Feider Machines FTDTR5220 User manual

1
ROLLER LAWN MOWER
FTDTR5220
ORIGINAL INSTRUCTIONS
WARNING: READ THESE INSTRUCTIONS BEFORE USE THIS MACHINE
BUILDER SAS
Zi du Casque, 32 rue Aristide Bergès, 31270 Cugnaux - France
Made in PRC

2
TABLE OF CONTENTS
1. Safety Messages…………………………………………………………………..3
2. Assembly……………………………………....………………….……………..…9
3. Before Operation……………………………....………………………………….12
4. Operation……………………………………..……………………………………14
5. Maintenance………………..……………..………………………………………17
6. Storage………………………………………….…………………………………23
7. DECLARATION OF CONFORMITY…….………………………………………24
8. WARRANTY …………………………………….…………………………………25
9. PRODUCT FAILURE ………………………….………………………………… 26
10. WARRANTY EXCLUSIONS ……………….…………………………………27

3
1. Safety messages
Your safety and the safety of others are very important. We have provided important
safety messages in this manual and on the mower. This information alerts you to potential
hazards that could hurt you or others. Please read these messages carefully.
Of course, it is not practical or possible to warn you about all the hazards associated
with operating or maintaining a lawn mower. You must use your own good judgment.
You will find important safety information in a variety of forms:
Safety Labels –on the lawn mower.
Instructions –how to use this mower correctly and safely.
Important: Read the instruction manual before using the machine.
Danger of thrown objects.
Keep other people at a safe distance while working
Warning: Remove the spark plug cable from the spark plug and read
instructions before carrying out any repair or maintenance.
Danger of cutting yourself.
Blades in movement. Do not put hands or feet near or under the opening
of the cutting plate.
Safety Messages – preceded by a safety alert symbol and one of three signal
words: DANGER, WARNING, or CAUTION.
You will be killed or seriously hurt if you don't follow instructions
You will be killed or seriously hurt if you don't follow instructions.
You can be hurt if you don't follow instructions.
Each message tells you what the hazard is, what can happen, and
what you can do to avoid or reduce injury.
Instructions
Read the instructions carefully. Be familiar with the controls and proper use of the
equipment.
Never allow children to use this mower. If the mower is given to an other people, also give
this manual. Also make sure that this person uses this device only after receiving the
necessary instructions. Local laws may restrict the age of the user.
Never mow while people, especially children, or animals are nearby.
Keep in mind that the operator or user is responsible for accidents or risks that may occur
to other persons or their properties.
If necessary, have training with an experienced person in order to use in a safe way this
tool.

4
Preparation
During mowing, always wear slip-resistant foot protection and long pants. Do not use the
equipment barefoot or wearing sandals open.
Wear personal protective equipment including at least: clothes of protection, gloves, foot
protection, mask, ocular and hearing protection
Carefully inspect the area where equipment and remove all foreign objects such as stones,
toys, stick and wires.
WARNING - Gasoline is extremely flammable.
oAdd fuel before starting. Do not remove the fuel tank cap while the machine is running
or when it is hot.
oIf the fuel has spilled or leaked, do not attempt to start the machine but move the
machine away from the leakage area and avoid creating a source of ignition until the
gasoline vapours has dissipated.
oRefuel only outside and do not smoke during refuelling.
oStore fuel in tanks specifically designated for this purpose.
oReplace the fuel tank or the defective gasoline plug securely.
Replace defective mufflers.
Before use, always inspect visually that the blades, blade assembly and blade lock are not
worn or damaged. Replace blades and blade assemblies that are not in good condition to
maintain balance. Always use recommended blades. Contact the manufacturer or your
dealer in order to have a list of recommended blades. Non-recommended blades can give
a risk of malfunctions, injuries and accidents.
The blades must be balanced to ensure proper operation and to be able to work safely.
Operation
Do not use the machine in a confined space or hazardous carbon monoxide emissions
can be collected.
Mow only under daylight or under good artificial light. Always have a good visibility.
Avoid using the equipment on greasy grass, where possible.
Always be sure of your walking on the slopes.
Walk, never run.
For lawn mowers, mow across slopes, never from top to bottom.
Exercise extreme caution when changing direction on slopes.
Stop the blades if the mower is to be tilted during transport when crossing surfaces other
than grass, and when transporting the mower due to the area to be mowed.
Do not mow on steep slopes.
Use extreme caution when tipping or pulling the mower towards you.
Never use the mower with defective guards, or without safety devices such as baffles and
or collection bins, which are not in place.
Do not change the motor configuration or increase the speed.
For starting, disengage all blades, the gears must be in neutral, the traction control lever
must be released. Set foot well away from the blades.
Before starting the engine or starting the engine, carefully read and understand all
instructions.

5
Do not tilt the mower when starting the machine or turn on the engine, unless the mower
needs to be tilted for starting. In this case, do not tilt it more than absolutely necessary and
lift only the part that is furthest away from the user.
Do not start the machine by standing in front of the ejection
Do not place hands or feet near or under rotating parts. Keep clean the mouth of the grass
extractor.
Never take or carry the mower while the machine is running.
Stop the machine and remove the ignition key, disconnect the spark plug from the spark
plug:
oBefore cleaning or unclogging the grass extractor.
oBefore checking, cleaning, and working on the mower.
oAfter hitting an object. Inspect the mower for damage and repair before re-using the
mower.
oIf the mower begins to vibrate abnormally, stop the engine immediately and check
according to previous recommendations.
The controls must be always checked if they are functioning correctly. In case of
malfunction, do not use the tool and bring to a service agent for inspection.
Stop the engine immediately:
oEvery time you leave the tool alone and the working area
oBefore refuelling.
When the tool is stopped, park it in a safe place.
Move slowly when moving.
The lawnmower should not be used in slopes and near drop-offs, ditches or embankments;
if the tool must be used in these kinds of emplacements, take an extreme precaution and
operate carefully the tool.
The lawnmower safety systems or features shall not be tampered with or disabled;
The operator should not alter or tamper with any sealed adjustments for the engine speed
control.
Maintenance and storage
Check and tighten all bolts and screws to ensure that the equipment is in safe operating
condition.
Never keep the mower with gasoline in the tank in a building or vapours can cause a bright
flame or spark.
Allow the machine to cool before storing it in an enclosed area.
To reduce the risk of fire, keep the machine clean without grass, without grease, the
muffler and the engine cools, disconnect the battery if necessary and empty the fuel tank
Check the grass catcher frequently, its condition or deterioration.
Replace worn and damaged parts for safety.
If the fuel tank is to be drained, it must be made outdoors.
Special safety instructions
Always use the mower with its pick-up bag and / or deflector in the intended position.
Switch off the engine before emptying the pick-up bag or before changing the cutting

6
height.
While the engine is running, never put your hands or feet under the mower or under the
grass ejection area.
Before mowing, remove all foreign objects from the grass that can be propelled by the
machine.
Keep children and pets at a safe distance while using the mower.
Never lift the mower when the engine starts.
Alcohol, drug, as well as illness, fever and fatigue affect your ability to respond. Do not use
power tools in such circumstances.
Never change the rated speed of the motor.
Never lift or carry the tool while the engine is running.
Before starting the engine, release the drawbar.
Before mowing, install the collection bag in its intended position.
Do not use the mower in the event of rain or when the grass is wet.
Never lift the rear of the mower when starting the engine and never place your hands or
feet under the mower deck or in the rear ejection port while the engine is running.
Turn off the engine and remove the spark plug cap in the following cases:
oBefore operating under the mower deck or near the ejection opening.
oBefore any maintenance, repair or verification.
oBefore transporting, lifting or storing the mower.
oIf you leave the mower unattended or change the cutting height.
oTo remove and empty the collection bag.
After striking a foreign object, turn off the engine and carefully inspect the mower for
damage. Take the lawnmower to an authorized service center for repair if necessary.
If the mower vibrates abnormally, try to understand the reason and bring your lawnmower
to an authorized repair center.
Regularly check that the bolts, nuts and screws are properly tightened for safe use of the
mower.
Do not use the tool where there is a risk of lighting.
Use the tool on daylight or under a good lighting. Always keep bystanders away.
Warning: Take an extreme precaution when operating the lawnmower in slopes and near
drop-offs, ditches or embankments; always be sure of your footing and stay in alert.
the lawnmower safety systems or features shall not be tampered with or disabled;
the operator should not alter or tamper with any sealed adjustments for the engine speed
control;
The operator must have, before using the tool for the first time, an adequate training with
an experienced people.
Warning: do not use of the unit while being tired, ill or under influence of alcohol or other
drugs;
Park safely the tool before leave it. The tool must be switched off.
The lawnmower shall not be operated without either the entire grass catcher or self-closing
discharge opening guard in place;
Warning: be careful about exhaust gas. Do not inhale them.
Wear adequate clothing such as long trousers and a protective equipment: slip-resistant

7
foot protection, hearing protection, eyes protection and gloves.
To avoid health issues, limit the time of operation. Take enough rest. Exposure to noise
and vibrate can have bas consequences on health.
WARNING: There is a danger about moving blade assemblies. Always handle blades
when they are in a complete stop and wear protective gloves.
WARNING: There is a danger about moving blade assemblies. Always handle blades
when they are in a complete stop and wear protective gloves.
Fuel Handling
Use caution when handling fuels. They are flammable and the vapours are explosive.
Use only an approved container.
Never remove the fuel cap or add fuel while the machine is on. Turn off the unit and allow the
engine and exhaust components to cool down before refuelling.
Do not smoke.
Never refuel inside a room.
Never store the tool and the fuel tank indoors where there is a naked flame, such as near a
water heater.
If fuel has spilled, do not attempt to start the machine, but move it away from the spill before
starting to use it. Please clean up any spills.
Replace and tighten the fuel tank cap after refuelling.
Follow strictly the instructions in this manual for filling the tool with fuel.
During maintenance and storage
Switch off the tool and wait until it stops completely. Make sure that all moving parts are
stopped.
Allow the machine to cool before performing inspection, adjustments, maintenance, servicing
and storage.
Store the tool where fuel vapour will not reach a flame or spark.
The transport of the tool must be secured in order to avoid fuel spillage, accidents and injuries.
Residual risks
Even if you use this product in compliance with all safety requirements, the potential risks of
injury and damage remain. The following hazards may arise in the structure and design of this
product:
There are risks of injury and property damage due to attachments or broken the sudden
impact of hidden objects when using cutting.
There are risks of injuries and accidents caused by flying objects.
Prolonged use of this product exposes the operator to vibrations and can produce so-called
"white finger" disease. To reduce the risk, wear gloves and keep your hands warm.
If any of the symptoms of "white finger syndrome" occur, seek immediate medical attention.
Symptoms of "white finger" include numbness, loss of sensitivity, tingling, pain, loss of strength,
colour changes or skin condition. These symptoms usually appear on the fingers, hands or
wrists. Risk increases at low temperatures.

8
A long exposition to noise can affect the health of the operator. A hearing protection must be
always used when operating the tool. The operation of the tool must be limited and some rest
must be taken between two sessions (e.g. 10min of operation and 20min of rest).
Intended use
This device is only for lawn mowing grass in the domestic area. The device is designed for
domestic use. It is not intended for continuous professional use. Any other use that is not
expressly permitted in this manual may result in damage to the device and constitute a serious
danger to the user.
This device is designed for use by adults. Children and those unfamiliar with this manual
should not use this device. The user is responsible for accidents or damage caused to people
or their property. The manufacturer is not liable for damage caused by improper use or
improper handling.
GASOLINE IS HIGHLY INFLAMMABLE
-Keep gasoline in a jerry can specially made for this purpose.
-Fill up the tank with a funnel, do the operation outside. Do not smoke. Do not use
mobile phone.
-Fill up with gasoline and oil before staring the engine. Never open the cap of the
fuel tank to add gasoline while the engine is running or still hot.
-Do not start the engine if there is some gasoline spread around, take the mower
away from the one where gasoline have been split and avoid any contact from a
hot source as long as the split gasoline is completely eva0porated.
-Tighten the fuel tank cap and close tightly the jerry can cap.
Technical data
Nominal power 4,2 kW
Maximum operating engine speed (rotational frequency) 2800 min−1
Machine mass 40,2 kg
Cutting width 52,5 cm
Sound Power Level:95dB (A) K= 1,86 dB (A)
Sound Pressure Level:83.2dB (A) K= 3 dB (A)
Vibration Value:3.12m/s² K= 1,5 m/s²
Guarantee sound power level 98 dB (A)

9
2. Assembly
Unpacking
Remove lawn mower from carton and check thoroughly for additional loose parts.
Handle Setup And Height Adjustment
Open out the handle and screw the handles parts with the two Nuts and Bolts by tool,
And screw the handles parts with the four knobs and Bolts by hand.
Put the recoil starter on the right of the handle and fix the cable with the plastic collar.
Introduce the rope of the recoil starter handle on its support guide rope.
If you want to adjust height of the handle bar, you can choose” L” or “H” two holes in
left-right Bracket to fix the handle bar with screws and knobs.
The “H” hole is high position of the handle bar, and the “L” hole is low position of the
handle bar.
Knob
Bolt
Nut
Bolt

10
Brake Cable Setup
Put the brake cable and Clutch cable to the hole of brake lever and Clutch lever. (see the
arrow mark)
Brake Cable
Clutch Cable

11
Panel Setup
Take out panel and two screws in a bag from carton, and fix the panel with screws.
Grass Bag Assembly
Slide the grass bag frame into the grass bag and attach the clips as shown.
Lift the rear discharge guard, remove the mulching plug, and install the grass bag.
SCREW
CONTROL PANEL

12
Rear Discharge Guard Props
Take out two supports in a bag from carton, and lift the rear discharge guard, install the
two supports which can hold the rear discharge guard, and this can make the grass out
more efficiently from the deck.
3. Before Operation
Engine Oil
The mower is shipped without oil in the engine.
All engines are run at the factory prior to packaging. Most of the oil is removed prior to
shipment; however, some oil remains in the engine. The amount of oil left in the engine
varies.
Add enough oil to bring the oil level between the upper and lower limit marks on the
dipstick as shown. Do not overfill engine with oil.
SUPPORT

13
FUEL
NOTICE: Engine delivered without gasoline, refuel
1.0 liter of before starting the engine.
Remove the filler cap
Add fuel to the bottom of the fuel level limit in the
neck of the fuel tank. Do not overfill. Wipe up spilled
fuel before starting the engine.
Tighten the fuel tank cap
Gasoline is extremely flammable, and gasoline vapor can
explode, causing serious injury or death. Use extreme
care when handling gasoline. Keep out of reach of children.
Refuel in a well-ventilated area with the engine stopped. Do not smoke or allow flames
or sparks in the area where the engine is refueled or where gasoline is stored. Avoid
repeated or prolonged contact with skin or breathing of vapor.
After refueling, tighten the fuel tank cap securely. If any fuel was spilled, make sure the
area is dry before starting the engine.
Cutting Height Adjustment
Check the cutting height settings, and make any necessary adjustments. Pull then handle
and move it forward or backward to change the cutting height. There are 5 heights of
adjustment.
The blade can cause serious injury. Stop the engine
before adjusting cutting height.

14
4. Operation
Starting The Engine
Move the choke lever to the “CHOKE” position.
Pull back on the brake lever and hold it against
the handle.
Release the clutch lever. This will prevent the mower from moving forward when you
operate the starter.
BRAKE LEVER
CLUTCH LEVER
CHOKE

15
With the starter handle in its support, take the starter handle with your right hand and
pull slowly as far as to have a resistance, then pull energetically on the starter handle
with starter rope through the support. (If the cold start is not sufficient enough, repeat
this operation 2 or 3 times)
Immediately after the start, push back the choke lever from “CHOKE” position to
“RUN” position.(If the temperature is low, allow the engine to run for a few minutes
before starting to work.)
Operation The Controls For Mowing
Blade is in action as soon as engine started. While the machine is working maintain the
security handle in working position. The engine will stop as soon as you release the
engine control bar.
Release the lever to stop the engine whenever you need to leave the mower.
RUN

16
Clutch Lever
Push the clutch lever forward and hold it against the handlebar to propel the mower
forward.
Release the clutch lever to stop the mower’s forward movement.
Always release the clutch lever before starting the engine. If the clutch is engaged, the
mower will move forward.
Operate the clutch lever with a quick and complete motion, so the clutch is either fully
engaged or fully released. Hold the clutch lever against the handlebar during
self-propelled mowing. This will help to extend the service life of the clutch mechanism.
Variable speed Lever
Speed can be adjusted from 2.7 – 5.0 km/h while driving. Activate the right handle on the
dashboard and set in one of the 4 different speeds. When driving in one the two lowest
speeds the pace difference will not vary significantly.

17
Stop Engine
Release the clutch lever.
Release the brake lever.
The blade will continue to rotate for a few seconds after the
engine has stopped. Disconnect the spark plug cap if the
lawnmower is to be left unattended.
5. Maintenance
IMPORTANT Regular, careful maintenance is essential for keeping the
safety level and original performance of the machine unchanged in time.
Keep all nuts, bolts and screws tight to be sure the equipment is in safe working
condition. Regular maintenance is essential for safety and performance.
Never store the equipment with fuel in the tank inside a building where vapour may
reach a flame or a spark or a source of extreme heat.
Allow the engine to cool before storing in an enclosed space.
To reduce the fire hazard, keep the engine, exhaust silencer, battery compartment
and fuel storage area free of grass, leaves, or excessive grease. Do not leave
containers with grass cuttings in rooms.
For reasons of safety, do not use the equipment with worn or damaged parts. Parts
are to be replaced and not repaired. Use genuine spare parts (blades should always
bear the symbol). Parts that are not of the same quality can damage the equipment
and be dangerous for your safety.
If the fuel tank has to be drained, this should be done outdoors and when the engine
is cool.
Wear strong work gloves when removing and reassembling the blade.
Check the blade’s balance after sharpening.
Check the self-closing guard and grass-catcher frequently for wear and deterioration.
Whenever the machine is to be handled, transported or tilted you must:
-Wear strong working gloves;
BLAKE LEVER
CLUTCH LEVER

18
-Grasp the machine at the points that offer a safe grip, taking account of the weight
and its distribution.
Blade
Inspection
Tilt the mower to the right, so the air cleaner side is up. This will help to prevent fuel
leakage and hard starting.
Inspect the blade for damage, cracks and excessive rust or corrosion.
A dull blade can be sharpened, but a blade that is excessively worn, bent, cracked, or
otherwise damaged must be replaced.
A torque wrench must always be used when installing the blade.
Check that the blade bolts are tight.
Removal and installation
If you remove the blade for sharpening or replacement, you will need a torque wrench
for installation. Wear heavy gloves to protect your hands.
Remove the bolt with a socket wrench. Use a wooden block to prevent the blade from
turning when removing the bolt. Then remove the blade.
Install the blade using the blade bolt and special washers. Be sure to install the
special washers with the concave side toward the blade and the convex side toward
the bolt.
Tighten the blade bolt with a torque wrench. Use a wooden block to prevent the blade
from turning when tightening the bolt.
BLADE ADAPTOR
BLADE
WASHER
BOLT

19
Grass Bag Cleaning And Replacement
Cleaning
Wash the bag with a garden hose, and allow it to dry completely before use; a wet bag
will clog quickly.
Replacement
Unclip the plastic edges of the bag from the frame,
remove the frame from the bag.
Insert the frame into the bag, clip the plastic edges of
the bag onto the frame.
Engine Maintenance
Check Engine Oil Level
Check the engine oil level with the engine stopped and the mower.
Remove the oil filler cap, and wipe the dipstick clean.
Insert the dipstick into the oil filler neck, but do not screw it in.
Check the oil level shown on the dipstick. If near the lower, fill to
the upper level with the oil. Do not overfill.
Screw in the filler cap securely.
NOTICE:Running the engine with a low oil level will cause
engine damage.
Change Engine Oil
Drain the used oil while the engine is warm. Warm oil drains quickly and completely.
Wipe the oil filler area clean, then remove the oil filler cap/dipstick.
Place a suitable container next to the mower to catch the used oil, then tilt the mower
on its right side. The used oil will drain through the filler neck. Allow the oil to drain
completely.
Please dispose of used motor oil and the containers in a manner that is compatible
with the environment. We suggest you take it in a sealed container to your local
recycling center or service station for reclamation. Do not throw it in the trash, pour it
on the ground, or pour it down a drain.
Fill with the recommended oil. Do not overfill. Allow a couple of minutes for the oil to
settle in the engine, then measure the oil level.

20
Air Cleaner Service
NOTICE:Operating the engine without an air cleaner, or with a damaged air cleaner,
will allow dirt to enter the engine, causing rapid engine wear.
Press down on the cover
tabs and remove the
cover.
Remove the filter from the
air cleaner base..
Inspect the filter and foam
element, and replace it if
damaged.
Clean the filter by tapping
it several times on a hard
surface to remove dirt, or
blow compressed air
through the air filter from
the inside. Never try to
brush off dirt; brushing will
force dirt into the fibers.
Wipe dirt from the inside of the air cleaner base and cover, using a moist rag. Be
careful to prevent dirt from entering the air duct that leads to the carburetor.
Reinstall the filter and cover.
Spark Plug Service
For good performance, the spark plug must be properly gapped and free of deposits.
Disconnect the spark plug cap and remove any dirt from around the spark plug area.
Remove the spark plug with a spark plug wrench.
