Informer-IP Desk Mount
Model I-IP-IO Series C
Two-Way IP-enabled Intercom and Alarm Initiation Point
Description, Specications,
Installation, and Operation Manual

All product names or trademarks are properties of their respective owners.
Limited Warranty
This product is subject to and covered by a limited warranty,
a copy of which can be found at www.fedsig.com/SSG-Warranty.
A copy of this limited warranty can also be obtained by written
request to Federal Signal Corporation, 2645 Federal Signal Drive,
University Park, IL 60484, email to [email protected] or
call [phone].
This limited warranty is in lieu of all other warranties, express or
implied, contractual or statutory, including, but not limited to the
warranty of merchantability, warranty of tness for a particular
purpose and any warranty against failure of its essential purpose.
2645 Federal Signal Drive
University Park, Illinois 60484
www.fedsig.com
Customer Support 800-548-7229 • [phone]
Technical Support 800-524-3021 • [phone]

3
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Contents
Safety Messages......................................................................................................................................................5
Safety Messages to Installers .............................................................................................................................5
General Description ................................................................................................................................................8
Introduction ........................................................................................................................................................8
Features..............................................................................................................................................................8
Ordering Information ...........................................................................................................................................9
Specications ........................................................................................................................................................10
Installation.............................................................................................................................................................. 11
Determine a Suitable Location..........................................................................................................................12
Wall Mounting ...................................................................................................................................................13
Desk Mounting ..................................................................................................................................................13
Memory Card Removal and Installation............................................................................................................14
Testing and Training..........................................................................................................................................14
Operations..............................................................................................................................................................15
Controls.............................................................................................................................................................15
Visual Indications ..............................................................................................................................................16
Rear Panel Input/Output ...................................................................................................................................16
Audio/Relay - Input/Output Connections...........................................................................................................17
Alert Rear Input.................................................................................................................................................17
RS232 Port .......................................................................................................................................................17
Ethernet Port.....................................................................................................................................................18
Power Connector ..............................................................................................................................................18
Disable Microphone (Internal option) ................................................................................................................18
Replacement Parts ................................................................................................................................................19
Getting Service ......................................................................................................................................................19

4
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
Tables
Table 1 Ordering Information .................................................................................................................................9
Table 2 Optional Accessories.................................................................................................................................9
Table 3 Specications ...........................................................................................................................................10
Table 4 Compliance ............................................................................................................................................... 11
Table 5 Controls.....................................................................................................................................................15
Table 6 Visual Indications (Located on keypad).................................................................................................16
Table 7 JP3 Input/Output Connections................................................................................................................17
Table 8 J1 Rear Input.............................................................................................................................................17
Table 9 FS232 Connector Pin-out ........................................................................................................................17
Table 10 J2 Input Power........................................................................................................................................18
Table 11 JP3 (on the main PCB) Microphone Enable Jumper...........................................................................18
Table 12 Replacement Part Numbers ..................................................................................................................19
Figures
Figure 1 Informer-IP Scrolling Message Display (optional).................................................................................9
Figure 2 PS Series Push Button Stations (optional)..........................................................................................10
Figure 3 Rear View - Hole Measurements ...........................................................................................................13
Figure 4 Informer-IP Keypad ................................................................................................................................15
Figure 5 Rear Panel Input/Output ........................................................................................................................16

5
Safety Messages
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Safety Messages
It is important to follow all instructions shipped with this product. This device is to be
installed by trained personnel who are thoroughly familiar with the country electric codes
and will follow these guidelines as well as local codes and ordinances, including any
state or local noise control ordinances. Listed below are important safety instructions and
precautions you should follow:
Planning
• If suitable warning equipment is not selected, the installation site for the Informer
is not selected properly or the Informer is not installed properly, it may not produce
the intended optimum audible warning. If applicable, follow Federal Emergency
Management Agency (FEMA) recommendations.
• If the Informer is not activated in a timely manner when an emergency condition
exists, it cannot provide the intended audible warning. It is imperative that
knowledgeable people, who are provided with the necessary information, be
available at all times to authorize activation.
• The sound output of the Informer is capable of causing permanent hearing damage.
To prevent excessive exposure, carefully plan placement, post warnings, and restrict
access to areas near sirens.
• Activating the Informer may not result in people taking the desired actions if those
to be warned are not properly trained about the meaning of warning sounds. Users
should follow FEMA recommendations and instruct those to be warned of correct
actions to be taken.
After installation, service, or maintenance, test the system to confirm that it is operating
properly. Test the system regularly to confirm that it will be operational in an emergency.
Safety Messages to Installers
People’s lives depend on your safe installation of our products. It is important to follow
all instructions shipped with this product. This device is to be installed by a trained
electrician who is thoroughly familiar with the National Electrical Code and/or Canadian
Electrical Code and will follow the NEC and/or CEC Guidelines as well as all local codes.
The selection of the mounting location for this Informer, its controls and the routing of
the wiring are to be accomplished under the direction of the Facilities Engineer and
the Safety Engineer. Listed below are some other important safety instructions and
precautions you should follow:
• Electrocution or severe personal injury can occur when performing various
installation and service functions such as making electrical connections, drilling
holes, or lifting equipment. Therefore, only experienced electricians should install
this product in accordance with national, state and any other electrical codes having
jurisdiction. Perform all work under the direction of the installation or service crew
safety foreman.
• Read and understand all instructions before installing, operating, or servicing this
equipment.

6
Safety Messages
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
• All eective warning sounds may, in certain circumstances, cause permanent hearing
loss. Take appropriate precautions such as wearing hearing protection. Maximum
sound level exposure limits specified in OSHA 29 CFR 1910 should not be exceeded.
Review and comply with any local or state noise control ordinances as well as OSHA
noise exposure regulations and guidelines.
• For optimum sound distribution do not install this speaker where objects would block
any portion of the front of the Informer.
• Establish a procedure to routinely check the signal system for proper activation and
operation.
• Any maintenance to the unit MUST be performed by a trained electrician in
accordance with NEC Guidelines and local codes or a Federal Signal certified Service
Provider.
• Never alter the unit in any manner.
• The nameplate should NOT be obscured, as it contains cautionary and/or other
information of importance to maintenance personnel.
• After installation and completion of initial system test, provide a copy of these
instructions to all personnel responsible for operation, periodic testing, and
maintenance of the equipment.
• File these instructions in a safe place and refer to them when maintaining and/or
reinstalling the device.
Failure to follow all safety precautions and instructions may result in property damage,
serious injury, or death.
Installation and Service
• After installation or service, test the system to confirm that it is operating properly.
Test the system regularly to confirm that it will be operational in an emergency.
• If future service and operating personnel do not have these instructions to refer to,
the system may not provide the intended audible warning, and service personnel
may be exposed to death, permanent hearing loss, or other bodily injury. File these
instructions in a safe place and refer to them periodically. Give a copy of these
instructions to new recruits and trainees. Also give a copy to anyone who is going to
service or repair the Informer.
• To reduce the risk of electric shock, do not perform any servicing other than what
is contained in the operating instructions unless you are qualified to do so. Refer all
servicing to qualified service personnel. Always test the Informer before using after
repairs have been made.
Ethernet Wiring
• Unless shielded or run in conduit, Ethernet wiring must be at least six feet from bare
power wiring or lightning rods and associated wires, and at least six inches from
other wire (for example, antenna wires, doorbell wires, wires from transformers to
neon signs), steam or hot water pipes, and heating ducts.
• Do not place Ethernet wiring or connections in any conduit, outlet or junction box
containing high voltage electrical wiring.

7
Safety Messages
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Symbol Definition
_A _V Indicates to reduce the risk of fire, replace fuse as marked.
Pay careful attention to the notice located on the equipment.
Read and understand the information contained in this manual before attempting to install
or service the Informer.

8
General Description
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
General Description
Introduction
The Informer-IP Desk Mount is an intercom, a warning device, and an alarm initiation
point that connects to an Ethernet network. An internal speaker is used to provide clear
two-way voice communications between control and monitoring points and distributed
locations. You can trigger two dierent alerts at the Informer-IP using the contact closure
input and the ALERT button.
The Informer-IP has an audio output for connecting to existing PA systems and two relay
outputs to control strobes or other devices. An RS232 port is available for driving an
optional scrolling message display. The Informer-IP provides seven standard alert tones
and can store up to 4,000 voice or tone messages with 17 hours of total prerecorded tone
and voice alerts.
You can wall mount the unit or have it sit on a desktop. You can power it through Power
over Ethernet (PoE) from a network, or through local AC power. (Use of strobe requires
AC powering or external powering of strobe.) Using existing network infrastructure
significantly lowers installation costs and simplifies wide-scale deployments.
The Informer-IP provides an unmatched value for two-way indoor alert and notification for
schools, hospitals, police and fire stations, government facilities, and industrial plants.
See the Informer-IP Series C Setup, Program, and User Manual (part number 25500395
revision C or later) to learn how to set up, configure, program, and use Informer-IP
devices.
Features
The Informer-IP has the following features; some features require using the Federal Signal
Commander®software system:
• Tone and Voice Alert and Notification compatible with Federal Signal Controllers.
• Two-Way Intercom with Remote audio monitoring, recording, and playback.
• Removable microSD card for custom message generation. Store up to 4000 voice or
tone messages that total up to 17 hours of recording time.
• Integrated Modbus®TCP industrial PLC interface for control and monitoring.
• Integrated SIP phone interface for live PA, remote wave file, and function control.
• Commander and CommanderOne®HMI software provide configuration, control,
activation, and notification options.
• Small size, rugged construction, and wide operating temperature range.
• High-output speaker with adjustable volume control and exceptional sound quality.
• Seven factory-installed siren tones: wail, alternate wail, pulsed wail, steady, alternate
steady, pulsed steady, and Westminster chime (auxiliary).
• LED status indicators for Power, Alert, Test, and Talk.
• Ability to activate on-board relays for strobe or other external devices.

9
General Description
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
• REPLAY button allows Alert messages to be replayed when the red Alert LED is
flashing.
• RESET button Silences Alerts.
• Local and remote volume level controls.
• Informers are addressable Individually, in Groups, or All.
• Requires minimal network bandwidth and uses TCP/IP protocol for security and
reliability.
• Remote supervision of Communications, Audio Output, Alert Function Execution.
• Supports fixed IP, DHCP, and Auto-IP.
• Wired Ethernet.
• Works with redundant SmartMsg and Commander®network servers for reliable fail-
safe operation with full two-way control, status monitoring, and configuration of the
Informer-IP.
Ordering Information
Table 1 Ordering Information
Part Numbers Description
I-IP-IO Informer-IP Desk Mount
Informer-IP requires Federal Signal Commander application software.
There is a programming fee associated with Informer-IPs programmed at the factory.
Contact your local representative for a quotation.
Table 2 Optional Accessories
Part Numbers Description
I-SMD2-36 Scrolling Message Display (2 x 36 inches)
I-IP-SW Informer-IP Setup Wizard Software and Cable
PSEV-YM Yellow Station with Momentary Contact – “EVACUATION”
PSEVSC-YM Yellow Station with Momentary Contact and Sounder Cover –
“EVACUATION”
PSEM-RM Red Station with Momentary Contact – “EMERGENCY”
PSEMSC-RM Red Station with Momentary Contact and Sounder Cover –
“EMERGENCY”
LP1-012* 12 VDC Strobe (can be powered by internal power supply for I-IPW)
*(A) Amber, (B) Blue, (C) Clear, (G) Green or (R) Red (I-IPW only)
The following figure illustrates the scrolling message display.
Figure 1 Informer-IP Scrolling Message Display (optional)

10
Specications
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
The following figure illustrates the wall mounted push buttons for activation.
Figure 2 PS Series Push Button Stations (optional)
Specications
Table 3 Specications
Operating Voltages at J2
using AC Transformer
9-15 Vdc
108-128 Vac, 60 Hz with wall transformer
Operating Current Standby: 9 V = < 200 mA, 12 V = < 150 mA
With siren or message audio:
9 V = < 450 mA, 12 V = < 350 mA
Operating with PoE,
IEEE 802.3af, 48V input
PoE: 42 to 57 VDC, IEEE 802.3af
units shipped prior to February 2014: mode B units
shipped after February 2014: mode A
Standby: < 60 mA
with siren or message audio: < 110 mA
Audio Data 8000 samples/sec, μLaw compression
Audio Data Playback Storage 17 hours and 4,000 messages with 2 GB microSD card
Audio Frequency response 300-3000 Hz, +1 to -3 dB per octave
Audio Output 0.5 W into 8 ohms
Audio Distortion < 5% at 80 dB output, with 700 Hz tone
Warning Siren Audio Seven factory-installed siren tones: wail, alternate wail,
pulsed wail, steady, alternate steady, pulsed steady, and
Westminster chime (auxiliary)
Internal Failure Alarm Unit will sound a short, low-level beep once every
30 seconds if network connectivity is lost.
Serial Port RS232C, N, 8, 1 Baud rate congurable
Ethernet Port IEEE 802.3, 10 BASE-T connection
Operating temp range -22°F to +140°F (-30°C to + 60°C)
Humidity range 0-95%, non-condensing
Size (H x W x L) 3.5 x 8.5 x 5 inches (88.9 x 215.9 x 127 mm)

11
Installation
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Weight < 2.0 lb (0.9 kg)
Shipping Weight 2.80 lb (1.27 kg)
Table 4 Compliance
Electromagnetic
Interference
Complies with FCC Title 47, Part 15
FCC Part 15
Class B
Radio Frequency Interference (RFI) (FCC 15.105)
The Informer-IP was tested and found to comply with the limits for
Class B digital devices pursuant to Part 15 Subpart B of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential environment. This equipment
generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on.
Try to correct the interference by one or more of the following measures:
• Increase the separation between the equipment and the receiver.
• Connect the equipment to a different circuit than the receiver that it
is connected to.
Electrical Code
Compliance
Complies with UL 1492
Installation
Read and adhere to all safety warnings in this manual before installing the
Informer-IP.
To prevent injury, this apparatus must be securely attached to the wall per the
installation instructions.
SHOCK HAZARD: Electrocution or severe personal injury can occur when making
electrical connections, drilling holes, or lifting equipment. Therefore, experienced
electricians, per national and local electrical codes, acting under the direction of
the installation crew safety foreman, should perform the installation.

12
Installation
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
Determine a Suitable Location
When choosing a location for the Informer-IP, consider the following criteria:
• Place as far as possible from electrically noisy electronic devices to avoid
interference. Examples of noisy devices may include microwave ovens, motor-driven
devices, light ballasts, and electrical switching devices.
• Requires a connection to a wired Ethernet network. Ethernet wire runs must be less
than 328 feet (100 meters) from the nearest network switch.
• Place in an area where you can hear the speaker when the Informer-IP is activated.
You can check the warning tone level by holding the VOLUME up and down buttons
until the desired level is reached. If the coverage area is large, multiple Informer-IP or
external amplifiers and speakers may be required to provide adequate warning.
• Position to keep the unit at least 6 inches (15.24 cm) away from the listener’s ears to
avoid potential hearing damage.
• Do not use near water, for example, near a bathtub, washbowl, kitchen sink, laundry
tub, in a wet basement, near a swimming pool, rain, or similar environments.
• Place where it will not be inadvertently covered or moved. A permanent wall mounting
is recommended after you have found a suitable location. Alternatively, you may place
the Informer-IP on a flat, level surface.
• Place within 6 feet (1.8 meters) of an AC power receptacle to eliminate the need for an
extension cord unless a Power over Ethernet (PoE) connection is available.

13
Installation
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Wall Mounting
Before mounting the unit, determine a suitable location considering the criteria listed.
Located on the bottom of the unit, the Informer-IP has two keyholes that accept #8
screws. Place the mounting screws horizontally level, approximately 6 inches (15.2 cm)
above eye level and 4 inches (10.16 cm) apart on center. Ensure the screws are placed into
material that can adequately support the weight of the Informer-IP. Use a #8 wall anchor
when mounting to the drywall. Ensure that the screws are tightened suciently to fasten
the Informer-IP against the wall securely.
Figure 3 Rear View - Hole Measurements
4.00 inches
Drill Holes for Mounting
#8 Screws
Connect the Informer-IP to the LAN using CAT5 cable. If the wired Ethernet has PoE, no
other power connection is required.
If PoE is not available, run the supplied external AC/DC power supply against the wall and
plugged into a 120 Vac, 60 Hz outlet. Plug the low-voltage end of the cord into the power
jack located at the rear of the Informer-IP. Route the cord to ensure it is protected against
walking on, tripping over, or pinching the cord.
Desk Mounting
Before installing the Informer-IP, determine a suitable location considering the criteria
listed in this manual.
Connect the Informer-IP to the LAN using CAT5 cable. If the Wired Ethernet has PoE, no
other power connection is required.
If PoE is not available, run the supplied external AC/DC power supply against the wall and
plugged into a 120 Vac, 60 Hz outlet. Plug the low voltage end of the cord into the power
jack located at the rear of the Informer-IP. Route the cord to ensure it is protected against
walking on, tripping over, or pinching the cord.

14
Installation
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
Memory Card Removal and Installation
The microSD card stores voice and tone messages.
To remove the card:
1. Remove the top of the Informer.
2. Find the microSD card.
3. Gently push the card into the slot. The card can then be removed.
To install the card:
1. Insert and gently push the card until it latches into place.
2. Replace cover and tighten screws.
Testing and Training
After the installation is complete:
• Test the Informer-IP and all accessories from the control point(s) to ensure it is
operating properly.
• Ensure all users are properly trained to use the system before putting the Informer-IP
into service.
• Verify all tone, voice, and text messages contain the correct content per the
emergency operating plan. Alerts should exceed the ambient sound levels by at least
10 dB to ensure they can be heard.
• Conduct testing regularly per facility safety plans to ensure the equipment remains in
working order, and operators remain familiar with the use of the equipment.

15
Operations
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Operations
The following is a picture of the Informer-IP keypad.
Figure 4 Informer-IP Keypad
Controls
Table 5 Controls
Button Description
ALERT The ALERT button sends an activation to the control points and
changes the status icon to Red. You can also congure inputs as
a Call Request to alert emergency operations personnel that an
intercom chat session is being requested. You can congure each
of the six alert inputs with application-specic names.
A Call Request is a request for an Intercom Chat Session with the
Emergency Operations personnel at the control point(s). The Call
Request opens the Commander Intercom window and turns on the
red Call Request status icon next to the Unit ID and Unit Name of
the Informer-IP that issued the request.
RESET Push to reset the following:
• Alert Signals
• Alert, Test, and Talk LEDs
• Scrolling Message Display
• Relay Outputs
REPLAY The REPLAY button replays the last voice message received if the
red alert light is blinking. If the Alert light is not blinking, the event
has ended or reset, which removes the message from memory.
Volume Up Button Increases volume and beeps at the current volume level.
Volume Down Button Decreases volume and beeps at the current volume level.

16
Operations
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
Visual Indications
Table 6 Visual Indications (Located on keypad)
LED Description
POWER The green Power LED turns on when power is connected and the device is
connected to a Federal Signal enabled network server. The Power LED ashes
on for 100 ms when the unit is disconnected from the server.
ALERT The red Alert LED Flashes on and off at a 1/2 second interval when an alert
is received. The LED is reset when the RESET button is pressed, or a reset
command is sent from a control station.
TEST The yellow Test LED turns on Steady when a Quiet Test function is executed.
The LED is reset when the RESET button is pressed, or a reset command
is received from a control station. The LED ashes on and off at a 1/10
second rate indicating the unit has been reset to factory defaults and requires
conguration. The unit does not attempt to connect to a server when this LED is
ashing.
TALK The blue Talk LED ashes at a 1/10 second interval when a Live PA, Intercom
Talk session or Text-To-Speech message is in progress. The Talk LED turns on
steady when the intercom monitor function is active. During an Intercom chat
session, the local operator must listen while the blue LED is blinking and may
talk when the LED is on steady. Audible turn-around beeps also indicate the
transitions from Talk and Listen modes. The Intercom chat session ends when
the control point Ends the Call or Resets the device.
Rear Panel Input/Output
Figure 5 Rear Panel Input/Output
Ethernet Port
Power Input
Audio Output Level Adjustment (Optional)
600 ohm Audio and Relay Output
Wall Mount Keyholes (2) RS232 Port Rear Input (J1)

17
Operations
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Audio/Relay - Input/Output Connections
The Informer-IP has two SPDT relays rated at 5 A at 30 Vdc. The relays can be
programmed to cycle on and o, or come on continuously with programmable on
time, o time, and total-time. The relay outputs can be reset manually or reset after a
programmable number of seconds.
A removable eight-position connector is located on the rear of the Informer-IP for making
electrical connections. The connector accepts 3/16-inch (5 mm) stripped wire,
18-26 AWG.
The 600-ohm audio output responds as the speaker does. Audio comes on with the
speaker and is reset or shut o when the speaker audio shuts o. The output level is
adjustable from 0 to 2.5 VP-P into 600 ohms with a 1 kHz tone. The audio out is not active
during Intercom sessions.
Make electrical connections to the Input/Output connector as follows.
Table 7 JP3 Input/Output Connections
JP3 (Field Wiring)
1 – Normally closed, relay #2
2 – Common, relay #2
3 – Normally open, relay 2
4 – Normally closed, relay #1
5 – Common, relay #1
6 – Normally open, relay 1
7 – 600 ohms audio output
8 – 600 ohms audio output
Alert Rear Input
Located on the back of the Informer-IP Desk Mount housing is a two-position Rear Input
Connector. The removable connector accepts 5 mm (3/16 in) stripped wire, 18-26 AWG.
Table 8 J1 Rear Input
J1 Rear Input (Dry contact across pins activates input)
2 – Active low input (Pulled to 4.5 Vdc internally through 4.75 kilohms)
1 – Ground
RS232 Port
The RS232 Port uses a six-pin modular connector. Federal Signal can provide pre-
terminated cables when scrolling message displays are purchased.
Table 9 FS232 Connector Pin-out
Pin Description
1 Serial / Flash Select
2 TXD
3 RXD
4 GND
5 CTS / Serial Clock In
6RTS

18
Operations
Informer-IP Desk Mount (Model I-IP-IO Series C)
Federal Signal www.fedsig.com
Ethernet Port
The Informer-IP has an eight-pin Ethernet port for connecting to the Communications
network. The port accepts 42 to 57 Vdc PoE per IEEE 802.3af. (Early versions of the
Informer-IP may require PoE Adapter 2005704A for proper PoE operation.) Ethernet wire
runs must be less than 328 feet (100 meters) from the nearest network switch. The wired
Ethernet port auto-negotiates at 10/100 Mbps, full or half-duplex connection.
Power Connector
The Informer-IP can be powered via PoE from the LAN connection. The Informer-IP can
also be powered from the equipped wall type plug-in external AC/DC power supply. The
connections for power are in the table.
Table 10 J2 Input Power
J2 Power connector
Center – (9 to 15 Vdc)
Outside – GND
Disable Microphone (Internal option)
Internal on the PCB is JP3, which normally has a shorting plug to enable the built-in
microphone functionality. Model I-IP-IO Series B and Series C of the Informer series uses
the speaker as the microphone.
Table 11 JP3 (on the main PCB) Microphone Enable Jumper
JP3 Short to enable microphone functionality, remove to disable.

19
Replacement Parts
Description, Specications, Installation, and Operation Manual
Federal Signal www.fedsig.com
Replacement Parts
The Informer-IP uses one of these two types of connectors: one with slots or one without
slots. Match the eight-pin connector of your Informer to the picture below and order the
corresponding part number.
Table 12 Replacement Part Numbers
Picture Part Number
13900406A-08
140372A-08
Getting Service
If you are experiencing any diculties, contact Federal Signal Customer Support at
800-548-7229 or 708-534-3400 extension 7511 or Technical Support at 800-524-3021
or 708-534-3400 extension 7329 or through e-mail at [email protected]. For
instruction manuals and information on related products, visit http://www.fedsig.com/

2645 Federal Signal Drive
University Park, Illinois 60484
www.fedsig.com
Customer Support 800-548-7229 • [phone]
Technical Support 800-524-3021 • [phone]
