ORIGO FH-T20P User manual

*使用暖風機前，請先細閱使用說明，並請妥善保存以便將來翻閱。
*Read all instructions carefully before using the FAN HEATER, and keep this instruction for
furture reference when necessary.
陶瓷暖風機
Ceramic Heater
FH-T20P
使用說明書
Instruction Manual

Ceramic Heater
陶 瓷 暖 風 機
Important Safety Information
重要安全提示
1
本機不是為體質、感覺或智力有障礙人
士或8歲以下小孩或缺乏經驗及知識者
使用，除非他們曾經接受負責安全人士
的監督或指示，大人應指導小孩不可把
玩電器。除非在負責安全人士的監督或
指示，8歲以下小孩不可清潔及維護本
機。
Thisappliance can be used by
children agedfrom 8years and
above andpersonswith reduced
切勿使用可使暖風機自動開機的外加管
理程式、時間制、遙控系統或任何其他
裝置，以免因暖風機被覆蓋或擺放位置
不當而發生火警。
The Heater is not intended to be
operated by means of an external
programmer, timer, seperate
remote-control system or any
other device that switches the
Heater on automatically, since a
fire risk exists if Heater is covered
or positioned incorrectly.
本機及其電源線應擺放於8歲以下小孩
不能觸及的地方。
Keep the appliance and its cord
out of reach of children less than 8
years.
如本產品的電源線有損壞痕跡，為保障
安全，請立即停止使用並聯絡供應商更
使用暖風機前，請先細閱使用說明。
Read all instructions carefully
before using the heater.
physical, sensory or mental
capabilities or lack of experience
and knowledge, if they have been
given supervision or instruction
concerning use of the appliance in
a safe way and understand the
hazards involved. Children shall
not play the appliance. Cleaning
and user maintenance shall not be
made by children unless they are
older than 8 and supervised.
換。
If the supply cord is damaged, it
must be replaced by manufacturer,
its service agent or similary
qualified persons in order to avoid
a hazard.
警告：為防暖風機過熱，切勿覆蓋暖風
機的出、入風口。使用中的暖風機出口
會發出高熱，切勿觸踫。暖風機應與易
燃物品(如傢俱、枕頭、床舖、毛巾或窗
簾等)保持安全距離。
出風口安全距離：不少於3英尺(0.9米)
入風口安全距離：不少於1英尺(0.3米)
WARNING: In order to avoid over
heating, do not cover the Heater.
The Heater is hot when in use. To
avoid burns, do not let bare skin
touch hot surface. Keep combustible
materials, such as furniture, pillows,
beddings, clothes and curtains at
least 3 feet (0.9m) from air outlet
and 1 feet (0.3m) from air inlet of
the Heater.
暖風機不可擺放於有潛在危險的地方使
用(例如：非常潮濕環境、易燃物品或化
學品倉庫)
The Heater must NOT be used in
potentially dangerous location such
as flammable explosive, chemical
laden or wet atmospheres.

Ceramic Heater
ഏ!ౠ!ཪ!!ᐒImportant Safety Information
ӼӄගҢ2᝾֋ǹమ౛߻Ѹ໪ӃܘନႝྍකᓐǶWARNING: To avoid danger of electric
shock, unplug from outlet when not in
use and before cleaning.
ཪᐒ೛Ԗวᖂ᝾ൔး࿼Ǵ྽ᐒيྕࡋၸ዗Ǵ᝾ൔᏔԾ୏วᖂගҢǴᔈҥջᜢᐒᔠࢗ٠䩳⌛ଶЗ٬ҔԜᐒǶThe Heater includes an audible alarm to
warn when the Heater are overheat. If
the alarm sounds, immediately turn the
Heater off and inspect the Heater .
DO NOT OPERATE THE HEATER WITH THE
ALARM SOUNDING!
ཪᐒόёᘍ߈Нࣧǵǵ޸᠀ǵݚԣǵዊᔸ܈ԖᑈНޑڬᜐᕉნ٬ҔǶThe Heater is not intended for use in the
immediate surroundings of a basin, a
bath, a shower, a swimming pool, a wet
or damp locations.
ཪᐒό፾Ҕܭ࠻ѦϷբπ཰Ҕ೼ǶHeater is intended for household use
ONLY, not for industrial or outdoor use. ϪϮஒҺՖ౦ނܫΕᐒϣǹ܈ߔᏲᐒيрαϷΕαǹ܈ஒཪᐒܫ࿼ӧࢋ೬܈όᛙڰޑ߄΢(ٯӵ׉ⱼ)ǴࣣӢа΢΋ϪՉࣁ֡཮Ꮴᐒيၸ዗ǴЇวอၡ܈О᝾Ƕ!!!!!!!ҁౢࠔ֖Ԗёӣԏ׷Ǵόёעҁౢࠔբ!!!ࣁ҂ϩᜪቲނǶፎᖄᛠ྽Ӧ൩߈ࡰۓӣԏ!!!ᗺǶThis product contains recyclable
materials. Do not dispose this
product as unsorted municipal waste.
Please contact your local municipality for
the nearest collection point.
220-240V~ 50Hz
٬Ҕཪᐒ߻Ǵፎዴۓೕ኱ຠ΢܌Ңޑᚐۓႝᓸᆶ྽Ӧٮႝႝᓸ࣬ӕǶӵԖᅪୢёӛٮᔈ୘ࢗ၌ǶBefore using the Heater, check if the
voltage marked on the rating label
corresponds to the mains in your home.
хးނ٠ߚވڀǴόёᡣλ࠸ވǶDo not let children play parts of package.
Ѻ໒хးǴᔠࢗౢࠔǶӵว౜ౢࠔԖཞᚯǴፎϮ٬ҔϷջᖄ๎ٮᔈ୘ǶRemove the package and ensure that the
Heater is undamaged. In case of doubt
do not use the Heater and contact your
supplier.
ܘନකᓐόё܎רႝྍጕǴѸ໪ᆙඝකᓐǴעකᓐܘрǶ
Do not pull the power cord to disconnect
with power source. Always grasp the plug
to pull out.
ፎ٬Ҕᐱҥක০Ƕ٬Ҕ࿤ૈකᓐ܈ܦ݈Ǵ৒ܰวғӒᓀǶ
Avoid using extension cord as the extension
cord may overheat and casue fire.
ϪϮעཪᐒᘍܫܭႝྍක০ϐΠǶThe Heater must not be located
immediately below a socket outlet.
Do not insert any objects into the Heater
as it may cause an electric shock or fire
or damage to the Heater. Do not block or
tamper with the Heater in any manner
while it is in operation, To prevent a
possible fire, do not block air inlet or
oultet in any manner. Do not place on
soft surfaces, like a bed, where opening
may become blocked.
᝾֋Ǻᕴႝྍ໒0ᜢᗖόᔈբࣁϪᘐႝྍҔ೼ˤWARNING: The Main Power Switch and
the On/Off switch should not be used as
the sole means of disconnecting power.

3
Ceramic Heater
陶 瓷 暖 風 機
Main Parts
各部名稱
出風口
總電源開/關
Plug
Air Outlet
Main Power Switch
插頭
LED顯示
LED Display
Base
底座
Bathroom Use
浴室使用
本暖風機已通過IP21防滴要求，可放置於任何室內位置(包括浴室)使用。
如在浴室中使用本暖風機，則必須擺放於與水源(洗手盤/浴缸)及使用者(伸手不能達到)
的0.6米以外位置。
This is a “IP21” heater which is constructed for protection against splashing and
allowed to be in all rooms, including bathroom.
The appliance must be placed 0.6 meter away from water sources, such as
washbasin and bathtub, and out of reach of hands.
Control Panel
Air Inlet
入風口
控制面板

Function Setting
功能設定
4
1. 小心從包裝取出暖風機。
2. 將暖風機擺放於穩固的平面上。
3. 按總電源開/關鍵至關機狀態，將插頭插入電壓 220-240V的獨立插座。按總電
源開/關鍵至開機狀態，LED顯示將會顯示‘--’，暖風機進入準備狀態。
The Heater may be operated by the manual controls located on the Heater or by
you renote control.
1. Carefully remove the Heater from the plastic bag and the carton.
2. Place the Heater on a stable flat surface.
3. Set the Main Power Switch to 'OFF' position. Plug the Power Cord into a a.c. 220
-240V electrical outlet. Turn the Main Power Switch to 'ON' position. LED display
will show '--', the Heater is ready to use.
陶 瓷 暖 風 機
Ceramic Heater
注意：第一次使用暖風機，可能會出現少量氣味約數分鐘，因本產品在生產時發熱元
件帶有一層保護油，此乃正常現象。
NOTE: For first time operation, there will have some smell for about few minutes.
Because this Heater have some protective oil on the surface of the heating
暖風機可使用機身頂部按鍵操控，或改用遙控器操控。
4. 開/關: 按 鍵，暖風機以低熱模式運作，LED會顯示預設運作溫度‘23℃’及‘LO’。
若室內溫度高於預設運作溫度，暖風機將不會加熱運作。
4. On / Off: Press the‘ ’key, the heater will start at low heat, and the LED will display the
preset temperature‘23℃’and‘LO’.
If the room temperature is higher than the preset temperature, Heater will
not working.
5. 模式 : 按 鍵，暖風機將以不同模式運作 : 低熱、高熱、及防結霜。
低熱 - LED會顯示預設運作溫度‘23℃’及‘LO’
高熱 - LED會顯示預設運作溫度‘23℃’及‘HI’
防結霜 - LED會顯示預設運作溫度‘7℃’及‘ ’
5. Mode: Pressing the ' ' key will set the Heater into different MODE: LOW HEAT,
HIGH HEAT and Anti-freeze.
LOW HEAT - LED will display preset temperature ‘23℃’and ‘LO’.
HIGHT HEAT - LED will display preset temperature ‘23℃’and ‘HI’.
Anti-freeze - LED will display preset temperature ‘7℃’and ‘ ’.
6. 定時(關機): 暖風機在工作狀態下按 鍵，按' '或' '鍵選擇需要設定的自動關
機時間(可設定自動關機時間 : 1-24小時)。
6. Timer(Shut-off): When the heater is ON, press the button, then press the ' ' or
' ' button to increase or descrease the length of operation from
1-24 hours.

陶 瓷 暖 風 機
Ceramic Heater
Function Setting
功能設定
5
7. SET TEMP : When the unit is in the LOW HEAT or HIGH HEAT MODE:
7.1. Press the ' ' key to increase the desired temperature and the ' ' key to
decrease the desired temperature. Working temperature:
5 -35 C
7.2. When the air temperature reaches the 'SET TEMP', the Heater will cut off.
7.3. When the air temperature drops below the 'SET TEMP', the Heater will back on.
7.4. Note: It is normal for the Heater to cycle ON and OFF as it maintains the 'SET
TEMP'.
7. 溫控調節：當暖風機於'低熱'或'高熱'模式：
9. 左右送風：按 鍵，暖風機以自動左右搖擺模式送風。如欲停止自動左右搖擺送風，
再控此鍵一次。
9. OSC : Pressing the ' ' button will allow the Heater to oscillate the wind direction.
To stop the oscillation, press the 'OSC' button again.
10.同時按下 ' '及' '鍵5秒，控制面板將被鎖上LED，將會顯示 及 。
10.Press and hold the ' ' and ' ' key for 5 seconds, control panel will be locked.
LED display will show & .
7.1. 按' '鍵或' '鍵選擇需要設定的溫度，可設定溫度：
7.2. 當室內溫度達到設定溫度，暖風機會自動停止工作。
7.3. 當室內溫度低於設定溫度，暖風機會自動恢復工作。
7.4. 注意：在溫度控制的設定狀態下，暖風機將不斷循環的自動開機/關機地工作。
8. 防結霜模式：暖風機在防結霜模式下，當室內溫度低於7 C會自動以工作，當室內溫度
高於7 C 會自動停止工作。
8. Anti-Freeze : Under this mode, when the air temperature drops below 7 C the Heater
will run automatically. When the air temperature reach 7 C, the Heater
Heater will stop working automatically.
再次同時按下' '及' '鍵5秒，即可解除鎖定。
Press and hold the ' ' and ' ' key for 5 seconds again, the lock will be released.
7.5. 在防結霜模式下，不可設定溫度。
7.5. Under anti-frost mode, the unit cannot set temperature.
注意：遙控器沒有鎮定功能。
Note: Remote control cannot perform this function.

Remote Control
遙控器
Safety Features
特殊安全裝置
6
1. A thermal overload protector is built-in to prevent overheating.
2. If the unit is tilted, a safety system will cut off the power automatically. Put the
unit on a vertical position and it will operate again.
3. When the Heater is overheat, it will be shut off automatically.
3.1. To RESET the Heater: Unplug the Heater and wait for 30 minutes to cool
down.
3.2. Turn ON the Heater again to resume operation.
1. 暖風機內置恆溫保護裝置，防止機身過熱。
2. 若暖風機傾倒，暖風機即時自動停止操作，直到將暖風機垂直放回固定平面上
，方可重新操作。
3. 當機內溫度超出限定溫度，暖風機將自動停止操作。需要重新設置才可恢復正
常操作。
3.1. 拔除插頭，等待30分鐘，讓機內溫度降低。
3.2. 重新插上插頭，讓暖風機繼續操作。
陶 瓷 暖 風 機
Ceramic Heater
OSCTIMER
UP DOWN
POWERON/OFF
FH-T20PFH-T20P
1.遙控器操作方式與機頂按鍵操作方式相同。
2.更換電池 : 使用一枚3伏特鋰電池。
1. All functions performed by the Remote Control work are identical
to the Manual.
2. Battery replacement:Install one 3V Lithium battery.
警告
1) 請把電池放在兒童碰不到的地方，如果孩子吞下電池，需立即致電咨詢醫生。
2) 不要對電池進行充電或隨意棄置在有火源的地方。
3) 應保持電池存放於乾燥，陰涼的地方。
4) 以正確的方向插入電池。
電池的處理 - 請按相關地區的法律規定處理曾經使用的電池。
1. Keep batteries out of reach of children. Should a child swallow a battery,
consult a doctor immediately.
2. Do not recharge or dispose in fire.
3. Keep in a dry and cool place.
4. Insert battery in rigdt direction.
Battery disposal - Please dispose the used battery per municipal
or provincial law.

陶 瓷 暖 風 機
Ceramic Heater
辦公時間
10:30am - 12:30pm (星期一至五)
02:30pm - 05:30pm (星期一至五)
10:30am - 12:30pm (星期六)
(星期日及公眾假期休息)
OFFICE HOURS
10:30am - 12:30pm (Mon to Fri)
02:30pm - 05:30pm (Mon to Fri)
10:30am - 12:30pm (Saturday)
(Closed on Sunday and Holiday)
7
ORIGIN MAP
源澤地圖

陶 瓷 暖 風 機
Ceramic Heater
產品保用証(一年自攜服務)
產品: 陶瓷暖風機
型號: FH-T20P
此產品由購買日期起計算，本公司將根據下列條款及細則，提供一年保養服務(商業用享為3個月):
1. 於購買後一年內，經本公司技術員判斷為正常運作下損壞之產品，
憑零售商之正式發票可獲免費維修和/或零件更換。
2. 以下情況不被包括在保養範圍內：
-若產品是因為濫用、錯誤使用、疏忽及/或意外而遭致損壞；
-未經授權之自行處理、維修及/或改裝；
-任何機殼、面蓋，遙控器及其配件。
3. 需要檢查或維修時，請將產品送往本公司服務中心，並於修理妥當後自行取回。
4. 更換後之任何損壞零件，均屬本公司所有。
5. 本保養服務只適用於香港特別行政區。
6. 顧客必須同時出示零售商之正式發票，方可得到免費維修服務。
服務中心
源澤市務有限公司
香港新界葵涌青山公路403號(近華星街12號)匯城集團大廈21樓H室
電話: 2156 8238
www.origo.hk
*** 額外3個月保用:凡於購買產品後10天內完成網上登記，即可免費延長保用期3個月，即15個月免費保用(商業用途
除外)。請即登入網站: www.origo.hk
Warranty Card(1 year carry-in)
Item : Ceramic Heater
Model :FH-T20P
This product is warranted for 1year (commercial use for 3 months) from the date of purchase under the
following conditions:
1. For any defect, in the judgment of our technician, if it is caused under normal use, we are responsible for
repairing the product, and/or replacing parts at free of charge.
2. This warranty DOES NOT apply to:
- If the product has been damaged through abuse, misuse, negligence or accidents;
- Unauthorized repair, alteration/modification;
- The housing, cover, remote control or accessories, is excluded from this warranty.
3. The customer is requested to bring the unit to and from our Service Centre whenever
service is needed.
4. Any defective parts, which had been replaced, shall be of our property.
5. This warranty is valid in H.K.S.A.R. only.
6. Please show the Invoice to get free service.
***Extra 3 months warranty: just complete Online Warranty Registration within 10 days from the date of
receipt, free warranty will be extended to 15 months (not applicable to commercial use). Please enter our
website: www.origo.hk
Service Centre
ORIGIN MARKETING LIMITED
Unit H, 21/F., Reason Group Tower,(nearby 12 Wah Sing Street) 403 Castle Peak Road, Kwai Chung, N.T., Hong Kong.
Tel: [phone]
www.origo.hk
