Featherlite AL60-30 Installation instructions

SL. No. Components name Images
1 Table Top
2Frame Top Caps
3Frame Botoom Caps
4Die Cast male Hooks
5Die Cast Female Hooks
6 Sheetmetal Male Hook
7 Sheetmetal Female hook
8 Side Trim
9 Leveller
10 KeyBoard Tray
Components Used in AL60-30 Panel System

Tool No.
Name of the tool
1 Cordless Machine
2 Rubber Mallet
TOOLS USED IN INSTALLATION

2400
1200
1200
1260
750
Key Board Tray (4 No's)
Gable End (4 No's)
60mm Frame (2 No's)
Intermed ate Galble end
Table Top (4 No's)

Step 1 :- Removing of Table Top.

Step 2 :- Removing of gable ends.
Tool No. 1

Step 3 :- Removing of Main Spine. Tool No. 2

Top Cap
Top Trim
Horizontal top Beam
Vertical extrusion
MDF Fabric
Top Corner Clamp
Raceway Door
Laminate Tile
Bottom Caps
M8 Leveller
Die Cast male Hoo
Die Cast Female Hoo
Tile Divider

Dis assembly instrcutions.
Disassembly Sequence, Time Schedule and Tools
Requirement for AL 60/30 Panel system.
Table 1
Sl,No Activity Time in
min Tools required
1. Disconnect sockets/switches and take
out the cables.
4 Cordless
machine
2. Removal of Table Tops 3 Cordless
machine
3. Removal of Gabel Ends 3 Cordless
machine
4. Removal of main Spine frames 3 Manual
5. Packing Of Materials. 2 Manual
Total time per work station- 15 Mins.
The timings are based on a cluster of 4 work stations. The dismantling team
consists of two persons. For dismantling more number of work stations, larger
team can be used and the activity can be telescoped.
