Fender Passport Mini User manual

™
mini
中文

中文 中文
IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use onlywiththe cart, stand, tripod, bracket, ortablespecifiedby the manufacturer
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15) To completely disconnect this apparatus from the AC mains, disconnect the power supply cord
plug from the AC receptacle.
16) The mains plug of the power supply cord shall remain readily operable.
17) WARNING – To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
18) Do not expose this equipment to dripping or splashing and ensure that no objects filled with
liquids, such as vases, are placed on the equipment.
19) Maintain at least 6 inches (15.25 cm) of unobstructed air space behind the unit to allow for proper
ventilation and cooling of the unit.
20) CAUTION – For rack mounted power amplifiers, keep all wiring and materials away from
the sides of the unit and allow the unit to cool down for 2 minutes before pulling from a rack
enclosure.
21) Amplifiers and loudspeaker systems, and ear/headphones (if equipped) are capable of producing
very high sound pressure levels which may cause temporary or permanent hearing damage. Use
care when setting and adjusting volume levels during use.
22) FCC COMPLIANCE NOTICE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not used in accordance with the
instructions, may cause harmful interference to radio communications and there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the
following measures: reorient or relocate the receiving antenna, increase the separation between
the equipment and receiver, connect the equipment into an outlet on a circuit different from that
of the receiver. Consult the dealer or an experienced radio/TV technician if help is needed with
interference. NOTE: FMIC will not be responsible for unauthorized equipment modifications that
could violate FCC rules, and/ or void product safety certifications.
23) WARNING – To maintain product safety, products with internal or external (battery pack)
batteries: •Batteries and/or the product in which they are installed, shall not be exposed to
excessive heat such as sunshine, fire or the like. •There may be a danger of explosion if the
battery is incorrectly connected/replaced. Replace only with the same or equivalent type battery
specified in the instructions or on the product.
24) CAUTION – Unplug unit and allow it to cool before touching/ replacing vacuum tubes.
25) WARNING – Provide an earthing connection before the mains plug is connected to the mains.
And, when disconnecting the earthing connection, be sure to disconnect after pulling out the
mains plug from the mains.
26) Apparatus with CLASS I construction (grounded type with a three-prong plug) must be
connected to a MAINS socket outlet with a protective earthing connection.
27) WARNING – Use only the AC/DC adapter provided with the amplifier. The unit must only be
connected to a safety agency certified power source (adapter), approved for use and compliant
with applicable local and national regulatory safety requirements.

6
mini
Getting Started
G
F
E
D
C
B
A
1 2
REVTONEVOLUME
VOLUME
INPUTINPUT
INPUT
PHONES AUXUSB
PRESET EFFECTS
3
OFF
A
D
B
C
NATURAL
BATTERY
PARLOR
DREADNAUGHT
JUMBO
BLACKFACE
TWEED
BRITISH 1
BRITISH 2
TAP
HOLDFOR
TUNER
VOLUMEINPUT PRESET EFFECTS
To set up your Passport® mini amplifier:
1. Plug in the power adapter cord -OR- install six C batteries.
2. Plug your guitar into the INSTRUMENT input jack -AND- plug your
microphone into one of the VOCAL input jacks.
3. Press the POWER switch to "ON" to turn on the amplifier.
4. Adjust the INSTRUMENT and VOCAL volume levels.
♫
Using Presets
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
G
F
E
D
C
B
A
G
F
E
D
C
B
A
G
F
E
D
C
B
A
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
PRESET
OFF
A
D
B
C
EFFECTS REVERB
TONE
Use the PRESET knob to select one of 24 presets for the
INSTRUMENT channel. Presets are stored in three banks,
AMBER, GREEN and RED, in the following order:
AMBER
GREEN
RED
. . .
NATURAL PARLOR
NATURAL PARLOR DREADNAUGHT
C
B
A
C
B
A
B
A
NATURAL PARLOR DREADNAUGHT
Each preset is based on one of the eight amplifier types labeled next to
each of the preset LEDs and may include effects which can be temporar-
ily changed with the EFFECTS knob.
PRESET NOTES: Please see page 22 for a complete list of preset names
with their associated amp models and effects.
♫
Effects/Tone
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
G
F
E
D
C
B
A
G
F
E
D
C
B
A
G
F
E
D
C
B
A
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
PRESET
OFF
A
D
B
C
EFFECTS
REVERB
TONE
Use the EFFECTS knob to temporarily change effects for
the currently active INSTRUMENT channel preset. Each
time you turn the PRESET knob to select a different pre-
set, the effects are reset to their pre-programmed default
selection for the preset. The position of the EFFECTS knob
will NOT show the actual effect selection until the
EFFECTS knob is turned. You can program the default effects for each
preset as well as see the names and details of each effect using Fender®
FUSE™ software.
The three numbered LEDs below the TAP button indicate exactly which
effect position (1, 2, or 3) is being selected within each of the four let-
tered selection ranges (A, B, C, D). For example, effect "A-1" is shown
below:
EFFECTS SELECTIONS
A1 Small Room Reverb C1 Chorus
A2 Large Hall Reverb C2 Flanger
A3 Fender '65 Spring Reverb C3 Phaser
B1 Tape Echo D1 Vintage Tremolo
B2 Tape Echo + Room Reverb D2 Vibratone
B3 Tape Echo + Chorus D3 Vibratone + Room Reverb
♫Passport® mini effects can be viewed and fully customized using Fender® FUSE™ software installed on your Mac or Windows
computer.
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
G
F
E
D
C
B
A
G
F
E
D
C
B
A
G
F
E
D
C
B
A
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
PRESET
OFF
A
D
B
C
EFFECTS
REVERB
TONE
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
G
F
E
D
C
B
A
G
F
E
D
C
B
A
G
F
E
D
C
B
A
NATURAL
‘65 TWIN REVERB®
PARLOR
‘57 CHAMP®
DREADNAUGHT
BRITISH 60’s
JUMBO
BRITISH 80’s
PRESET
OFF
A
D
B
C
EFFECTS
REVERB
TONE
Use the TONE and REVERB knobs to adjust
the tone and reverb levels, respectively, for
the VOCAL channel.
Tap/Tuner
TAP
123
HOLDFOR
TUNER
The TAP button can be used to tap in the delay time or mod-
ulation rate setting for the currently active effect. When a
delay type effect is active, the TAP button will blink green in
sync with the delay time setting. When a modulation type effect is
active, the TAP button will blink red in sync with the modulation rate set-
ting. (If both delay and modulation effects are simultaneously active, the
TAP button will only indicate and control the delay effect.
To use the TAP button to adjust the effect time/rate interval, simply tap
the TAP button twice in sync with the desired interval. Pressing the TAP
button only one time will set the interval to the maximum value.
♫Effect time/rate intervals can be adjusted with total precision using Fender® FUSE™ software.
中文 中文

7
mini
TAP
123
HOLDFOR
TUNER
To activate the onboard guitar tuner, press and hold the
TAP button for 2 seconds. Strike a string on your guitar.
The "A, B, C, D, E, F, G" LEDs indicate the nearest note.
The "#" LED indicates a sharp note. Use the three LEDs
below the TAP button for fine tuning. The red LEDs indi-
cate the note is slightly flat or sharp and the green LED
indicates the note is in tune. Press the TAP button to exit
from the tuner.
Anti-Feedback
You can reduce microphone feedback at a troublesome frequency
in the VOCAL channel using the adjustable anti-feedback feature.
To select the anti-feedback frequency:
1. Press and hold the TUNER button for two seconds (this will activate
Tuner mode for the INSTRUMENT channel).
2. Rotate the EFFECTS knob to locatethe anti-feedback notch fre-
quency that reduces microphone feedback the most (VOCAL chan-
nel). Rotate counter-clockwise to decrease the notch frequency and
clockwise to increase the notch frequency. Rotate fully counter-
clockwise to turn the anti-feedback feature off.
3. Press the TUNER button to exit and save the anti-feedback frequency
setting. Your custom anti-feedback setting is stored even after the
amp is turned off.
Aux/Phones Jacks
PHONES
AUX
USB
You can connect the headphone output on your MP3 player
to the AUX jack on the Passport® mini using a standard 1/8"
mini-stereo cable. Use the volume control on your player to
control the auxiliary input level. Stereo signals from your
player are output through the PHONES jack in stereo.
PHONES
AUX
USB
Plug in your headphones, ear buds, or powered speakers to
the PHONES jack to enjoy the Passport® mini in stereo. This
jack may also be used as a stereo recording output. Use the
INSTRUMENT and VOCAL channel volume controls to adjust
the output level of the PHONES jack. The amp's speaker
output is muted when the PHONES jack is used.
USB Port
PHONES AUX
USB Connect the Passport® mini USB port to your computer to take
your music to the next level:
•
Use Fender® FUSE™ software toview the details and fully customize
presets and effects on your Passport® mini
• Record and edit Passport® mini audio using your favorite record-
ing software. Use the INSTRUMENT and VOCAL volume controls
to adjust the USB audio output level as needed.
Battery Indicator
BATTERY
The BATTERY indicator on your Passport® mini will show the
following states/battery conditions:
• OFF: The unit is being powered through the power adapter.
• GREEN: Battery powered, good charge.
• YELLOW: Battery powered, limited charge.
• BLINKING RED: Battery powered, replace batteries.
Firmware Updates
& Factory Restore
From time to time, Fender may make available firmware updates for your
Passport® mini amplifier to improve performance or to add new features.
To update the firmware on your amplifier you will need to connect it
through the USB port to a computer with an internet connection, run-
ning Fender® FUSE™ software. Hold down the TAP button while turning
the unit on to initiate the firmware update. You can also restore your
Passport® mini to the original factory settings if desired, using Fender®
FUSE™ .
Specifications
TYPE: PR 2501
PART NUMBERS: 0694600000 (120V, 60Hz) 0694600900 (120V, 60Hz) DS 0694601900 (110V, 60Hz) TW DS 0694603900 (240V, 50Hz) AUS DS
0694604900 (230V, 50Hz) UK DS 0694605900 (220V, 50Hz) ARG DS 0694606900 (230V, 50Hz) EUR DS 0694607900 (100V, 50/60Hz) JPN DS
0694608900 (220V, 50/60Hz) CN DS
POWER REQUIREMENTS: AC/DC ADAPTER: 12VDC 800mA Earth grounded BATTERY POWER: Six "C" cell batteries (Battery life approximately 20 hours)
INPUT IMPEDANCE GUITAR: >1MΩ AUX:>13kΩ VOCAL XLR: >2kΩ VOCAL 1/4":>2kΩ
POWER OUTPUT: 7W RMS into 8Ω @ 5%THD
SPEAKER: 8Ω, 6.5", Fender Special Design
DIMENSIONS HEIGHT: 9.45 in (240 mm) WIDTH:9.45 in (240 mm) DEPTH: 43.18 in (170 mm)
WEIGHT: 7.25 lb (3.3 kg)
Product specifications are subject to change without notice.
中文 中文
