit Wiring Diagram

13
Figure 5
STP-SCI Master/Slave Alternating Circuit Wiring Diagram

14
REPLACEMENT PARTS
Upper Board (Relay Assembly): P/N 225005930
Lower Board (Control Assembly): P/N 225000930
Lower Board
Upper Board
Picture 4

15
This page intentionally left blank

©2004 FE Petro
Form No. 223987101 Rev. 4
