Feit Electric LAN11RND/SYNC/BZ User manual

We appreciate the trust and confidence you have placed in Feit Electric through the purchase of this LED Round Wall Lantern.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Feit Electric.
USE AND CARE GUIDE
LED ROUND WALL LANTERN
Questions, problems, missing parts?
Before returning to store, visit feit.com/help for further assistance.
Model: LAN11RND/SYNC/BZ

Table of Contents
Safety Information
For your safety, always remember to:
□
WARNING: RISK OF SHOCK. House electric current can
cause painful shock or serious injury unless handled properly.
CAUTION: Turn off the main power at the circuit breaker
before installing the fixture, in order to prevent possible shock.
NOTICE: All electrical connections must be in accordance with local
and national standards, National Electric Code (N.E.C.) in the US and
Canadian Electrical Code (C.E.C.) in Canada. If you are unfamiliar with
proper electrical wiring connections obtain the services of a qualified
electrician.
Remove the fixture and the mounting package from the box and make
sure that no parts are missing by referencing the illustrations on the
installation instructions.
□
□
□
□
Limited Warranty
2WWW.FEIT.COM
Supplier’s Declaration of Conformity:
47 CFR § 2.1077 Compliance Information
Responsible Party:
Feit Electric Company
4901 Gregg Road,
Pico Rivera, CA 90660, USA
Unique Identifier:
LAN11RND/SYNC/BZ
This product is warrantied to be free from defects in workmanship and materials for up to 3 years from date of purchase. If the product fails within the warranty
period, please contact feit electric at [email protected], visit feit.com/contact-us for instructions on replacement or refund. Replacement or refund is your sole remedy.
Except to the extent prohibited by applicable law, any implied warranties are limited in duration to the duration of this warranty. Liability for incidental or
consequential damages is hereby expressly excluded. Some states and provinces do not allow the exclusion of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or
province to province.
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the
equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment. CAN ICES-005 (B). RF Exposure. The equipment complies
with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with
minimum distance 20cm between the radiator & your body.
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Hardware Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Operation without Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Operation with Remote . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Operation with Smart Bridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Turn off the power supply at the fuse or circuit breaker box
before you install the fixture.
Ground the fixture to avoid potential electric shock and to ensure
reliable starting.
Double-check all connections to be sure they are
tight and correct.
Wear rubber soled shoes and work on a sturdy
wooden ladder.
Account for small parts and destroy packing material, as these
may be hazardous to children.
This fixture is designed for use in a circuit protected by a fuse or
circuit breaker. It is also designed to be installed in accordance with
local electrical codes. If you are unsure about your wiring, check your
local electrical code or consult a qualified electrician.
PRODUCT SPECIFICATIONS:
• 120 VAC, 60 Hz, 12.5 Watts
• Not for use with dimmer
• Wet Location
DUSK TO DAWN OPERATION:
The light will turn on at dusk and remain on through the night until
dawn. The light will remain off throughout the day, until dusk.
NOTE: To make sure this function works properly, always have the
switch in the ‘ON’ position (including daytime).
NOTE: A convenience cover is provided which can be used to block
out light and bypass the sensor. This will keep the light continuous on
and fixture can be controlled to turn on/off through the wall switch or a
master photocell.

Pre-Installation
TOOLS REQUIRED
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA Fixture 1
BB Mounting Plate 1
CC Junction Box Screws 2
DD Washers 2
EE Decorative Nuts 2
AA BB CC DD EE
3WWW.FEIT.COM
Phillips
screwdriver
Flathead
screwdriver

Installation
Turning off the power
□Turn the power OFF at the switch
and fusebox or the circuit breaker.
1
Removing the mounting plate
□Unscrew the decorative nuts (EE), remove
the washers (DD) and keep them for Step 7.
□Remove the mounting plate (BB).
2
3Identifying the wires
□Identify the wires at the junction box.
□(Black-line voltage, White-neutral, Green-ground).
□Make them accessible for easy connection.
Installing the mounting plate
□Attach the mounting plate (BB) to the outlet box
using the provided junction box screws (CC).
□Make sure to run the house wires through the
center hole on the mounting plate (BB).
4
Connecting the wires
□Connect the house wires directly to the terminal block.
□Tighten the screws on the terminal block using a screw
driver to secure the wire connections.
See below
5
Terminal Block
Black
wire to
“L” input
Ground
wire to
“GND” input
White
wire to
“N” input
Black Ground
BB
BB
CC
EE
DD
AA
Junction Box
White
4WWW.FEIT.COM

AA AA
Installation (continued)
7
Turning the power on
□Turn the power on at the circuit breaker or replace fuse.
8
Installing the fixture
□Gently align the quick-connect pins to the top holes
on the terminal block.
□Make sure the screws on the mounting plate (BB)
are also aligned.
□Push the fixture back plate to the mounting plate (BB).
Make sure that the threaded screw ends are coming
out through the front side of the fixture back plate.
6
Quick-connect pins
EE
Threaded screws
Fixture back plate
Terminal Block
BB
DD
WWW.FEIT.COM
5
Securing the fixture
□Install the rubber washers (DD) and secure the fixture
to the mounting plate (BB) by tightening decorative
nuts (EE).
□Caulk around the junction between the fixture and wall
to prevent water or moisture from entering the wiring
compartment.

Operation without Remote
Turning on the fixture
□Turn the fixture on by pressing the button on the bottom of the fixture.
1
Selecting a Color
□To cycle through the colors, push the button. Colors are: Soft
White, Bright White, Cool White, Daylight, Deluxe Daylight,
Red, Blue, Green, Yellow, Orange, Purple, Teal, Pink. The
lantern will remember the color setting when next turned on.
This OneSync fixture works on its own or with a OneSync Remote or Smart Bridge for grouping and expanded control (sold separately).
2
Using Dusk to Dawn Function
□To operate using the Dusk to Dawn Function, the
CAP MUST BE REMOVED.
3
Dusk to Dawn Sensor
with Cap
On/Off/Cycle
&
Pairing Button
WWW.FEIT.COM
6

Operation with Remote (sold separately)
Entering pairing mode
□Hold down the pairing button for 3 seconds. Once the lantern starts to
blink slowly, it will be in pairing mode for 3 minutes before timing out
or accepting a remote command.
1
Pairing the remote to the fixture
□While the lantern is in pairing mode press and hold the desired
Groups button (1, 2, 3, 4, 5 or 6) for 3 seconds to pair the Remote
to the selected group.
The light will flash once and the fixture will exit pairing mode.
2
Unpairing the fixture from the remote
□To unpair, first follow step 1 so that the fixture is in pairing mode.
Once the fixture is in pairing mode, on the OneSync Remote, press
the pairing group button and hold the power button for 3 seconds.
The light will flash once and the fixture will exit pairing mode.
□To unpair from all groups at once, hold down the button on the
OneSync fixture for 10 seconds. It will flash three times rapidly to
indicate that all groups have been unpaired from the fixture.
3
1 2 3
4 5 6
2hr 4hr 8hr
Timer
Groups
LOW HIGH
RGB
WWW.FEIT.COM
7
On/Off
Select Group
Colors Cycle
Brightness
Level Selectable
White Color
Cycle
Set Daily Time
Downloading and installing the Feit Electric app
□Search for the Feit Electric app in the App Store or Google Play Store.
□Download and Install the Feit Electric app on your smart device.
□Connect to a 2.4GHz Wi-Fi network that covers your installation location.
□Follow the instructions in the Feit Electric app & Smart Bridge manual
to pair your OneSync lights.
1
Operation with Smart Bridge
Operating with a OneSync remote allows for expanded control. Modify settings of individual OneSync fixtures or multiple fixtures in groups.
The OneSync Remote has a 100ft control range and will command all paired fixtures within 100ft of the remote.
All OneSync fixtures are equipped with a signal repeater that will repeat any remote commands to all other fixtures within 100ft. Placing
fixtures within 100ft of at least one other fixture creates a control network and allows for unlimited remote control range, as long as there is a
functioning OneSync fixture within 100ft to relay the command.
NOTE: The remote is equipped with a
universal Group #1. To create unique groups, pair
using Groups #2-6. All fixtures are pre-paired to
the universal Group #1 so that they will
immediately respond with any remote Group #1
command. To not operate on this universal group,
follow the unpairing instructions in Step 3.
Only supports
2.4GHz Wi-Fi
Networks
Feit Electric App
Example: You can install a OneSync fixture, then another OneSync fixture 100ft away from the first unit. Continue to install 3 more OneSync
fixtures in this way so that the last fixture is 500ft away. Using this relay technology, the remote will control the farthest fixture that is 500ft away.

FEIT ELECTRIC COMPANY | PICO RIVERA, CA | www.feit.com
Questions, problems, missing parts?
Before returning to store, visit feit.com/help for further assistance.
