CB2 MINI CHILL User manual

Made in Vietnam - r03 Page 1 of 6
mini chill MEDIA CONSOLE
hardware
components
tools required
Thank you for purchasing the Mini Chill Media Console.
This page lists all the contents included in the box. Please
take the time to identify the hardware as well as the
individual components to this product. As you unpack
and prepare for assembly, place the contents on a
carpeted or padded area to protect them from damage.
NOTE: 2 people are required to safely assemble this product.
Missing hardware?
Please call 800.606.6387
for replacements.
(We recommend the use of hand tools instead of power tools)
14 - cam
screws
1 - top
panel
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
1 - bottom
panel
1 - back panel
1 - partition
1 - drawer
back–
2 - side panels
(1 left, 1 right)
1 - drawer
bottom
1 - drawer
front
2 - drawer
sides
(1 left, 1 right)
22 - wood
dowels
14 - cams 4 - bolts
12 - screws
4 - spring
washers
phillips head screwdriver
4 - flat
washers
6 - cam
covers
1 - middle
panel
1 - apron
1 - drawer
bottom rail
4 - small
screws
4 - large
screws
2 - wall
straps
4 - mounting
brackets
4 - plastic
anchors
mounting hardware

A. Insert 4 cams into middle panel as shown. Make
sure arrows on each cam point toward nearest edge
with holes.
B. Insert 4 cam screws, 6wood dowels and 2
cams into left and right side panels as shown.
Secure, but do not over tighten, cam screws with a
phillips head screwdriver.
mini chill MEDIA CONSOLE
Made in Vietnam - r03 Page 2 of 6
1
34
middle
panel
A
top panel
2
Fit dowels of apron into corresponding holes of
bottom panel as shown. Secure bottom panel with
2 bolts, 2 spring washers, and 2 flat washers,
using a phillips head screwdriver. Do not over
tighten the bolts.
A. Insert 6 wood dowels and 6 cam screws into
top panel as shown.
B. Insert 4 cams into bottom panel as shown.
NOTE: Make sure arrows
on each cam point toward
nearest edge with holes
left and right
side panels
A. Insert 2 wood dowels and 2 cams into partition
as shown.
B. Insert 2 wood dowels into apron as shown.
partition
NOTE: Do not over
tighten the cam
screws
NOTE: Do not over
tighten the bolts
bottom
panel
B
A
B
apron
A
B
apron
bottom
panel
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com

mini chill MEDIA CONSOLE
Made in Vietnam - r03 Page 3 of 6
5
78
Fit dowels of right side panel into corresponding
holes of assembly and as shown. Turn cams
clockwise with a screwdriver, until each cam
securely engages each cam screw.
6
Fit back panel into grooves of assembly as shown.
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
Fit dowels of left side panel into corresponding
holes of assembly as shown. Secure cams.
Fit dowels of partition into corresponding holes of
middle panel as shown. Secure middle panels
with 2 bolts, 2 spring washers, and 2 flat
washers.
partition
middle
panel
right side
panel
back
panel
left side
panel
NOTE: Make sure
groove of middle
panel is positioned
down during assembly
as shown

mini chill MEDIA CONSOLE
Made in Vietnam - r03 Page 4 of 6
9
11
10
12
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
A. Attach drawer left side to drawer front with 2
screws as shown. Secure screws with a
screwdriver.
B. Slide drawer bottom into grooves of drawer
assembly as shown.
drawer
front drawer
left side
NOTE: Do not over
tighten the screws
drawer
bottom
A. With the assistance of another adult, carefully
position assembled unit upright. Fit dowels of top
panel into corresponding holes of assembled unit.
Secure all cams.
B. At this point, cover all exposed cams with cam
covers.
A
B
top
panel
B
A
B
A. Attach drawer back to drawer left side with
2 screws as shown.
B. Attach drawer right side to drawer assembly
with 4 screws as shown.
Adrawer
back
B
drawer
right side
Position drawer assembly upside down and
attach drawer bottom rail with 4 screws.
drawer
bottom rail

cleaning and care
Clean surfaces with a dry or damp soft cloth. Do not use
abrasive cleaners. Do not use furniture wax or polish as
the unit is finished with a protective clear lacquer. It is
recommended to use coasters to protect surface from heat
and water.
weight limitations
Conventional TV: Top holds 360 lbs evenly distributed
Flat Screen TV: Top holds 100lbs evenly distributed
Other supporting surfaces: Holds 60lbs evenly distributed
Drawer: 40lbs weight capacity
mini chill MEDIA CONSOLE
Made in Vietnam - r03 Page 5 of 6
13
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
With assistance of another adult, insert glides of drawer assembly into
corresponding glides of case assembly. Keeping the drawer level, carefully push
the drawer until it is all the way in the case and glides are securely engaged.
Assembly is now complete.
NOTE: Make sure glides are
pulled out of the case, and
ball bearings are at the front of
the extended glides
NOTE: Make sure to
keep drawer level so
as not to damage glides
during assembly

mini chill MEDIA CONSOLE
Made in Vietnam - r03 Page 6 of 6
NOTE: If you are unsure about your wall type or what mounting method you should use,
consult a qualified professional or your local hardware store.
For added safety and stability, it is recommended that the wall mounting hardware be installed. For
safe mounting, it is essential to use wall anchors appropriate to your wall type (i.e. plaster, drywall,
concrete, etc.). Mount to wood studs whenever possible.
A) Attach 2 mounting brackets to top of unit using 2 small screws per bracket.
B) Determine the final location of unit. Mark position on the wall, approximately 2" below each
mounting bracket on the back of the unit.
C) Drill a hole in the wall stud. If a wall stud is not available, drill a hole in the wall that is slightly
smaller in diameter than the anchor. Gently tap the plastic anchor until the flange of the anchor is
flush with the wall.
D) Attach the mounting brackets to the wall by inserting 2 large screws through each mounting
bracket and into the wall anchor in the wall.
E) Position the unit so the mounting brackets on the back of the unit are aligned with the wall
brackets.
F) Lace one end of each wall strap through corresponding brackets, and into the other end of the
strap.
G) Pull the straps tightly until secure.
Wall mounting assembly is now complete.
