FELLER ENGINEERING OR 23110 User manual
1
OR 23110
:رادشه
2
3
AC
4
OR 23110
English
Read this booklet thoroughly before using and save it for
future reference
Important safeguards
Correct Disposal of this product
1
This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To
prevent possible harm to
the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please
1. Warning: In order to avoid overheating, do not cover the heater.
2. If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualied person in order to avoid a hazard.
3. This appliance is not intended for used by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliances by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
4. The heater must not be located immediately below a socket-outlet.
5. Do not use this heater in the immediate surroundings of a bath, a
shower or a swimming pool.
6. This heater is lled with a precise quantity of special oil. Repairs requiring
opening of oil-container are only to be made by the manufacturer or
his service agent who should be contacted if there is an oil leak. When
scrapping the heater, follow the regulations concerning the disposal of oil.
Technical Data
Power: 2300W
Fins: 11
2
Part gure
Use of oil lled radiator
[Installation of the wheel carrier plate
assembly]
1. Place the heater body inversely with
the bottom upward.
2. Connect and tighten two wheel
carrier plates to the body with buttery
nuts as shown in the gure.
use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe
recycling.
WARNING: IN ORDER TO AVOID OVERHEATING, DO NOT COVERTHE HEATER.
3
Operating instruction
[Inspection before start]
1. The power cord shall not be damaged or fractured.
2. This machine uses 220-240V AC power so please verify the rated current
of the power socket is in line with the requirements in the table above and
is equipped with a safety grounding device before use; otherwise, replace
the socket.
[Start and power selection]
1.Start
Plug in the power, clockwise turn the thermostat knob to the “ “ mark
position, then turn on the power switch, the heater starts to work.
2. Power selection
Under normal circumstances, please use the maximum power “III” gear for
rapid heating. If the room temperature reaches a suitable temperature,
please choose a lower power “II” or “I” gear to reduce energy consumption
so as to prevent the room becoming overheated.
[Note]
To use the machine for the rst time or to re-insert the socket, please pay
attention to check whether the plug and the socket are tted well.
<Inspection method>
Insert the power plug into the socket and start for use; after about half an
hour, turn o and pull out the plug. Check whether the plug pins are hot;
replace the socket if so (more than about 50 °C) to avoid burning the plug
or even causing a re caused by overheating of the socket due to poor
contact.
3. Place the heater upward after it is installed securely with the wheels
touching the ground.
4
Cleaning and maintenance instruction
[Temperature adjustment]
During use, if you feel it is necessary to lower the room temperature since
it is too high, you can use the following adjustment modes:
1. Turn the power switch to gear “II” or “I”.
2. Counterclockwise turn the thermostat knob back by a certain angle, for
which it indicates that the set temperature is lower when the temperature
indication is closer to the “ “ position.
[Stop]
Turn the power switch to indication point “0”, and then pull out the power
plug.
[Movement of the heater]
To move the heater, turn it o rst, and pull out the power plug; then push
the body to make the four casters below the body to roll.
1. The electric heater should be cleaned regularly to wipe out the dust on
the surface of anges. As this may inuence the radiating eciency.
2. Disconnect electricity supply and allow radiator to cool, wipe out dust
with a soft damp cloth. Do not use detergent or abrasives.
3. Do not scrap the surfaces of anges with sharp hard tools, to avoid
surfaces getting rusty, because of damage of the paint coat.
This manual suits for next models
