Fender 215 PRO User manual

215 PRO
(This is the model name for warranty claims)
Fender Musical Instruments Corporation, 8860 East Chaparral Road Suite 100 Scottsdale, AZ 85250
Issued: September, 2007
p/n 2215200000 (120V)
SERVICE MANUAL
ATTENTION:
WARRANTY SERVICE PROCEDURES
The Fender 215 PRO is covered by the standard FMIC 5 Year Electronic Limited Warranty as it
applies to Speaker Enclosures. PCB Assemblies and Electronic Components are covered for 5
years. Speakers, Drivers, Cabinet Assemblies, and Cabinet Hardware are covered for 1 year.
Cables and wiring harnesses for 90 days. This enclosure is considered to be repairable to the
component level in the field. If you have questions please contact the FMIC Customer Service
Support Center at [phone] or Email [e-mail]

215 PRO
(This is the model name for warranty claims)
2
September, 2007
IMPORTANT NOTICE
•Copyright © 2007 FMIC. All rights reserved. All
information contained herein is CONFIDENTIAL
and PROPRIETARY and is the property of
Fender® Musical Instruments Corporation. It is
not to be sold or assigned to another party and is
disclosed solely for use by Fender Authorized
Service Centers for purposes of product service
and maintenance. All information is not to be dis-
closed to others without the expressed permission
of Fender® Musical Instruments Corporation. All
specifications are subject to change without no-
tice. This information and any copies produced
electronically or otherwise must be surrendered
upon demand of Fender® Musical Instruments
Corporation.
•Parts marked with two asterisks (**) indicate the
required use of that specific part. This is neces-
sary for RELIABILITY and SAFETY requirements.
DO NOT USE A SUBSTITUTE!
PARTS LIST CODES
The description codes used in the itemized Parts Lists are defined below:
CAPACITOR CODES
CAP AE = Aluminum Electrolytic
CAP CA = Ceramic Axial
CAP CD = Ceramic Disk
CAP CR = Ceramic Radial
CAP MPF = Metalized Polyester Film
CAP MY = Mylar
CAP PFF = Polyester Film/Foil
RESISTOR CODES
RES CC = Carbon Comp
RES CF = Carbon Film
RES FP = Flame Proof
RES MF = Metal Film
RES MOX = Metal Oxide
RES WW = Wire Wound
HARDWARE CODES
BLX = Black Oxide
CR = Chrome Plated
HWH = Hex Washer Head
M = Machine Screw
NI = Nickel Plated
OHP = Oval Head Phillips
PB = Particle Board
PHP = Pan Head Phillips
PHPS = Pan Head Phillips Sems
SMA = Sheet Metal "A" Point
SMB = Sheet Metal "B" Point
SS = Stainless Steel
TF = Thread Forming
ZI = Zinc Plated

215 PRO
(This is the model name for warranty claims)
3
SPECIFICATIONS
Model Name: 215 PRO
Release Number: PR 730
Part Number: 2215200000
Impedance: 4 ohms
Sensitivity: 101 dB, 1w-1m
Power Handling: 800 Watts, Continuous
1600 Watts, Program
Drivers: Two 15” (38.1 cm) Fender Special Design cast frame woofers with
3” (7.6 cm) voice coil and 105 0z. (2.98 kg) magnet (p/n 0075912000)
One horn tweeter with 1” (2.5 cm) voice coil and 8 oz. (0.23 kg) magnet
(p/n 0048847000)
Connections: Dual, parallel wired, ¼” (6.35 mm) high current input jacks and Speakon
connector
Cabinet: ¾” (1.9 cm) Baltic Birch plywood
Dimensions Height: 36 5/8 in (93.0 cm)
Width: 26 in (66.0 cm)
Depth: 17 in (43.2 cm)
Weight: 110 lb (50.0 kg)
Product specifications are subject to change without notice

215 PRO
(This is the model name for warranty claims)
4
SERVICE NOTES
Input Assembly removal is required for lamp re-
placement and is accomplished by following these
steps:
1. Remove the four screws from the input panel
corners.
2. Pull the panel out at the top until the L-pad is
clear of the mounting plate, then pull upward on
the assembly.
3. Use a small screwdriver or other tool to remove
the blown lamp, which is visible through a cut-
out in the circuit board.
4. Remove the spare lamp stowed on the side of
the circuit board and install it where the blown
lamp was removed.
5. Install the input assembly in the reverse order
of removal.
PCB EXCHANGE POLICY
Parts marked with a single asterisk (*) in the Part
Lists are not field replaceable. If a failure due to
one of these components is detected, please con-
tact the FMIC Customer Service Department to
order the complete PCB Assembly.

215 PRO
(This is the model name for warranty claims)
*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + *Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
5
.PARTS LIST: PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0075753000 *PCB ASSEMBLY BASS PRO SPEAKERS
1 0051858000 INDUCTOR AIR CORE .18mH L1
2 0051857000 LAMP TYPE 561 LMP1, LMP2
4 0053475000 LAMP CLIP
4 0012555000 EYELET-ROLLED FLANGE G.S. 3-4
2 0051861000 CAP MPF RDL 3.3Uf 250v 10% C1, C2
2 0029175000 JACK PHONE ¼” HI CURRENT PC J1, J2
PARTS LIST: INPUT ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0075735000 * INPUT ASSEMBLY FBA BASS PRO SPKRS
1 0075605000 PLATE INPUT FBA PRO SERIES
1 0049348000 CONTROL L PAD 8 OHM 50W
1 0064463000 KNOB PLASTIC W/POINTER XOVER
2 0016436000 WSHR LCK INTL 3/8x.687x.065 NI
2 0031153000 WSHR FLAT 3/8x.614 NI
2 0016352000 NUT HEX 3/8-32x3/32 TK NI
1 0040432000 JACK SPEAKON 4-POLE (NL-4MP)
2 0059914000 SCRW TF 4-40X3/8 FHP BLK
PARTS LIST: CABINET ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0074214000 *CABINET ASSEMBLY 215 PRO
16 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX
2 0059919000 FOOT RUBBER 2.50 DIA
2 0059916000 WSHR FLAT 7/16X1X.070 STL ZI
2 0059918000 SCRW 3/8-16X1 ½ HH ZINC
2 0012094000 NUT T 3/8-16x7/16 TWIST 4 PRNG
8 0059920000 CORNER STL/NI STACKING C1335N
32 0026571000 SCRW SMAB 8X5/8 THP NI
2 0059843000 “CASTER FXD 3”” WHL W2080K/HD”
52 0033380000 SCRW SMAB 8x1 THP BLX
2 0059844000 HANDLE RECESSED STEEL BAR
2 0074224000 RAIL GLIDE HDPE 215/610 PRO
10 0059921000 SCRW SMA 10X1 ¼ THP BLK
1 0054842000 PLATE KICK 810 PRO
10 0037543000 SCRW SMAB 8x3/4 OHP NI
3.35 0051343000 VINYL TOLEX 4227A SY
PARTS LIST: END ITEM ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0074214000 *CABINET ASSEMBLY 215 PRO
2 0075912000 SPEAKER 15 INCH 8 OHM CAST FRAME
1 0075735000 *INPUT ASSEMBLY FBA BASS PRO SPEAKERS

215 PRO
(This is the model name for warranty claims)
*Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY section above.
shaded Unique Fender® part. Order directly from the FMIC Parts Department.
shaded + *Access to this part or assembly is controlled. Please contact the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
shaded + ** Both a unique Fender® part and a Safety Requirement part as defined above.
6
PARTS LIST: END ITEM ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0073681000 GRILLE 215/610 PRO
1 0074228000 *BADGE X-LARGE FBA
1 0048847000 HORN FOSTER 8 OHM
1 0054212000 INPUT MOUNTING PLATE SUNN 410H
8 0030858000 SCRW SMA 8x5/8 PHP NI
4 0026553000 SCRW M 8-32 x 3/8 PHP BLX
4 0033380000 SCRW SMAB 8 x 1 THP BLX
11 0036112000 SCRW SMAB 6 x 1-1/4 OHP BLX w/WS
16 0057975000 SCREW M 10-32 x 1-1/4 FLHP STL BL
22 0055734000 RUBBER FOOT ¾” DIA
4 0059644000 SCRW CAP 6-32x3/8 HEX SKT NI
4 0069393000 NUT 6-32 HEX EXT LOCK
1 0055831000 GASKET HORN BASSMAN SERIES

215 PRO
(This is the model name for warranty claims)
7
Schematics and Drawings
Service Diagram (Schematic) ............Bassman 410 PRO
Input Assembly ............FBA Bass Pro Speakers
End Item Assembly ............215 PRO

FRACT. -------------------------------+/-1/32 .X ---------------------------------------+/-.050 .XX -------------------------------------+/-.015 .XXX------------------------------------+/-.010 ANGLES-------------------------------+/-.5 DEGREES HOLE DIA-----------------------------+.005 -.001 UNMARKED ANGLES ARE 90 DEGREES.
TOL. UNLESS NOTED
FINISH
MATERIAL
NONE
NONE
D
R
C
CORONA, CALIFORNIA U.S.A.
ENGINEER
DRAWN
DATE
DATE DATE DATE
DATE
DFT. ENG. ENG.
APPROVED SHEET
SCALE
SIZE REV
PART NUMBER
1of1
TITLE
0075735000
INPUT ASSEMBLY FBA BASS PRO SPEAKERS
DA
05/17/2007
NONE
FENDER MUSICAL INSTRUMENTS CORP.
B A
FENDER MUSICAL INSTRUMENTS CORP.
DATE/ARCHIVE
EC NUMBERREV BY
123456
THIS DOCUMENT CONTAINS INFORMATION OF A PROPRIETARY NATURE TO FENDER MUSICAL INSTRUMENTS AND IS SUBMITTED TO YOU IN CONFIDENCE AND SHALL NOT BE DISCLOSED OR TRANSMITTED TO OTHERS WITHOUT AUTHORIZATION FROM
ASSEMBLY
09/27/2007
SERVICE MANUAL DOCUMENT
ITEM QTY DESCRIPTION
10 2 SCRW TF 4-40X3/8 FHP BLK
9 1 JACK SPEAKON 4-POLE (NL-4MP) 8 AR TAPE VINYL NITRITE W/ADHESIVE 7 1 PCB ASSEMBLY BASS PRO SPEAKERS 6 2 NUT HEX 3/8-32x3/32 TK NI 5 2 WSHR FLAT 3/8x.614 NI 4 2 WSHR LCK INTL 3/8x.687x.065 NI 3 1 KNOB PLASTIC W/POINTER XOVER 2 1 CONTROL L PAD 8 OHM 50W 1 1 PLATE INPUT FBA PRO SERIES
6
7
1
8
2X
5
3
9
10
4
REF
2X
2X
2X
2
GRN
RED BLU
WHT
ORN
BRN
BK
LOCATIONS
WIRING AND SOLDERING
BLU
GRN
8
WIRE TIE
4.25±.03
2X
4.00±.03
2X

FRACT. -------------------------------+/-1/32 .X ---------------------------------------+/-.050 .XX -------------------------------------+/-.015 .XXX------------------------------------+/-.010 ANGLES-------------------------------+/-.5 DEGREES HOLE DIA-----------------------------+.005 -.001 UNMARKED ANGLES ARE 90 DEGREES.
TOL. UNLESS NOTED
FINISH
MATERIAL
NONE
SEE PARTS LIST
D
R
C
CORONA, CALIFORNIA U.S.A.
ENGINEER
DRAWN
DATE
DATE DATE DATE
DATE
DFT. ENG. ENG.
APPROVED SHEET
SCALE
SIZE REV
DRAWING NUMBER
TITLE
END ITEM ASSEMBLY 215 PRO
2215200000
DA
06/07/2007
1of2
NONE
FENDER MUSICAL INSTRUMENTS CORP.
B A
FENDER MUSICAL INSTRUMENTS CORP.
DATE/ARCHIVE
EC NUMBERREV BY
123456
THIS DOCUMENT CONTAINS INFORMATION OF A PROPRIETARY NATURE TO FENDER MUSICAL INSTRUMENTS AND IS SUBMITTED TO YOU IN CONFIDENCE AND SHALL NOT BE DISCLOSED OR TRANSMITTED TO OTHERS WITHOUT AUTHORIZATION FROM
ASSEMBLY
16
19
18
SEE DETAIL A
9
2
8
15
14
13
12
1
7
6
4X
11X
4X
4X
2X
16X
11
22X
4
3
4X
58X
17
10
09/27/2007 (N.S.) = NOT SHOWN
SERVICE MANUAL DOCUMENT
BLACK WIRE FROM UPPER SPEAKER "-" TO LOWER SPEAKER "-". WHITE WIRE FROM UPPER SPEAKER "+" TO LOWER SPEAKER "+". GREEN WIRE FROM INPUT ASSEMBLY TO "-" ON TWEETER. BLUE WIRE FROM INPUT ASSEMBLY TO "+" ON TWEETER. BROWN WIRE FROM INPUT ASSEMBLY TO "-" ON UPPER SPEAKER. ORANGE WIRE FROM INPUT ASSEMBLY TO "+" ON UPPER SPEAKER.
ITEM QTY DESCRIPTION
20 1 WIRE SET FINAL 215 PRO (N.S.) 19 1 LABEL INPUT 215 PRO 18 1 LABEL POP 215 PRO 17 1 LABEL SERIAL MEXICO 16 4 NUT 6-32 HEX EXT LOCK 15 4 SCRW CAP 6-32x3/8 HEX SKT NI 14 1 BADGE X-LARGE FBA 13 11 SCRW SMAB 6x1-1/4 OHP BLX w/WS 12 22 RUBBER FOOT 3/4" DIA 11 1 GRILLE 215/610 PRO 10 16 SCREW M10-32x1-1/4 FLHP STL BL
9 2 SPEAKER 15 INCH 8 OHM CAST FRAME 8 4 SCRW SMAB 8x1 THP BLX 7 1 GASKET HORN BASSMAN SERIES 6 1 HORN FOSTER 8 ohm 5 8 SCRW SMA 8x5/8 PHP NI 4 4 SCRW M 8-32x3/8 PHP BLX 3 1 INPUT MOUNTING PLATE SUNN 410H 2 1 INPUT ASSEMBLY FBA BASS PRO SPEAKERS 1 1 CABINET ASSEMBLY 215 PRO

GRN BLU
BRN
ORG
BK
WHT
SPEAKER ORIENTATION DETAIL
SEE NOTES ON SHEET 1 FOR SPEAKER WIRE CONNECTIONS
SCALE: NONE
+
+
RED CODED TERMINAL
LOGO, P.O.P. LABEL PLACEMENT
AND STANDOFF DETAIL
AS HOLES WILL PERMIT
SCALE: NONE
SERVICE MANUAL DOCUMENT
09/27/2007
14
11
REF
REF
17.50
3.88
1.53
26.59
27.66
33.47
.50
8.67
12.19
23.88
8.41
20.38
R
FENDER MUSICAL INSTRUMENTS CORP. CORONA, CALIFORNIA U.S.A.
ENGINEER
DRAWN
DATE
DATE DATE DATE
DATE
DFT. ENG. ENG.
APPROVED SHEET
SCALE
SIZE REV
PART NUMBER
TITLE
END ITEM ASSEMBLY 215 PRO
2215200000
DA
06/07/2007
2of2
NONE
THIS DOCUMENT CONTAINS INFORMATION OF A PROPRIETARY NATURE TO FENDER MUSICAL INSTRUMENTS AND IS SUBMITTED TO YOU IN CONFIDENCE AND SHALL NOT BE DISCLOSED OR TRANSMITTED TO OTHERS WITHOUT AUTHORIZATION FROM FENDER MUSICAL INSTRUMENTS CORP.
DATE/ARCHIVE
EC NUMBERREV BY
123456
A B
C D
ASSEMBLY
DETAIL A
SOME PARTS OMITTED
FOR CLARITY
CUT VINYL FLAP OFF ALONG BOTTOM EDGE OF ITEM 3 (INPUT MOUNTING PLATE)
