Federal SSRPF Series Installation instructions

E3555-1
5/17/19 REV C
Installation & Operation Instructions
Refrigerated SSRPF & SSRVS Models
Federal Industries
215 Federal AVE
Belleville, WI 53508
Toll Free: [phone]
WI Phone: [phone]
Fax: [phone]

Page 2 of 39
Contents
(1) Introduction ....................................................................................................................................................4
1.1 REGISTRATION & SERIAL NUMBER..................................................................................................4
(2) Warning Labels & Safety Instructions ...........................................................................................................5
(3) Pre-Installation Procedures.............................................................................................................................6
3.1 Inspection for Shipping Damage................................................................................................................6
(4) General Electrical & Grounding.....................................................................................................................6
4.1 Cord Connected..........................................................................................................................................6
4.2 Permanent Connected (Option)..................................................................................................................6
4.3 Electrical information.................................................................................................................................7
(5) Refrigeration Operation..................................................................................................................................8
5.1.1 Self-Contained Models...........................................................................................................................8
5.1.2 Remote Models.......................................................................................................................................8
5.2 Evaporator Condensate Drain Tube .........................................................................................................10
5.3 Condensate Pump.....................................................................................................................................10
(6) Installation Instructions................................................................................................................................11
6.1 Locating the Display Case........................................................................................................................11
6.2 Removing Case From Shipping Skid and General Installation................................................................11
6.3 Cleaning....................................................................................................................................................11
6.4 SSRVS33 UNDER COUNTER INSTALLATION .................................................................................12
(7) Shelving Installation & Removal .................................................................................................................13
7.1 SHELF BRACKETS AND SUPPORTS INSTALLATION....................................................................13
7.2 Solid Shelf Installation.............................................................................................................................14
7.3 Glass Shelf Installation (OPTIONAL) .....................................................................................................15
(8) SSRPF CASE REAR DOORS (OPTION)...................................................................................................16
(9) NIGHT CURTAIN OPERATION ...............................................................................................................17
(10) SECURITY NIGHT COVER (OPTION) ....................................................................................................18
(11) Operating Instructions..................................................................................................................................19
11.1 User Controls Overview...........................................................................................................................19
11.2 Power Switch............................................................................................................................................19
11.3 Light Switch .............................................................................................................................................19
11.4 Electronic Temperature Control...............................................................................................................19
11.4.1 Button and Display overview...............................................................................................................20
11.4.2 Powering on control .............................................................................................................................20
11.4.3 Adjusting the set point..........................................................................................................................20
11.4.4 Entering Manual Defrost Mode............................................................................................................21
11.4.5 Error codes............................................................................................................................................21
11.5 Electronic Control Operation....................................................................................................................22
11.6 Control Parameters...................................................................................................................................22

Page 3 of 39
11.7 Initial Startup............................................................................................................................................23
11.8 Placing Product in Case............................................................................................................................23
(12) MAINTENANCE (LIGHTS).......................................................................................................................24
(13) Periodic Maintenance (CLEAN CONDENSER) .........................................................................................25
(14) Cleaning Instructions....................................................................................................................................26
14.1 Daily Cleaning..........................................................................................................................................26
14.2 Weekly Cleaning......................................................................................................................................27
14.3 Weekly Exterior Cleaning........................................................................................................................28
(15) Sale & Disposal............................................................................................................................................29
15.1 Owner Responsibility...............................................................................................................................29
(16) Service Information......................................................................................................................................29
16.1 Special Service Instructions......................................................................................................................30
16.2 Pre-Service checklist................................................................................................................................30
Lights do not operate............................................................................................................................................30
Case temperature too warm (product is exceeding 41°F).....................................................................................30
(17) Wiring Diagrams E555-1 EXCEL.........................................................................................................31
17.1 Self Contained (mfg’d before 1/1/19) ......................................................................................................31
17.2 SELF CONTAINED (MFG’D AFTER 1/1/19).......................................................................................32
17.3 Remote (mfg’d before 1/1/19)..................................................................................................................33
17.4 REMOTE (MFG’D AFTER 1/1/19) ........................................................................................................34
(18) Replacement Parts........................................................................................................................................35

Page 4 of 39
(1) INTRODUCTION
Thank you for purchasing a Federal Industries display case. This manual contains important instructions for installing and
servicing the SSRPF and SSRVS refrigerated self-service merchandisers. A repair parts list and wiring diagram are also
included in the manual. Read all of these documents carefully before installing or servicing your case.
NOTICE
Read this manual before installing your case. Keep this manual and refer to it before
doing any service on the equipment. Failure to do so could result in personal injury or
damage to the case.
NOTICE
Installation and service of the electrical components in the case must be performed by
a licensed electrician.
The portions of this manual covering components contain technical instructions
intended only for persons qualified to perform electrical work.
DANGER
Improper or faulty hookup of electrical components in the case can result in severe
injury or death.
All electrical wiring hookups must be done in accordance with all applicable local,
regional, or national standards.
1.1 REGISTRATION & SERIAL NUMBER
It’s important to keep a record of the model and serial number of your merchandiser for warranty and part identification.
Please write them here for your quick reference.
Register your product online! Visit our website at www.federalindustries.com and register your product today.
Case Model__________________________ Serial Number ______________________
We’re here to provide you with the best possible experience with your new product, however, we cannot cover everything
about your merchandiser in this manual, so if you have any additional questions or issues, please see the SERVICE
INFORMATION PAGE to find who you should contact.

Page 5 of 39
(2) WARNING LABELS & SAFETY INSTRUCTIONS
This is the safety-alert symbol. When you see this symbol on your case or in the
manual, be alert to the potential for personal injury or damage to your equipment.
Be sure you understand all safety messages and always follow recommended precautions and safe operating procedures.
NOTICE TO EMPLOYERS:
You must make sure that everyone who installs, uses, or services your case is
thoroughly familiar with all safety information and procedures.
Important safety information is presented in this section and throughout the manual. The following signal words are used
in the warning and safety messages:
DANGER: Severe injury or death will occur if you ignore the message.
WARNING: Severe injury or death can occur if you ignore the message.
CAUTION: Minor injury or damage to your case can occur if you ignore the message.
NOTICE: This is important installation, operation, or service information. If you ignore the message, you
may damage your case.
The warning and safety labels shown throughout this manual are placed on your Federal Industries case at the factory.
Follow all warning label instructions. If any warning or safety labels become lost or damaged, call our customer service
department at [phone] for replacements.
This
label is located on the back of the display case
This label is located below the display pan.

Page 6 of 39
(3) PRE-INSTALLATION PROCEDURES
3.1 INSPECTION FOR SHIPPING DAMAGE
You are responsible for filing all freight claims with the delivering truck line. Inspect all cartons and crates for damage as
soon as they arrive. If damage is noted to shipping crates, cartons, or if a shortage is found, note this on the bill of lading
(all copies) prior to signing.
If damage is discovered when the case is uncrated, immediately call the delivering truck line and follow up the call with a
written report indicating concealed damage to your shipment. Ask for an immediate inspection of your concealed damage
item. Crating material must be retained to show the inspector from the truck line.
(4) GENERAL ELECTRICAL & GROUNDING
DANGER:
Improper or faulty hookup of electrical components in the display case can result in
severe injury or death.
4.1 CORD CONNECTED
All standard models are supplied with a power cord that is properly sized to the amperage requirements of the
case. See the electrical data plate located on the rear left interior of the case for the proper circuit size for each
case.
The cord is factory installed protruding from the bottom rear corner of the case.
A separate circuit for each display case is required to prevent other appliances on the same circuit from
overloading the circuit and causing malfunction.
4.2 PERMANENT CONNECTED (OPTION)
Only a licensed electrician must perform all case electrical connections.
All electrical wiring hookups must be done in accordance with all applicable local, regional, or national electrical
standards.
A separate circuit for each display case is required to prevent other appliances on the same circuit from
overloading the circuit and causing malfunction.
The electrical service must be grounded upon installation.
See the electrical data plate located at the rear of the case for proper circuit size and wire ampacity.
The electrical connection box is accessible from the rear of the case with rear grill removed.
FIELD CONNECTION BOX
FLOOR CONDUIT
CONNECTION 0.875 DIAMETER
CONDUIT OR POWER CORD
CONNECTION 0.875 DIAMETER
REAR BASE PANEL
SIX REAR PANEL SCREWS

Page 7 of 39
4.3 ELECTRICAL INFORMATION
E3555-1 EXCEL
PERMANENTLY CONNECTED
MODEL VOLTAGE TOTAL AMPS MAX FUSE SIZE VOLTAGE
MAX FUSE SIZE
SSRPF3652/
SSRVS3642/
SSRVS3633/
SSRVS5033
120/60/1 14.3 20 120/60/1 15
SSRPF5052/
SSRVS5042/ 230/60/1 9.5 20 120/60/1 15
SSRPF5952/
SSRVS5942/
SSRVS5933 230/60/1 14.5 20 120/60/1 15
SSRPF7752/
SSRVS7742/
SSRVS7733 230/60/1 14.5 20 120/60/1 15
CORD CONNECTED OPTIONAL
MODEL VOLTAGE TOTAL AMPS CORD STYLE
SSRPF3652/
SSRVS3642/
SSRVS3633/
SSRVS5033
120/60/1 14.3 20AMP NEMA 5-20
SSRPF5052/
SSRVS5042/ 230/60/1 9.5 15AMP NEMA 6-15
SSRPF5952/
SSRVS5942/
SSRVS5933 230/60/1 14.5 20AMP NEMA 6-20
SSRPF7752/
SSRVS7742/
SSRVS7733 230/60/1 14.5 20AMP NEMA 6-20
SELF CONTAINED
SELF CONTAINED REMOTE

Page 8 of 39
(5) REFRIGERATION OPERATION
5.1.1 Self-Contained Models
E3555-1 EXCEL
The self-contained models are shipped from the factory with a completely operational 404A refrigeration system
and require no modifications or adjustments upon installation. Case must be installed as per the installation
section of this manual to provide proper condenser air cooling.
The unit temperature is controlled by the electronic control outlined in the control section of this manual.
Note: The condenser fan runs continuously.
5.1.2 Remote Models
E3555-1 EXCEL
SELF CONTAINED
RefrigerationR404 Charge 30 OZ 32 OZ 34 OZ 34 OZ
Low Pressure SwitchCut In 80 psi 80 psi 80 psi 80 psi
Low Pressure SwitchCut Out 20 psi 20 psi 20 psi 20 psi
HighPressure SwitchCut Out
SSRPF7752/
SSRVS7742/
SSRVS7733
WITH ELECTRONIC CONTROL
SSRPF3652/
SSRVS3642/
SSRVS3633/
SSRVS5033
SSRPF5052/
SSRVS5042
SSRPF5952/
SSRVS5942/
SSRVS5933
450 psi
REMOTE
RefrigerationR449 Charge
Remote Low Press. SwitchCut In
Remote Low Press. SwitchCut Out
Remote High Press. SwitchCut Out
BTU Requirement @90F/20F 4400 5400 6400 7400
RefrigerationR449 Charge
Remote Low Press. SwitchCut In
Remote Low Press. SwitchCut Out
Remote High Press. SwitchCut Out
BTU Requirement @90F/20F 3600 4400 5400 6400
50
15
450 psi
SSRVS3633 SSRVS5033 SSRVS5933 SSRVS7733
CHARGED IN FIELD
450 psi
CHARGED IN FIELD
50
15
SSRPF7752/
SSRVS7742
SSRPF3652/
SSRVS3642 SSRPF5052/ SSRVS5042 SSRPF5952/ SSRVS5942

Page 9 of 39
The remote models are designed to use R449 refrigerant and shipped from the factory with the evaporator coil, expansion
valve, sight glass, and refrigerant solenoid valve. Filter Drier must be installed in field. Electronic control runs identical to
the self-contained models except the electronic control opens and closes a refrigeration solenoid valve located on the
suction line instead of turning on and off a compressor. The solenoid valve closes and shuts off the refrigeration flow to
the unit and initiates a pump down cycle. This will allow the remote low-pressure switch to open and shut off remote
compressor.
The condensing unit and pressure controls are optionally supplied from the factory for remote location installation. The
condensing unit must be mounted and wired by the installer. The high low-pressure switch must be wired in series with
the compressor power supply as shown in diagram below
1. Mount condensing unit indoors as close to the remote display case as practical. The refrigeration line should be
as short as possible and must not exceed 30 feet.
2. All refrigeration and/or electrical materials between the condensing unit and display case are to be supplied by
installing contractor.
3. Route properly sized and designed refrigeration lines from the condensing unit to the cabinet.
4. Horizontal suction lines should be pitched downward towards the condensing unit at least ½” per 10’ run to aid
the oil drainage. A “P” trap must be installed in the suction line at the foot of every riser to insure oil return. Dry
nitrogen must be used to flow through tubing while brazing refrigeration lines.
5. Suction line must be insulated the entire length with Armaflex (or equivalent). Do not run liquid line inside
insulation with suction line.
6. The remote high/low-pressure control must be mounted, wired and set pressures by the installer.
7. Leak check condensing unit, cabinet, and all connecting tubing. Cabinet and condensing unit tubing should be
checked to insure no leaks occurred during shipping or from rough handling.
8. Make certain all refrigeration valves are opened and evacuate system to 500 microns. Charge the system with
refrigerant type specified on the data plates.
REMOTE
HIGH LOW
PRESSURE
CONTROL
LIQUID LINE
SUCTION LINE (INSULATED)
REMOTE
CONDENSING
UNIT
EVAPORATOR
COILS
DISPLAY CASE
EXPANSION
VALVE
HIGH
LOW
LIQUID LINE
SOLENOID VALVE
SIGHT GLASS
DRIER FILTER
FIELD CONNECTION
HOT
FUSED
POWER
SUPPLY
DEFROST
TERMINATE
PROBE
ELECTRONIC
CONTROL
AIR TEMP. CONTROL PROBE
FUSED
CASE
POWER
Figure 1 - Remote Refrigeration Diagram

Page 10 of 39
5.2 EVAPORATOR CONDENSATE DRAIN TUBE
WARNING TO INSTALLER:
Evaporator Condensate Drain Tube may become dislodged during shipping. Installer must check
Evaporator Condensate Drain Tube upon installation to be sure drain tube is properly seated and
installed correctly.
Evaporator Drain Tube must be attached to tube protruding from bottom of Evaporator Tub and must either be inside the
Condensate Pan area or inside of hole of Condensate Pump.
5.3 CONDENSATE PUMP
A condensate pump is Standard on some models and Optional on all models. Installer must check unit to see if a
condensate pump has been provided with case.
WARNING TO INSTALLER:
Installer must determine if case was provided with condensate pump. Failure to hook up pump
hose to drain will cause water on floor and cause a slip hazard.
Instead of using heat energy to remove condensate run off from the evaporator coil a condensate pump moves the water to
a nearby drain.
•The Condensate Pump is provided with 50ft of clear 1/2in OD x 3/8in ID tubing that must be run out of the base
area to a drain.
•There are several drain tube exit locations provided in the base as noted in the drawing above. Plugs or caps will
need to be removed in the desired exit location.
•The hose can be run the entire 50ft in any direction as required, but no higher than 20ft from the pump base. A
check valve is provided in the pump to prevent water from flowing back into the reservoir. For best efficiency
extend the hose level below the level of the pump base to create a siphoning effect. Never run the hose to or
through an area below freezing (32°F, 0°C) or freezing water will block the tube.

Page 11 of 39
(6) INSTALLATION INSTRUCTIONS
6.1 LOCATING THE DISPLAY CASE
The case should be located where it is not subjected to the direct rays of the sun, heating ducts, grills, radiator, or ceiling
fans, nor should it be located near open doors or main door entrances. Also, avoid locations where there are excessive air
movement or air disturbances.
The case requires a minimum of 4 inches of clearance at the rear of the unit for air discharge. Do not locate case with back
tight against the wall.
No clearance is needed on sides of the unit.
6.2 REMOVING CASE FROM SHIPPING SKID AND GENERAL INSTALLATION
CAUTION:
Do not push or pull against the top end glass, or door frames and do not pull on end panels when
removing the case from the skid or moving the case. Case damage or glass breakage will result.
1. Remove crate top and sides and note missing or damaged items as explained in the pre-installation procedures
outlined above.
2. Move the case as near as possible to the final location and before removing it from the shipping skid.
3. Remove the (4) brackets that secure the case to the shipping skid.
4. Prepare cabinet according to instructions in this section that pertain to your model.
5. Lift the case off of skid and into required position. Only lift the case from under the rear lip and front bottom trim
channel above the base. Note: Do not push or pull on front bottom trim channel.
6. The case must be level for proper drainage of defrost condensate to the condensate evaporator. Using the wrench
provided level and square the case as needed by adjusting the leg leveler in each corner of base. The 6ft cases also
have a set of leg levelers in the center. These must be adjusted so the base is flat.
7. The leveled case must be sealed to the floor using a NSF listed sealant.
6.3 CLEANING
For initial setup, clean the case as outlined in the “Weekly Cleaning” section of this manual.

Page 12 of 39
6.4 SSRVS33 UNDER COUNTER INSTALLATION

Page 13 of 39
(7) SHELVING INSTALLATION & REMOVAL
7.1 SHELF BRACKETS AND SUPPORTS INSTALLATION
SHELF STANDARD
REAR SHELF SUPPORT
SHELF BRACKET
SHELF LIGHT CORD
RETAINER CLIP
SHELF STANDARD
RETAINING SCREW
REAR SHELF SUPPORT
LIGHT ASSEMBLY
LIGHT ASSEMBLY
SHELF LIGHT CORD
RETAINER CLIP
1. Turn the light switch to the off position.
2. Follow the instructions in the illustration below and insert (1) of the shelf brackets in the desired shelf standard slot
on one side of the case. Place the additional bracket in the same shelf standard slot on the opposite end of case. The
bracket with a clear plastic cord retainer clip must be on the side with the shelf light.
0 v NOTCH
6 v NOTCH
4
1
2
3
4
INSTALLATION REMOVAL
23
1
TOP HOOK
BOTTOM TAB
SHELF BRACKET
SHELF STANDARD
1. Place shelf bracket top hook into desired shelf
standard slot.
2. Lift shelf bracket top hook to allow shelf bracket
bottom tab to clear shelf standard slot.
3. Swing shelf bracketbottom tab into shelf standard
slot.
4. Place the desired shelf bracket notch of 0, 6, or 12
degrees onto bottom of shelf standard slot.
1. Lift shelf bracket up to allow shelf bracket notch
to clear the bottom of shelf standard slot.
2. Swing shelf bracket bottom tab out of shelf
standard slot.
3. Drop shelf bracket down to allow shelf bracket top
hook to clear top of shelf standard slot.
4. remove shelf bracket top from shelf standard slot.
CLEAR BUMPER
TOWARDS END PANEL
3. Hang one end of the shelf light housing on the front notch of a shelf bracket and then the other end of the shelf light
housing on the notch of the shelf bracket on the opposite end. Note: On models without shelf lights, use a shelf
support instead of a shelf light housing.
4. Push shelf light cords into plastic shelf cord retainer clip located on the inside of the shelf bracket.
5. Remove the cap from the appropriate female light sockets. Important: Grip each side of cap firmly and wiggle and
pull cap straight out of socket. Do not roll cap during removal. Incorrect removal of cap may cause damage to
electrical connection

Page 14 of 39
RIGHT WRONG
6. If the socket is not being used for a shelf light, the cap must be plugged into socket for entire light system to operate.
On Models with the 5 pin shelf plug, this is necessary for the entire light system to operate. On models with the 3 pin
shelf plug, this is necessary to prevent buildup and damage to the receptacle.
7. Plug in shelf light by aligning the male pins on the appropriate shelf light cord plugs with the female light sockets and
push together. IMPORTANT: Do not roll plug during insertion.
8. Hang one end of the shelf support on to the rear notch of one shelf bracket and then on the rear notch of the shelf
bracket on the opposite side.
9. Place supplied shelving onto shelf supports as outlined in the appropriate “Shelf Installation” section of this manual.
10. Removal of shelving is performed by following steps in reverse order.
11. The shelf standards are removable from case by removing the (2) shelf standard retaining screws holding them to the
inside wall of case.
7.2 SOLID SHELF INSTALLATION
SHELF STANDARD
REAR SHELF SUPPORT
SHELF BRACKET
SHELF LIGHT CORD
RETAINER CLIP
SHELF STANDARD
RETAINING SCREW
REAR SHELF SUPPORT
SHELF LIGHT ASSEMBLY
SHELF LIGHT ASSEMBLY
TAB
SLOT
1. Install shelf brackets & shelf supports as described in Shelf Bracket & Supports Installation Section of this manual.
2. Place the front of metal shelf onto front shelf light. (On front shelf support for models without shelf lights). The tab on
end of shelf bracket must go through slot in front of shelf.
3. Place the back of shelf over the back of the rear shelf support.

Page 15 of 39
7.3 GLASS SHELF INSTALLATION (OPTIONAL)
GLASS SHELF
SHELF STANDARD
REAR SHELF
SUPPORT
SHELF LIGHT ASSEMBLY
SHELF BRACKET
GLASS SHELF RETAINER CLIP
BACK OF CLIP ONE INCH FROM BACK OF GLASS SHELF
CORD RETAINER CLIP
PRODUCT STOP
PLACE GLASS SHELF RETAINER
CLIP OVER REAR SHELF SUPPORT
SHELF STANDARD
RETAINING SCREW
OPTIONAL BOTTOM
SECTION GLASS SHELF
CLIP LOCATED ONE INCH FROM BACK
EDGE IN FAR CORNER OF GLASS SHELF.
CLIPS FIELD INSTALLED TO GLASS.
TOP VIEW
PRODUCT STOP
1. For first time installation attach (2) glass shelf retainer clips to each glass shelf in location shown in illustration one
inch from back of glass as shown. Clean area of glass where glass shelf holder is to be located with rubbing alcohol
and let air dry before installing shelf glass holder. Remove backing from tape located on flat side of glass shelf holder.
Position the glass shelf holders in the (2) far corners of glass. Repeat for each glass shelf.
2. For first time installation attach (1) product stop to each glass shelf as shown in detail above. Align the product stop
edge with the edge of the glass and push the “U” portion of the product stop on to glass lip across the entire front of
glass.
3. Attach a clear bumper on both sides of the light housing top surface for the front of the glass to set on. This step may
have already been performed at the factory for you.
4. Place front of glass shelf onto clear bumpers on front shelf light. (On front shelf support for models without shelf
lights).

Page 16 of 39
(8) SSRPF CASE REAR DOORS (OPTION)
INNER DOOR LOWER TRACK
INNER DOOR UPPER TRACK
INNER DOOR CATCH SLOT
2. SWING BOTTOM OUT
OUTSIDE DOOR SET
1. LIFT UP DOOR
TO REMOVE DOOR
INNER DOOR CATCH
OUTER DOOR UPPER TRACK
OUTER DOOR LOWER TRACK
1. Start with the outer “outside door” and lift the door upward until the bottom edge of door clears the lower track and
then swing the bottom of the door outward and down and out of upper track.
2. Remove the outer “inside door” using the same procedure.
3. The inner door set can then be removed using the same procedure starting with the inner “outside door” followed by
the inner “inside door”.
4. Reverse this procedure for door reinstallation starting with the inner “inside door” followed by the inner “outside
door”. Check that all the doors slide freely.
5. Replace the outside “inner door” and the outside “outer door”. Be sure to slide the inner door catch into the inner door
catch slot for each left and right side door.
Note: All four rear doors are “not” interchangeable. Each rear door must be replaced in
each doors original location.

Page 17 of 39
(9) NIGHT CURTAIN OPERATION
SSRPF
SSRPF
NIGHT CURTAIN LOCATION
IN STORED POSITION
NIGHT CURTAIN SNAP
TO FRONT PANEL
NIGHT CURTAIN COVERING
FRONT SERVICE AREA
The night curtain rolls up and is stored on the back top edge of the case as shown in first view.
The curtain can be used to cover the front open display area as shown in the second view above.
OPENING SSRPF NIGHT CURTAIN:
Standing in back of the case, grab the night curtain strap and pull the rolled night curtain up and over the top and front of
the case. Attach the snap located under the night curtain strap on to the snap located on the case front lower panel
CLOSING SSRPF NIGHT CURTAIN:
From front of case grab the night curtain strap and detach the snap located in the case front lower panel. Allow the night
curtain to roll up over the top and back of the case. Note: The 59”’ and 77” models have (2) night curtains.
SSRVS
SSRVS
NIGHT CURTAIN LOCATION
IN STORED POSITION
NIGHT CURTAIN SNAP
TO FRONT PANEL
NIGHT CURTAIN COVERING
FRONT SERVICE AREA
OPENING SSRVS NIGHT CURTAIN:
Standing in back of the case, grab the night curtain strap and pull the rolled night curtain up and over the top and front of
the case. Attach the snap located under the night curtain strap on to the snap located on the case front lower panel
CLOSING SSRVS NIGHT CURTAIN:
From front of case grab the night curtain strap and detach the snap located in the case front lower panel. Allow the night
curtain to roll up over the top and back of the case.
Note: The 59”’ and 77” models have (2) night curtains.

Page 18 of 39
(10) SECURITY NIGHT COVER (OPTION)
LOCK HANDLE
(SHOWN IN LOCK POSITION)
LOCK HANDLE
(SHOWN IN LOCK POSITION)
SECURITY NIGHT COVER
GRAB HANDLE
GRAB HANDLE
LOCK HANDLE CATCH
LOCK HANDLE CATCH
FRONT CLEAR DEFLECTOR
"U" RETAINER CLIP
"U" RETAINER CLIP
"U" RETAINER CLIP ON CENTER
(ON SOME MODELS)
REMOVAL:
9. Unlock the lock handles and turn handles vertical to disengage from lock handle catches.
10. Grab the front grab handles and lift the cover straight up out of the case opening.
INSTALATION:
1. Turn the lock handle so the latch handle is vertical to the top of the case.
2. Holding the grab handles place the bottom flange of the security night cover inside the “U” retainer clips located
on each side of case opening behind the front clear deflector. There also may be a “U” retainer clip in the center
of the case that must also engage the security night cover flange.
3. Set the top flange of the security cover down against the top glass handle.
4. Turn the lock handles so they engage the lock handle catches and use the key to lock them in place.
IMPORTANT: Cleaning the Acrylic plastic security night cover require special care to prevent hazing of material.
Lightly dust (not wipe) the surface with clean soft cloth. Then the surface can be wiped carefully with a soft, wet cloth or
chamois. The cloth or chamois must be kept free of grit by frequently rinsing in clean water. Grease and oil can be
removed with kerosene. Do not use window cleaners or kitchen scouring compounds. DO NOT use solvents such as
Acetone, Benzene, Carbon Tetrachloride, and Lacquer Thinners. A spray wax such as Pledge or Maguire’s polish can be
applied and wiped with a clean soft cloth. The wax tends to fill in and hide small scratches.

Page 19 of 39
(11) OPERATING INSTRUCTIONS
11.1 USER CONTROLS OVERVIEW
TEMPERATURE CONTROL
POWER SWITCH
LIGHT SWITCH
SSRPF CASE CONTROLS
LIGHT SWITCH
POWER SWITCH
EXTERNAL POWER OUTLET
TEMPERATURE CONTROL
SSRVS CASE CONTROLS
11.2 POWER SWITCH
The unit has a power switch that turns off power to the entire unit, including the condensate evaporator and the lights.
11.3 LIGHT SWITCH
The unit has a light switch that turns on and off the interior lights of unit.
11.4 ELECTRONIC TEMPERATURE CONTROL
Located in the rear grille of the display case, the temperature control allows the user to adjust the temperature of the
display merchandiser to their needs.

Page 20 of 39
11.4.1 Button and Display overview
DIGITAL DISPLAY
SET POINT ADJUST MODE
POWER TO CONTROL ON OFF
AND SET POINT UP ADJUST
MANUAL DEFROST AND
SET POINT DOWN ADJUST
COMPRESSOR RUN
INDICATOR
DEFROST MODE INDICATOR
ALARM INDICATOR
Button Overview
Press and hold this button for three seconds to turn system on (if off) or off (if on).
Also used to adjust set point when in set point adjust mode
Press to enter set point adjust mode, confirm set point changes, and mute alarms.
Press and hold this button for three seconds to initiate a manual defrost (and cancel defrost
if initiated), also adjusts set point down when in set point adjust mode
11.4.2 Powering on control
To turn refrigeration control power on, press and hold for approx. three seconds. The display will read
“On” while the button is depressed. When the control powers on, the display will read the current set point (a
number “1” thru “9” ). The compressor run indicator will illuminate on the display, meaning that the
compressor is running. (Note: the control may already be in the on mode when shipped from factory).
To turn refrigeration control power to off, press and hold for approx. three seconds. The display will read
“Off” while the button is depressed. When the control powers off the display will flash back and forth between
the relative current case temperature and “Off”. The compressor run indicator will be off on the display.
When refrigeration control is in the off-mode cabinet lights and evaporator fans will still operate, but the
compressor will not turn on causing the case to gradually reach room temperature.
11.4.3 Adjusting the set point
The set point is what determines how cold the display case will hold food and beverage. To adjust the set point press and
hold the button approx. three seconds until the display begins to flash a number. Then press the use the button
to scroll number up (colder) or press the button to scroll number lower (warmer). There are nine (9) available set
points numbers, the higher the number of the set point, the colder the display case will run, with setting “9” being the
coldest and setting “1” being the warmest. Once you have chosen your desired setting press the button again to
confirm your choice.
