Feider Machines FTDT461ZT User manual

1
ORIGINAL INSTRUCTIONS
LAWN MOWER PETROL
FTDT461ZT
OWNER’S MANUAL
CAUTION: Read and follow all Safety Rules and Instructions before operating
this equipment
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux - France
MADE IN PRC

2
1. SAFETY INSTRUCTIONS
Instructions
Read the instructions carefully. Be familiar with the controls and proper use
of the equipment.
Never allow children to use this mower. If the mower is given to an other
people, also give this manual. Also make sure that this person uses this
device only after receiving the necessary instructions. Local laws may
restrict the age of the user.
Never mow while people, especially children, or animals are nearby.
Keep in mind that the operator or user is responsible for accidents or risks
that may occur to other persons or their properties.
If necessary, have training with an experienced person in order to use in a
safe way this tool.
Preparation
During mowing, always wear slip-resistant foot protection and long pants.
Do not use the equipment barefoot or wearing sandals open.
Wear personal protective equipment including at least: clothes of
protection, gloves, foot protection, mask, ocular and hearing protection
Carefully inspect the area where equipment and remove all foreign objects
such as stones, toys, stick and wires.
WARNING - Gasoline is extremely flammable.
oAdd fuel before starting. Do not remove the fuel tank cap while the
machine is running or when it is hot.
oIf the fuel has spilled or leaked, do not attempt to start the machine but
move the machine away from the leakage area and avoid creating a
source of ignition until the gasoline vapours has dissipated.
oRefuel only outside and do not smoke during refuelling.
oStore fuel in tanks specifically designated for this purpose.
oReplace the fuel tank or the defective gasoline plug securely.
Replace defective mufflers.
Before use, always inspect visually that the blades, blade assembly and
blade lock are not worn or damaged. Replace blades and blade
assemblies that are not in good condition to maintain balance. Always use
recommended blades. Contact the manufacturer or your dealer in order to
have a list of recommended blades. Non-recommended blades can give a
risk of malfunctions, injuries and accidents.
The blades must be balanced to ensure proper operation and to be able to
work safely.
Operation
Do not use the machine in a confined space or hazardous carbon

3
monoxide emissions can be collected.
Mow only under daylight or under good artificial light. Always have a good
visibility.
Avoid using the equipment on greasy grass, where possible.
Always be sure of your walking on the slopes.
Walk, never run.
For lawn mowers, mow across slopes, never from top to bottom.
Exercise extreme caution when changing direction on slopes.
Stop the blades if the mower is to be tilted during transport when crossing
surfaces other than grass, and when transporting the mower due to the
area to be mowed.
Do not mow on steep slopes.
Use extreme caution when tipping or pulling the mower towards you.
Never use the mower with defective guards, or without safety devices such
as baffles and or collection bins, which are not in place.
Do not change the motor configuration or increase the speed.
For starting, disengage all blades, the gears must be in neutral, the traction
control lever must be released. Set foot well away from the blades.
Before starting the engine or starting the engine, carefully read and
understand all instructions.
Do not tilt the mower when starting the machine or turn on the engine,
unless the mower needs to be tilted for starting. In this case, do not tilt it
more than absolutely necessary and lift only the part that is furthest away
from the user.
Do not start the machine by standing in front of the ejection
Do not place hands or feet near or under rotating parts. Keep clean the
mouth of the grass extractor.
Never take or carry the mower while the machine is running.
Stop the machine and remove the ignition key, disconnect the spark plug
from the spark plug:
oBefore cleaning or unclogging the grass extractor.
oBefore checking, cleaning, and working on the mower.
oAfter hitting an object. Inspect the mower for damage and repair before
re-using the mower.
oIf the mower begins to vibrate abnormally, stop the engine immediately
and check according to previous recommendations.
The controls must be always checked if they are functioning correctly. In
case of malfunction, do not use the tool and bring to a service agent for
inspection.
Stop the engine immediately:
oEvery time you leave the tool alone and the working area
oBefore refuelling.

4
When the tool is stopped, park it in a safe place.
Move slowly when moving.
The lawnmower should not be used in slopes and near drop-offs, ditches
or embankments; if the tool must be used in these kinds of emplacements,
take an extreme precaution and operate carefully the tool.
The lawnmower safety systems or features shall not be tampered with or
disabled;
The operator should not alter or tamper with any sealed adjustments for
the engine speed control.
Maintenance and storage
Check and tighten all bolts and screws to ensure that the equipment is in
safe operating condition.
Never keep the mower with gasoline in the tank in a building or vapours
can cause a bright flame or spark.
Allow the machine to cool before storing it in an enclosed area.
To reduce the risk of fire, keep the machine clean without grass, without
grease, the muffler and the engine cools, disconnect the battery if
necessary and empty the fuel tank
Check the grass catcher frequently, its condition or deterioration.
Replace worn and damaged parts for safety.
If the fuel tank is to be drained, it must be made outdoors.
Special safety instructions
Always use the mower with its pick-up bag and / or deflector in the
intended position.
Switch off the engine before emptying the pick-up bag or before changing
the cutting height.
While the engine is running, never put your hands or feet under the mower
or under the grass ejection area.
Before mowing, remove all foreign objects from the grass that can be
propelled by the machine.
Keep children and pets at a safe distance while using the mower.
Never lift the mower when the engine starts.
Alcohol, drug, as well as illness, fever and fatigue affect your ability to
respond. Do not use power tools in such circumstances.
Never change the rated speed of the motor.
Never lift or carry the tool while the engine is running.
Before starting the engine, release the drawbar.
Before mowing, install the collection bag in its intended position.
Do not use the mower in the event of rain or when the grass is wet.
Never lift the rear of the mower when starting the engine and never place

5
your hands or feet under the mower deck or in the rear ejection port while
the engine is running.
Turn off the engine and remove the spark plug cap in the following cases:
oBefore operating under the mower deck or near the ejection opening.
oBefore any maintenance, repair or verification.
oBefore transporting, lifting or storing the mower.
oIf you leave the mower unattended or change the cutting height.
oTo remove and empty the collection bag.
After striking a foreign object, turn off the engine and carefully inspect the
mower for damage. Take the lawnmower to an authorized service center
for repair if necessary.
If the mower vibrates abnormally, try to understand the reason and bring
your lawnmower to an authorized repair center.
Regularly check that the bolts, nuts and screws are properly tightened for
safe use of the mower.
Do not use the tool where there is a risk of lighting.
Use the tool on daylight or under a good lighting. Always keep bystanders
away.
Warning: Take an extreme precaution when operating the lawnmower in
slopes and near drop-offs, ditches or embankments; always be sure of
your footing and stay in alert.
the lawnmower safety systems or features shall not be tampered with or
disabled;
the operator should not alter or tamper with any sealed adjustments for the
engine speed control;
The operator must have, before using the tool for the first time, an
adequate training with an experienced people.
Warning: do not use of the unit while being tired, ill or under influence of
alcohol or other drugs;
Park safely the tool before leave it. The tool must be switched off.
The lawnmower shall not be operated without either the entire grass
catcher or self-closing discharge opening guard in place;
Warning: be careful about exhaust gas. Do not inhale them.
Wear adequate clothing such as long trousers and a protective equipment:
slip-resistant foot protection, hearing protection, eyes protection and
gloves.
To avoid health issues, limit the time of operation. Take enough rest.
Exposure to noise and vibrate can have bas consequences on health.
WARNING: There is a danger about moving blade assemblies. Always
handle blades when they are in a complete stop and wear protective
gloves.

6
Fuel Handling
Use caution when handling fuels. They are flammable and the vapours are
explosive.
Use only an approved container.
Never remove the fuel cap or add fuel while the machine is on. Turn off the unit
and allow the engine and exhaust components to cool down before refuelling.
Do not smoke.
Never refuel inside a room.
Never store the tool and the fuel tank indoors where there is a naked flame,
such as near a water heater.
If fuel has spilled, do not attempt to start the machine, but move it away from
the spill before starting to use it. Please clean up any spills.
Replace and tighten the fuel tank cap after refuelling.
Follow strictly the instructions in this manual for filling the tool with fuel.
During maintenance and storage
Switch off the tool and wait until it stops completely. Make sure that all moving
parts are stopped.
Allow the machine to cool before performing inspection, adjustments,
maintenance, servicing and storage.
Store the tool where fuel vapour will not reach a flame or spark.
The transport of the tool must be secured in order to avoid fuel spillage,
accidents and injuries.
Residual risks
Even if you use this product in compliance with all safety requirements, the
potential risks of injury and damage remain. The following hazards may arise in
the structure and design of this product:
There are risks of injury and property damage due to attachments or broken
the sudden impact of hidden objects when using cutting.
There are risks of injuries and accidents caused by flying objects.
Prolonged use of this product exposes the operator to vibrations and can
produce so-called "white finger" disease. To reduce the risk, wear gloves and
keep your hands warm.
If any of the symptoms of "white finger syndrome" occur, seek immediate
medical attention.
Symptoms of "white finger" include numbness, loss of sensitivity, tingling, pain,
loss of strength, colour changes or skin condition. These symptoms usually
appear on the fingers, hands or wrists. Risk increases at low temperatures.
A long exposition to noise can affect the health of the operator. A hearing
protection must be always used when operating the tool. The operation of the
tool must be limited and some rest must be taken between two sessions (e.g.
10min of operation and 20min of rest).

7
Symbols
Read the instructions manual
Risk of projections; keep bystanders away
Sharp blades; Beware of cutting fingers and feet. Do not touch
the blades until the tool is on a completely stop.
Clean the area to be mowed, keep children and other people
at a safe distance from the machine.
Sharp, be careful not to cut your fingers or toes, remove the spark
plug wire before maintenance.
Guarantee sound power level
The surface is very hot, do not touch
Exhaust emissions are harmful to health of body
No naked fire near the machine!

8
Intended use
This device is only for lawn mowing grass in the domestic area. The device is
designed for domestic use. It is not intended for continuous professional use.
Any other use that is not expressly permitted in this manual may result in
damage to the device and constitute a serious danger to the user.
This device is designed for use by adults. Children and those unfamiliar with
this manual should not use this device. The user is responsible for accidents or
damage caused to people or their property. The manufacturer is not liable for
damage caused by improper use or improper handling.
Description

9
Technical data
ASSEMBLY
Handle
Unfold handle carefully so as not to pinch or
damage control cables.
1. Raise handles until lower handle section
locks into place in mowing position.
2.Remove protective padding, raise upper
handle section into place on lower handle
and tighten both handle knobs.
Mount the front wheel
1. Insert the two screws from the inside through the recesses on the front sheet
steel housing.
2. Fix the front wheel with the two washers and nuts.
3. Attach the front wheel to the top of the lawnmower housing with the nuts and
bolts.
Model
FTDT461ZT
Power
2.4 kW
Engine speed
2900/min
Cutting width
460mm
Adjustable cutting height
6 positions
Grass collection capacities
50 L
weight
22.3 kg
Guaranteed Sound Power Level
96 dB(A )
Sound power level
Max.93 dB (A); K=2.98 dB(A)
Sound pressure level
Max.82,5 dB (A) K= 3 dB(A)
Vibration
Max. 3,913 m/s²K= 1,5 m/s²

10
Instruction for grass bag assembly
Before using the grass catcher, the side discharge must be removed.
Pull plastic loops over basket rods.
Open the flap then Install the grass catcher on the hook on the rear of the tool.
Release the flap.
Disassemble the grass catcher
Lift the flap and remove the grass catcher.
Side discharge
Before using the side grass discharge, the grass collection basket
removed.
- Unlock the flap of the side discharge
- Lift the cover.
- Hook the side discharge. Release the flap.

11
Mulching kit
Before using the mulching kit, the lateral discharge must be removed.
Assembly
- Remove the grass catcher if installed.
- Lift the flap.
- Fully insert the mulching kit at the back of the tool.
- Press the kit to lock it in place.
Disassembly
-Lift the flap.
-Press the center of the mulching kit firmly.
-Hold and pull the handle to remove the mulching kit.
ADJUST CUTTING HEIGHT
Raise wheels for low cut and lower wheels for deep cut; adjust cutting height to
suit your requirements. Medium position is best for most lawns.

12
FILLING FUEL TANK
a. Filling tank
WARNING! Gasoline is extremely flammable.
Store fuel in specially designed cans for this purpose.
Fill the fuel tank only outdoors and before starting the engine. Do not
smoke when filling the fuel tank or handling fuel.
Never open the fuel tank cap and never add fuel while the engine is
running or when it is hot.
If fuel has spilled, do not start the engine any further, move the tool away
from where the fuel has been spilled, and be careful not to create a spark
or flame until the fuel vapors have dissipated.
Fully close all fuel tank and fuel canisters.
Before tilting the mower to maintain the blade or drain the oil, empty the
fuel tank.
WARNING: Never fill the fuel tank indoors, while the engine is running, or
before the engine has cooled down for at least 15 minutes after use.
CAUTION: Do not use unapproved gasoline, such as E15 and E85. Do not
mix the oil with gasoline or modify the engine to operate with alternative
fuels. The use of unapproved fuels will damage the engine parts and will
void the engine warranty. To protect the fuel system from scale formation,
add a fuel stabilizer to the fuel. All fuels are not identical. If startup or
performance problems occur, change supplier or fuel brand.
Fuel must meet the following criteria:
- Clean, new and lead-free gasoline.
- A minimum octane rating of 87/87 AKI (91 RON). For use at high
altitudes, see below
- A gasoline containing up to 10% ethanol is acceptable.
- Remove the fuel tank cap. Add fuel.
- Close the fuel tank with the cap.
Do not overfill. Wipe off any fuel that has overflowed before starting the
engine.
a. Engine oil
Recommended oil: We recommend the use of high quality detergent oil
classified such as SAE30. Do not use special additives.

13
Filling oil tank
- Open the oil tank.
- Fill directly the oil in the tank. Do not overfill.
- Close the oil tank. Wipe any spillage.
Checking the oil level
- Check the oil level when the engine is off and horizontal.
- Remove the plug / dipstick from the oil tank and wipe it off.
- Insert the oil tank plug / dipstick into the tank neck as shown, without
screwing it in, and then remove it to check the oil level.
- If the oil level is near or below the lower limit of the dipstick, remove the
dipstick and fill the recommended oil reservoir up to the upper limit of
the dipstick (bottom edge of the dipstick). Do not overfill.
- Replace the oil tank plug / dipstick.
Upper limit : height limit
Lower limit :low limit
OPERATION
Start the device on a safe and flat ground, preferably not in tall grass. Make
sure that the cutting tools do not touch objects or the ground.
a. Start the engine
- Push 3 times the primer bulb.
- Pull the drive lever bar the operation control bar (control lever) in the
direction of the handle and hold it.
- Pull the starter rope.
- If the engine starts, pull back slowly the starter rope.

14
b. Stop the engine
-Release the bars. The engine turns off and the blade is slowed down.
Wait until the complete stop of the blade.
c. Mowing
-Self-propeller function
The self-propelled mechanism engages by pressing the safety lever on
the handle.
Self-propelled mechanism ceases when you release this bar.
Pull the safety lever back towards the handle to mow without the
self-propelled mechanism.
-Work instructions
Mow dry grass as much as possible to save grass.
Adjust the cutting height so that the machine is not overworked.
Drive the machine at moderate speed (walking) along the belt as
straight as possible. For a perfect mowing result, the strips must
always overlap for a few centimetres
Do not back away.
Always work perpendicular to the slopes.
If the blades come into contact with a foreign object, immediately turn
off the engine. Wait for the blades to stop turning completely and
check that the unit has not been damaged. Only resume work if the
unit has not been damaged.
Turn off the appliance when taking long breaks during work and
carrying the appliance.
Wait for the blades to stop turning completely.
Clean the appliance after each use as described in the chapter
"Cleaning and maintenance".

15
MAINTENANCE AND STORAGE
Carry out maintenance and cleaning work when the engine is off and the
spark plug are out. Risk of injury!
Allow the tool to cool down before performing any maintenance or
cleaning work. The engine elements are hot. Risk of burns!
Wear gloves when handling the blades.
Cleaning and general maintenance task
Carefully clean the machines with water after each cut; remove the grass
debris and mud accumulated inside the chassis to avoid their drying and
thus making the next start-up difficult
The paintwork on the inside of the chassis may peel off in time due to the
abrasive action of the cut grass; in this case, intervene promptly by
touching up the paintwork using a rustproof paint to prevent the formation
of rust that would lead to corrosion of the metal.
Remove the transmission casing by removing the screws and clean
around the transmission and drive belts with a brush or compressed air
once or twice a year.
Once every season, the wheels should be cleaned. Remove the wheels
to clean them.
Changing blades
To replace the blade, undo the screw. Empty the oil tank before removing
the blade. Wear gloves when handle the blades.

16
Changing the Oil
Have a container ready to catch the oil
and remove the drain plug. We should
incline machine to make sure all the oil
could be go out. Once the oil has been
emptied, replace the drain plug making
sure that the washer is in place and wipe
clean any spillages.
Refill with SAE30 oil. Do not overfill.
Start the engine and allow it to run briefly. Stop the engine, wait one
minute and check the oil level. Top up if necessary.
Spark Plug
Once the engine has cooled, remove the spark plug. Clean the plug
with a wire brush. Using a feeler gauge, set the gap to 0.75
mm( 0.030"). Refit the spark plug taking care not to over tighten.
Air Filter
Unclip the air filter cover and remove the sponge filter element. To avoid
objects falling into the air intake, replace the air filter cover.

17
DRAINING THE FUEL TANK AND CARBURETOR
1. Place an approved gasoline container below the carburetor, and
use a funnel to avoid spilling fuel.
2. Remove the drain bolt, then move the fuel valve lever to the ON
position
3. After all the fuel has drained into the container, reinstall the drain
bolt and washer. Tighten the drain bolt securely

18
MAINTENANCE SCHEDULE
SERVICE
Befor
After
After5
h
After 8
h
After
50 h
Once
a year
Mowing
check and tighten nuts,
bolts and screws

Check the oil / fuel level
and refill oil / fuel if
necessary


Clean control elements /
area around sound
insulation


Change the engine oil



Exchange air filters

Clean / adjust & replace
spark plugs


Control the sound
insulation and the spark
screen


Clean the air cooling
system


19
DECLARATION OF CONFORMITY
BUILDER SAS
ZI, 32 rue Aristide Bergès – 31270 Cugnaux - France
Tel: [phone] Fax: [phone]
Declares that the machines:
LAWN MOWER PETROL
Model: FTDT461ZT
Serial No.: 20210112270-20210112387
Have been designed in compliance with the following standards:
EN ISO 5395-1:2013+A1:2018
EN ISO 5395-2:2013+A1:2016+A2:2017
EN ISO 14982:2009
And in accordance with the following directives:
Directive Machine 2006/42/EC
Directive EMC 2014/30/EU
Emission directive (EU) 2016/1628 & 2017/656/EU
Noise Directive 2000/14/EC Annex VI & Directive 2005/88/EC
Sound power level: Max.93 dB (A); K=2.98 dB(A)
Guarantee sound power level: 96 dB(A)
Responsible of the technical file：M. Olivier Patriarca
Philippe MARIE / PDG
Cugnaux, 01-01-2021

WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
WARRANTY
20
